SANYO VCC-HD5600 1080p 2 MEGAPIXEL DAY-NIGHT PTZ CAMERA WITH AUDIO
Project Name/Project Number 28 23 29 - 19 Video Surveillance Remote Devices and Sensors
SanyoCompanyNovember,2009
SecurityProductsDivision
21605PlummerStreet
Chatsworth,CA91311
Phone:888.818.2597
Fax:818.717.27162239180
http://us.sanyo.com/security

ProductGuideSpecification












SECTION 28 23 29
VIDEO SURVEILLANCE REMOTE DEVICES AND SENSORS
Sanyo VCC-HD5600 2 MEGAPIXEL DAY/NIGHT PTZ CAMERA WITH AUDIO
PART 1 - GENERAL
1.1 SUMMARY
A. Section Includes
1. Video Surveillance Remote Devices
B. Related Sections
1. Section 28 23 13 – Video Surveillance Control and Management
Systems
SpecifierNotes:ThisproductguidespecificationiswrittenaccordingtotheConstructionSpecifications
Institute(CSI)3‐PartFormat,basedonMasterFormat2004andTheProjectResourceManual—CSIManual
ofPractice.TheManufacturerisresponsiblefortechnicalaccuracy.Byremovingthereferencestospecific
Sanyoproductnamesorpartnumbers,thetextmaybeusedalsoinperformance‐basedspecifications.

ThesectionmustbecarefullyreviewedandeditedbytheArchitectorEngineertomeettherequirementsof
theprojectandlocalbuildingcode.Wordsandsentenceswithinbrackets[]arechoicestoincludeor
excludeaparticularitemorstatement.Coordinatethissectionwithotherspecificationsectionsandthe
Drawings.

SANYO VCC-HD5600 1080p 2 MEGAPIXEL DAY-NIGHT PTZ CAMERA WITH AUDIO
Project Name/Project Number 28 23 29 - 19 Video Surveillance Remote Devices and Sensors
2. Section 28 23 16 – Video Surveillance Monitoring and Supervisory
Interfaces
3. Section 28 23 19 – Digital Video Recorders and Analog Recording
Devices
4. Section 28 23 23 – Video Surveillance Systems Infrastructure
1.2 REFERENCES
A. Federal Communications Commission (FCC) (www.fcc.gov)
1. FCC CFR 47 part 15 Class B – Telecommunications – Radio
Frequency Devices – Digital Emission
B. International Electrotechnical Commission (IEC)
1. IEC 60529 Degrees of Protection provided by enclosures (IP Code)
C. International Organization of Standardization (ISO)
1. 9001 – Quality System
D. Underwriters Laboratories, Inc. (UL) (www.ul.com)
UL 2044 Commercial Closed-Circuit Television Equipment
1.3 SYSTEM DESCRIPTION
A. Video Surveillance Remote Devices
1. 2 Megapixel 1080p Full High Definition Day/Night Network CMOS
PTZ Dome Camera with Audio
B. Performance Requirements
1. Provide surveillance with high definition detail images – day or
night.
2. Possesses advanced intelligence features.
3. The camera shall be of manufacturer’s official product line,
designed for commercial/industrial continuous 24/7 use.
4. The camera shall be based upon standard components and proven
technology.
1.4 SUBMITTALS
A. Submit under provisions of Section [01 33 00.]
B. Product Data:
1. Manufacturer’s data, user and installation manuals for all
equipment and software programs including computer equipment
and other equipment required for complete video system.
C. Shop Drawings; include

SANYO VCC-HD5600 1080p 2 MEGAPIXEL DAY-NIGHT PTZ CAMERA WITH AUDIO
Project Name/Project Number 28 23 29 - 19 Video Surveillance Remote Devices and Sensors
1. System device locations on architectural floor plans.
2. Full Schematic of system, including wiring information for all
devices.
D. Closeout Submittals
1. User manual.
2. Parts list.
3. System device locations on architectural floor plans.
4. Wiring and connection diagram.
5. Maintenance requirements.
1.5 QUALITY ASSURANCE
A. Manufacturer:
1. Minimum of 10 years experience in manufacture and design Video
Surveillance Devices.
2. Manufacturer’s quality system: Registered to ISO 9001 Quality
Standard.
B. Video Surveillance System
C. Installer:
1. Minimum of 5 years experience installing Video Surveillance
System.
2. All camera installation, configuration, setup, program and related
work shall be performed by electronic technicians thoroughly
trained by the manufacturer in the installation and service of the
equipment provided.
1.6 DELIVERY, STORAGE AND HANDLING
A. Comply with requirements of Section [01 60 00]
B. Deliver materials in manufacturer’s original, unopened, undamaged
containers; and unharmed original identification labels.
C. Protect stored materials from environmental and temperature conditions
following manufacturer’s instructions.
D. Handle and operate products and systems according to manufacturer’s
instructions.
PART 2 - PRODUCTS
2.1 MANUFACTURERS
A. Acceptable Manufacturer
Sanyo Company

SANYO VCC-HD5600 1080p 2 MEGAPIXEL DAY-NIGHT PTZ CAMERA WITH AUDIO
Project Name/Project Number 28 23 29 - 19 Video Surveillance Remote Devices and Sensors
Security Products Division
21605 Plummer Street
Chatsworth, CA 91311
Phone: [phone]
Fax: [phone]
http://us.sanyo.com/security
B. Substitutions: Under provisions of Division 1
1. All proposed substitutions must be approved by the Consultant, or
Architect/Engineer professional.
2. Proposed substitutions must provide a line-by-line compliance
documentation.
2.2 2 Megapixel 1080p Full High Definition Day/Night Network PTZ CMOS Camera
with Audio
A. General Characteristics:
1. Full Pan-Tilt-Zoom Functionality with continuous Pan, 10x AF
Optical Zoom and 220° tilt with digital image flip
2. Be designed to provide advanced image support resolutions up to 2
Megapixels of effective picture elements 1920(H) x 1080(V).
3. Provide dual Codec for simultaneous H.264 and JPEG
transmission.
4. Be designed to provide 1080p H.264 compressed video at 30
frames per second.
5. Use a high quality 1/2.5” CMOS progressive scan image sensor
6. Provide color pictures in light down to 2.0 lux at F 1.8
7. Provide B/W pictures in light down to 0.1 lux at F1.8
8. Provide for Audio input and output directly to and from the camera
9. Be capable of accepting power from 24V AC (with optional power
unit.)
10. Be capable of transmitting analog NTSC video for setup and
installation purposes.
11. Be capable of storing images on-camera via SDHC storage
12. Be capable of offering optional HDMI output at 1080p
B. Camera shall be capable of the following adjustments and features:
1. The camera shall be of a indoor Pan-Tilt-Zoom form factor with the
following mechanical features:
a. SDHC port

SANYO VCC-HD5600 1080p 2 MEGAPIXEL DAY-NIGHT PTZ CAMERA WITH AUDIO
Project Name/Project Number 28 23 29 - 19 Video Surveillance Remote Devices and Sensors
b. Support mic in and line out audio input and output
2. Shall be mountable in the following configurations (with optional
mounting accessories)
a. Indoor ceiling mount
b. Indoor Wall Mount
c. Indoor Pendant Mount
d. Outdoor Wall Mount
e. Outdoor Pendant Mount
3. Shall be compatible with the mounting accessories that support the
SANYO VCC-9xxx series of PTZ cameras.
4. Provide full continuous 360° pan at 420°/sec maximum
5. Provide a total tilt range of -20° to 200° for a total tilt travel of 220°
at 350°/sec maximum
6. Provide 10x AF Optical Zoom with an additional available 16x
Digital Zoom
7. Image flip via user selectable digital image flip or mechanical image
flip.
8. Provide image stabilization.
9. Provide auto pursuit function.
10. The camera will provide a sixteen (16) character camera ID.
11. Provide selection of languages from English, French, German,
Japanese and Spanish.
12. Progressive Scan CMOS technology for image clarity.
13. Two (2) Megapixels maximum resolution
14. Five levels of operator privileges shall be available.
a. Admin level shall have full access to all functions.
b. Operator1 level shall have access to all functions except
Network settings.
c. Operator 2 level shall have access to all functions except
configuration settings.
d. Download level shall be restricted to downloading recorded
images only.
e. Guest will be restricted to monitoring live video only.
15. Provide Day & Night function allowing automatic changeover from
color mode to B&W mode as well as removal of an IR cut filter
during low light operation.

SANYO VCC-HD5600 1080p 2 MEGAPIXEL DAY-NIGHT PTZ CAMERA WITH AUDIO
Project Name/Project Number 28 23 29 - 19 Video Surveillance Remote Devices and Sensors
16. Camera shall have advanced programmable motion detection.
Selectable modes include
a. Motion Detection
b. Motion Masking
c. Off.
17. Human Face Detection shall be available in both Detection and
Masking modes selectable by area.
a. Up to 32 faces shall be detectable at once.
b. The camera shall tune its focus, BLC via detected faces
c. The camera shall be able to transmit an alarm based on
detecting one or more faces and motion detection at the same
time in the scene.
18. The camera shall support digital trip wire functionality at no
additional cost
a. Up to 8 digital tripwires shall be configurable with independent
controls for length, angle, vector (left to right, right to left or
both) and tripwire sensitivity.
b. Up to 4 areas shall be configurable.
19. The camera shall support Back Light Compensation (BLC) circuitry
20. Provide HD image recording to an on-board SD memory card slot
(card optional)
21. Provide flexible on-board recording capability allowing recording by
Alarm (motion or input 1/2...8) including programmable pre-alarm
recording, or Back-up in the event of loss of network.
22. Provide internal verification whether or not any electronic alteration
was made to original images.
23. When image data is output on a conventional SD output
The camera shall eliminate “smearing” associated caused by
vertical noise associated with bright spots (such as headlights).
C. Video Requirements and Adjustments:
1. Minimum Adjustments and Requirements
a. Imager: Progressive Scan 1/2.5"inch CMOS.
b. Pixels: 1920(H) x 1080(V) effective picture elements.
c. Image Size: H.264 – 16:9 HD: 1920 x 1080, 30 ips. HD: 1280
x 720 30 ips; ; 640 x 360 30 ips; 320 x 180 30 ips. H.264 4:3:

SANYO VCC-HD5600 1080p 2 MEGAPIXEL DAY-NIGHT PTZ CAMERA WITH AUDIO
Project Name/Project Number 28 23 29 - 19 Video Surveillance Remote Devices and Sensors
1600x1200 30 ips; 1280 x 960 30 ips; 1024 x 768 30 ips;
640x480 30 ips; 320 x 240p 30 ips.
d. Image Size: MJPEG 16:9 HD: 1920 x 1080; HD 1280 x 720;
1024 x 576; 640 x 360. JPEG 4:3 1600 x 1200, 1280 x 960;
1024 x 768; 800 x 600; 640 x 480; 320 x 240.
e. Iris Control: Selectable Auto/Manual.
f. Shutter: Electronic range of 1/30, 1/60, 1/100, 1/250, 1/500,
1/1000, 1/2000, 1/4000, 1/10000. Long shutter: x1, x2, x4, x8,
x16, x32.
g. Aperture Compensation: Selectable On/Off.
h. Minimum Color Illumination: 2.0 lux at F 1.8 Minimum B/W
Illumination: 0.1 lux at F 1.8
i. Signal to Noise Ratio: more than 50 dB (AGC off).
j. The camera shall provide selectable White Balance settings
include Auto-tracing White (ATW), AWC for technical support
adjustments; Outdoor, Indoor, Fluorescent and Manual control
(MWB). MWB allows individual red and blue adjustments.
k. The camera shall support Backlight Compensation: Selectable
Multi-spot metering, Center-zone metering, Face and Off.
Mask settings available.
l. Auto-focus: Selectable Auto/Manual/One push. Selectable
focus area.
m. Day/Night: Selectable Auto/Color/Black and White.
n. AGC Gain: Selectable Normal/Middle/High/Off. Adjustable
gain control in Off mode.
o. Gamma: 0.45/1, other settings available.
p. Electronic Sensitivity Boost: Selectable Auto/Off. Max. 32x.
D. Operating Environment:
1. PC: IBM PC/AT or compatible.
2. Operating System: Windows XP Professional SP2 or Windows
Vista
3. CPU: Core2Duo E6700 2.66 GHz or higher.
4. Memory: Windows XP : 1 GB or more. Windows Vista: 2 GB or
higher.
5. Network Interface: 10/100Base-TX (RJ-45 connector).
6. Display Card: 1920 x 1200 pixels or higher.

SANYO VCC-HD5600 1080p 2 MEGAPIXEL DAY-NIGHT PTZ CAMERA WITH AUDIO
Project Name/Project Number 28 23 29 - 19 Video Surveillance Remote Devices and Sensors
7. Graphics Chip: ATI Radeon HD2600 series or higher; nVidia
GeForce 8600 series or higher; nVidia Quadro FX550 series or
higher.
8. Web Browser: Internet Explorer Ver 6.0 SP2 or higher or Ver 7.0
E. IP Interfaces:
1. Protocols supported include TCP/IP, HTTP, HTTPS, UDP, SMTP,
FTP, DHCP, DDNS, NTP, RTP, RTSP.
2. Camera IP interface at 10 Base-T/100 Base-TX/PoE compatible.
3. The camera shall interface to Microsoft Internet Explorer ver 6.0
SP2 or higher or ver. 7.0 via Plug-in module software making video
images and configuration menus available.
4. When accessed from a browser on-line, context sensitive help shall
be provided.
5. The camera shall provide an integral E-mail function for up to five
(5) E-mail addresses. E-mails can be automatically sent as an
alarm notification or at regular intervals. An image can be attached
to the e-mail in either case.
6. Web access protected by user ID and password. A maximum of 20
users shall be assignable.
7. Camera shall maintain a transactional log when accessed via the
network containing the most recent 100 times and IP addresses of
those given access.
8. Camera shall maintain an “Up Log” showing power on time; SD
Memory record time; External HDD record time and a Camera High
Temperature warning.
9. Up to 20users may access a camera via the web server
simultaneously.
10. Eight alarm inputs (NO/NC) shall be provided.
11. Two alarm output (NO/NC) shall be provided.
12. The camera shall support both fixed IP addresses and dynamically
assigned IP addresses provided by a Dynamic Host Control
Protocol (DHCP) server.
13. The camera shall be able to interface with SANYO Video Pilot
software. Video Pilot shall support full functionality when operating
on Windows Vista or Windows XP Professional Edition with
SP2/SP3.

SANYO VCC-HD5600 1080p 2 MEGAPIXEL DAY-NIGHT PTZ CAMERA WITH AUDIO
Project Name/Project Number 28 23 29 - 19 Video Surveillance Remote Devices and Sensors
14. Third party application integration of the camera is supported via
two (2) Development Kits which provide the necessary information
for interfacing. Contact SANYO for details.
15. Image quality selectable at Basic, Normal, Enhanced (default), Fine
and Super Fine.
16. Resolutions may be set for Live, Recorded modes.
17. Recording Time Examples:
CODEC Resolution Pic Quality Recording Bit Rate Record Hrs
16:9 Rate (max) (approx) Per 80GB
H.264 1920 x 1080 Enhanced 30 ips 6.0 Mbps 19.2
1280 x 720 Enhanced 30 ips 4.6 Mbps 25.0
640 x 360 Enhanced 30 ips 0.98 Mbps 115.6
1920 x 1080 Basic 30 ips 4.0 Mbps 28.7
1280 x 720 Basic 30 ips 2.5 Mbps 45.7
640 x 360 Basic 30 ips 0.46 Mbps 239.1
MJPEG 1920 x 1080 Enhanced 5 ips 8.96 Mbps 12.9
1280 x 720 Enhanced 10 ips 9.36 Mbps 12.3
1024 x 576 Enhanced 15 ips 9.00 Mbps 12.8
1920 x 1080 Basic 5 ips 3.4 Mbps 21.3
1280 x 720 Basic 10 ips 4.8 Mbps 24.0
640 x 360 Basic 30 ips 3.84 Mbps 29.9
* without audio recording
18. Selectable IP resolutions include:
a. 1920x1080 H.264
b. 1280x720 H.264
c. 640x360 H.264
d. 320x180 H.264
e. 1920x1080 MJPEG
f. 1280x720 MJPEG

SANYO VCC-HD5600 1080p 2 MEGAPIXEL DAY-NIGHT PTZ CAMERA WITH AUDIO
Project Name/Project Number 28 23 29 - 19 Video Surveillance Remote Devices and Sensors
g. 1024x576 MJPEG
h. 640x360 MJPEG
i. 1600x1200 H.264
j. 1280x960 H.264
k. 1024x768 H.264
l. 640x480 H.264
m. 320x240 H.264
n. 2288x1712 MJPEG
o. 1600x1200 MJPEG
p. 1280x960 MJPEG
q. 1024x768 MJPEG
r. 800x600 MJPEG
s. 640x480 MJPEG
t. 320x240 MJPEG
F. Electrical:
1. Camera input voltage/power requirements: 24V AC(with optional
power unit.)
2. Power Consumption: 29 W.
G. Mechanical:
1. Weight: 67.02 oz. (1.90 kg).
2. Dimensions: Φ192 x 181 mm (Φ7.56” x 7.13”)
H. Environmental:
1. Operating Temperature: 14°F to 122°F (-10° to +50°C) within 90%
relative humidity.
2. Storage Temperature: -4°F to 158°F (-20°C to +70°C) within 70%
maximum relative humidity.
PART 3 - EXECUTION
3.1 EXAMINATION
A. Examine areas to receive devices and notify adverse conditions affecting
installation or subsequent operation.
B. Do not begin installation until unacceptable conditions are corrected.
3.2 PREPARATION
A. Protect devices from damage during construction.
3.3 INSTALLATION

SANYO VCC-HD5600 1080p 2 MEGAPIXEL DAY-NIGHT PTZ CAMERA WITH AUDIO
Project Name/Project Number 28 23 29 - 19 Video Surveillance Remote Devices and Sensors
A. Install devices in accordance with manufacturer’s instruction at locations
indicated on the floor drawings plans.
B. Perform installation with qualified service personnel.
C. Install devices in accordance with the National Electrical Code or applicable
local codes.
D. Ensure selected location is secure and offers protection from accidental
damage.
E. Location must provide reasonable temperature and humidity conditions,
free from sources of electrical and electromagnetic interference.
3.4 FIELD QUALITY CONTROL
A. Test snugness of mounting screws of all installed equipment.
B. Test proper operation of all video system devices.
C. Determine and report all problems to the manufacturer’s customer service
department.
3.5 ADJUSTING
A. Make proper adjustment to video system devices for correct operation in
accordance with manufacturer’s instructions.
B. Make any adjustment of camera settings to comply with specific customer’s
need.
3.6 DEMONSTRATION
A. Demonstrate at final inspection that video management system used with
devices functions properly.
END OF SECTION
