Sanyo VCC-3944 - 1/4" Color CCD DSP Camera User manual

• Built In DSP (Digital Signal Processing) Circuitry
• More than 350 TV Lines of Horizontal Resolution
• High Sensitivity – Minimum Illumination of 0.3 Lux
(High Gain, F1.2)
• Two Types of Backlight Compensation
• 24V AC and 12V DC, Dual Power Operation
1/4” Color CCD DSP
High Performance Camera
VCC-3944
ISO
9001

LENS
Controls
1 Electronic Iris (EI) / Auto iris (AI) setting
2 Gain up setting (HI / NORM)
3 Backlight compensation
(Multi-spot photometry (64-section) / Center-zone light measuring system)
4 White balance
5 Sync setting
6 White balance adiustment volume (R, B)
7 Line phase
8 Lens iris adjustment volume
9 Flange-back adiustment dial
Flange-back lock screw
6 8
10
1 2 3 4 5
10
7 9
(Unit: mm)
VCC-3944
56
28
45
1/4"–20UNC
threaded hole
(top / bottom selectable)
25.8
10.7
16
1.4 99 9
108
COLORCCD CAMERA
LENS
LENS 4-pin
POWERVIDEO OUT
GND AC24V
DC12V
CLASS 2
WIRING
~~
+-
Rear panel
SANYO Security Video
21605 Plummer Street
Chatsworth, CA 91311
Phone: [phone], ext. 282
Fax: [phone]
Technical Support: (888) 66-SANYO
www.sanyocctv.com
Specifications
Specifications and product design are subject to change without notice.
©2003 SANYO Security Video
MODEL VCC-3944
Scanning system NTSC standard 525 lines,30 frames/sec
Image sensor 1/4” Interline transfer CCD
Picture elements 537(H) x 505(V) picture elements
510(H) x 492(V) effective picture elements
Horizontal resolution Horizontal: 350TV lines
Minimum illumination Approx.0.9 lx (Gain: NORM @ F1.2)
Approx 0.3lx (Gain: HI @ F1.2)
Video output level 1.0Vp-p ( 75 ohms, composite )
Video S/N ratio More than 48dB
Backlight compensation ON/OFF – Slide SW (side)
ON = Multi-spot photometry (64-section)/
Center focus photometry
White balance ATW/MANUAL
Color adjust at manual Red, Blue – VR (side)
Gain control HI (High)/NORM (Normal) – Slide SW (side)
Light control Optical auto iris lens/Electronic iris (indoor use)
Lens mount CS mount
Flange back 12.5mm +/- 0.5mm adjustment
Auto iris lens DC auto iris
Lens iris level LEVEL: L to H – VR (side)
Electronic iris ON/OFF – Slide SW (side)
Electronic iris range 0.9 lx to 45,000 lux (F1.2)
Synchronizing system Internal Sync/ Line lock -- Slide SW (side)
V phase adjustment LINE PHASE – VR (side)
Camera mount 1/4” – 20 UNC ( top or bottom selectable)
Environmental condition
Operating: Temperature: 14˚F to 122˚F (-10˚C to +50˚C)
Humidity : within 90% RH
Storage: Temperature: -20˚C to +70˚C
Humidity : within 70% RH
Power requirement 24V AC, 60 Hz/12 to 15V DC
Power consumption approx. 2.8W (with AI lens), 2.1W (without AI lens)
Size 2.2 (W) x 1.77(H) x 3.92(D) in.
[56(W) x 45(H) x 99.5(D) mm]
Weight 9.9 oz. (280g) without lens
VCC-3944
1/4” COLOR CCD DSP HIGH
PERFORMANCE CAMERA
