Sanyo CP21AF2T User manual

SERVICE MANUAL Colour Television
-
+P
MENU
TV/AV
Specifications
Power Source . . . . . . . . .AC220 - 240V, 50/60Hz.
Colour System . . . . . . . .PAL (AV input: PAL/NTSC4.43/NTSC/PAL-60Hz)
Television System . . . . . .B/G
Channel Coverage . . . . .Australia
VHF: 0-11, 5A UHF: 28-69
CATV: S1-S41, X, Y, Z, Z+1, Z+2
New Zealand
VHF: 1-11 UHF: 21-69
CATV: S1-S41, X, Y, Z, Z+1, Z+2
Video IF . . . . . . . . . . . . .38.0MHz
Aerial Input Impedance . . 75Ω
Ext.Terminals
Video inputs: Phono jack ✕2 (1.0Vp
- p, impedance 75Ω)
S-Video input ✕1 (Din 4 pin, SeparateY/C Signals Input)
Audio inputs:Phono jack (R/L) ✕ 2 (436mVrms, impedance more than 40KΩ)
Video monitor outputs: Phono jack ✕1 (1.0Vp
- p, 75Ω)
Audio monitor outputs: Phono jack(R/L) ✕1
(436mVrms, Impedance less than 600Ω)
Headphone jack: Mini stereo jack ✕ 1
Speakers ......... 5cm ✕12cm ✕ 2
Sound Output (Music) . . . 3W + 3W
Dimensions . . . . . . . . . . 587(W) ✕458(H) ✕486(D)mm
Weight . . . . . . . . . . . . . .approx. 21.8 Kg
Specifications subject to change without notice
Product Code: 1 113 514 38
Chassis Series: FC1-B
C2GYT
FILE NO.
Model No. CP21AF2T
Service Ref. No. CP21AF2T-00
(Australia/New Zealand)
Give complete “SERVICE REF. NO.” for parts
order or servicing.It is shown on the rating plate
at the cabinet back of the unit.
This T.V. receiver will not work properly in
foreign countries where the television
transmission system and power source
differ from the design specifications. Refer
to the specification table.
0
7
14
8
5
23
6
9
JXMLA
MENU
-/--
PP
A•B
CH SCAN
TIMER
i
?
X
TV/TEXT
TV/AV
P
▲
P
▼
ZOOM
SWAPVSM
BBE BASS
ASM
SURROUND
REFERENCE NO. SM5110153
Original Version

Contents
-2-
Safety Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chassis Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
IC Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Service Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Service Adjustments with replacing Memory IC (IC802) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
Service Mode Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12
Protection Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Purity and Convergence Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Mechanical Disassemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Cabinet Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Chassis Electrical Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-25
Safety Notice
SAFETY PRECAUTIONS
1: An isolation transformer should be connected in the
power line between the receiver and the AC line
when a service is performed on the primary of the
converter transformer of the set.
2: Comply with all caution and safety-related notes pro-
vided on the cabinet back, inside the cabinet, on the
chassis or the picture tube.
3: When replacing a chassis in the cabinet, always be
certain that all the protective devices are installed
properly, such as, control knobs, adjustment covers
or shields, barriers, isolation resistor-capacitor net-
works etc.. Before returning any television to the
customer, the service technician must be sure that
it is completely safe to operate without danger of
electrical shock.
X-RADIATION PRECAUTION
The primary source of X-RADIATION in television receiver is the picture tube.The picture tube is specially con-
structed to limit X-RADIATION emissions.For continued X-RADIATION protection, the replacement tube must be
the same type as the original including suffix letter. Excessive high voltage may produce potentially hazardous X
- RADIATION.To avoid such hazards, the high voltage must be maintained within specified limit. Refer to this ser-
vice manual, high voltage adjustment for specific high voltage limit. If high voltage exceeds specified limits, take
necessary corrective action.Carefully follow the instructions for + B1 volt power supply adjustment, and high volt-
age check to maintain the high voltage within the specified limits.
PRODUCT SAFETY NOTICE
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by mark in the parts list and the schematic diagram designate components in which
safety can be of special significance. It is particularly recommended that only parts designated on the parts list
in this manual be used for component replacement designated by mark . No deviations from resistance
wattage or voltage ratings may be made for replacement items designated by mark .

Chassis Block Diagrams (MAIN SIGNAL PROCESSING CIRCUIT)
-3-
IC001A
AUDIO AMP.
IC3071
AUDIO-CONTROL
TV-AUDIO
SIF IN
IC201
IF/VIDEO/CHROMA
IF-IN
X161
SAW
FILTER
IF
OUT
C-IN
SOUND
CARRIER TRAP
(5.5MHz)
IC1501
VIDEO SW
A101
TUNER
V
L
R
Y
C
IC1401
VIDEO-SW
REAR AV1 IN
V
L
R
FRONT AV2 IN
V
L
R
IC1201
AUDIO-SW
IC3501
BBE
9
6
4
1
7215
1
13
12
14
54
3
36
34
Q101
BUFFER 6/7
IIC BUS
52
VIDEO DET.
VIF
SIF
RGB OUT
SOUND FILTER
(5.5MHz)
MONITOR OUT
11 13
15
2
3
4
1/5
8
17
7
210
2
19 5
7
18
7
14
L-OUT L-OUT L-OUT L-OUT
R-OUT R-OUT R-OUT R-OUT
REAR L-IN
REAR R-IN
FRONT L-IN
FRONT R-IN
3FM
DET. 48
K001
HEADPHONE
JACK
Q901 CRT
HORIZ. OUT
VERT. OUT
R/G/B OUT
L902
DEF.YOKE
Q431
H-DRIVE
IC501
VERT. DEF.
CRT UNIT
21
12
R
B
G
42
Q432
H-OUT
VERT. DY
H.V.
T471
FBT
FOCUS
SCREEN
HORIZ. DY
PINCUSHION
CIRCUIT
(Q461,Q462)
18/19/20
Y/VIDEO IN
FROM IC801(CPU)
PIN-32/34
IC801
CPU IC802
MEMORY
IIC BUS
IIC BUS
OSD
(RGB)
40/41/42
32/34
31/33 5/6
23/28/30
10/14
IIC BUS
9/10
INT.VIDEO
EXT.VIDEO
VIDEO MONITOR OUT
Y
EXT. VIDEO
AV1 VIDEO IN
Y-IN
C-IN
AV2 VIDEO IN
AUDIO MONITOR OUT (L)
AUDIO MONITOR OUT (R)
12/14
TELETEXT
UNIT
VIDEO IN
IC2001
TELE TEXT
8/9/10
1TEXT(RGB OUT)
16/17
IIC BUS FROM CPU PIN-32,34
RGB
IN
COLOR
DEMOD.
DELAY
LINE
VIDEO
TONE
SP901
SP902
5V-2
3
130V FBT+B
9V
5V-1
TELETEXT
ONE CHIP
CPU
20V AUDIO AMP.
T611
CONVERTER
TRANS.
26V VERT. OUT/HORIZ.
IC651
13
IC202
1
5V-3
POWER
SUPPLY
CIRCUIT
AC

Chassis Block Diagrams (SYSTEM CONTROL)
-4-
26 28
8
COLOUR SYSTEM OPTION
KEY SWITCH IN KEY
SWITCH
AV1/AV2 SWITCH OUT
(TV=LOW, AV1=LOW, AV2=HIGH)
SCL (TO BUS IC)
34
32
15
29
SDA (To BUS IC)
POWER ON/OFF OUTPUT
COUPLE (ON=HIGH, OFF=LOW)
IC801
CPU
QXXAVB692
39
42 41
40
1 2
24
3133
20
19
13
23
ADJUSTMENT DATA IN
OSD BLK OUT
OSD RED OUT
OSD GREEN OUT
OSD BLUE OUT
DEFLECTION
CIRCUIT
HORIZ. SYNC IN
(ACTIVE=LOW)
VERT. SYNC IN
(ACTIVE=LOW)
POWER PROTECT IN
(POWER ERROR=LOW) POWER CIRCUIT
etc.
SCL
SDA
IC802
MEMORY
OSC
8MHz CPU OSC OUT
CPU OSC IN
LED ON-TIMER LED OUT (ON=LOW)
RC SIGNAL IN
(ACTIVE=LOW) RC PRE-AMP.
IC001A
AUDIO AMP. 6
SOUND MUTE OUT (MUTE ON=LOW)
AFT IN
30
IC201
(ONE CHIP)
VIDEO / CHROMA
A101
TUNER
IC3071
AUDIO CONTROL
IC2001
TELETEXT
IC3501
BBE 4
BBE ON/OFF OUTPUT
(ON=LOW, OFF=HIGH)
3
4
56
17
16
10
9
SCL
SDA
14
10
SCL
SDA
7
TV/AV SWITCH OUT
(TV=LOW, AV=HIGH)
IC1501
VIDEO SW 9/10
8
IC1401
VIDEO SW
14
S-TERMIAL INPUT (IN=LOW)
S-TERMINAL
22
+5V VCC
25 RESET INPUT (ACTIVE=LOW)
37 50/60Hz OUTPUT (50Hz=LOW,60Hz=HIGH)
SDA
SCL

IC Block Diagrams
-5-
IC201 < IF/Video/Chroma/Def. > QXXAVB488
VIF IN
IFAGC OUT AFT
TV IN
EXT IN
AUDIO
OUT
33
29
35
26
37
40
32
13
44
43
11
15
16
12
2725242122412819201830239101445
QXXAVB241
SYNC IN
KILLER FILTER
IDENT FILTER
COLOURAPC
AFAMP
AFAMP
4.5/6.0
SIF IOADJ BUS
I/F
FM DET
LIMITTER
B EXIT INPUT R EXIT INPUT G EXIT INPUT V SYNC TRIG
SYNC SEP.
SYSTEM ID
EQ ELIMINATE
BGP GENE.
PHASE CONT
KILLER DET
LOCK DET
ID DET
CHROMA APC DET
PAL SW
SECAM FF
SELF ADJ
V.RAMP
AFC
AFC
1H DL
VCXO
ACC DET
F/F
2NDAMP
CHROMA BPF
1STAMP (ACC)
HPF
AFT
AFT OUT
VIDEO
MUTE
H STOP
H.PHASE
AUDIO MUTE SW SDA
SCL FAST BLK B IN
R IN
B-OUT
R- OUT G-OUT
G-IN
H-VCC SECAM REF
V.SIZESERVICE
SW
H-OSC
SELFADJ.
CLAMP
50/60 OUT
R
TINT
B
R
DRIVE
BG
ABCL
ABCL
ID CUT BLUEBACK
WHITE BACK
COLOR
CONTRAST
SERVICE BRIGHT
STATION DET STATION
SYSTEM SET SYSTEM
IFAGC
DELAYADJ
DEFEAT
DLTIME DLFINE
VIDEO
VCC
VIDEO
GND
DEFLECTION
GND
TRAP SW
D.TRAP
F.TRAP
BLACK STRECH OFF
FAGC
VIDEO DET
VIF AMP
APC DET ADJ DET
BLACK STRECH
VIDEO TONE
CHROMA TRAP
VIDEO MUTE
CLAMP
SHARPNESS
CONTRAST
DELAY
FEF FILTER
AGC
R-Y IN
B-Y IN
H OUTPUT
SYSTEM DECODE
BRIGHT
CHROMA DEMODULATOR
DR/VE AMP
AFC GAIN
RGB MATRIX CONTRAST
32 FH VCO
MUTE DET
HV BLK
VERTICAL COUNTDOWN HORIZONTAL COUNTDOWN
EXITAUDIO
IN
GND
VCC
VIF
SIF
SIF IN
47
48
46
1
8
3
42
52
51
50
49
5
4 6 7 2 9 31 38
36
34
39
V-OUT
V-FB
V RAMP
BLK
AUDIO
DIRECT
OUT
AF DC
FB
HI VCC
IF OUT
IFAPC
IF VCO
IF VCO
BLACK
PEAK ACL/CLK Y-SW
OUT
X TAL 4.43
X TAL 3.58
BLACK PEAK
QXXAVB488

-6-
IC501 < Vertical Output > LA7841
THERMAL
PROTECTION PUMP UP
AMP
-
+
GND
Ver. Output
Output Stage Vcc
Non Inv. Input
Inverting Input
Vcc
Pump Up Output
LA7841
123 4 567
IC Block Diagrams
1
GND
2
3
4
DETR
CTL
DEFR
5
6
CTL
VCAR
R-MIX
7
R-OUT
VCA
8
R-IN
9
APFR
10
HPFR HPF
LPF
11
LPFR
12
BIASC
LD
–
++
HI MID
+
+
++
CTL
24 DETL
23
22 DEFL
VCA 21 VCC
20 VCAL
19 L-MIX
18
17
16
L-OUT
L-IN
15
14
13
APFL
HPFL
LPFL
HPF
LPF
+
++
+
MID
LO
+
+–
HI
IC3501 <BBE> QBA3880AFS
20 19 18 17 16
+
-
15 14 13 12 11
CONTROL
LOGIC
I2C BUS
INTERFACE
AVDD 1.8K VR4
VR6
200K
200K
+
-
TONE
AMP2
6.5K
S8
S6S4
S2
6.5K
136K SIMAMP2
ref
+
-
VOLAMP2
VR2
ref
VOLAMP1
+
-
6.5K
ref
VR1
S1 S3
+
-
ref
12
S5 S7
6.5K
+
-
TONE
AMP1
200K
200K
VR5
VR3
1.8K
ref
136K
SIMAMP1
3456
278910
REF
CH1 IN
SCL
SDA
D GND
OUT 1
TRE 1
BASS 1
SIM IN1
SIM OUT1
AVDD
CH2 IN
RESET
DVDD
A GND
OUT 2
TRE 2
BASS 2
SIM IN2 SIM OUT2
IC3071 <Audio Control > QM62420FP
IC001A < Sound Output > LA4270
CH1
CH2
Thermal
Shutdown
Over
Voltage
Ripple
Filter
30K
300
30K
300
Vcc
-
+
+
-
Feedback 1
Input 1
Ripple filter
Input side earth
Input 2
Feedback 2
Output 2
Output side earth
Power supply
Output 1
LA4270

-7-
Service Adjustments
IC3501
BBE
IC1201
AUDIO SW
VIDEO SW
IC1501
IC1401
VIDEO SW
IC501
VERT. OUT
K1003 K1002
K1004
Q461
H-WIDTH
VR462
C641
Q432
H-OUT
Q431
H-DRIVE
OUT
IC201
IF/VIDEO/CHROMA
IC281
SECAM
(SOLDER SIDE)
(SOLDER SIDE)
(SOLDER SIDE)
A101TUNER
T471
FBT.
T431
H-DRIVE
TRANS.
ANS.
TP-E
(1)Receive the monochrome circular pattern.
(2) Set the brightness to normal and contrast to maximum.
(3) Adjust the focus control on the F.B.T. (T471) for well-
defined scanning lines.
FOCUS ADJUSTMENT
MAIN BOARD
(1)Connect DC meter to R103 (L631 side) and the ground.
(2)Tune the receiver to an active channel and
synchronized picture.Select DYNAMIC picture mode by
pressing the VSM (Video Status Memory) button on
the remote control .
(3) Voltage must measure 130 ± 1 volt DC.
B-VOLTAGE SUPPLY CHECK
Note: Grayscale and Horizontal Width Adjustment must be
completed before attempting High Voltage Check.
(1)Connect a high voltage probe to anode lead of the
picture tube.
(2)Receive the monochrome circular pattern.
(3)Set the brightness and contrast to maximum.
(4)The high voltage must measure 28 ± 1KV and less than
31KV at 0 beam current (Brightness and contrast
minimum setting).
If reading is not within range, check horizontal circuit.
NOTE:
If the picture tube is replaced, check the high voltage.
HIGH VOLTAGE CHECK
(1)Tune receiver to an active channel.
(2) Adjust H-Width Control (VR462) for proper width.
(3) Select several other channels and check width.
HORIZONTAL WIDTH ADJUSTMENT
FOCUS ADJUSTMENT
B-VOLTAGE SUPPLY CHECK
HORIZONTAL WIDTH ADJUSTMENT

-8-
Service Adjustments with Replacing Memory IC(IC802)
[1] Initializing Procedure
1. Put a new memory IC.
2. Turn on the TV set.
3. Press and hold the TV/AV Selector button on the TV set for more than 2 seconds.The following picture appears on
the screen.
4. Press the MENU button on the TV set while the above On-Screen Display is still on the screen.The following
picture appears on the screen.
This completes the initialization of memory IC.
Following shows the initialized contents of memory data by this procedure.
- Plug & play : No executed
- Inhibit data : Cancelled
- Ch skip data : Cancelled
- Sound volume data : 10/63 steps.
- Volume Lock : OFF
- Tuning Lock : OFF
- Music Mode : OFF
- AV Start : OFF
- Language : English
- Colour system : AUTO
- AV status : When the memory IC replaced, the CPU writes the initial value of the AV Status
to the replaced memory IC as shown in below table.
Note:The CPU (IC801) and memory IC (IC802) store the service adjustments data and controls data for each circuit.
When the Memory IC(IC802) is replaced, some of the service adjustments should be readjusted to obtain the
best performance. The necessary service adjustments are carried out by using the RC handset. Please set
up the TV set with following steps [1] to [2].
MEMORY CLEAR
ITEM PERSONAL DYNAMIC NATURAL ECO GAME
COLOUR 34/63 36/63 34/63 34/63 31/63
BRIGHTNESS 33/63 30/63 33/63 33/63 33/63
CONTRAST 63/63 63/63 63/63 50/63 38/63
TINT 31/63 31/63 31/63 31/63 31/63
SHARPNESS 31/63 54/63 31/63 24/63 34/63
Press and hold for more than 2 seconds
Video Status
1
Audio Status
ITEM PERSONAL MUSIC TALK NORMAL
BASS 8/15 13/15 4/15 8/15
TERBLE 8/15 15/15 12/15 8/15
-
+P
MENU
TV/AV
-
+P
MENU
TV/AV

-9-
Service Adjustments with Replacing Memory IC(IC802)
[2] Required Service Adjustments
Readjust the following service adjustments.
Adjustments Service Mode No. & Item
Horizontal centre adjustment Item 01, H-P
Vertical centre adjustment Item 02, V-P
Vertical size adjustment Item 03, V-S
RF AGC adjustment Item 05, AGC
AFT adjustment Item 06, VCO
SIF adjustment Item 07, SIF
Grey scale adjustment Item 18-22, 25-26.
Further adjustment please refer to page 11 and 12 .
Following table shows the initial values which have been stored in the CPU ROM, and items for the service
adjustments.
Notes:
+ The initial value that the CPU writes down the CPU ROM data to the memory when replaced the memory IC.TV set
may not operate correctly with this initial value. It is required to set up the fine adjustment for service adjustments
described in the above.
Service mode adjustments table in CPU ROM
NO. ITEM INITIAL
VALUE RANGE
OF DATA FUNCTION NO. ITEM INITIAL
VALUE RANGE
OF DATA FUNCTION
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
H-Phase (H-Centering) AdjustmentH-P 08 00-15 V-Position (V-Centering) AdjustmentV-P 02 00-07 V-Size AdjustmentV-S 70 00-127 OSD H-Position AdjustmentOSD 01 00-15 RF AGC Adjustment
AGC 64 00-127 VCO (AFT) Adjustment
VCO 128 00-255 SIF VCO AdjustmentSIF 00 00-03 Self Adjustment Mode Setting
SELF 00 00-15 DL Time Adjustment
DLT 02 00-03 DL Fine AdjustmentDL F 01 00, 01 Black Stretch On/Off SettingB-ST 00 00, 01 ABCLABCL 01 00, 01 ABCL GainAB-G 00 0, 01 Trap Frequency AdjustmentTRAP 03 00-03 White Back SettingWBK 00 00, 01 Blue Back SettingBBK 00 00, 01 AFC Gain AdjustmentAFCG 02 00-02 Red Bias AdjustmentRBI 00 00-255 Green Bias AdjustmentGBI 00 00-255 Blue Bias AdjustmentBBI 00 00-255
21
22
23
24
25
26
27
98
99
Red Drive Adjustment
RD 64 00-127 Blue Drive Adjustment
BD 64 00-127
CPU Debug Data
BRI 32 00-63
1 LINE
00 00-63 White Balance Adjustment
-
AV mode contrast under the no signal condition
CON
FF 00-FFh
DRV
Check Code
R00
R71
R72 FF
FF 00-FFh
00-FFh
AV mode brightness under the no signal condition
--
-
-
CPU Debug Data

-10-
Service Adjustments with Replacing Memory IC(IC802)
[Entering to Service Mode]
1. Press and hold the MENU button on the TV set and press the [1] button on the remote control handset. Following
setting items appears on the screen.
Display for [AGC] AGC adjustment
■00010100 ■
ADDRESS DATA
05 AGC 64
Read Status
Item No. Item Data value
Display for [H-P] Horizontal centre adjustment
■00110100 ■
ADDRESS DATA
01 H-P 8
Read Status
Item No. Item Data value
Data value for Red
Display for [DRV] White balance adjustment
■00010100 ■
ADDRESS DATA
25 DRV R 64 B 64
Read Status
Item No. Item
Data value for Blue
To return to normal TV mode, press the MENU button on the TV set or the remote control handset.
2. Select item by pressing the TIMER (Item No. UP) or SOUND MUTE (Item No. DOWN) button on the remote control
handset.
3. Adjust data value by pressing the VOLUME + or VOLUME - button on the remote control handset.
Example
-
+P
MENU
TV/AV
01➔02➔03➔04➔05......99 99➔98➔97➔96➔95......01
0
7
14
8
5
23
6
9/
TIMER TV/AV
TIMER
MENU
P
▲
P
▼
ZOOM

-11-
Service Mode Adjustments
Following adjustments should be carried out when the memory IC is replaced. How to enter the service mode and
adjust values, please refer to “ Entering to Service mode” on page 10.
IC3501
BBE
IC1201
AUDIO SW IC1401
VIDEO SW
K1003 K1002
K1004
1
HROMA
IC281
SECAM
(SOLDER SIDE)
(SOLDER SIDE)
A101TUNER
TP-E
TP-A
MAIN BOARD
pin-2
IC201 pin-2
Q101
IC201 pin-46
TP-E
TP-A
IC201
IF/VIDEO/CHROMA
MAIN BOARD
(1)Receive the monochrome circular pattern.
(2)Set the brightness and contrast to normal.
(3) Select [H-P] in the service mode.
(4)Change value to be optimum horizontal centre position.
(5)Exit from the service mode.
Item 01 [H-P] HORIZONTAL CENTRE
Horizontal centre
(1)Receive the monochrome circular pattern.
(2)Set the brightness and contrast to maximum.
(3) Select [V-P] in the service mode.
(4)Change value to be optimum vertical centre position.
(5)Exit from the service mode.
Item 02 [V-P] VERTICAL CENTRE
Vertical centre
(1)Receive the monochrome circular pattern.
(2)Set the brightness and contrast to maximum.
(3) Select [V-S] in the service mode.
(4)Change value to be optimum vertical size.
(5)Exit from the service mode.
Item 03 [V-S] VERTICAL SIZE
Vertical size
NOTE: Do not attempt this adjustment with weak signal.
(1)Tune the receiver to most clearest (or strongest) VHF
station in your area. Set the brightness and contrast
controls to maximum. Set the colour control to mini-
mum.
(2)Select [AGC] in the service mode.
(3)Change value until the snow noise just disappears.
Item 05 [AGC] AGC
(1)Input the SG signal to collector of Q101.
SG signal frequency : 38.0MHz
SG signal level : 70 dB~75dB
SG signal : COLOUR bar
(2) Connect a short clip between the base of Q101 and
ground. Connect a short clip between TP-A and TP-E.
(3) Connect oscilloscope to pin 2 of IC201.
(4)Select [VCO] in the service mode.
(5)Change value until the VCO level to be 4.5 ± 1.0V.
(6)Exit from the service mode.
(1)Tune the receiver to the clearest station with System
B/G(5.5MHz) in your area.
(2) Connect DC voltmeter to pin 46 of IC201 and ground.
(3)Select [SIF] in the service mode.
(4)Change value until the voltage to be about 3.43V.
(5)Exit from the service mode.
Item 06 [VCO] AFT
Item 07 [SIF] SIF

-12-
Service Mode Adjustments
(1)Receive the monochrome circular pattern.
(2)Set the brightness and colour to normal, contrast to
maximum.
(3)Enter to the service mode.
(4) Select No.18 RBI (Red Bias), No, 19 GBI (Green Bias),
and No. 20 BBI (Blue Bias) and set each data to 0 with
+ or - key.
(5)Select No. 21 RD (Red Drive) and No. 22 BD (Blue
Drive) and set each data to 64 with + or - key.
(6)Turn Screen Control (T471) to minimum (fully counter-
clock-wise).
(7) Select the TV Service Menu No. 26.
(8) Advance Screen Control (T471) clockwise to obtain
just visible one color line. If line does not appear,
place this control to maximum (fully clockwise).
(9) Raise each Bias Level with 1, 2, 5, 6, 9 and 0 keys to
obtain just visible white line.
(10) Select the TV Service Menu No. 25 DRV (White
Balance Adjustments).
(11) Adjust Red and Blue Drive Levels alternately with 3, 4,
-/-- or RECALL key to produce normal black and white
picture in highlight areas.
(12) Check for proper grayscale at all brightness levels.
To turn off the TV Service Menu display, press the
MENU key.
Note: If Grayscale Adjustment is made after picture tube
replacement, check High Voltage
Items 18-22, 25-26 GREY SCALE
This TV set has a built-in power supply protection circuit.
It is provided to protect the TV set in case of a power supply circuit malfunctions.When something abnormality
occurs during TV reception, the TV set goes to the stand-by mode.
When an abnormality occurs duringTV reception, it causes pin 24 of the CPU to go continually Low(less than
0.75V) for about one second. The CPU detects that this has occurred and outputs the signal from pin 15 to
switch off the power supply lines.
■Releasing the protective circuit and restoring power supply
To release the protective circuit and restore power supply, turn the power to the TV set OFF and then ON again
via either the main power switch or the ON-OFF button on the remote control.This will work only if the power
supply trouble was temporary. If there is permanent trouble such as a damaged circuit, power cannot be
restored and the circuit will have to be repaired.
Protection Circuit
0
7
14
8
5
23
6
9
JXMLA
MENU
-/--
PP
A•B
CH SCAN
TIMER
i
?
X
TV/TEXT
TV/AV
P
▲
P
▼
ZOOM
SWAPVSM
BBE BASS
ASM
SURROUND
Red Bias -
Red Bias +
Green Bias -
Green Bias +
Blue Bias -
Blue Bias +
Press the
MENU
button to exit
from service
mode
Red Drive -
Red Drive +
Blue Drive -
Blue Drive +

-13-
Purity and Convergence Adjustment
CAUTION:The Convergence and Purity adjustments have been made at the factory. Readjustment
should be made only after picture tube or deflection yoke replacement, following the steps below:
PURITY ADJUSTMENT
1. Demagnetize the picture tube and receiver using an
external degaussing coil.When replacing picture tube or
deflection yoke, mount deflection yoke and purity-con-
vergence magnets assembly properly, see figures 1 and
4.
2. Turn Red and Blue guns off and provide only Green
raster. Rotate Screen control to fully counterclockwise.
Rotate Red and Blue Bias controls fully counterclock-
wise. Slowly rotate Green Bias control clockwise to pro-
duce Green raster.
3. Loosen the screw holding the Deflection Yoke and
remove the 3 Rubber Wedges, and slide the Deflection
Yoke fully forward.
4. Rotate and spread the Tabs of the two Purity Magnets
to centre the vertical green belt in the picture screen.
The Purity Magnets are also adjusted to obtain vertical
centring of the raster.
5. Slowly slide the Deflection Yoke backward until a uni-
form green screen is obtained.
6. Check the purity of the red and blue screens for unifor-
mity, turn off other colours to check this (use bias con-
trols). Readjust the yoke position if necessary until all
screens are pure.
7. Adjust each Bias control and screen control to obtain
white raster. Refer to Gray Scale Adjustment. If part of
the picture screen is coloured, adjust the Deflection
Yoke position forward or backward slightly.
8. Tighten the mounting screw of the Deflection Yoke.
Adjust Convergence next.
CENTRE CONVERGENCE ADJUSTMENT
1. Use a dot crosshatch pattern signal.
2. Turn Red and Blue guns on and turn off Green gun.
Adjust the angle between the Tabs of the Four Pole
Magnet 1 and 2, and superimpose the Red and Blue
vertical lines in the centre area of the picture screen.
Refer to figure 2.
3. Keeping the mutual angle of the Tabs of the Four Pole
Magnet turn them together to superimpose the Blue and
Red horizontal lines in the centre area of the picture
screen. Refer to figure 2.
4. Turn Green gun on and adjust Six Pole Magnet 3 and 4
that the Green line superimposed on the Red/Blue lines.
This is the same procedure used in steps 2 and 3.
Refer to figure 3.
OUTER AREA CONVERGENCE ADJUSTMENT
Slightly loosen the screw holding the Deflection Yoke.
Adjust the Deflection Yoke to converge the detail in the
outer area (left side and right side) of the picture screen by
orbital movement of the front of the Yoke, then secure the
Deflection Yoke in appropriate position by putting the
wedges as illustrated.Tighten screw holding the Deflection
Yoke.
RED
BLUE
Adjust tabs together to
superimpose red and
blue horizontal line.
Figure- 2 BLUE AND RED LINE MOVEMENT Figure- 3 BLUE/RED AND GREEN MOVEMENT
Adjust tabs together to
superimpose red/blue
and green horizontal
line.
Adjust tabs angle to superimpose
blue and red vertical line. Adjust tabs angle to superimpose red/blue and green vertical line.
GREEN
BLUE / RED

-14-
L
R
AUDIO
AV1 INPUT
VIDEO
(MONO)
S-VIDEO
MONITOR
OUT
ANT. 75Ω
Mechanical Disassemblies
CABINET BACK REMOVAL
1. Refer to Figure 1, remove 8 screws.
2. Pull off cabinet back and remove.
CHASSIS REMOVAL
1. Remove cabinet back.
2. Discharge the picture tube anode (2nd anode lead) to the dag
coating (picture tube grounding lead).
3. Disconnect Degaussing coil socket (KE), Picture tube socket,
Deflection yoke connector (KDY), Speaker connectors (K002
and K003), and 2nd anode lead.
4. Remove chassis completely by sliding it straight back.
PICTURE TUBE REMOVAL
CAUTION: Do not disturb the deflection yoke or magnet
assembly on the picture tube neck. Care must be taken
to keep these assemblies intact, unless picture tube is
being replaced . Discharge the picture tube to the coat-
ing before handling the tube.
1. Remove chassis, referring to Chassis Removal instructions.
2. Place cabinet’s front face down on the soft surface.
3. Remove the screw on each corner of the picture tube and
GENTLY lift the picture tube out of the cabinet.
4. Install a replacement picture tube in reverse order.
Properly install the degaussing coil and picture tube ground
ing lead on the picture tube. See Figure 2.
Note: If the Picture Tube is being replaced, mount the
Degaussing Coil on the picture tube. See Figure 2.
Figure 2. PictureTube Removal
Figure 1. Cabinet Back Removal

0
7
14
8
5
23
6
9
JXMLA
MENU
-/--
PP
A•B
CH SCAN
TIMER
i
?
X
TV/TEXT
TV/AV
P
▲
P
▼
ZOOM
SWAPVSM
BBE BASS
ASM
SURROUND
-15-
Cabinet Parts List
C2GYT
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
11 12
-
+
P
MENU
TV/AV
L
R
AUDIO
AV1 INPUT
VIDEO
(MONO)
S-VIDEO
MONITOR
OUT
ANT. 75Ω
1
2
3
4-a
9
10
1 610 286 4977 ASSY,BUTTON POWER
610 286 7770 SPRING COIL
2 610 286 5097 DEC IND
3 610 286 4984 ASSY,BUTTON UNIT
4 610 288 4692 ASSY,CABINET FRONT
4-a 610 286 5066 CABINET FRONT
4-b 610 286 5080 DOOR
5 610 284 7741 DOOR COVER
6 610 288 4791 DEC SHEET DOOR
7 645 041 7269 BADGE,SANYO
8 610 284 7833 SPRING PLATE
9 610 286 5073 CABINET BACK
10 610 287 1463 LABEL RATING
11 645 040 7833 ASSY,REMOCON JXMLA
12 610 284 7277 RC-BATTERY LID
610 287 0701 INSTRUCTIONS MANUAL
Key No. Part No. Description Key No. Part No. Description
4-b5
6
7
8

-16-
C2GYT
OUT OF CIRCUIT BOARD
PICTURE TUBE
Q901 414 010 6400 CRT A51LTH196X
Q901A 645 008 8674 MAGNET,CG.PR
610 003 1739 CG PURITY MAGNET
Q901B1 610 233 7891 DY SPACER E2HA
Q901B2 610 233 7891 DY SPACER E2HA
Q901B3 610 233 7891 DY SPACER E2HA
COIL
L901 645 040 0247 COIL,DEGAUSSING
L902 645 040 2395 YOKE,DEFLECTION
MISCELLANEOUS
SP901 645 032 2037 SPEAKER,8
SP902 645 032 2037 SPEAKER,8
W901 645 009 9991 CORD,POWER-2.4MK-A5003
W902 610 283 5335 ASSY,WIRE GND CONNECTOR C
610 283 7179 ASSY,WIRE GND CONNECTOR C
610 279 5042 ASSY,PWB,TEXT F8LC
1AA0B10E56500
TRANSISTOR
Q2001 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
Q2002 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
Q2003 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
!
!
!
!
Chassis Electrical Parts List
Ref. No. Part No. Description Ref. No. Part No. Description
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by a mark in this parts list and the circuit diagram show components whose value have
special significance to product safety. It is particularly recommended that only parts specified on the following parts
list be used for components replacement pointed out by the mark.
!
Note: Parts order must contain Service Ref. No., Part No., and descriptions. The main PCB unit will be supplied without tuner and
flyback transformer. They should be ordered separately.
Read description in the Capacitor and Resistor as follows:
CAPACITOR
CERAMIC 100P K 50V
Rated Voltage
Tolerance Symbols:
Less than 10pF
A : Not specified B : ±0.1pF C : ±0.25pF
D : ±0.5pF F : ±1PF G : ±2pF
R : ±0.25-0pF S : ±0-0.25pF E : +0-1pF
More than 10pF
A : Not specified B : ±0.1% C : ±0.25%
D : ±0.5% F : ±1% G : ±2%
H : ±3% J : ±5% K : ±10%
L : ±15% M : ±20% N : ±30%
P : +100-0% Q : +30-10% T : +50-10%
U : +75-10% V : +20-10% W : +100-10%
X : +40-20% Y : +150-10% Z : +80-20%
Rated value: P=pico farad, U=micro farad
Material:
CERAMIC...........Ceramic
MT-PAPER.........Metallized Paper
POLYESTER......Polyester
MT-POLYEST.....Metallized Polyester
POLYPRO..........Polypropylene
MT-POLYPRO....Metallized Polypropylene
COMPO FILM.....Composite film
MT-COMPO........Metallized Composite
STYRENE...........Styrene
TA-SOLID...........Tantalum Solid
AL-SOLID...........Aluminium Solid
ELECT................Electrolytic
NP-ELECT..........Non-polarised Electrolytic
OS-SOLID.......... Aluminium Solid with Organic Semiconductive Electrolytic
DL-ELECT..........Double Layered Electrolytic
RESISTOR
CARBON 4.7K J A 1/4W Rated Wattage
Performance Symbols:
A: General B: Non flammable Z: Low noise
Other: Temperature coefficient
Tolerance Symbols:
A: ±0.05% B: ±0.1% C: ±0.25% D: ±0.5%
F: ±1% G: ±2% J: ±5% K: ±10%
M: ±20% P: +5-15%
Rated value, ohms:
K: 1,000, M: 1,000,000
Material:
CARBON........... Carbon
MT-FILM............ Metal Film
OXIDE-MT......... Oxide Metal Film
SOLID................ Composition
MT-GLAZE.........Metal Glaze
WIRE WOUND...Wire Wound
CERAMIC RES.. Ceramic
FUSIBLE RES....Fusible
NOTES:

405 020 7907 TR 2SC945A-RA
Q2004 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
Q2005 406 000 6804 TR 2SA1015-GR(SAN)
405 001 7407 TR 2SA1015-O(SAN)
405 001 7605 TR 2SA1015-Y(SAN)
405 004 3109 TR 2SA564A-Q(CU)
405 004 3208 TR 2SA564A-R(CU)
405 151 3304 TR 2SA608NF-NPA
405 006 1707 TR 2SA933S-Q
405 006 1806 TR 2SA933S-R
INTEGRATED CIRCUIT
IC2001 409 458 8703 IC STV5348
CAPACITOR
C2001 403 057 3107 POLYESTER 0.1U K 50V
403 181 8207 POLYESTER 0.1U K 50V
403 311 8909 POLYESTER 0.1U K 50V
C2002 403 049 0008 ELECT 1U M 50V
C2006 403 041 8804 ELECT 10U M 16V
C2007 403 057 3107 POLYESTER 0.1U K 50V
403 181 8207 POLYESTER 0.1U K 50V
403 311 8909 POLYESTER 0.1U K 50V
C2008 403 024 0009 CERAMIC 39P J 50V
C2009 403 024 0009 CERAMIC 39P J 50V
C2010 403 049 0008 ELECT 1U M 50V
C2011 403 057 0601 POLYESTER 0.01U K 50V
403 179 3801 POLYESTER 0.01U K 50V
403 311 8701 POLYESTER 0.01U K 50V
C2012 403 041 8804 ELECT 10U M 16V
RESISTOR
R2004 401 027 6608 CARBON 75 JA 1/6W
R2005 401 027 6608 CARBON 75 JA 1/6W
R2006 401 027 6608 CARBON 75 JA 1/6W
R2007 401 026 7002 CARBON 3.9K JA 1/6W
R2008 401 024 7004 CARBON 1K JA 1/6W
R2009 401 026 7002 CARBON 3.9K JA 1/6W
R2010 401 025 8208 CARBON 22K JA 1/6W
R2011 401 027 3003 CARBON 56K JA 1/6W
R2012 401 027 0309 CARBON 47K JA 1/6W
R2013 401 024 7400 CARBON 10K JA 1/6W
R2014 401 024 7400 CARBON 10K JA 1/6W
R2015 401 025 8208 CARBON 22K JA 1/6W
R2016 401 024 7004 CARBON 1K JA 1/6W
R2017 401 024 7004 CARBON 1K JA 1/6W
R2018 401 025 1902 CARBON 15K JA 1/6W
COIL
L2006 645 008 2894 INDUCTOR,5.6U K
DIODE
D2001 408 008 2406 DIODE 1N4148
407 012 4406 DIODE 1SS133
407 013 4306 DIODE 1S2076A
407 013 7109 DIODE 1S2473
D2002 408 008 2406 DIODE 1N4148
407 012 4406 DIODE 1SS133
407 013 4306 DIODE 1S2076A
407 013 7109 DIODE 1S2473
D2003 408 008 2406 DIODE 1N4148
407 012 4406 DIODE 1SS133
407 013 4306 DIODE 1S2076A
407 013 7109 DIODE 1S2473
D2004 407 063 8606 ZENER DIODE MTZJ5.1A
407 056 8002 ZENER DIODE RD5.1EB2
D2005 401 026 9907 CARBON 4.7K JA 1/6W
MISCELLANEOUS
K20C 645 009 8185 SOCKET,PWB-PWB 11P
X2001 645 006 3756 OSC,CRYSTAL 13.875MHZ
610 287 1128 ASSY,PWB,CTV C2GYT
1AA0B10E618C0
610 287 1104 ASSY,PWB,MAIN C2GYT
1AA0B10E618CA
TRANSISTOR
Q101 405 013 3305 TR 2SC2216(SAN)
Q1230 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q1231 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
Q137 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q138 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q140 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
Q1401 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
Q1402 406 000 6804 TR 2SA1015-GR(SAN)
405 001 7407 TR 2SA1015-O(SAN)
405 001 7605 TR 2SA1015-Y(SAN)
405 004 3109 TR 2SA564A-Q(CU)
405 004 3208 TR 2SA564A-R(CU)
405 151 3304 TR 2SA608NF-NPA
405 006 1707 TR 2SA933S-Q
405 006 1806 TR 2SA933S-R
Q1501 405 014 4509 TR 2SC2412K T146 R
-17-
C2GYT
Ref. No. Part No. Description Ref. No. Part No. Description

-18-
C2GYT
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q1502 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
Q1503 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q1504 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q183 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q190 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
Q1902 406 000 6804 TR 2SA1015-GR(SAN)
405 001 7407 TR 2SA1015-O(SAN)
405 001 7605 TR 2SA1015-Y(SAN)
405 004 3109 TR 2SA564A-Q(CU)
405 004 3208 TR 2SA564A-R(CU)
405 151 3304 TR 2SA608NF-NPA
405 006 1707 TR 2SA933S-Q
405 006 1806 TR 2SA933S-R
Q191 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
Q200 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
Q261 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
Q431 405 018 0507 TR 2SC3332-R
405 018 0606 TR 2SC3332-S
Q432 405 153 0202 TR 2SD2578-YB
Q461 405 064 7307 TR 2SB1274-Q-RA
405 064 7406 TR 2SB1274-R-RA
Q462 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
Q527 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q540 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
Q611 406 000 6804 TR 2SA1015-GR(SAN)
405 001 7407 TR 2SA1015-O(SAN)
405 001 7605 TR 2SA1015-Y(SAN)
405 004 3109 TR 2SA564A-Q(CU)
405 004 3208 TR 2SA564A-R(CU)
405 004 4205 TR 2SA608-E-CTV-NP
405 004 4809 TR 2SA608-F-CTV-NP
405 006 1103 TR 2SA933-Q
405 006 1202 TR 2SA933-R
405 006 1707 TR 2SA933S-Q
405 006 1806 TR 2SA933S-R
Q612 405 058 0208 TR 2SC3807-R-CTV-YA
Q613 405 096 7702 TR 2SC4430-L-YB
405 096 7603 TR 2SC4430-M-YB
Q661 405 059 9903 TR 2SD1913-R-RA
405 060 0005 TR 2SD1913-S-RA
Q681 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q683 405 089 0000 TR 2SA1707-S
405 089 0109 TR 2SA1707-T
405 009 6907 TR 2SB985-S
405 009 7003 TR 2SB985-T
Q684 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
Q685 405 012 2002 TR 2SC1815-GR
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
Q686 406 000 6804 TR 2SA1015-GR(SAN)
405 001 7605 TR 2SA1015-Y(SAN)
405 004 3208 TR 2SA564A-R(CU)
405 151 3304 TR 2SA608NF-NPA
Q811 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
Ref. No. Part No. Description Ref. No. Part No. Description

405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q813 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q814 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q815 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
Q816 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
Q824 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
Q886 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
INTEGRATED CIRCUIT
IC001A 409 017 7505 IC LA4270
IC1201 409 051 2702 IC TC4052BF-TP1
IC1401 409 479 3206 IC MM1188XS
IC1501 409 051 2900 IC TC4053BF-TP1
IC201 410 342 8907 IC QXXAVB488—-M
IC202 409 241 5407 IC BA178M05T
409 265 4806 IC L78M05CV
409 172 1509 IC MC78M05CT
409 320 5700 IC UPC78M05AHF
IC3071 409 421 8808 IC M62420FP
IC3501 409 473 1604 IC BA3880AFS
IC501 409 340 1904 IC LA7841
IC631 409 172 8102 IC SE130NH
IC651 409 241 5407 IC BA178M05T
409 172 1509 IC MC78M05CT
409 320 5700 IC UPC78M05AHF
IC801 410 374 3208 IC M37221M8-165SP
IC802 409 383 6805 IC 24LC08B/P
CAPACITOR
C005 403 157 6701 CERAMIC 560P K 50V
C006 403 049 0008 ELECT 1U M 50V
C007 403 045 7803 ELECT 220U M 25V
C008 403 044 9501 ELECT 100U M 25V
C009 403 057 2100 POLYESTER 0.1U J 50V
403 243 6806 MT-COMPO 0.1U J 50V
C010 403 045 1504 ELECT 1000U M 25V
C011 403 049 0008 ELECT 1U M 50V
C012 403 045 1504 ELECT 1000U M 25V
C013 403 045 1504 ELECT 1000U M 25V
C019 403 157 6701 CERAMIC 560P K 50V
C020 403 049 0008 ELECT 1U M 50V
C021 403 049 0008 ELECT 1U M 50V
C022 403 044 9501 ELECT 100U M 25V
C023 403 057 2100 POLYESTER 0.1U J 50V
403 243 6806 MT-COMPO 0.1U J 50V
C1000 403 041 8804 ELECT 10U M 16V
C1001 403 041 8804 ELECT 10U M 16V
C1002 403 041 8804 ELECT 10U M 16V
C101 403 050 6600 ELECT 3.3U M 50V
C102 403 043 3906 ELECT 33U M 16V
C1030 403 041 8804 ELECT 10U M 16V
C1031 403 041 8804 ELECT 10U M 16V
C1032 403 041 8804 ELECT 10U M 16V
C106 403 051 3103 ELECT 47U M 50V
C1060 403 041 8804 ELECT 10U M 16V
C1061 403 041 8804 ELECT 10U M 16V
C1062 403 043 0202 ELECT 220U M 16V
C107 403 043 3906 ELECT 33U M 16V
C1081 403 215 2201 CERAMIC 0.01U K 50V
C1082 403 041 8804 ELECT 10U M 16V
C1084 403 215 2201 CERAMIC 0.01U K 50V
C117 403 149 9208 CERAMIC 0.01U Z 50V
C118 403 149 9208 CERAMIC 0.01U Z 50V
C119 403 149 9208 CERAMIC 0.01U Z 50V
C120 403 149 9208 CERAMIC 0.01U Z 50V
C121 403 149 9208 CERAMIC 0.01U Z 50V
C122 403 043 9106 ELECT 47U M 16V
C1230 403 041 8804 ELECT 10U M 16V
C1231 403 041 8804 ELECT 10U M 16V
C124 403 149 9208 CERAMIC 0.01U Z 50V
C1301 403 164 0204 CERAMIC 0.1U Z 25V
C1302 403 049 0008 ELECT 1U M 50V
C1303 403 051 0607 ELECT 4.7U M 50V
C1304 403 049 0008 ELECT 1U M 50V
C1305 403 051 0607 ELECT 4.7U M 50V
C1306 403 215 2201 CERAMIC 0.01U K 50V
C1307 403 157 6602 CERAMIC 470P K 50V
C1308 403 051 0607 ELECT 4.7U M 50V
C1309 403 051 0607 ELECT 4.7U M 50V
C131 403 215 2201 CERAMIC 0.01U K 50V
C1310 403 215 2201 CERAMIC 0.01U K 50V
C1311 403 356 5109 CERAMIC 0.047U K 50V
C1312 403 051 3103 ELECT 47U M 50V
C1313 403 356 5109 CERAMIC 0.047U K 50V
C1314 403 215 2201 CERAMIC 0.01U K 50V
C1315 403 051 0607 ELECT 4.7U M 50V
C1316 403 051 0607 ELECT 4.7U M 50V
C1317 403 157 6602 CERAMIC 470P K 50V
C1318 403 215 2201 CERAMIC 0.01U K 50V
C1319 403 149 9208 CERAMIC 0.01U Z 50V
C138 403 048 1907 ELECT 0.22U M 50V
C1401 403 042 2405 ELECT 100U M 16V
C1402 403 149 9208 CERAMIC 0.01U Z 50V
C142 403 157 2901 CERAMIC 47P J 50V
C1501 403 149 9208 CERAMIC 0.01U Z 50V
C152 403 155 1609 CERAMIC 33P J 50V
C172 403 048 1907 ELECT 0.22U M 50V
C176 403 155 2200 CERAMIC 3300P K 50V
C177 403 048 4205 ELECT 0.33U M 50V
C181 403 049 4204 ELECT 10U M 50V
C186 403 049 4204 ELECT 10U M 50V
C200 403 314 5905 CERAMIC 0.47U K 16V
C201 403 043 9106 ELECT 47U M 16V
C202 403 149 9208 CERAMIC 0.01U Z 50V
C203 403 338 0108 CERAMIC 0.039U K 25V
C205 403 087 1302 NP-ELECT 0.47U M 160V
C206 403 042 4805 ELECT 1000U M 16V
C207 403 149 9208 CERAMIC 0.01U Z 50V
C208 403 149 9208 CERAMIC 0.01U Z 50V
C221 403 164 0204 CERAMIC 0.1U Z 25V
C222 403 164 0204 CERAMIC 0.1U Z 25V
-19-
C2GYT
Ref. No. Part No. Description Ref. No. Part No. Description

-20-
C2GYT
C223 403 164 0204 CERAMIC 0.1U Z 25V
C225 403 049 0008 ELECT 1U M 50V
C241 403 047 8402 ELECT 0.1U M 50V
C245 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
C246 403 049 0008 ELECT 1U M 50V
C247 403 215 2409 CERAMIC 0.015U K 50V
C248 403 224 7006 CERAMIC 0.047U Z 50V
C3072 403 072 1607 CERAMIC 0.022U K 50V
C3073 403 281 5205 CERAMIC 0.22U Z 16V
C3074 403 281 5007 CERAMIC 0.033U K 25V
C3076 403 043 9106 ELECT 47U M 16V
C3077 403 149 9208 CERAMIC 0.01U Z 50V
C3078 403 281 5007 CERAMIC 0.033U K 25V
C3079 403 281 5205 CERAMIC 0.22U Z 16V
C3080 403 072 1607 CERAMIC 0.022U K 50V
C3081 403 044 1703 ELECT 470U M 16V
C3082 403 149 9208 CERAMIC 0.01U Z 50V
C3084 403 086 2300 NP-ELECT 1U M 50V
C3085 403 086 2300 NP-ELECT 1U M 50V
C3086 403 313 8006 CERAMIC 1000P J 25V
C350 403 164 0204 CERAMIC 0.1U Z 25V
C351 403 043 0202 ELECT 220U M 16V
C354 403 215 2409 CERAMIC 0.015U K 50V
C355 403 048 6308 ELECT 0.47U M 50V
C356 403 164 0204 CERAMIC 0.1U Z 25V
C357 403 215 2201 CERAMIC 0.01U K 50V
C358 403 049 9803 ELECT 2.2U M 50V
C359 403 215 2201 CERAMIC 0.01U K 50V
C360 403 009 3100 CERAMIC 100P J 50V
C3601 403 044 1703 ELECT 470U M 16V
C361 403 260 2003 MT-COMPO 1U J 50V
403 270 2109 MT-COMPO 1U J 50V
C362 403 145 9905 CERAMIC 22P J 50V
C371 403 157 7203 CERAMIC 3900P K 50V
C372 403 049 0008 ELECT 1U M 50V
C420 404 081 2104 MT-POLYPRO 4700P H 1.5K
C423 404 082 5104 MT-POLYPRO 4500P H 1.5K
403 353 5508 MT-POLYPRO 4500P H 1.5K
C424 403 083 2501 POLYPRO 0.01U J 400V
C425 403 083 4901 POLYPRO 0.027U J 400V
C427 403 066 6106 MT-POLYEST 0.47U J 250V
C432 403 075 7101 CERAMIC 1000P K 500V
C433 403 076 3102 CERAMIC 3900P K 500V
C434 403 054 0703 ELECT 47U M 35V
C441 403 078 9607 MT-POLYPRO 0.18U J 200V
C442 403 227 3104 MT-POLYPRO 0.12U J 200V
C462 403 049 0008 ELECT 1U M 50V
C465 403 066 0104 MT-POLYEST 2.2U K 100V
C466 403 256 0808 MT-COMPO 0.47U J 50V
403 264 2207 MT-COMPO 0.47U J 50V
C467 403 040 3701 ELECT 220U M 10V
C468 403 045 5809 ELECT 22U M 25V
C469 403 049 4204 ELECT 10U M 50V
C470 403 069 8305 CERAMIC 0.01U Z 50V
C471 404 056 5307 NP-ELECT 2.2U M 100V
C482 403 042 4805 ELECT 1000U M 16V
C486 403 260 0702 ELECT 33U M 250V
C511 403 069 8305 CERAMIC 0.01U Z 50V
C514 403 051 0607 ELECT 4.7U M 50V
C515 403 045 9807 ELECT 2200U M 25V
C517 403 053 2104 ELECT 220U M 35V
C518 403 023 9706 CERAMIC 39P J 50V
C520 403 064 1202 POLYESTER 0.1U K 100V
403 276 9706 POLYESTER 0.1U K 100V
C521 403 052 8503 ELECT 1000U M 35V
C524 403 064 1202 POLYESTER 0.1U K 100V
403 276 9706 POLYESTER 0.1U K 100V
C527 403 049 4204 ELECT 10U M 50V
C540 403 085 5906 NP-ELECT 33U M 16V
C601 404 071 2107 MT-POLYEST 0.1U K 250V
404 072 5602 MT-POLYEST 0.1U M 250V
404 060 7205 MT-POLYEST 0.1U M 250V
404 066 1702 MT-POLYEST 0.1U M 275V
C602 404 071 2107 MT-POLYEST 0.1U K 250V
404 072 5602 MT-POLYEST 0.1U M 250V
404 060 7205 MT-POLYEST 0.1U M 250V
404 066 1702 MT-POLYEST 0.1U M 275V
C603 403 076 6707 CERAMIC 1000P K 1K
C604 403 076 6707 CERAMIC 1000P K 1K
C605 403 076 6707 CERAMIC 1000P K 1K
C606 403 076 6707 CERAMIC 1000P K 1K
C607 404 047 1608 ELECT 270U M 400V
404 051 8105 ELECT 270U M 400V
C613 403 061 7504 POLYESTER 4700P J 50V
403 179 1203 POLYESTER 4700P J 50V
C614 403 057 2100 POLYESTER 0.1U J 50V
403 067 5603 MT-COMPO 0.1U J 50V
C615 403 058 2604 POLYESTER 0.015U J 50V
403 179 3207 POLYESTER 0.015U J 50V
C616 403 246 9507 CERAMIC 1200P K 2K
C617 403 060 8403 POLYESTER 0.033U K 50V
C627 404 073 3904 CERAMIC 1000P K 250V
404 073 2105 CERAMIC 1000P M 250V
404 071 3302 CERAMIC 1000P M 400V
C629 404 073 3904 CERAMIC 1000P K 250V
404 073 2105 CERAMIC 1000P M 250V
404 071 3302 CERAMIC 1000P M 400V
C631 403 247 5003 CERAMIC 470P K 1K
403 269 1809 CERAMIC 470P K 1K
403 232 0501 CERAMIC 470P K 1K
C633 403 247 5003 CERAMIC 470P K 1K
403 269 1809 CERAMIC 470P K 1K
403 232 0501 CERAMIC 470P K 1K
C634 403 247 5003 CERAMIC 470P K 1K
403 269 1809 CERAMIC 470P K 1K
403 232 0501 CERAMIC 470P K 1K
C641 404 074 9103 ELECT 220U M 160V
404 042 4505 ELECT 220U M 160V
C643 403 148 2002 ELECT 470U M 35V
C644 403 148 0404 ELECT 1000U M 25V
C645 403 045 1504 ELECT 1000U M 25V
C651 403 040 9406 ELECT 330U M 10V
C661 403 043 0202 ELECT 220U M 16V
C662 403 043 6006 ELECT 330U M 16V
C685 403 049 0008 ELECT 1U M 50V
C801 403 149 9208 CERAMIC 0.01U Z 50V
C809 403 041 2109 ELECT 47U M 10V
C810 403 164 0204 CERAMIC 0.1U Z 25V
C811 403 164 0204 CERAMIC 0.1U Z 25V
C815 403 149 9208 CERAMIC 0.01U Z 50V
C816 403 149 9208 CERAMIC 0.01U Z 50V
C818 403 149 9208 CERAMIC 0.01U Z 50V
C820 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
C828 403 041 8804 ELECT 10U M 16V
C835 403 049 0008 ELECT 1U M 50V
C840 403 155 2200 CERAMIC 3300P K 50V
C855 403 149 9208 CERAMIC 0.01U Z 50V
C886 403 149 9208 CERAMIC 0.01U Z 50V
RESISTOR
R001 401 007 7601 CARBON 150 JA 1/2W
R002 401 007 7601 CARBON 150 JA 1/2W
R007 401 015 6504 CARBON 2.2 JA 1/4W
R008 401 105 7305 MT-GLAZE 820 JA 1/16W
!
Ref. No. Part No. Description Ref. No. Part No. Description
