Sanyo CP21EF1 User manual

FILE NO.
REFERENCE NO. SS3010240
Model No. CP21EF1
Service Ref. No. CP21EF1-11
(Australia)
Product Code: 113004716
Original Version
Chassis Series: AC6-A1
Give complete “SERVICE REF. NO.” for
parts order or servicing. It is shown on the
rating plate at the cabinet back of the unit.
SERVICE MANUAL
(SUPPLEMENT)
Colour Television
-NOTE-
These model (CP21EF1-11) is electrically similar to original model (CP21EF1-00).
Any information not contained in this manual will be found in the original model’s service manual
SM3010194 (Issue date-Jul., 2006).
TV/AV MENU CH
- +
BA5VZ
123
456
789
0
TV/AV
TIMER
x
-/--
SWAP
CH SCAN
MENU
BASS
SOUND
S. SYS
SURROUND
CH
CH
A B
.
PP
JXPSC
SS_21-BA5VZ-01(AC6-A1)AUS 12/12/06 8:23 AM Page 1

-2-
(/JE0304B)
Service Adjustments with Replacing Memory IC(IC801)
DATA INITIAL
No. ITEM RANGE SETUP DESCRIPTION
DATA
01 RFAGC 0~63 27 RF AGC Adj.
02 H-PHA 0~31 9 H-Phase (H-Centering) Adj. (50Hz)
03 V-POS 0~63 40 V-Position Adj. (50Hz)
04 V-SHIFT 0~15 4 V-Phase (V-Centering) Adj. (50Hz)Fixed.
05 V-SIZ 0~127 65 V-Size Adj. (50Hz)
06 V-LIN 0~31 17 V-Linearity Adj. (50Hz)
07 V-SCO 0~31 10 V-S-Correction (50Hz)
08 VTRANS 0, 1 0 Data transmission between V Retrace
09 VRES 0, 1 0 Vertical Reset Timing
10 H-P60 -16~+15 +3 H-Phase Adj. (60Hz) difference val.
11 V-S60 -64~+63 -8 V-Size Adj. (60Hz) difference val.
12 V-SHIF60 -16~+15 -3 V-Phase Adj. (60Hz) difference val.
13 OSDHP 0~255 22 OSD H-Position Adj.
14 OSDC 0~3 4 OSD Contrast Adj.
15 V-SCP 0~7 7 V-Size COMP Adj.
16 SBIAS 0~255 105 Sub Bias Adj.
17 RBIAS 0~255 0 Red Bias Adj.
18 GBIAS 0~255 0 Green Bias Adj.
19 BBIAS 0~255 0 Blue Bias Adj.
20 RDRIV 0~127 64 Red Drive Adj.
21 GDRIV 0~15 8 Green Drive Adj.
22 BDRIV 0~127 64 Blue Drive Adj.
23 1 Line Appear White Balance Adj.
24 DRV White Balance Adj.
25 B-YD 0~15 12 B-Y DC Level Adj.
26 R-YD 0~15 10 R-Y DC Level Adj.
27 B-YDN - 16~+15 0 NTSC B-Y DC level Adj.
28 R-YDN - 16~+15 0 NTSC R-Y DC level Adj.
29 SBDC - 16~+15 0 SECAM B-Y DC Level Adj.
30 SRDC - 16~+15 0 SECAM R-Y DC Level Adj.
31 B-YDD - 16~+15 -5 DVD B-Y DC Level Adj.
32 R-YDD - 16~+15 -5 DVD R-Y DC Level Adj.
33 RGBTEMP 0, 1 0 RGB Temp SW
34 RGBTEST 0, 1 0 RGB Test
35 DRVTEST 0, 1 0 Drive Test Mode
36 HALFTONE 0, 1 2 Halftone Color
37 G-YA 0, 1 0 G-Y Angle
38 GYAMP 0~15 8 G-Y Amplitude Adjust
39 RBGB 0~15 8 R-Y / B-Y Gain Balance
40 RBAG 0~15 8 R-Y / B-Y angle
41 G-YAN 0, 1 0 NTSC G-Y Angle
42 GYAMPN -8~+7 0 NTSC G-Y Amplitude Adj.
43 RBGBN - 16~+15 0 NTSC R-Y / B-Y Gain Balance
44 RBAGN - 16~+15 0 NTSC R-Y / B-Y Angle
45 RBGBDN - 16~+15 +10 DVD NTSC R-Y / B-Y Gain Balance
Following table shows the initial values which have been stored in the CPU ROM, and items for the service adjustments.
Service mode adjustments table in CPU ROM
DATA INITIAL
No. ITEM RANGE SETUP DESCRIPTION
DATA
46 RBAGDN - 16~+15 +10 DVD NTSC R-Y / B-Y Angle
47 VOLFIL 0, 1 0 DAC Volume filter disable
48 IF-AGC 0, 1 0 IF AGC defeat
49 COGV 0~3 1 Coring Gain
50 BLKS 0~3 3 Blk.str.start(W/Defeat)
51 BLKG 0~3 3 Blk.str.gain
52 BRTA 0, 1 0 Brt.Abl.Def
53 BRST 0, 1 0 Mid.Stp.Def
54 BRTH 0~7 0 Bright.Abl.Treshold
55 WPL 0~3 2 White Peak Limit Op. Point
56 YGAM 0~3 0 Y Gamma Start
57 PRS 0~3 0 Pre-shoot AV Adj.
58 ORS 0~3 2 Over-shoot AV Adj.
59 DCREST 0~3 0 Select Luminance DC Restoration
60 RFCO 0~3 1 RF Coring Gain Difference
61 PRSN 0~3 0 Pre-shoot RF Adj.
62 ORSN 0~3 3 Over-shoot RF Adj.
63 CTRAP 0~7 4 Chroma Trap Control
64 CBPF 0~3 1 Chroma BPF Control
65 CBPFN 0~3 1 Chroma BPF Control NTSC
66 CBPFAVN 0~3 0 Chroma BPF Control AV NTSC
67 TINT -16~+15 +10 Tint RF
68 TINT443 -16~+15 -12 Tint (NTCS4.43)
69 SHRF -32~+31 -10 RF Sharpness
70 COL TEST 0, 1 1 Color Test
71 CODP -16~+15 -6 DVD PAL Color
72 CODN -16~+15 0 DVD NTSC Color
73 TINTDN -16~+15 0 DVD NTSC Tint
74 YTH 0~3 0 Select Y signal sensitivity for Blue Strect
75 YGAIN 0~3 0 Select Blue Stretching gain w/ defeat
76 RWIDTH 0~3 0 R Width
77 ROFFSET 0~3 0 R Offset
78 BWIDTH 0~3 0 B Width
79 BOFFSET 0~3 0 B Offset
80 VOLUM 0~127 127 Volume Control Adj.
81 DEEM 0, 1 0 De-emphasis TC
82 VIFSW 0~3 0 VIF System Switch
83 SIFSW 0~3 1 SIF System Switch
84 V-LVL 0~7 4 Video Level
85 V-LVLOFS 0~3 1 Video Level Offset
86 FMGAIN 0, 1 0 FM Gain
87 IFOM-S 0, 1 0 Over Modulation Switch
88 IFMN-S 0, 1 1 Audio Monitor Sw. Monitor or FM
89 IFTRPS 0, 1 1 IC inside SIF Trap Sw ON-OFF
90 IFMLVL 0~15 0 IF Over Modulation Level Adj.
SS_21-BA5VZ-01(AC6-A1)AUS 12/12/06 8:23 AM Page 2

-3-
Following table shows the initial values which have been stored in the CPU ROM, and items for the service adjustments.
Service mode adjustments table in CPU ROM
DATA INITIAL
No. ITEM RANGE SETUP DESCRIPTION
DATA
91 IFTEST1 0, 1 0 IF Test 1
92 TRAPT 0~7 4 Sound Trap-Test
93 H-FRQ 0~63 35 Horizontal Frequency
94 FBTS 0, 1 0 FBPBLK Switch
95 COOP 0~7 4 Color Killer Option
96 HBLKL 0~3 6 H-Blanking Control Left
97 HBLKR 0~3 2 H-Blanking Control Right
98 AFCRF 0, 1 0 RF AFC Gain & gate Adj.
99 VSURF 0, 1 0 RF VSync. Separation sensitivity
100 CDMRF 0~7 0 RF Vertical count down circuit Adj.
101 AFCAV 0, 1 0 AV AFC Gain & gate Adj.
102 VSUAV 0, 1 0 AV Vsync. Separation sensitivity
103 CDMAV 0~7 0 AV Vertical count down circuit Adj.
104 HLVDRF 0, 1 1 H Lock, V Det.
105 HLVDAV 0, 1 1 H Lock, V Det.
106 VTEST 0~3 0 Select Vertical DAC test mode
107 VCOTEST 0~15 8 IF VCO free run Freq. Adj.
108 C.VCOADJ 0~7 4 Control free run Freq. of Chroma VCO
109 VCOFREQ 0~255 40 ES Sample IF VCO Freq. Adj.
110 CROSS-BW 0~3 0 Pattern Output
111 AVNCON 0~127 64 AV non-signal Contrast
112 AVNBRI 0~127 64 AV non-signal Brightness
113 POMT 0~127 25 Power Mute Time
114 CHMT 0~31 7 Channel Change Mute Time Adj.
115 SYST 0~15 5 The number of times that a color sys-
tem AUTO is judged
116 S-STE 0~3 1 Stereo/Mono Option, 0=Mono,
1=Simple AV Stereo, 2,3=AV Stereo
117 VOLTBL 0, 1 1 Volume Table Select
118 MPP 0, 1 0 Multi Personal Preference function
on/off 0=without M.P.P., 1=with M.P.P.
119 TUNER 0, 1 0 Tuner Option
120 BOOSTER 0, 1 0 Booster Option
121 OPT AVIN 0~3 1 AV1/AV2/AV3 Option, 0=AVonly,
1=AV1,AV2, 2~3=AV1, AV2, AV3
122 OPT POS 0, 1 1 Programme number option, position
No. Option, 0=100 pos., 1=256 pos.
123 LANGUAGE 0, 1 1 Language Option, 0=without la-
nguage, 1=with language
124 OPT COL 0, 1 0 Color System Option
125 OPT SIF 0, 1 1 SIF System Option
126 OPT BASS 0~3 2 BASS Expander Option, 0=without BASS,
1~2=BASS EXPANDER, 3=WOOFER
127 OPT SURR 0, 1 1 Surround Option
128 OPT BLBK 0, 1 1 Blue Back Option
129 AUDGAIN 0~7 1 Gain Control LV1116
130 L/RGAIN 0~7 7 L/R Output Gain Control LV1116
Service Adjustments with Replacing Memory IC(IC801)
DATA INITIAL
No. ITEM RANGE SETUP DESCRIPTION
DATA
300 R18 0~255 3 ROM Correction
301 R19 0~255 53 ROM Correction
302 R20 0~255 5 ROM Correction
303 R21 0~255 193 ROM Correction
304 R22 0~255 167 ROM Correction
305 R23 0~255 153 ROM Correction
306 R24 0~255 9 ROM Correction
307 R25 0~255 44 ROM Correction
308 R26 0~255 15 ROM Correction
309 R27 0~255 19 ROM Correction
310 R28 0~255 2 ROM Correction
311 R29 0~255 136 ROM Correction
312 R30 0~255 224 ROM Correction
313 R31 0~255 3 ROM Correction
314 R32 0~255 33 ROM Correction
315 R33 0~255 3 ROM Correction
316 R34 0~255 55 ROM Correction
317 R35 0~255 33 ROM Correction
318 R36 0~255 3 ROM Correction
319 R37 0~255 66 ROM Correction
320 R38 0~255 0 ROM Correction
321 R39 0~255 0 ROM Correction
322 R40 0~255 0 ROM Correction
323 R41 0~255 0 ROM Correction
324 R42 0~255 34 ROM Correction
325 R43 0~255 153 ROM Correction
326 R44 0~255 100 ROM Correction
327 R45 0~255 33 ROM Correction
328 R46 0~255 167 ROM Correction
329 R47 0~255 137 ROM Correction
330 R48 0~255 0 ROM Correction
331 R49 0~255 0 ROM Correction
332 R50 0~255 0 ROM Correction
333 R51 0~255 0 ROM Correction
334 R52 0~255 0 ROM Correction
335 R53 0~255 0 ROM Correction
336 R54 0~255 0 ROM Correction
337 R55 0~255 0 ROM Correction
338 R56 0~255 0 ROM Correction
339 R57 0~255 0 ROM Correction
340 R58 0~255 0 ROM Correction
341 R59 0~255 341 ROM Correction
342 R60 0~255 224 ROM Correction
343 R61 0~255 4 ROM Correction
344 R62 0~255 223 ROM Correction
SS_21-BA5VZ-01(AC6-A1)AUS 12/12/06 8:23 AM Page 3

-4-
Service Adjustments with Replacing Memory IC(IC801)
DATA INITIAL
No. ITEM RANGE SETUP DESCRIPTION
DATA
345 R18 0~255 0 ROM Correction
346 R19 0~255 1 ROM Correction
347 R20 0~255 2 ROM Correction
348 R21 0~255 255 ROM Correction
349 R22 0~255 0 ROM Correction
350 R23 0~255 33 ROM Correction
351 R24 0~255 5 ROM Correction
352 R25 0~255 195 ROM Correction
353 R26 0~255 0 ROM Correction
354 R27 0~255 0 ROM Correction
355 R28 0~255 0 ROM Correction
356 R29 0~255 153 ROM Correction
357 R30 0~255 211 ROM Correction
358 R31 0~255 2 ROM Correction
359 R32 0~255 129 ROM Correction
360 R33 0~255 0 ROM Correction
361 R34 0~255 249 ROM Correction
362 R35 0~255 1 ROM Correction
363 R36 0~255 33 ROM Correction
364 R37 0~255 9 ROM Correction
365 R38 0~255 46 ROM Correction
366 R39 0~255 0 ROM Correction
367 R40 0~255 0 ROM Correction
368 R41 0~255 0 ROM Correction
369 R42 0~255 0 ROM Correction
370 R43 0~255 0 ROM Correction
371 R44 0~255 0 ROM Correction
372 R45 0~255 0 ROM Correction
373 R46 0~255 1 ROM Correction
374 R47 0~255 205 ROM Correction
375 R48 0~255 1 ROM Correction
376 R49 0~255 205 ROM Correction
377 R50 0~255 0 ROM Correction
SS_21-BA5VZ-01(AC6-A1)AUS 12/12/06 8:23 AM Page 4

-5-
BA5VZ
123
456
789
0
TV/AV
TIMER
x
-/--
SWAP
CH SCAN
MENU
BASS
SOUND
S. SYS
SURROUND
CH
CH
A B
.
PP
JXPSC
Cabinet Parts List
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
TV/AV MENU CH
- +
1 610 332 2247 BUTTON PW-BA5A
610 229 8406 SPRING-E3HA
(for power button)
2 610 314 4344 DEC.IND-C5ZJ
3 610 330 3499 BUTTON UNITED-BA4A
4 610 332 2261 ASSY,CABINET FR-BA5A
4-a 610 333 1812 CABINET FRONT-BA5A
4-b 610 330 3505 DOOR-BA4A
5 610 284 7741 DOOR COVER-C2SA
6 645 069 2185 BADGE,SANYO*43.5X10L43.5
7 610 323 4656 CABINET BACK-C7LJ
8 645 071 1145 ASSY,REMOCON JXPSC
or 652 002 0634 REMOCON,JXPSG
9 610 313 3393 RC-BATTERY LID-JXPLA
10 610 206 7842 BATTERY JXGA
or 645 000 6708 BATTERY,MANGAN,COMPOSITE
11 645 042 4519 ANTENNA,ROD
or 645 004 8616 ROD ANTENNA ASSY
or 645 004 8753 ANTENNA,ROD
12 645 003 2837 ANTENNA CONVERTER
or 652 001 2875 ANTENNA CONVERTER
or 610 230 3216 ANT MATCHING BOX
610 334 2382 INSTRUCTION MANUAL-C7MT-B
Key No. Part No. Description Key No. Part No. Description
8
9
1
2
3
4-a
ANT. 75Ω
MONITOR
OUT
INPUT
AV1 / DVD
AUDIO
CR
CB
VIDEOVIDEOS-VIDEO
AUDIO
R
L
R
L
Y
(MONO)
7
6
4-b
5
(+)
(-)
(+)
(-)
10
11
12
SS_21-BA5VZ-01(AC6-A1)AUS 12/12/06 8:23 AM Page 5

-6-
BA5VZ
OUT OF CIRCUIT BOARD
PICTURE TUBE
Q901 4140136902 CRT ASSY A51QDX993X001(A)
A100 4140137008 CRT A51QDX993X(A) (BARE)
A200 6450651472 YOKE,DEFLECTION
Q901-1 6450088674 MAGNET,CG.PR
6450867484 MAGNET,CG,PR
Q901-2A 6101170154 DY SPACER-D4AK
6102337891 DY SPACER E2HA
6102904154 DY SPACER-F8LZ
Q901-2B 6101170154 DY SPACER-D4AK
6102337891 DY SPACER E2HA
6102904154 DY SPACER-F8LZ
Q901-2C 6101170154 DY SPACER-D4AK
6102337891 DY SPACER E2HA
6102904154 DY SPACER-F8LZ
COIL
L901 6450837616 ASSY,COIL,DEGAUSSING
MISCELLANEOUS
SP901 6520018181 SPEAKER,8
SP902 6520018181 SPEAKER,8
W901 6450655111 CORD,POWER-2.4MK-A5003
6450646102 CORD,POWER-2.4MK-A5003
W902 6103112633 ASSY,WIRE GND CONNECTOR C
6103345987 ASSY,PWB MAIN BA5VZ
1AA0B10S244EA
TRANSISTOR
Q002 4051648016 TR KTA1504S-GR-RTK
4051345925 TR 2SA1037AK-T146-R
4051472215 TR 2SA1037AK-S-T146
4050020318 TR 2SA1037K T146 R
4050020417 TR 2SA1037K T146 S
4050026726 TR 2SA1179-M6-TB
4050026924 TR 2SA1179-M7-TB
4051631513 TR 2SA1179N-M6-TB
4051739615 TR 2SA1235A1E
4051739714 TR 2SA1235A1F
Q1001 4051648016 TR KTA1504S-GR-RTK
4051345925 TR 2SA1037AK-T146-R
4051472215 TR 2SA1037AK-S-T146
4050020318 TR 2SA1037K T146 R
4050020417 TR 2SA1037K T146 S
4050026726 TR 2SA1179-M6-TB
4050026924 TR 2SA1179-M7-TB
4051631513 TR 2SA1179N-M6-TB
4051739615 TR 2SA1235A1E
4051739714 TR 2SA1235A1F
Q1002 4051648016 TR KTA1504S-GR-RTK
4051345925 TR 2SA1037AK-T146-R
4051472215 TR 2SA1037AK-S-T146
!
!
!
!
!
Chassis Electrical Parts List
Ref. No. Part No. Description Ref. No. Part No. Description
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by a mark in this parts list and the circuit diagram show components whose value have
special significance to product safety. It is particularly recommended that only parts specified on the following parts
list be used for components replacement pointed out by the mark.
!
Note: Parts order must contain Chassis No., Part No., and descriptions. The main PCB unit will be supplied without tuner and
flyback transformer. They should be ordered separately.
Read description in the Capacitor and Resistor as follows:
CAPACITOR
CERAMIC 100P K 50V
Rated Voltage
Tolerance Symbols:
Less than 10pF
A : Not specified B : ±0.1pF C : ±0.25pF
D : ±0.5pF F : ±1PF G : ±2pF
R : ±0.25-0pF S : ±0-0.25pF E : +0-1pF
More than 10pF
A : Not specified B : ±0.1% C : ±0.25%
D : ±0.5% F : ±1% G : ±2%
H : ±3% J : ±5% K : ±10%
L : ±15% M : ±20% N : ±30%
P : +100-0% Q : +30-10% T : +50-10%
U : +75-10% V : +20-10% W : +100-10%
X : +40-20% Y : +150-10% Z : +80-20%
Rated value: P=pico farad, U=micro farad
Material:
CERAMIC........... Ceramic
MT-PAPER......... Metallized Paper
POLYESTER...... Polyester
MT-POLYEST.....Metallized Polyester
POLYPRO.......... Polypropylene
MT-POLYPRO....Metallized Polypropylene
COMPO FILM.....Composite film
MT-COMPO........Metallized Composite
STYRENE...........Styrene
TA-SOLID........... Tantalum Solid
AL-SOLID........... Aluminium Solid
ELECT................ Electrolytic
NP-ELECT..........Non-polarised Electrolytic
OS-SOLID.......... Aluminium Solid with Organic Semiconductive Electrolytic
DL-ELECT.......... Double Layered Electrolytic
RESISTOR
CARBON 4.7K J A 1/4W
Rated Wattage
Performance Symbols:
A: General B: Non flammable Z: Low noise
Other: Temperature coefficient
Tolerance Symbols:
A: ±0.05% B: ±0.1% C: ±0.25% D: ±0.5%
F: ±1% G: ±2% J: ±5% K: ±10%
M: ±20% P: +5-15%
Rated value, ohms:
K: 1,000, M: 1,000,000
Material:
CARBON........... Carbon
MT-FILM............ Metal Film
OXIDE-MT......... Oxide Metal Film
SOLID................ Composition
MT-GLAZE......... Metal Glaze
WIRE WOUND...Wire Wound
CERAMIC RES.. Ceramic
FUSIBLE RES....Fusible
NOTES:
P List-BA5VZ 12/12/06 7:56 AM Page 6

4050020318 TR 2SA1037K T146 R
4050020417 TR 2SA1037K T146 S
4050026726 TR 2SA1179-M6-TB
4050026924 TR 2SA1179-M7-TB
4051631513 TR 2SA1179N-M6-TB
4051739615 TR 2SA1235A1E
4051739714 TR 2SA1235A1F
Q1003 4051648016 TR KTA1504S-GR-RTK
4051345925 TR 2SA1037AK-T146-R
4051472215 TR 2SA1037AK-S-T146
4050020318 TR 2SA1037K T146 R
4050020417 TR 2SA1037K T146 S
4050026726 TR 2SA1179-M6-TB
4050026924 TR 2SA1179-M7-TB
4051631513 TR 2SA1179N-M6-TB
4051739615 TR 2SA1235A1E
4051739714 TR 2SA1235A1F
Q111 4052187712 TR KTC3879S-Y
4050159721 TR 2SC2814-F4-TB
Q122 4051648412 TR KTC3875S-GR-RTK
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q1902 4051413515 TR KTA1266-Y—T
4050017615 TR 2SA1015-Y(SAN)
4050061816 TR 2SA933S-R
Q402 4051648412 TR KTC3875S-GR-RTK
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q431 4050180517 TR 2SC3332-R
4050180616 TR 2SC3332-S
Q432 4060171908 TR TT2140LS-YB11
Q511 4051648412 TR KTC3875S-GR-RTK
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q631 4051648412 TR KTC3875S-GR-RTK
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q641 4051648412 TR KTC3875S-GR-RTK
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q661 4052144200 TR KTC2026-Y-U/P
4050599903 TR 2SD1913-R-RA
4050600005 TR 2SD1913-S-RA
Q681 4051413317 TR KTC3198-GR-T
4050118411 TR 2SC1740S-Q
4050118510 TR 2SC1740S-R
4050118619 TR 2SC1740S-S
4050122012 TR 2SC1815-GR
4050122111 TR 2SC1815-O
4050207511 TR 2SC945A-PA
4050207719 TR 2SC945A-QA
4050207917 TR 2SC945A-RA
Q683 4050890010 TR 2SA1707-S
4050890119 TR 2SA1707-T
4050096917 TR 2SB985-S
4050097013 TR 2SB985-T
Q684 4051413317 TR KTC3198-GR-T
4050118411 TR 2SC1740S-Q
4050118510 TR 2SC1740S-R
4050118619 TR 2SC1740S-S
4050122012 TR 2SC1815-GR
4050122111 TR 2SC1815-O
4050207511 TR 2SC945A-PA
4050207719 TR 2SC945A-QA
4050207917 TR 2SC945A-RA
Q886 4051648412 TR KTC3875S-GR-RTK
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC001 4096563510 IC LA42032-E
IC201 4105869401 IC LA76931AD56S1-E
IC202 4092415407 IC BA178M05T
4094636701 IC KIA7805API
4092654806 IC L78M05CV
IC3701 4095922734 IC LV1116NV-TLM-E
IC501 4094494103 IC LA78040
4095070900 IC LA78040N
IC601 4106062108 IC STR-W6753(LF2003
IC651 4092415407 IC BA178M05T
4094636701 IC KIA7805API
4092654806 IC L78M05CV
IC801 4096760701 IC LE24C161-E-C
4104958007 IC AT24C16A-10PU-2.7
4094594506 IC 24LC16B/P
CAPACITOR
C001 4041087006 ELECT 2200U M 25V
4040886600 ELECT 2200U M 25V
4031943840 ELECT 2200U M 25V
C002 4040968504 ELECT 10U M 50V
4040848905 ELECT 10U M 50V
4031957748 ELECT 10U M 50V
C003 4031577213 CERAMIC 3900P K 50V
C004 4033423310 CERAMIC 0.1U K 25V
4031640214 CERAMIC 0.1U Z 25V
C005 4033423310 CERAMIC 0.1U K 25V
4031640214 CERAMIC 0.1U Z 25V
C006 4031577213 CERAMIC 3900P K 50V
C007 4033670417 CERAMIC 0.1U K 50V
C008 4033670417 CERAMIC 0.1U K 50V
C009 4033670417 CERAMIC 0.1U K 50V
C010 4033670417 CERAMIC 0.1U K 50V
C011 4040968504 ELECT 10U M 50V
-7-
BA5VZ
Ref. No. Part No. Description Ref. No. Part No. Description
P List-BA5VZ 12/12/06 7:56 AM Page 7

-8-
BA5VZ
4040848905 ELECT 10U M 50V
4031957748 ELECT 10U M 50V
C013 4041087709 ELECT 220U M 50V
4040875505 ELECT 220U M 50V
4032001935 ELECT 220U M 50V
C1001 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C1002 4040968504 ELECT 10U M 50V
4040848905 ELECT 10U M 50V
4031957748 ELECT 10U M 50V
C1003 4040968504 ELECT 10U M 50V
4040848905 ELECT 10U M 50V
4031957748 ELECT 10U M 50V
C1004 4040968504 ELECT 10U M 50V
4040848905 ELECT 10U M 50V
4031957748 ELECT 10U M 50V
C1005 4040968504 ELECT 10U M 50V
4040848905 ELECT 10U M 50V
4031957748 ELECT 10U M 50V
C1006 4040971900 ELECT 220U M 16V
4040848004 ELECT 220U M 16V
4032006722 ELECT 220U M 16V
C1007 4040968504 ELECT 10U M 50V
4040848905 ELECT 10U M 50V
4031957748 ELECT 10U M 50V
C1008 4040968504 ELECT 10U M 50V
4040848905 ELECT 10U M 50V
4031957748 ELECT 10U M 50V
C1009 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C101 4041072002 ELECT 470U M 16V
4040848301 ELECT 470U M 16V
4031768621 ELECT 470U M 16V
C1010 4033670417 CERAMIC 0.1U K 50V
C1011 4033670417 CERAMIC 0.1U K 50V
C1012 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C104 4040973508 ELECT 47U M 50V
4040849308 ELECT 47U M 50V
4032001727 ELECT 47U M 50V
C105 4030749512 CERAMIC 680P K 50V
4031576810 CERAMIC 680P K 50V
C106 4040973102 ELECT 22U M 50V
4040875406 ELECT 22U M 50V
4032001529 ELECT 22U M 50V
C111 4032152211 CERAMIC 0.01U K 50V
C112 4032152211 CERAMIC 0.01U K 50V
C114 4032152211 CERAMIC 0.01U K 50V
C120 4032844314 CERAMIC 0.022U K 50V
C121 4032152211 CERAMIC 0.01U K 50V
C122 4040971702 ELECT 100U M 16V
4040847809 ELECT 100U M 16V
4031957837 ELECT 100U M 16V
C123 4011506011 MT-GLAZE 0.000 ZA 1/10W
4011057919 MT-GLAZE 0.000 ZA 1/16W
C132 4033363517 CERAMIC 0.47U K 16V
C138 4032844314 CERAMIC 0.022U K 50V
C171 4031552111 CERAMIC 1500P K 50V
C172 4032152211 CERAMIC 0.01U K 50V
C174 4031571914 CERAMIC 10P D 50V
C176 4011506011 MT-GLAZE 0.000 ZA 1/10W
4011057919 MT-GLAZE 0.000 ZA 1/16W
C1902 4040973102 ELECT 22U M 50V
4040875406 ELECT 22U M 50V
4032001529 ELECT 22U M 50V
C202 4031793217 POLYESTER 0.015U J 50V
C203 4032152211 CERAMIC 0.01U K 50V
C204 4040968306 ELECT 100U M 25V
4040897200 ELECT 100U M 25V
4031957936 ELECT 100U M 25V
C210 4040968306 ELECT 100U M 25V
4040897200 ELECT 100U M 25V
4031957936 ELECT 100U M 25V
C212 4031397316 CERAMIC 18P J 50V
C215 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C223 4031792517 POLYESTER 0.022U J 50V
4031792418 POLYESTER 0.022U K 50V
C224 4032789011 CERAMIC 0.027U K 25V
4032456517 CERAMIC 0.027U K 50V
C225 4040972709 ELECT 0.47U M 50V
4040848707 ELECT 0.47U M 50V
4032002625 ELECT 0.47U M 50V
C226 4040972709 ELECT 0.47U M 50V
4040848707 ELECT 0.47U M 50V
4032002625 ELECT 0.47U M 50V
C230 4032152211 CERAMIC 0.01U K 50V
C231 4030677815 MT-COMPO 0.47U J 50V
4032560848 MT-COMPO 0.47U J 50V
C232 4032152211 CERAMIC 0.01U K 50V
C233 4041072101 ELECT 10U M 25V
4040871507 ELECT 10U M 25V
C234 4032152211 CERAMIC 0.01U K 50V
C236 4011506011 MT-GLAZE 0.000 ZA 1/10W
4011057919 MT-GLAZE 0.000 ZA 1/16W
C243 4032152211 CERAMIC 0.01U K 50V
C244 4040971900 ELECT 220U M 16V
4040848004 ELECT 220U M 16V
4032006722 ELECT 220U M 16V
C245 4032070317 CERAMIC 1U Z 16V
4032789615 CERAMIC 1U Z 16V
C247 4040972907 ELECT 2.2U M 50V
4040849001 ELECT 2.2U M 50V
4032001222 ELECT 2.2U M 50V
C273 4033423310 CERAMIC 0.1U K 25V
C291 4040968207 ELECT 47U M 16V
4040848202 ELECT 47U M 16V
4032006623 ELECT 47U M 16V
C356 4031032257 CERAMIC 100P K 50V
4034162921 CERAMIC 100P K 50V
C358 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C3701 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C3702 4040973300 ELECT 4.7U M 50V
4040849209 ELECT 4.7U M 50V
4032001420 ELECT 4.7U M 50V
C3703 4031552418 CERAMIC 5600P K 50V
C3704 4032152211 CERAMIC 0.01U K 50V
C3705 4031576919 CERAMIC 820P K 50V
C3706 4033082111 CERAMIC 0.056U K 16V
4033565218 CERAMIC 0.056U K 50V
C3707 4033082111 CERAMIC 0.056U K 16V
4033565218 CERAMIC 0.056U K 50V
C3708 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C3710 4040968405 ELECT 1U M 50V
Ref. No. Part No. Description Ref. No. Part No. Description
P List-BA5VZ 12/12/06 7:56 AM Page 8

4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C3711 4040973300 ELECT 4.7U M 50V
4040849209 ELECT 4.7U M 50V
4032001420 ELECT 4.7U M 50V
C3712 4041086207 ELECT 2200U M 16V
4040936909 ELECT 2200U M 16V
4031937443 ELECT 2200U M 16V
C3713 4040973300 ELECT 4.7U M 50V
4040849209 ELECT 4.7U M 50V
4032001420 ELECT 4.7U M 50V
C3714 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C3715 4040973300 ELECT 4.7U M 50V
4040849209 ELECT 4.7U M 50V
4032001420 ELECT 4.7U M 50V
C3716 4040973300 ELECT 4.7U M 50V
4040849209 ELECT 4.7U M 50V
4032001420 ELECT 4.7U M 50V
C3717 4030750449 CERAMIC 6800P K 50V
C3718 4033423310 CERAMIC 0.1U K 25V
C3719 4031576919 CERAMIC 820P K 50V
C3720 4033082111 CERAMIC 0.056U K 16V
4033565218 CERAMIC 0.056U K 50V
C3721 4033082111 CERAMIC 0.056U K 16V
4033565218 CERAMIC 0.056U K 50V
C3722 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C3724 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C402 4040973102 ELECT 22U M 50V
4040875406 ELECT 22U M 50V
4032001529 ELECT 22U M 50V
C431 4030677815 MT-COMPO 0.47U J 50V
4032560848 MT-COMPO 0.47U J 50V
C432 4031149519 CERAMIC 1000P K 500V
4034171814 CERAMIC 1000P K 500V
C433 4032753329 CERAMIC 3900P K 500V
4034172910 CERAMIC 3900P K 500V
C434 4041087303 ELECT 330U M 35V
4041075508 ELECT 330U M 35V
4032003632 ELECT 330U M 35V
C435 4041020003 MT-POLYPRO 6500P H 1.5V
4033534214 MT-POLYPRO 6500P H 1.5K
C436 4033242327 CERAMIC 270P K 3K
4032690416 CERAMIC 270P K 3K
4034141015 CERAMIC 270P K 3K
C437 4030677815 MT-COMPO 0.47U J 50V
4032560848 MT-COMPO 0.47U J 50V
C438 4033242327 CERAMIC 270P K 3K
4032690416 CERAMIC 270P K 3K
4034141015 CERAMIC 270P K 3K
C441 4033493214 MT-POLYPRO 0.3U J 250V
4033726916 MT-POLYPRO 0.3U J 250V
C469 4040968504 ELECT 10U M 50V
4040848905 ELECT 10U M 50V
4031957748 ELECT 10U M 50V
C471 4040565208 NP-ELECT 2.2U M 100V
4041089000 NP-ELECT 2.2U M 100V
4040849902 NP-ELECT 2.2U M 100V
4034336817 NP-ELECT 2.2U M 100V
C486 4040968900 ELECT 22U M 100V
4040876106 ELECT 22U M 100V
4032109423 ELECT 22U M 100V
C491 4034164915 CERAMIC 680P K 500V
4034173115 CERAMIC 680P K 500V
C510 4032114516 ELECT 22U M 50V
C511 4032113519 ELECT 10U M 50V
C514 4032118019 ELECT 4.7U M 50V
C515 4031904722 ELECT 1000U M 25V
C517 4032114427 ELECT 220U M 35V
C518 4031041922 CERAMIC 3300P K 50V
4034171111 CERAMIC 3300P K 50V
C521 4032112532 ELECT 1000U M 35V
C524 4030641212 POLYESTER 0.1U K 100V
4032769726 POLYESTER 0.1U K 100V
C525 4031573611 CERAMIC 100P J 50V
C601 4040725909 MT-POLYEST 0.22U M 250V
4040881704 MT-POLYEST 0.22U K 250V
4040662204 MT-POLYEST 0.22U M 275V
4040888802 MT-POLYEST 0.22U M 275V
C602 4040796503 MT-POLYEST 0.068U M 250V
4040737506 MT-POLYEST 0.068U M 275V
4040920700 MT-POLYEST 0.068U M 275V
C603 4040846307 CERAMIC 1000P K 1K
4030766707 CERAMIC 1000P K 1K
4033990911 CERAMIC 1000P K 1K
C604 4040846307 CERAMIC 1000P K 1K
4030766707 CERAMIC 1000P K 1K
4033990911 CERAMIC 1000P K 1K
C605 4031576711 CERAMIC 560P K 50V
C609 4041048304 ELECT 220U M 400V
4041107100 ELECT 150U M 400V
C610 4031793712 POLYESTER 1200P J 50V
C611 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C612 4030572130 POLYESTER 0.1U J 50V
4031818316 POLYESTER 0.1U J 50V
C613 4040904601 POLYESTER 2200P K 63V
4030593046 POLYESTER 2200P J 50V
4031792715 POLYESTER 2200P J 50V
C615 4040968702 ELECT 47U M 35V
4040876007 ELECT 47U M 35V
4032003424 ELECT 47U M 35V
C616 4041119707 CERAMIC 470P K 2K
4040862109 CERAMIC 470P K 2K
4032454404 CERAMIC 470P K 2K
4032758106 CERAMIC 470P K 2K
4034140414 CERAMIC 470P K 2K
C627 4040733904 CERAMIC 1000P K 250V
4040732105 CERAMIC 1000P M 250V
4040713302 CERAMIC 1000P M 400V
4040978503 CERAMIC 1000P K 400V
4041039104 CERAMIC 1000P M 400V
C628 4040733904 CERAMIC 1000P K 250V
4040732105 CERAMIC 1000P M 250V
4040713302 CERAMIC 1000P M 400V
4040978503 CERAMIC 1000P K 400V
4041039104 CERAMIC 1000P M 400V
C629 4040733904 CERAMIC 1000P K 250V
4040732105 CERAMIC 1000P M 250V
4040713302 CERAMIC 1000P M 400V
4040978503 CERAMIC 1000P K 400V
4041039104 CERAMIC 1000P M 400V
C631 4041082902 CERAMIC 1500P K 1K
4032384107 CERAMIC 1500P K 1K
4033316444 CERAMIC 1500P K 1K
4033316404 CERAMIC 1500P K 1K
4033991215 CERAMIC 1500P K 1K
C632 4032475023 CERAMIC 470P K 1K
!
!
!
!
!
-9-
BA5VZ
Ref. No. Part No. Description Ref. No. Part No. Description
P List-BA5VZ 12/12/06 7:56 AM Page 9

-10-
BA5VZ
4034084510 CERAMIC 470P K 1K
4034084510 CERAMIC 470P K 1K
C633 4032475023 CERAMIC 470P K 1K
4034084510 CERAMIC 470P K 1K
4034084510 CERAMIC 470P K 1K
C634 4032475023 CERAMIC 470P K 1K
4034084510 CERAMIC 470P K 1K
4034084510 CERAMIC 470P K 1K
C641 4040739005 ELECT 220U M 160V
4040973706 ELECT 220U M 160V
C643 4032119620 ELECT 470U M 35V
C644 4031904722 ELECT 1000U M 25V
C645 4032115127 ELECT 2200U M 50V
C650 4032115919 ELECT 3.3U M 50V
C651 4041071906 ELECT 470U M 10V
4040847601 ELECT 470U M 10V
4032008221 ELECT 470U M 10V
C661 4032113519 ELECT 10U M 50V
C662 4032112918 ELECT 100U M 16V
C691 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C801 4031397316 CERAMIC 18P J 50V
C802 4031397316 CERAMIC 18P J 50V
C803 4032152211 CERAMIC 0.01U K 50V
C805 4040968306 ELECT 100U M 25V
4040897200 ELECT 100U M 25V
4031957936 ELECT 100U M 25V
C842 4033423310 CERAMIC 0.1U K 25V
C843 4033423310 CERAMIC 0.1U K 25V
C863 4040968405 ELECT 1U M 50V
4040848806 ELECT 1U M 50V
4032001123 ELECT 1U M 50V
C893 4040972907 ELECT 2.2U M 50V
4040849001 ELECT 2.2U M 50V
4032001222 ELECT 2.2U M 50V
C894 4032815017 CERAMIC 0.033U K 25V
RESISTOR
R001 4012560418 MT-GLAZE 12K JA 1/10W
4011051115 MT-GLAZE 12K JA 1/16W
R002 4012560418 MT-GLAZE 12K JA 1/10W
4011051115 MT-GLAZE 12K JA 1/16W
R003 4011623114 MT-GLAZE 3.3K JA 1/10W
4011054116 MT-GLAZE 3.3K JA 1/16W
R004 4011623114 MT-GLAZE 3.3K JA 1/10W
4011054116 MT-GLAZE 3.3K JA 1/16W
R005 4011623015 MT-GLAZE 22K JA 1/10W
4011052914 MT-GLAZE 22K JA 1/16W
R007 4010247034 CARBON 1K JA 1/6W
R008 4011506011 MT-GLAZE 0.000 ZA 1/10W
4011057919 MT-GLAZE 0.000 ZA 1/16W
R009 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R010 4010255435 CARBON 2.2 JA 1/6W
R011 4010255435 CARBON 2.2 JA 1/6W
R012 4010255435 CARBON 2.2 JA 1/6W
R013 4010255435 CARBON 2.2 JA 1/6W
R014 4011506110 MT-GLAZE 2.2K JA 1/10W
4011052815 MT-GLAZE 2.2K JA 1/16W
R015 4011505915 MT-GLAZE 10K JA 1/10W
4011050613 MT-GLAZE 10K JA 1/16W
R1001 4012562719 MT-GLAZE 75 JA 1/10W
4011134412 MT-GLAZE 75 JA 1/16W
R1002 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R1003 4012567219 MT-GLAZE 18K JA 1/10W
4011052112 MT-GLAZE 18K JA 1/16W
R1004 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R1005 4012567219 MT-GLAZE 18K JA 1/10W
4011052112 MT-GLAZE 18K JA 1/16W
R1006 4012566915 MT-GLAZE 680 JA 1/10W
4011056516 MT-GLAZE 680 JA 1/16W
R1007 4011505816 MT-GLAZE 100K JA 1/10W
4011050712 MT-GLAZE 100K JA 1/16W
R1008 4012566915 MT-GLAZE 680 JA 1/10W
4011056516 MT-GLAZE 680 JA 1/16W
R1009 4011505816 MT-GLAZE 100K JA 1/10W
4011050712 MT-GLAZE 100K JA 1/16W
R101 4011506011 MT-GLAZE 0.000 ZA 1/10W
4011057919 MT-GLAZE 0.000 ZA 1/16W
R1010 4012562719 MT-GLAZE 75 JA 1/10W
4011134412 MT-GLAZE 75 JA 1/16W
R1011 4011505816 MT-GLAZE 100K JA 1/10W
4011050712 MT-GLAZE 100K JA 1/16W
R1012 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R1013 4012567219 MT-GLAZE 18K JA 1/10W
4011052112 MT-GLAZE 18K JA 1/16W
R1014 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R1015 4012567219 MT-GLAZE 18K JA 1/10W
4011052112 MT-GLAZE 18K JA 1/16W
R1016 4012562719 MT-GLAZE 75 JA 1/10W
4011134412 MT-GLAZE 75 JA 1/16W
R1017 4011506011 MT-GLAZE 0.000 ZA 1/10W
4011057919 MT-GLAZE 0.000 ZA 1/16W
R1018 4012562719 MT-GLAZE 75 JA 1/10W
4011134412 MT-GLAZE 75 JA 1/16W
R1019 4011506011 MT-GLAZE 0.000 ZA 1/10W
4011057919 MT-GLAZE 0.000 ZA 1/16W
R1020 4012562719 MT-GLAZE 75 JA 1/10W
4011134412 MT-GLAZE 75 JA 1/16W
R1021 4012562719 MT-GLAZE 75 JA 1/10W
4011134412 MT-GLAZE 75 JA 1/16W
R1026 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R1027 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R1028 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R1029 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R103 4010618111 OXIDE-MT 39K JA 1W
R1030 4012567516 MT-GLAZE 390 JA 1/10W
4011054512 MT-GLAZE 390 JA 1/16W
R1031 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R106 4010246730 CARBON 100 JA 1/6W
R107 4010246730 CARBON 100 JA 1/6W
R108 4012567219 MT-GLAZE 18K JA 1/10W
4011052112 MT-GLAZE 18K JA 1/16W
R109 4012566618 MT-GLAZE 68K JA 1/10W
4011058213 MT-GLAZE 68K JA 1/16W
R111 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R112 4011624111 MT-GLAZE 5.6K JA 1/10W
4011056011 MT-GLAZE 5.6K JA 1/16W
R114 4011523216 MT-GLAZE 330 JA 1/10W
4011054017 MT-GLAZE 330 JA 1/16W
R115 4010272135 CARBON 56 JA 1/6W
R116 4012564119 MT-GLAZE 56 JA 1/10W
4011055816 MT-GLAZE 56 JA 1/16W
Ref. No. Part No. Description Ref. No. Part No. Description
P List-BA5VZ 12/12/06 7:56 AM Page 10

R121 4012567318 MT-GLAZE 6.8K JA 1/10W
4011056615 MT-GLAZE 6.8K JA 1/16W
R122 4011506110 MT-GLAZE 2.2K JA 1/10W
4011052815 MT-GLAZE 2.2K JA 1/16W
R124 4011505915 MT-GLAZE 10K JA 1/10W
4011050613 MT-GLAZE 10K JA 1/16W
R125 4012566014 MT-GLAZE 27K JA 1/10W
4011053416 MT-GLAZE 27K JA 1/16W
R130 4011506011 MT-GLAZE 0.000 ZA 1/10W
4011057919 MT-GLAZE 0.000 ZA 1/16W
R132 4011623619 MT-GLAZE 470 JA 1/10W
4011055212 MT-GLAZE 470 JA 1/16W
R140 4011624012 MT-GLAZE 560 JA 1/10W
4011055915 MT-GLAZE 560 JA 1/16W
R141 4011624012 MT-GLAZE 560 JA 1/10W
4011055915 MT-GLAZE 560 JA 1/16W
R176 4011505915 MT-GLAZE 10K JA 1/10W
4011050613 MT-GLAZE 10K JA 1/16W
R1902 4012560418 MT-GLAZE 12K JA 1/10W
4011051115 MT-GLAZE 12K JA 1/16W
R1903 4011624111 MT-GLAZE 5.6K JA 1/10W
4011056011 MT-GLAZE 5.6K JA 1/16W
R1904 4012567615 MT-GLAZE 3.9K JA 1/10W
4011054611 MT-GLAZE 3.9K JA 1/16W
R1905 4011506110 MT-GLAZE 2.2K JA 1/10W
4011052815 MT-GLAZE 2.2K JA 1/16W
R1906 4011622810 MT-GLAZE 1.8K JA 1/10W
4011052013 MT-GLAZE 1.8K JA 1/16W
R1907 4010246730 CARBON 100 JA 1/6W
R1911 4011622919 MT-GLAZE 220 JA 1/10W
4011052716 MT-GLAZE 220 JA 1/16W
R1912 4011622919 MT-GLAZE 220 JA 1/10W
4011052716 MT-GLAZE 220 JA 1/16W
R1913 4011622919 MT-GLAZE 220 JA 1/10W
4011052716 MT-GLAZE 220 JA 1/16W
R209 4012556510 MT-GLAZE 100 JA 1/10W
4011050415 MT-GLAZE 100 JA 1/16W
R210 4012556411 MT-GLAZE 3K JA 1/10W
4011053713 MT-GLAZE 3K JA 1/16W
R211 4010251338 CARBON 150 JA 1/6W
R212 4010251338 CARBON 150 JA 1/6W
R223 4010247034 CARBON 1K JA 1/6W
R225 4012560418 MT-GLAZE 12K JA 1/10W
4011051115 MT-GLAZE 12K JA 1/16W
R226 4012566014 MT-GLAZE 27K JA 1/10W
4011053416 MT-GLAZE 27K JA 1/16W
R227 4012561712 MT-GLAZE 33K JA 1/10W
4011054215 MT-GLAZE 33K JA 1/16W
R228 4010254933 CARBON 180K JA 1/6W
R229 4012567110 MT-GLAZE 680K JA 1/10W
4011056714 MT-GLAZE 680K JA 1/16W
R230 4010269333 CARBON 47 JA 1/6W
R231 4011622810 MT-GLAZE 1.8K JA 1/10W
4011052013 MT-GLAZE 1.8K JA 1/16W
R232 4011622810 MT-GLAZE 1.8K JA 1/10W
4011052013 MT-GLAZE 1.8K JA 1/16W
R233 4011622810 MT-GLAZE 1.8K JA 1/10W
4011052013 MT-GLAZE 1.8K JA 1/16W
R234 4012560012 MT-GLAZE 120 JA 1/10W
4011050910 MT-GLAZE 120 JA 1/16W
R235 4012560012 MT-GLAZE 120 JA 1/10W
4011050910 MT-GLAZE 120 JA 1/16W
R236 4012560012 MT-GLAZE 120 JA 1/10W
4011050910 MT-GLAZE 120 JA 1/16W
R243 4010679211 OXIDE-MT 390 JA 2W
R244 4012566311 MT-GLAZE 47K JA 1/10W
4011055410 MT-GLAZE 47K JA 1/16W
R245 4012566311 MT-GLAZE 47K JA 1/10W
4011055410 MT-GLAZE 47K JA 1/16W
R246 4012556510 MT-GLAZE 100 JA 1/10W
4011050415 MT-GLAZE 100 JA 1/16W
R251 4012556510 MT-GLAZE 100 JA 1/10W
4011050415 MT-GLAZE 100 JA 1/16W
R280 4010246730 CARBON 100 JA 1/6W
R286 4012651710 MT-GLAZE 4.7K FA 1/10W
4012039914 MT-GLAZE 4.7K FA 1/16W
R290 4010681610 OXIDE-MT 4.7 JA 2W
R340 4012559719 MT-GLAZE 82K JA 1/10W
4011057513 MT-GLAZE 82K JA 1/16W
R351 4010256531 CARBON 20K JA 1/6W
R352 4010126953 CARBON 10K JA 1/4W
4010127059 CARBON 10K JA 1/4W
R355 4010153751 CARBON 18K JA 1/4W
4010153850 CARBON 18K JA 1/4W
R357 4010267032 CARBON 3.9K JA 1/6W
R358 4011506011 MT-GLAZE 0.000 ZA 1/10W
4011057919 MT-GLAZE 0.000 ZA 1/16W
R3701 4012567318 MT-GLAZE 6.8K JA 1/10W
4011056615 MT-GLAZE 6.8K JA 1/16W
R3702 4012567318 MT-GLAZE 6.8K JA 1/10W
4011056615 MT-GLAZE 6.8K JA 1/16W
R3704 4010257439 CARBON 220 JA 1/6W
R3705 4010257439 CARBON 220 JA 1/6W
R401 4010200752 CARBON 470 JA 1/4W
4010200851 CARBON 470 JA 1/4W
R422 4010233651 CARBON 82K JA 1/4W
4010233750 CARBON 82K JA 1/4W
R423 4010184834 CARBON 33K JA 1/4W
4010184943 CARBON 33K JA 1/4W
R424 4010247034 CARBON 1K JA 1/6W
R426 4010247440 CARBON 10K JA 1/6W
R430 4010269630 CARBON 470 JA 1/6W
R431 4010247034 CARBON 1K JA 1/6W
R433 4010071134 CARBON 1K JA 1/2W
R434 4010602714 OXIDE-MT 220 JA 1W
R435 4020803702 OXIDE-MT 6.8 JB 7W
R441 4010693712 OXIDE-MT 6.8K JA 2W
R445 4010648712 OXIDE-MT 1K JA 2W
R475 4010095843 CARBON 330 JA 1/2W
R479 4010257835 CARBON 2.2K JA 1/6W
R481 4010663715 OXIDE-MT 2.7 JA 2W
R488 4010573113 OXIDE-MT 0.22 JA 1W
R501A 4010648712 OXIDE-MT 1K JA 2W
R502 4012565314 MT-GLAZE 56K JA 1/10W
4011058114 MT-GLAZE 56K JA 1/16W
R510 4010247440 CARBON 10K JA 1/6W
R511 4010247440 CARBON 10K JA 1/6W
R514 4010534728 MT-FILM 6.8K FA 1/6W
R515 4010254636 CARBON 18K JA 1/6W
R516 4010278632 CARBON 8.2K JA 1/6W
R518 4010578019 OXIDE-MT 1 JA 1W
R522 4010257439 CARBON 220 JA 1/6W
R525 4010582511 OXIDE-MT 100 JA 1W
R602 4020998200 WIRE WOUND 1.8 KA 10W
R603 4011113110 OXIDE-MT 0.82 JA 2W
R604 4010643816 OXIDE-MT 1 JA 2W
R607 4010246433 CARBON 10 JA 1/6W
R609 4010246730 CARBON 100 JA 1/6W
R610 4010247034 CARBON 1K JA 1/6W
R611 4010247034 CARBON 1K JA 1/6W
R613 4010088627 CARBON 220K JA 1/2W
R614 4010082615 CARBON 180K JA 1/2W
R631 4020008602 SOLID 5.6M KA 1/2W
4020976604 CARBON 5.6M KA 1/2W
!
-11-
BA5VZ
Ref. No. Part No. Description Ref. No. Part No. Description
P List-BA5VZ 12/12/06 7:56 AM Page 11

-12-
BA5VZ
R632TM 4020008602 SOLID 5.6M KA 1/2W
4020976604 CARBON 5.6M KA 1/2W
R635 4010075815 CARBON 120K JA 1/2W
R636 4011624111 MT-GLAZE 5.6K JA 1/10W
4011056011 MT-GLAZE 5.6K JA 1/16W
R640 4011505816 MT-GLAZE 100K JA 1/10W
4011050712 MT-GLAZE 100K JA 1/16W
R641 4012567318 MT-GLAZE 6.8K JA 1/10W
4011056615 MT-GLAZE 6.8K JA 1/16W
R642 4010247737 CARBON 100K JA 1/6W
R643 4010708010 OXIDE-MT 12 JA 3W
R644 4012691518 OXIDE-MT 0.56 JA 2W
R645 4010251932 CARBON 15K JA 1/6W
R661 4010602714 OXIDE-MT 220 JA 1W
R667 4010084421 CARBON 2.7 JA 1/2W
R668 4010673110 OXIDE-MT 3.9 JA 2W
R681 4010247034 CARBON 1K JA 1/6W
R685 4010145132 CARBON 15K JA 1/4W
4010145251 CARBON 15K JA 1/4W
R686 4010126953 CARBON 10K JA 1/4W
4010127059 CARBON 10K JA 1/4W
R687 4010191852 CARBON 3.9K JA 1/4W
4010191951 CARBON 3.9K JA 1/4W
R688 4010258238 CARBON 22K JA 1/6W
R689 4010273231 CARBON 560K JA 1/6W
R691 4010191852 CARBON 3.9K JA 1/4W
4010191951 CARBON 3.9K JA 1/4W
R801 4012565819 MT-GLAZE 270K JA 1/10W
4011053515 MT-GLAZE 270K JA 1/16W
R813 4011505915 MT-GLAZE 10K JA 1/10W
4011050613 MT-GLAZE 10K JA 1/16W
R814 4011505915 MT-GLAZE 10K JA 1/10W
4011050613 MT-GLAZE 10K JA 1/16W
R815 4011505915 MT-GLAZE 10K JA 1/10W
4011050613 MT-GLAZE 10K JA 1/16W
R817 4010247034 CARBON 1K JA 1/6W
R818 4010247034 CARBON 1K JA 1/6W
R819 4011505915 MT-GLAZE 10K JA 1/10W
4011050613 MT-GLAZE 10K JA 1/16W
R830 4011506219 MT-GLAZE 1K JA 1/10W
4011050514 MT-GLAZE 1K JA 1/16W
R834 4011505915 MT-GLAZE 10K JA 1/10W
4011050613 MT-GLAZE 10K JA 1/16W
R837 4012563617 MT-GLAZE 15K JA 1/10W
4011051610 MT-GLAZE 15K JA 1/16W
R838 4012563617 MT-GLAZE 15K JA 1/10W
4011051610 MT-GLAZE 15K JA 1/16W
R839 4012556510 MT-GLAZE 100 JA 1/10W
4011050415 MT-GLAZE 100 JA 1/16W
R840 4010269630 CARBON 470 JA 1/6W
R841 4011623718 MT-GLAZE 4.7K JA 1/10W
4011055311 MT-GLAZE 4.7K JA 1/16W
R842 4011623718 MT-GLAZE 4.7K JA 1/10W
4011055311 MT-GLAZE 4.7K JA 1/16W
R844 4012556510 MT-GLAZE 100 JA 1/10W
4011050415 MT-GLAZE 100 JA 1/16W
R845 4010247440 CARBON 10K JA 1/6W
R850 4012556510 MT-GLAZE 100 JA 1/10W
4011050415 MT-GLAZE 100 JA 1/16W
R852 4011505915 MT-GLAZE 10K JA 1/10W
4011050613 MT-GLAZE 10K JA 1/16W
R853 4011505915 MT-GLAZE 10K JA 1/10W
4011050613 MT-GLAZE 10K JA 1/16W
R863 4012566311 MT-GLAZE 47K JA 1/10W
4011055410 MT-GLAZE 47K JA 1/16W
R886 4011623015 MT-GLAZE 22K JA 1/10W
4011052914 MT-GLAZE 22K JA 1/16W
R887 4010258238 CARBON 22K JA 1/6W
R888 4011624012 MT-GLAZE 560 JA 1/10W
4011055915 MT-GLAZE 560 JA 1/16W
R893 4012556015 MT-GLAZE 1M JA 1/10W
4011058015 MT-GLAZE 1M JA 1/16W
R894 4012556510 MT-GLAZE 100 JA 1/10W
4011050415 MT-GLAZE 100 JA 1/16W
VARIABLE RESISTOR
VR631 6450065514 VR,SEMI,2.2K N
6450035579 VR,SEMI,2.2K N
TRANSFORMER
T431 6450833847 TRANS,DRIVE
6520011144 TRANS,DRIVE
T471 6520018303 TRANS,FLYBACK
T611 6450862595 TRANS,POWER,PULSE
COIL
L201 6101975711 CUTTING WIRE
L204 6101975711 CUTTING WIRE
L431 6450187025 CORE,PIPE
6520010475 PIPE CORE
L432 6450187025 CORE,PIPE
6520010475 PIPE CORE
L441 6520010581 COIL,LINEARITY
L601 6450193873 LINE FILTER
6520001961 LINE FILTER
L602 6100785946 PIPE CORE
6100785953 PIPE CORE
6520010123 CORE,PIPE
6520010147 CORE,PIPE
L603 6101975711 CUTTING WIRE
L630 6100785946 PIPE CORE
6100785953 PIPE CORE
6520010123 CORE,PIPE
6520010147 CORE,PIPE
L631 6101975711 CUTTING WIRE
L632 6101975711 CUTTING WIRE
L633 6100785946 PIPE CORE
6100785953 PIPE CORE
6520010123 CORE,PIPE
6520010147 CORE,PIPE
L634 6100785946 PIPE CORE
6100785953 PIPE CORE
6520010123 CORE,PIPE
6520010147 CORE,PIPE
L652 6101975711 CUTTING WIRE
L805 6450082887 INDUCTOR,5.6U K
DIODE
D001 4072128818 DIODE KDS160-RTK
4071490817 DIODE 1SS355-TE-17
D004 4072128818 DIODE KDS160-RTK
4071490817 DIODE 1SS355-TE-17
D005 4080093204 DIODE 1N4148
4070124426 DIODE 1SS133
4070134336 DIODE 1S2076A
D1001 4070639623 ZENER DIODE MTZJ9.1A
4070579632 ZENER DIODE RD9.1EB1
4080480004 ZENER DIODE MTZJ9.1B
4080480301 ZENER DIODE MTZJ9.1C-52
D1002 4070639623 ZENER DIODE MTZJ9.1A
4070579632 ZENER DIODE RD9.1EB1
4080480004 ZENER DIODE MTZJ9.1B
4080480301 ZENER DIODE MTZJ9.1C-52
!
!
!
!
Ref. No. Part No. Description Ref. No. Part No. Description
P List-BA5VZ 12/12/06 7:56 AM Page 12

D1003 4070639623 ZENER DIODE MTZJ9.1A
4070579632 ZENER DIODE RD9.1EB1
4080480004 ZENER DIODE MTZJ9.1B
4080480301 ZENER DIODE MTZJ9.1C-52
D1004 4070638329 ZENER DIODE MTZJ11C
4070541827 ZENER DIODE RD11EB3
D1005 4070638329 ZENER DIODE MTZJ11C
4070541827 ZENER DIODE RD11EB3
D1006 4070638329 ZENER DIODE MTZJ11C
4070541827 ZENER DIODE RD11EB3
D1007 4070638329 ZENER DIODE MTZJ11C
4070541827 ZENER DIODE RD11EB3
D1008 4070638329 ZENER DIODE MTZJ11C
4070541827 ZENER DIODE RD11EB3
D1010 4070638329 ZENER DIODE MTZJ11C
4070541827 ZENER DIODE RD11EB3
D1011 4070638329 ZENER DIODE MTZJ11C
4070541827 ZENER DIODE RD11EB3
D1012 4070638329 ZENER DIODE MTZJ11C
4070541827 ZENER DIODE RD11EB3
D1016 4072128818 DIODE KDS160-RTK
4071490817 DIODE 1SS355-TE-17
D102 4070995620 ZENER DIODE MTZJ6.8A
4070574013 ZENER DIODE RD6.8EB1
4080478506 ZENER DIODE MTZJ6.8A
D103 4071000224 ZENER DIODE MTZJ36A
4070562317 ZENER DIODE RD36EB1
4080476106 ZENER DIODE MTZJ36A
D104 4070638220 ZENER DIODE MTZJ10A
4070996122 ZENER DIODE MTZJ10B
D105 4070638220 ZENER DIODE MTZJ10A
4070996122 ZENER DIODE MTZJ10B
D122 4071661118 DIODE 1SS356-TW11
D1901 4080093204 DIODE 1N4148
4070124426 DIODE 1SS133
4070134336 DIODE 1S2076A
D1910 4071589204 LED SPR-39MVWF
4080429607 LED BT-603W-30
D1910A 6102737929 HOLDER LED-S4KF
6103039954 HOLDER LED-C4LA
D249 4070996023 ZENER DIODE MTZJ9.1B
4070579711 ZENER DIODE RD9.1EB2
D352 4070638626 ZENER DIODE MTZJ5.1A
4070567916 ZENER DIODE RD5.1EB1
4080476403 ZENER DIODE MTZJ5.1A
D357 4080093204 DIODE 1N4148
4070124426 DIODE 1SS133
4070134336 DIODE 1S2076A
D3701 4070058632 DIODE ERA15-02-V1
4070114318 DIODE TVR1B
4080537708 DIODE TVR1B
D421 4070997228 ZENER DIODE MTZJ16A
4070547027 ZENER DIODE RD16EB1
4070547215 ZENER DIODE RD16EB3
4080475208 ZENER DIODE MTZJ16A-52
D445 6101975711 CUTTING WIRE
D467 4080093204 DIODE 1N4148
4070124426 DIODE 1SS133
4070134336 DIODE 1S2076A
D468 4080093204 DIODE 1N4148
4070124426 DIODE 1SS133
4070134336 DIODE 1S2076A
D476 4070996023 ZENER DIODE MTZJ9.1B
4070579711 ZENER DIODE RD9.1EB2
4080480004 ZENER DIODE MTZJ9.1B
D485 4070077415 DIODE EU1
4080614102 DIODE EU1
D507 4071182217 ZENER DIODE 1Z75
D512 4070058632 DIODE ERA15-02-V1
4080456801 DIODE ERA15-02
D603 4070066310 DIODE ERC05-10BV1
4070096921 DIODE RM11C
4080614003 DIODE ERC05-10B
D604 4070066310 DIODE ERC05-10BV1
4070096921 DIODE RM11C
4080614003 DIODE ERC05-10B
D605 4070066310 DIODE ERC05-10BV1
4070096921 DIODE RM11C
4080614003 DIODE ERC05-10B
D606 4070066310 DIODE ERC05-10BV1
4070096921 DIODE RM11C
4080614003 DIODE ERC05-10B
D609 4080093204 DIODE 1N4148
D610 4072348701 PHOTO COUPLE PC123X5YFZ
4072303908 PHOTO COUPLE PC123Y52
D612 4070077415 DIODE EU1
4080614102 DIODE EU1
D613 4070077415 DIODE EU1
4080614102 DIODE EU1
D614 4070995422 ZENER DIODE MTZJ6.2B
D615 4080093204 DIODE 1N4148
4070124426 DIODE 1SS133
4070134336 DIODE 1S2076A
D631 4070098816 DIODE RU3AM
4080584405 DIODE RU3AM
D632 4072116102 DIODE FE301-1L43
4071296706 DIODE RU4YX LF-L1
4080458706 DIODE RU4YX LF-L1
D633 4070077613 DIODE EU2
4080458102 DIODE EU2Z
D634 4070098915 DIODE RU3M
4080614201 DIODE RU3M
D661 4070996122 ZENER DIODE MTZJ10B
4070540018 ZENER DIODE RD10EB2
D681 4080093204 DIODE 1N4148
4070124426 DIODE 1SS133
4070134336 DIODE 1S2076A
D686 4070995521 ZENER DIODE MTZJ6.2C
4070572831 ZENER DIODE RD6.2EB3
D801 4072505817 ZENER DIODE KDZ10V
4072065618 ZENER DIODE UDZS-TE-1710B
D802 4072505817 ZENER DIODE KDZ10V
4072065618 ZENER DIODE UDZS-TE-1710B
D803 4072505817 ZENER DIODE KDZ10V
4072065618 ZENER DIODE UDZS-TE-1710B
D804 4072505817 ZENER DIODE KDZ10V
4072065618 ZENER DIODE UDZS-TE-1710B
D805 4072505817 ZENER DIODE KDZ10V
4072065618 ZENER DIODE UDZS-TE-1710B
MISCELLANEOUS
F601 4240059507 FUSE 250V 4A
4230288603 FUSE 250V 4A
F601A 6450705434 HOLDER,FUSE
F601B 6450705434 HOLDER,FUSE
A101 6450904059 TUNER, U/V
A1901A 6450476228 UNIT,REMOCON RECEIVER
6450794124 UNIT,REMOCON RECEIVER
6450820465 UNIT,REMOCON RECEIVER
K1001 6520012974 JACK,RCA-3
6520018914 JACK,RCA-3
K1003 6520015425 JACK,RCA-6
K1005 6520015401 JACK,RCA-3
PS601 4080465407 TH PTDCA1BF4R5Q200
!
!
!
-13-
BA5VZ
Ref. No. Part No. Description Ref. No. Part No. Description
P List-BA5VZ 12/12/06 7:56 AM Page 13

-14-
BA5VZ
4080545109 THERMISTOR ECPCD4R5Q270
SW1901 6450034701 SWITCH,PUSH 1P-1TX1
6450194887 SWITCH,PUSH 1P-1TX1
SW1902 6450034701 SWITCH,PUSH 1P-1TX1
6450194887 SWITCH,PUSH 1P-1TX1
SW1903 6450034701 SWITCH,PUSH 1P-1TX1
6450194887 SWITCH,PUSH 1P-1TX1
SW1904 6450034701 SWITCH,PUSH 1P-1TX1
6450194887 SWITCH,PUSH 1P-1TX1
SW1905 6450034701 SWITCH,PUSH 1P-1TX1
6450194887 SWITCH,PUSH 1P-1TX1
SW1906 6450034701 SWITCH,PUSH 1P-1TX1
6450194887 SWITCH,PUSH 1P-1TX1
SW601 6450590061 SWITCH, POWER 1P-1TX1
VA601 4071712008 VARISTOR ERZV14D471
4072471300 VARISTOR SVC471D-07ABW7
X161 4210121906 SAW F TSF6376BL
4210115202 SAW F TSF6376Y
X211 6450248818 OSC,CRYSTAL 4.433619MHZ
6450820052 OSC,CRYSTAL 4.433619MHZ
6520010154 OSC,CRYSTAL 4.433619MHZ
X801 6450041938 OSC,CRYSTAL 32.768KHZ
6103342290 ASSY,PWB CRT C8WAZ
1AA0B10S244BB
TRANSISTOR
Q701 4050416507 TR 2SC2621-D-RA
4050416705 TR 2SC2621-E-RA
4050669903 TR 2SC2688(1)-K
4050670008 TR 2SC2688(1)-L
4050670107 TR 2SC2688(1)-M
Q703 4050416507 TR 2SC2621-D-RA
4050416705 TR 2SC2621-E-RA
4050669903 TR 2SC2688(1)-K
4050670008 TR 2SC2688(1)-L
4050670107 TR 2SC2688(1)-M
Q705 4050416507 TR 2SC2621-D-RA
4050416705 TR 2SC2621-E-RA
4050669903 TR 2SC2688(1)-K
4050670008 TR 2SC2688(1)-L
4050670107 TR 2SC2688(1)-M
Q721 4051413515 TR KTA1266-Y—T
4050017615 TR 2SA1015-Y(SAN)
CAPACITOR
C703 4030736730 CERAMIC 470P K 50V
C705 4030736730 CERAMIC 470P K 50V
C707 4030736730 CERAMIC 470P K 50V
C708 4032873522 CERAMIC 100P K 3K
C710 4041054701 ELECT 22U M 250V
4034553610 ELECT 22U M 250V
4034320816 ELECT 22U M 250V
RESISTOR
R701 4010278137 CARBON 82 JA 1/6W
R702 4010253837 CARBON 180 JA 1/6W
R704A 4010278137 CARBON 82 JA 1/6W
R705 4010253837 CARBON 180 JA 1/6W
R707A 4010278137 CARBON 82 JA 1/6W
R708 4010253837 CARBON 180 JA 1/6W
R711 4010654614 OXIDE-MT 12K JA 2W
R712 4010654614 OXIDE-MT 12K JA 2W
R713 4010654614 OXIDE-MT 12K JA 2W
R715 4010091528 CARBON 2.7K JA 1/2W
R716 4010091528 CARBON 2.7K JA 1/2W
R717 4010091528 CARBON 2.7K JA 1/2W
R723 4010249335 CARBON 1.2K JA 1/6W
R724 4010269630 CARBON 470 JA 1/6W
R732 4010246433 CARBON 10 JA 1/6W
R743 4010249731 CARBON 12K JA 1/6W
COIL
L702 6450079740 INDUCTOR,180U K
DIODE
D741 4080093204 DIODE 1N4148
4070124426 DIODE 1SS133
4070134336 DIODE 1S2076A
D742 4080093204 DIODE 1N4148
4070124426 DIODE 1SS133
4070134336 DIODE 1S2076A
MISCELLANEOUS
K701L 6450262005 SOCKET,CRT 8P
6520017726 SOCKET,CRT 8P
!
!
!
Ref. No. Part No. Description Ref. No. Part No. Description
P List-BA5VZ 12/12/06 7:56 AM Page 14

-15-
DIP
E
E
V
L
D1910A
R
***
1AA4B10S04100
KE-2
KE-1
34
21
KG
T4AL250V
F601
E
132
33 64
1020
40 50 60
30
14
5
8
E
1
1
15
1
E
E
E
E
17
9
16
17
10
A30C5
R1907
C644
C661
R686
Q683
D634
IC651
C651
Q681
C1902
J638
R644-H1
R644-H2
J640
K1005
JW25
JP683
SW1906SW1905SW1904SW1903SW1902SW1901
CH UP CH DOWN VOL UP VOL DOWN MENU AV/TV
J101
IC202
OUT
IN
JW4
C643
1AA4B10S0410A
K1005A
KE
JP601
JP602
C609-H1
C609-H2
C602
C601A
D610
KG-3
KG-2
KG-1
L601-H1
L601-H2
L601-H3 L601-H4
L601-H7 L601-H8
L601-H5
L601-H6
R601
C625
L601
F601A F601B
TP-EE
SW601-H2
SW601-H1
SW601
C601
D605
VA601
D603
D606
R602-H4
C603
D604
C604
AC6A1
CHASSIS
R631
R632
R661
C629
A1901A
C645
J639
JP644
C602A
D1910
Q1902
R887
C634 C633
C632
C631
IC201
X171
C358
C233
C225
R230
R228
J213
R357
D357
C210
C215
C202
R211
R212
X801
C204
IC801
R818
C627
D632
R668
R668-H1
R668-H2
C662
D681
R681
D633
J607
D682
Q684
R688
C231
C244
C247
C226
X211
C353
R351
D352
R280
L204
C893
C805
R690
C609
D1901
J1103
C1001
C1002
C1003
D1002
D1003
D1001
KX
K001
C001
J1004
C3712
C3710
C3702
J1003
C3725
J1005 C3701
J007
J002
R012
R013
R011
R010
C015
C3711
C3724
C3713
C011
C002
R3704
R3705
J004
C3708
J202
JW14
JP3704
JP3702 J212
J637 J227
R243
J1008
J206
J207
J208
KP
J210
C122
C291
J217
J218
X161
J220 R102 J221
L111
X161A
R115
J216
R290
J224
R223
R604
R609
C610
D609
C613
R611
C612
R605
C611
C615
D612
D613
R607
D611
R606
J603
J601
J604
R610
D614
R643
R642
D661 R689
J509
J602
J235
J1009
J244
J243A
JW22
JW23
JW18
JW16
JW10
JW11
JW7
JW3
JW6
JW5
JW9
JW8
JW21
IC601
IC601-1
T611-H10
T611-H15
T611-H11
T611-H13
T611-H7
R817
R291
R687
J238
J237
J236
L431
T431
R355
C641
L631
R486
C471
T471-H11
T471-H2
T471-H4
T471-H7
T471-H10
T471-H1
T471
KDY-6
KDY-5
KDY-4
KDY-1
KDY-3
C521
C515
R516
R522
D512
C517 J506
C510
C518
R512
R519
C520
R515
R514
C514
D507
C524
R501
R511
R510
J505
JP437
KQ
R432
C491
C433
R433
C432
C434
R434
R431
Q431
D485
R485
C486
R488
C441B C441C441A
R435
C435B
C436A
C436
C435A
C435
YC-C
R481
R424
JP1001
C469
R103
D1014
K1003
J1012
D1005
J1011
J1014
D1006
C1016 C1014
D1013
R479
L432
R426 D467
D421
R422
R423
C1012
D1011
D1010
D1012
D1007
D1009
D1008
C1007
C1009
C1008
C1004
C1006
D1004
J103
D103
R105
C101
C106
J108
A101
TP-E
TP-A
TP-M
R106
R107
J104
D102
K1001
C104
JP436
D1015
K1004
Y
SW
D445
R475
C437
DVD
AUD
L
R
R
AUD
VID AUD AUD L
VID
D476
KDY
J1016
Q432-H2
Q432-H1 Q432-H3
Q432-H4
Q432-H5
Q432
Q405
Q401
R411
R409
J613
13
1
IC001
J1902
J1901
C3715
C3722 C3716
C3714
J240
IC501
JW1
JW24
Q661A
Q661
C435-H1C435-H3C435-H4
C441-H1C441-H2C441-H3
C441-H4
C435-H2
L441-H2
JW30
R845
J243
C1005
C1015
C863
J412
J222
J109
J201
J107
J650
PS601-H1
PS601-H3
PS601-H2
PS601
J413
STATUS
IIC-SCL
IIC-SDA
GND
IC1001
+B
ADJUST
C511
R425
R650
JP665
TP-B
D632B
JP671
R603
D468
JW12JW13
R685
R691
JP632
VR631
D686
L632
C691
C438
C438A
IC001-1
J006
J008
R007
K1901
C013
C650
C649
R445
J003
JP005
J005
R667
J643
L431A
JW15
D005
R525
R501A
JP501 JP502
R635
D631
JW29
Q1901
R1910 R1909
JW31
JW26
R645
R646
R647
D615
JP001
T611
T611B
J405
R401
L201
JP004
C435C
C435-H5
R352
J410
JP441A
JP441
R518
R441
L441-H1
L441
IC201
IC3701
J010
D3701
JW17
JW28
D249
JW27
JW2
R602-H1
JW32
JW33
JW34
T611-H2
T611-H16
T611-H12
C616
C626
C617
R602-H2R602-H3
J652
C618
VA602
C628
K001A
C618A
JW35
C614A C614
L602
L634 L633
L630
C431
JW36
J401
R602
R840
J402
J403
R1025
R410
R1914
J605
J503
J508
J203
D632-H1D632-H2
C3717
R430
J651
R614
R613
D1904
C356
J3702
JW-M
J3705
J3706
R644
R644-H3
L805
J501
D105 D104
J009
K1002
JW38
JW37
C223
Component Locations
Main Board (Parts Side)
SS_21-BA5VZ-01(AC6-A1)AUS 12/12/06 8:23 AM Page 7

Component Locations
E
E
E
3
1
5
1
1AA4B10S0410B ***
E
1
15
A30C5
R717
K701L
C708A
R743
JS741
J701
C701
K7Y
L702
C710
R724
Q721
R715
R732
R716
C708
Q701A
Q703A
C721
Q703
R701
C702
Q705
Q701
R703
R702
C703
R723
D742
D741
R707
R706
R705
R709
C705
C707
R708
D732
D733
D731
K701-M
R704
R704A
R707A
R712
R711
R713
K7U
JW7Y
K7Q
K7P
CRT Board (Parts Side)
SANYO Electric Co., Ltd.
Dec./’06 /30 CPS Printed in Indonesia
SS_21-BA5VZ-01(AC6-A1)AUS 12/12/06 8:23 AM Page 8
