Sanyo DP23845 User manual

Specifications
Power Rating . . . . . . . . . . . . . . . . . . . . . . . . 120VAC
92W (Avg), 1.6A (Max)
Antenna Input Impedance . . . . . . . . . . . . . . . . . 75Ω
UHF/VHF/CATV
Receiving Channel . . . . . . . . . . . . . . . . 2 - 13 (VHF),
14 - 69 (UHF),
01, 14-94, 95-125 (CATV)
Remote Ready . . . . . . . . . . 25 Key Remote Control
Sound Output . . . . . . . . . . . . . . . . . . . . . . 2.0 W/CH
Intermediate Frequency
Picture IF Carrier. . . . . . . . . . . . . . . . . . 45.75MHz
Sound IF Carrier . . . . . . . . . . . . . . . . . . 41.25MHz
Color Sub Carrier . . . . . . . . . . . . . . . . . 42.17MHz
LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . V230W1-L02
Cabinet Dimensions
Width. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 692mm
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . 385mm
Depth including base . . . . . . . . . . . . . . . . 181mm
REFERENCE No. SM780108
DP23845, N2TF, PRODUCT CODE 111377005
Contents
Safety Instructions . . . . . . . . . . . . . . . . . . 2
Service Adjustments . . . . . . . . . . . . . 3 - 14
Power Failure Circuit . . . . . . . . . . . . . . . 15
Mechanical Disassemblies. . . . . . . 16 – 17
Chassis Electrical Parts List . . . . . . 18 - 33
Cabinet Parts List . . . . . . . . . . . . . . . . . . 34
Component and Test Point
Locations . . . . . . . . . . . . . . . . . . . 35 – 39
Block Diagrams . . . . . . . . . . . . . . . . 40 – 45
Trouble Shooting Flow Charts . . . . 46 – 48
Control Port Functions. . . . . . . . . . . 49 – 50
Schematic Notes . . . . . . . . . . . . . . . . . . . 51
Pin Layouts. . . . . . . . . . . . . . . . . . . . . . . . 51
Capacitor and Resistor Codes . . . . . . . . 52
Schematic Diagrams . . . . . . . . . . . . 53 - 64
AS
FILE NO.
SERVICE MANUAL Remote Control Digital
Color Television DP23845 (U.S.A.)
(CANADA)
ORIGINAL VERSION
Chassis No. 23845-00
NOTE: Match the Chassis No. on
the unit’s back cover with
the Chassis No. in the
Service Manual.
If the Original Version
Service Manual Chassis
No. does not match the
unit’s, additional Service
Literature is required. You
must refer to “Notices” to the
Original Service Manual
prior to servicing the unit.

— 2 —
SAFETY INSTRUCTIONS
SAFETY PRECAUTIONS
1. Comply with all caution and safety-related notes provided
on the side of the cabinet, inside the cabinet, and on the
chassis,
2. When replacing a chassis in the cabinet, always be certain
that all the protective devices are installed properly, such
as control knobs, adjustment covers, shields and barriers.
3. Before replacing the back cover of the set, thoroughly
inspect the inside of the cabinet to see that no stray parts
or tools have been left inside.
ANTENNA COLD CHECK
Remove AC plug from the 120 VAC outlet and place a
jumper across the two blades. Connect one lead of an ohm-
meter to the jumpered AC plug, and touch the other lead to
each exposed antenna terminal (UHF and VHF antenna ter-
minals). The resistance must measure between 1M ohm and
5.2M ohm. Any resistance value below or above this range
indicates an abnormality which requires corrective action.
LEAKAGE CURRENT CHECK
Plug the AC line cord directly into a 120 VAC outlet. (Do not
use an isolation transformer for this check.) Use an AC volt-
meter, that has 5000 ohms per volt or more sensitivity.
Connect a 1500 ohm 10 watt resistor, paralleled by a 0.15 µF
150 VAC capacitor, between a known good earth ground
(water pipe, conduit, etc.) and all exposed metal parts of the
cabinet (antennas, handle bracket, metal cabinet, screw
heads, metal overlays, control shafts, etc.). Measure the AC
voltage across the 1500 ohm resistor. The AC voltage
should not exceed 750 mV. A reading exceeding 750 mV
indicates that a dangerous potential exists. The fault must
be located and corrected. Repeat the above test with the
receiver power plug reversed.
NEVER RETURN A RECEIVER TO THE CUSTOMER
WITHOUT TAKING THE NECESSARY CORRECTIVE ACTION.
PRODUCT SAFETY NOTICE
When replacing components in a receiver, always keep in
mind the necessary product safety precautions. Pay special
attention to the replacement of components marked with a
star () in the parts list and in the schematic diagrams. To
ensure safe product operation, it is necessary to replace
those components with the exact same PARTS.
0.15 µF 150V AC
1500 ohm
10 watt
Good earth ground
such as a water pipe,
conduit, etc.
AC OUTLET
TELEVISION
RECEIVER
READING SHOULD NOT EXCEED 750 mV.
AC VOLTMETER
(5000 ohms per volt or more sensitivity)
To be touched to all of exposed metal parts.
Voltmeter Hook-up for Leakage Current Check.

1 2 3
4 5 6
7 8 9
0
MUTE
MENU
CAPTION SLEEP
RECALL
RESETINPUT POWER
DISPLAY
V-GUIDE
123
456
789
0
CH
CH
VOL VOL
PIX SHAPE
GENERAL
This set has an On-screen Service Menu system included in
the CPU that allows remote operation for most of the ser-
vice adjustments.
ON-SCREEN SERVICE MENU SYSTEM
1. Enter the Service Menu:
•While pressing the Volume (–) button on the televi-
sion, press the Number Key 1 on the remote control
unit. The Service Menu will now appear.
2. Service Adjustments:
•Press the or key to select the desired service
menu item you want to adjust. See page 4 for the
On-screen Service Menu.
Note: Press the Mute key to skip up 16 items.
•Use the + or – key or number keys to adjust the data.
The + or – keys will increase or decrease the data
sequentially. The number keys (0 ~ 7) toggle only
their respective bits between 1 and 0 and are used to
change the Sub-Address. For example to change bit
5 press the number 5 key. See below.
Note: Using the + or – is not recommended due to possi-
ble rapid changes.
3. Exit from the Service Menu:
•Press the MENU key to turn off
the Service Menu display.
255_ 255
255 / 255 / 255
255 : 255 : 255__00000
M016___S0A __TV____RC00
V_ENH__GAIN__TV
000____01__00000001
Item No.Hexadecimal
Data Binary Data
Title
— 3 —
SERVICE ADJUSTMENTS
Service Menu Display
(b7) (b6) (b5) (b4) (b3) (b2) (b1) (b0)
0 1 0 1 0 1 1 0 BINARY DATA
(8 bit)
Menu:
Exit Service Menu
 :Select Item
Volume + / –:
Adjust Service Menu
Mute:
Skip Next 16 items
Numeric:
1:
Enter Service Menu
0, 1, 2, 3, 4, 5, 6, 7:
Change Binary Data
1, 3, 4, 6, 7, 9:
Adjust White Balance
POWER VOL
CH

Volume – :Enter Service Menu

000 V ENH GAIN TV 01h RF input
001 V ENH GAIN OTHER 01h Except RF
002 V ENH MAX POINT TV 03h RF input
003 V ENH MAX POINT OTHER 03h Except RF
004 V ENH SLICE LEVEL TV 00h RF input
005 V ENH SLICE LEVEL OTHER 00h Except RF
006 FENH TV 01h RF input
007 FENH OTHER 01h Except RF
008 SHARPNESS GAIN TV 01h RF input
009 SHARPNESS GAIN OTHER 01h Except RF
00A SHARPNESS SLICE LEVEL TV 00h RF input
00B SHARPNESS SLICE LEVEL OTHER 00h Except RF
00C FBCLMPEX 01h
00D NOISE CANCEL TV 00h RF input
00E NOISE CANCEL OTHER 00h Except RF
00F SET DELAY–TV 0Dh RF input
010 SET DELAY–Video 0Bh Composite Video input
011 SET DELAY–OTHER 08h Except RF and Composite Video input
012 LTI GAIN TV 03h RF input
013 LTI GAIN OTHER 03h Except RF
014 LTI SLICE LEVEL TV 00h RF input
015 LTI SLICE LEVEL OTHER 00h Except RF
016 CTI GAIN TV 03h RF input
017 CTI GAIN OTHER 03h Except RF
018 CTI SLICE LEVEL TV 00h RF input
019 CTI SLICE LEVEL OTHER 00h Except RF
01A CONTRAST TV 30h RF input, (See Service Adjustments)
01B CONTRAST AV 30h Video1/2, Composite, S input
01C CONTRAST 480i/p 30h 480i/p input
01D CR OUTPUT GAIN TV 03h RF input
01E CR OUTPUT GAIN AV 03h Video1/2, Composite, S input
01F CR OUTPUT GAIN 480i/p 03h 480i/p input
020 CB OUTPUT GAIN TV 03h RF input
021 CB OUTPUT GAIN AV 03h Video1/2, Composite, S input
022 CB OUTPUT GAIN 480i/p 03h 480i/p input
023 CR OFFSET–TV 00h RF input
024 CR OFFSET–AV 00h Video1/2, Composite, S input
025 CR OFFSET–480i 01h 480i input
026 CR OFFSET–480p 00h 480p input
027 CB OFFSET–TV 00h RF input
028 CB OFFSET–AV 00h Video1/2, Composite, S input
029 CB OFFSET–480i 00h 480i input
02A CB OFFSET–480p 01h 480p input
02B HUE–TV 00h RF input
02C HUE–AV 00h Video1/2, Composite, S input
— 4 —
ON-SCREEN SERVICE MENU
No. Name Initial Data Note
•All data except in gray box area is fixed. Do not change for correct operation.
•Data in gray box is initial. Can be set according to adjustment information.

02D HUE–480i/p 00h 480i/p input
02E TOF TV 01h RF input
02F TOF OTHER 01h Except RF
030 Y–CLAMP–MAIN 00h Except 480i/p
031 Y–CLAMP–480i 6Dh 480i input
032 Y–CLAMP–480p 6Dh 480p input
033 C–CLAMP–MAIN 00h Except 480i/p
034 C–CLAMP–480i 00h 480i input
035 C–CLAMP–480p 80h 480p input
036 C–CLAMP F–MAIN 00h Except 480i/p
037 C–CLAMP F–480i 6Fh 480i input
038 C–CLAMP F–480p 6Dh 480p input
039 COL–KILLER TV 07h RF input
03A COL–KILLER AV 07h Video1/2, Composite, S input
03B ACC TV 08h RF input
03C ACC AV 08h Video1/2, Composite, S input
03D PLL–TV AMP1 00h RF input
03E PLL–TV AMP2 04h ↓
03F PLL–TV AMP3 05h ↓
040 PLL–TV GAIN1 0Eh ↓
041 PLL–TV GAIN2 05h ↓
042 PLL–TV GAIN3 06h ↓
043 PLL–AV AMP1 00h Video1/2, Composite, S input
044 PLL–AV AMP2 04h ↓
045 PLL–AV AMP3 05h ↓
046 PLL–AV GAIN1 0Eh ↓
047 PLL–AV GAIN2 05h ↓
048 PLL–AV GAIN3 06h ↓
049 PLL–480i/p AMP1 00h Video3, Component(480i/p) input
04A PLL–480i/p AMP2 04h ↓
04B PLL–480i/p AMP3 05h ↓
04C PLL–480i/p GAIN1 0Eh ↓
04D PLL–480i/p GAIN2 05h ↓
04E PLL–480i/p GAIN3 06h ↓
04F HDPH COMP 00h RF, Composite input
050 HDPH S 02h S input
051 HDPH 480i 0Eh 480i input
052 HDPH 480p 00h 480p input
053 Y NOISE LIM TV 00h RF input
054 Y NOISE LIM OTHER 00h Except RF
055 Y NOISE GAIN TV 01h RF input
056 Y NOISE GAIN OTHER 00h Except RF
057 Y NOISE TV 01h RF input
058 Y NOISE OTHER 00h Except RF
059 COL–KILLER GAIN TV 01h RF input
05A COL–KILLER GAIN OTHER 01h Except RF
05B C NOISE LIM TV 01h RF input
05C C NOISE LIM OTHER 01h Except RF
05D C NOISE GAIN TV 00h RF input
05E C NOISE GAIN OTHER 00h Except RF
05F C NOISE TV 01h RF input
— 5 —
No. Name Initial Data Note

060 C NOISE OTHER 00h Except RF
061 480i SUB–CONT 00h Component (480i) input (Difference)
062 480i SUB–BRIGHTNESS 00h ↓
063 480i SUB–COLOR 00h ↓
064 480i SUB–TINT 00h ↓
065 480i SUB–SHARP 00h ↓
066 480p SUB–CONT 00h Component (480p) input (Difference)
067 480p SUB–BRIGHTNESS 00h ↓
068 480p SUB–COLOR 0Ch ↓
069 480p SUB–TINT 00h ↓
06A 480p SUB–SHARP 00h ↓
06B AV SUB–CONT 00h Composite Video input (Standard)
06C AV SUB–BRIGHTNESS 0Fh ↓
06D AV SUB–COLOR 08h ↓
06E AV SUB–TINT 08h ↓
06F AV SUB–SHARP 10h ↓
070 S SUB–CONT 00h S Video input (Difference)
071 S SUB–BRIGHTNESS 00h ↓
072 S SUB–COLOR 00h ↓
073 S SUB–TINT 00h ↓
074 S SUB–SHARP 00h ↓
075 RF SUB–CONT 00h RF input (Difference)
076 RF SUB–BRIGHTNESS 00h ↓
077 RF SUB–COLOR 00h ↓
078 RF SUB–TINT 00h ↓
079 RF SUB–SHARP 00h ↓
07A 720p SUB-CONT 00h Component(720p) input (Difference)
07B 720p SUB-BRIGHT 00h ↓
07C 720p SUB-COLOR 00h ↓
07D 720p SUB-TINT 00h ↓
07E 720p SUB-SHARP F8h ↓
07F 1080i SUB-CONT 00h Component(1080i) input (Difference)
080 1080i SUB-BRIGHT 00h ↓
081 1080i SUB-COLOR 00h ↓
082 1080i SUB-TINT 00h ↓
083 1080i SUB-SHARP F8h ↓
084 480i D SUB-CONT 00h DVI(480i) input (Difference)
085 480i D SUB-BRIGHT 00h ↓
086 480i D SUB-COLOR 00h ↓
087 480i D SUB-TINT 00h ↓
088 480i D SUB-SHARP 00h ↓
089 480p D SUB-CONT 00h DVI(480p) input (Difference)
08A 480p D SUB-BRIGHT 00h ↓
08B 480p D SUB-COLOR 00h ↓
08C 480p D SUB-TINT 00h ↓
08D 480p D SUB-SHARP 00h ↓
08E 720p D SUB-CONT 00h DVI(720p) input (Difference)
08F 720p D SUB-BRIGHT 00h ↓
090 720p D SUB-COLOR 00h ↓
091 720p D SUB-TINT 00h ↓
092 720p D SUB-SHARP 00h ↓
— 6 —
No. Name Initial Data Note

— 7 —
No. Name Initial Data Note
093 1080i D SUB-CONT 00h DVI(1080i) input (Difference)
094 1080i D SUB-BRIGHT 00h ↓
095 1080i D SUB-COLOR 00h ↓
096 1080i SUB-TINT 00h ↓
097 1080i SUB-SHARP 00h ↓
098 AUTO CONTRAST 0Ah Composite, S, Component input, Picture: Auto
099 AUTO TINT 22h ↓
09A AUTO COLOR 28h ↓
09B AUTO BRIGHT 20h ↓
09C AUTO SHARP 10h ↓
09D MANUAL AV CONTRAST 2Fh Composite, S, Component input, Picture: Manual
09E MANUAL AV TINT 20h ↓
09F MANUAL AV COLOR 28h ↓
0A0 MANUAL AV BRIGHT 20h ↓
0A1 MANUAL AV SHARP 10h ↓
0A2 GAME AV CONTRAST 10h Composite, S, Component input, Picture: Game
0A3 GAME AV TINT 20h ↓
0A4 GAME AV COLOR 10h ↓
0A5 GAME AV BRIGHT 20h ↓
0A6 GAME AV SHARP 07h ↓
0A7 WHITE-RF R 00h RF(TV) input, White Balance (Difference)
0A8 WHITE-RF G 00h ↓
0A9 WHITE-RF B 00h ↓
0AA BLACK-RF R 00h RF(TV) input, Black Balance (Difference)
0AB BLACK-RF G 00h ↓
0AC BLACK-RF B 00h ↓
0AD WHITE-AV R 52h Composite (AV) input, White Balance (Standard)
0AE WHITE-AV G 44h ↓
0AF WHITE-AV B 40h ↓
0B0 BLACK-AV R 30h Composite (AV) input, Black Balance (Standard)
0B1 BLACK-AV G 30h ↓
0B2 BLACK-AV B 30h ↓
0B3 WHITE-S R 00h S(AV) input, White Balance (Difference)
0B4 WHITE-S G 00h ↓
0B5 WHITE-S B 00h ↓
0B6 BLACK-S R 00h S(AV) input, Black Balance (Difference)
0B7 BLACK-S G 00h ↓
0B8 BLACK-S B 00h ↓
0B9 WHITE-480i R 00h 480i(Component) input, White Balance (Difference)
0BA WHITE-480i G 00h ↓
0BB WHITE-480i B 00h ↓
0BC BLACK-480i R 00h 480i(Component) input, Black Balance (Difference)
0BD BLACK-480i G 00h ↓
0BE BLACK-480i B 00h ↓
0BF WHITE-480p R 00h 480p(Component) input, White Balance (Difference)
0C0 WHITE-480p G 00h ↓
0C1 WHITE-480p B 00h ↓
0C2 BLACK-480p R 00h 480p(Component) input, Black Balance (Difference)
0C3 BLACK-480p G 00h ↓
0C4 BLACK-480p B 00h ↓

— 8 —
No. Name Initial Data Note
0C5 WHITE-720p R 00h 720p (Component) input, White Balance (Difference)
0C6 WHITE-720p G 00h ↓
0C7 WHITE-720p B 00h ↓
0C8 BLACK-720p R 00h 720p (Component) input, Black Balance (Difference)
0C9 BLACK-720p G 00h ↓
0CA BLACK-720p B 00h ↓
0CB WHITE-1080i R 00h 1080i (Component) input, White Balance (Difference)
0CC WHITE-1080i G 00h ↓
0CD WHITE-1080i B 00h ↓
0CE BLACK-1080i R 00h 1080i (Component) input, Black Balance (Difference)
0CF BLACK-1080i G 00h ↓
0D0 BLACK-1080i B 00h ↓
0D1 WHITE-480i D R 00h 480i (DVI) input, White Balance (Difference)
0D2 WHITE-480i D G 00h ↓
0D3 WHITE-480i D B 00h ↓
0D4 BLACK-480i D R 00h 480i (DVI) input, Black Balance (Difference)
0D5 BLACK-480i D G 00h ↓
0D6 BLACK-480i D B 00h ↓
0D7 WHITE-480p D R 00h 480p (DVI) input, White Balance (Difference)
0D8 WHITE-480p D G 00h ↓
0D9 WHITE-480p D B 00h ↓
0DA BLACK-480p D R 00h 480p (DVI) input, Black Balance (Difference)
0DB BLACK-480p D G 00h ↓
0DC BLACK-480p D B 00h ↓
0DD WHITE-720p D R 00h 720p (DVI) input, White Balance (Difference)
0DE WHITE-720p D G 00h ↓
0DF WHITE-720p D B 00h ↓
0E0 BLACK-720p D R 00h 720p (DVI) input, Black Balance (Difference)
0E1 BLACK-720p D G 00h ↓
0E2 BLACK-720p D B 00h ↓
0E3 WHITE-1080i D R 00h 1080i (DVI) input, White Balance (Difference)
0E4 WHITE-1080i D G 00h ↓
0E5 WHITE-1080i D B 00h ↓
0E6 BLACK-1080i D R 00h 1080i (DVI) input, Black Balance (Difference)
0E7 BLACK-1080i D G 00h ↓
0E8 BLACK-1080i D B 00h ↓
0E9 CT-COOL R F6h Color Enhancer: Cool
0EA CT-COOL G FBh ↓
0EB CT-COOL B 00h ↓
0EC CT-NORM R 00h Color Enhancer: Normal
0ED CT-NORM G 00h ↓
0EE CT-NORM B 00h ↓
0EF CT-WARM R 00h Color Enhancer: Warm
0F0 CT-WARM G F2h ↓
0F1 CT-WARM B 00h ↓
0F2 SHARP F0 RF 02h RF input, Sharpness: Center
0F3 SHARP F0 OTHER 02h Other input, Sharpness: Center
0F4 SHARP F0 480p 02h 480p input, Sharpness: Center
0F5 GAMMA1 01h Under APL setting value
0F6 GAMMA2 01h Beyond APL setting value

— 9 —
No. Name Initial Data Note
0F7 GAMMA APL 00h Gamma Threshold
0F8 NOSIG 00h Select Sync.
0F9 BSCB 00h Cut of Sub-Bass or Setup of Boost
0FA BSCT 00h Cut of Sub-Treble or Setup of Boost
0FB SUB-BASS 00h Setup of Cut Level of Sub Bass and Boost Level
0FC SUB-TREBLE 00h Setup of Cut Level of Sub Treble and Boost Level
0FD BBE-LOW 0Ah Setup of Low-Pass Boost Level (Lo contour)
0FE BBE-HIGH 08h Setup of High Region Boost Level (Process)
0FF AGC 00h AGC ON/OFF
100 AGC LEVEL 00h AGC Level Setup
101 WB ** White Balance Adjustment
102 BB ** Black Balance Adjustment
103 AUTO B-BRIGHT 00h Back Light Auto Bright (Absolute value)
104 BLIGHT-BRIGHT F0h Back Light Bright (PWM value)
105 BLIGHT-MID B0h Back Light Middle (PWM value)
106 BLIGHT-DARK 60h Back Light Dark (PWM value)
107 APL-SW 01h APL Switch
108 APL-PER 10h AI Cycle (8ms/step)
109 APL-LO 36h APL Low-Pass and Inside Region Threshold
10A APL-HI 48h APL Inside and High Region Threshold
10B APL-MIN 10h Gamma Minimum Value (Table No.)
10C APL-CEN 24h Gamma Center Value (Table No.)
10D APL-MAX 48h Gamma Maximum Value (Table No.)
10E APL-READ-NUM 05h Number of APL Read-out Times
10F APL-READ-PER 01h APL Read-out Cycle
110 APL-0 70h APL Read-out Value (APL=0%: Black)
111 APL-100 E0h APL Read-out Value (APL=100%: White)
112 POWER ERR 00h Power Failure History
113 OPTION **h Option Monitor (Read-out)
114 PANEL TIME1 **h Used Time of LCD Panel
115 PANEL TIME2 **h Used Time of Unit
116 OSD HP 00h OSD H-Phase
117 CCD HP 14h CCD H-Phase
118 CCD SLICER LEVEL 0Bh CCD Slicer Level
119 PASSWORD **h Password
11A VUP FULL 01h
11B VUP JUST 01h
11C VUP ZOOM 01h
11D VUP NORMAL 01h
11E VSC FULL 0Fh
11F VSC JUST 07h
120 VSC ZOOM 04h
121 VSC NORMAL 0Fh
122 HSC1 N FULL 10h
123 HSC1 N JUST 0Fh
124 HSC1 N ZOOM 0Fh
125 HSC1 N NORMAL 0Bh
126 HSC1 D FULL 1Fh
127 HSC1 D JUST 08h
128 HSC1 D ZOOM 1Eh

— 10 —
No. Name Initial Data Note
129 HSC1 D NORMAL 10h
12A HSC2 N FULL 13h
12B HSC2 N JUST 07h
12C HSC2 N ZOOM 07h
12D HSC2 N NORMAL 0Ch
12E HSC2 D FULL 0Fh
12F HSC2 D JUST 0Fh
130 HSC2 D ZOOM 0Fh
131 HSC2 D NORMAL 11h
132 HST FULL 0Ah
133 HST JUST 0Fh
134 HST ZOOM 0Fh
135 HST NORMAL 04h
136 VST FULL 34h
137 VST JUST 54h
138 VST ZOOM 7Eh
139 VST NORMAL 34h
13A VUP FULL 480p 01h
13B VUP JUST 480p 01h
13C VUP ZOOM 480p 01h
13D VUP NORMAL 480p 01h
13E VSC FULL 480p 0Fh
13F VSC JUST 480p 07h
140 VSC ZOOM 480p 04h
141 VSC NORMAL 480p 0Fh
142 HSC1 N FULL 480p 10h
143 HSC1 N JUST 480p 0Fh
144 HSC1 N ZOOM 480p 07h
145 HSC1 N NORMAL 480p 0Bh
146 HSC1 D FULL 480p 1Fh
147 HSC1 D JUST 480p 08h
148 HSC1 D ZOOM 480p 0Eh
149 HSC1 D NORMAL 480p 10h
14A HSC2 N FULL 480p 13h
14B HSC2 N JUST 480p 07h
14C HSC2 N ZOOM 480p 07h
14D HSC2 N NORMAL 480p 0Ch
14E HSC2 D FULL 480p 0Fh
14F HSC2 D JUST 480p 0Fh
150 HSC2 D ZOOM 480p 0Fh
151 HSC2 D NORMAL 480p 11h
152 HST FULL 480p 12h
153 HST JUST 480p 18h
154 HST ZOOM 480p 16h
155 HST NORMAL 480p 0Ah
156 VST FULL 480p 3Dh
157 VST JUST 480p 5Ch
158 VST ZOOM 480p 89h
159 VST NORMAL 480p 3Dh
15A VUP 480i D 01h
15B VUP 480p D 01h

— 11 —
No. Name Initial Data Note
15C VUP 720p D 01h
15D VUP 720p A 01h
15E VUP 1080i D 00h
15F VUP 1080i A 00h
160 VSC 480i D 0Ah
161 VSC 480p D 12h
162 VSC 720p D 10h
163 VSC 720p A 10h
164 VSC 1080i D 12h
165 VSC 1080i A 12h
166 HSC1N 480i D 0Fh
167 HSC1N 480p D 0Bh
168 HSC1N 720p D 10h
169 HSC1N 720p A 1Dh
16A HSC1N 1080i D 1Ch
16B HSC1N 1080i A 1Fh
16C HSC1D 480i D 1Eh
16D HSC1D 480p D 15h
16E HSC1D 720p D 11h
16F HSC1D 720p A 1Fh
170 HSC1D 1080i D 14h
171 HSC1D 1080i A 16h
172 HST 480i D 21h
173 HST 480p D 0Ch
174 HST 720p D 0Fh
175 HST 720p A 0Ah
176 HST 1080i D 0Bh
177 HST 1080i A 08h
178 VST 480i D 44h
179 VST 480p D 38h
17A VST 720p D 1Eh
17B VST 720p A 1Eh
17C VST 1080i D 1Fh
17D VST 1080i A 20h
17E H RANGE 480i 04h
17F 480I DATA1 31h
180 480I DATA2 81h
181 480I DATA3 40h
182 480I DATA4 83h
183 H RANGE 480p 02h
184 480P DATA1 71h
185 480P DATA2 81h
186 480P DATA3 80h
187 480P DATA4 83h
188 H RANGE 720p 04h
189 720P DATA1 F1h
18A 720P DATA2 83h
18B 720P DATA3 20h
18C 720P DATA4 83h
18D H RANGE 1080i 02h
18E 1080I DATA1 B1h

— 12 —
No. Name Initial Data Note
18F 1080I DATA2 83h
190 1080I DATA3 60h
191 1080I DATA4 83h
192 V RANGE 480i 17h
193 R Gain 480i D FFh
194 R Gain 480p D FFh
195 R Gain 720p D FFh
196 R Gain 720p A 42h
197 R Gain 1080i D FFh
198 R Gain 1080i A 42h
199 G Gain 480i D FFh
19A G Gain 480p D FFh
19B G Gain 720p D FFh
19C G Gain 720p A 42h
19D G Gain 1080i D FFh
19E G Gain 1080i A 42h
19F B Gain 480i D FFh
1A0 B Gain 480p D FFh
1A1 B Gain 720p D FFh
1A2 B Gain 720p A 42h
1A3 B Gain 1080i D FFh
1A4 B Gain 1080i A 42h
1A5 R offAD 480i D 00h
1A6 R offAD 480p D 00h
1A7 R offAD 720p D 00h
1A8 R offAD 720p A 00h
1A9 R offAD 1080i D 00h
1AA R offAD 1080i A 00h
1AB R off 480i D 80h
1AC R off 480p D 80h
1AD R off 720p D 80h
1AE R off 720p A 80h
1AF R off 1080i D 80h
1B0 R off 1080i A 80h
1B1 G offAD 480i D 00h
1B2 G offAD 480p D 00h
1B3 G offAD 720p D 00h
1B4 G offAD 720p A 00h
1B5 G offAD 1080i D 00h
1B6 G offAD 1080i A 00h
1B7 G off 480i D 00h
1B8 G off 480p D 00h
1B9 G off 720p D 00h
1BA G off 720p A 12h
1BB G off 1080i D 00h
1BC G off 1080i A 12h
1BD B offAD 480i D 00h
1BE B offAD 480p D 00h
1BF B offAD 720p D 00h
1C0 B offAD 720p A 00h
1C1 B offAD 1080i D 00h

— 13 —
No. Name Initial Data Note
1C2 B offAD 1080i A 00h
1C3 B off 480i D 80h
1C4 B off 480p D 80h
1C5 B off 720p D 80h
1C6 B off 720p A 80h
1C7 B off 1080i D 80h
1C8 B off 1080i A 80h
1C9 R001 00h ROM Correction Data
1CA 00h ROM Correction Data
1CB 00h ROM Correction Data
↓↓↓
↓↓↓
↓↓↓
261 00h ROM Correction Data
262 00h ROM Correction Data
263 00h ROM Correction Data

— 14 —
SERVICE ADJUSTMENTS (Continued)
WHITE BALANCE ADJUSTMENT
Composite (External Video Input)
1. Connect a color-bar generator to the external compos-
ite video input terminal.
2. Switch the generator to the white pattern.
3. Set the television to following conditions:
Picture: AUTO
Color Enhancer: Normal
Back Light: Bright
Display Area: 16:9
4. Enter the Service Mode. The Menu display will appear.
5. Select “White Balance Adjustment” Menu (No. 101).
6. Adjust Red, Green, and Blue Levels alternately with 1, 3,
4, 6, 7, or 9 keys to produce normal black and white
picture in highlight areas.
The White Balance Level adjustment data will be
written automatically in the Service Menu No. 0AD(R),
No. 0AE(G), and No. 0AF(B).
Note: One or two data of RGB should be left at ”52” for
normal contrast level. Do not change the data to
more than “52.”
Other Inputs
Caution: White Balance Adjustment of Composite must
be completed before attempting other input
adjustments.
White Balance Adjustment for other modes [RF, S (Y/C),
Component (480i/ 480p)] may be unnecessary if the adjust-
ment of Composite is OK.
1. Connect a color-bar generator to the preferred video
input terminal.
2. Switch the generator to the white pattern.
3. Set the television to following conditions:
Picture: AUTO
Color Enhancer: Normal
Back Light: Bright
Display Area: 16:9
4. Enter the Service Mode.The Menu display will appear.
5. Select “White Balance Adjustment” Menu (No. 101).
6. Adjust Red, Green, and Blue Levels alternately with 1, 3,
4, 6, 7, or 9 key to produce normal black and white picture
in highlight areas.
The White Balance Level adjustment data will be written
automatically in the following Service Menu:
RF No 0A7 (R), 0A8 (G), 0A9 (B)
S (Y/C) No.0B3 (R), 0B4 (G), 0B5 (B)
Component (480i) No.0B9 (R), 0BA (G), 0BB (B)
Component (480p) No.0BF (R), 0C0 (G), 0C1 (B)
BLACK BALANCE ADJUSTMENT
Black Balance Adjustment may be unnecessary if the White
Balance Adjustment of Composite is OK.
Composite (External Video Input)
1. Connect a color-bar generator to the external (compos-
ite) video input terminal.
2. Switch the generator to the dark grey pattern (“30%
white” recommended).
3. Set the television to following conditions:
Picture: AUTO
Color Enhancer: Normal
Back Light: Bright
Display Area: 16:9
4. Enter the Service Mode. The Menu display will appear.
5. Select “Black Balance Adjustment” Menu (No. 102).
6. Adjust Red, Green, and Blue Levels alternately with 1,
3, 4, 6, 7, or 9 key to produce normal black and white
picture in dark grey areas. The Black Balance Level
adjustment data will be written automatically in the
Service Menu No. 0B0(R), No. 0B1(G), and No. 0B2(B).
Other Inputs
Caution: Black Balance Adjustment of Composite must
be completed before attempting other input
adjustments.
1. Connect a color-bar generator to the preferred video
input terminal.
2. Switch the generator to the dark gray pattern.
3. Set the television to following conditions:
Picture: AUTO
Color Enhancer: Normal
Back Light: Bright
Display Area: 16:9
4. Enter the Service Mode.The Menu display will appear.
5. Select “Black Balance Adjustment” Menu (No. 102).
6. Adjust Red, Green, and Blue Levels alternately with 1,
3, 4, 6, 7, or 9 key to produce normal black and white
picture in dark grey areas. The Black Balance Level
adjustment data will be written automatically in the fol-
lowing Service Menu.
RF No 0AA (R), 0AB (G), 0AC (B)
S (Y/C) No. 0B6 (R), 0B7 (G), 0B8 (B)
Component (480i) No. 0BC (R), 0BD (G), 0BE (B)
Component (480p) No. 0C2 (R), 0C3 (G), 0C4 (B)
Component (720p) No. 0C8 (R), 0C9 (G), 0CA (B)
Component (1080i) No. 0CE (R), 0CF (G), 0D0 (B)
DVI (480i) No. 0D4 (R), 0D5 (G), 0D6 (B)
DVI (480p) No. 0DA (R), 0DB (G), 0DC (B)
DVI (720p) No. 0E0 (R), 0E1 (G), 0E2 (B)
123
456
7 98
RD(–) RD(+)
BD(–) BD(+)
(N/A)
GD(–) (N/A) GD(+)
(N/A)
Remote Control Number keys’ functions in Service Menu
“White Balance Adjustment”
FOR RED LEVEL ADJUSTMENT
FOR BLUE LEVEL ADJUSTMENT
FOR GREEN LEVEL ADJUSTMENT

— 15 —
CPU (IC801) is programmed so the set will go to the stand-
by mode when there is circuit failure as described below.
(Refer to “Block Diagram Power Lines” and “Block
Diagram Power Board.”)
1. Power Failure 1: Detected voltage failure for digital
circuit. (Connected to IC801 pin 1.)
2. Power Failure 2: Detected voltage failure for ana-
log circuit. (Connected to IC801 pin 16.)
(Normal: High; Failure: Low)
POWER FAILURE CIRCUIT
Note: If power failure is detected 3 times in 15 minutes, the
set will enter the standby mode and cannot be
switched On. To reset the operating programs of the
CPU it is necessary to disconnect the AC cord for a
short time.
History of Power Failure
When finishing the repair or stopping the Power Failure, the
history of past failures can be checked.
To see the history
1. Enter the service mode. See “Service Adjustments”
page 3.
2. Select Item No.112 POWER ERR from the Service
Adjustment Data Table.
Note: If simultaneous failures have been detected, the
sum of each data is displayed.
For example:
Power failures 1 & 2
01h + 02h = 03h(3)
Attention:
After finishing service, reset the data of Item No. 112 with
the + or – keys to ““0000hh((00))..””
Failure Name Data
No Failure 00h(0)
Power Failure 1 01h(1)
Power Failure 2 02h(2)
History of Power Failures (Item No. 0C9)

— 16 —
STAND REMOVAL
Note: Position TV face down on a padded or cush-
ioned surface to protect the screen and finish.
Remove 4 screws to take the stand off.
MECHANICAL DISASSEMBLY
TUNER
VHF
UHF
CATV
CABINET BACK REMOVAL
Remove 8 screws (B: 4X14) to take the cabinet back
(C/B) off.
Note: The cabinet back can be removed without
removing the stand.
A
B
B
B
A
A
B
B
B
B
A
STD
C/B
B
CABINET BOTTOM REMOVAL
Press 2 hooks inside to remove the cabinet bottom
(C/BTM).
C
C
C
C
D
C
C
M/BRKT
SH/B
Hook Hook
C/BTM
SHIELD BACK REMOVAL
Remove 6 screws (C: 3X10) to remove the shield back
(SH/B).
MOUNTING BRACKET REMOVAL
Remove a screw (D: 3X10) to remove the mounting
bracket (M/BRKT).
CAUTION: This LCD TV uses several different kinds of
screws. Using the correct screw is neces-
sary to prevent damage. Lead wires must
be redressed to their previous locations
after servicing.

— 17 —
MAIN BOARD REMOVAL
Remove 5 screws (E: 3X10) to remove the main board
with the terminal base (TMNL/B) and audio output jacks
(MO/JACK) (assembly parts).
RC BOARD REMOVAL
Remove a screw (F: 4X14) to remove the RC board.
POWER BOARD REMOVAL
Remove 4 screws (G: 3X10) to remove the power board
with the chassis holder (CH/HLD) (assembly parts).
CONTROL BOARD REMOVAL
Press 2 hooks inside to remove the control board with
the panel top and button assembly.
CH/HLD E
HookHook
F
EE
E
E
GG
GG
MAIN
POWER
CONTROL
RC
TMNL/B
MO/JACK
Spacer
Spacer
Spacer
Spacer
H
LCD PANEL
HLD/PNL-T
HLD/PNL-B
H
H
I I DEC-RC
H
JJ
SP/HLD
SP/HLD
SP/HLD
SP/HLD
SPEAKER REMOVAL
Remove 4 holders (SP/HLD) to remove speakers.
LCD PANEL REMOVAL
1. Remove 4 screws (H: 3X10) to remove the LCD
panel with the top (HLD/PNL-T) and bottom
(HLD/PNL-B) panel holders.
2. Remove 2 screws (J: 3X10) to remove the top
panel holder (HLD/PNL-T).
3. Remove 2 screws (I: 3X10) to remove the bottom
panel holder (HLD/PNL-B).
CABINET FRONT REMOVAL
1. Complete previous disassembly procedures.
2. Remove spacer (Buffer tape) and DEC-RC
(Decoration for remote control receiver).
Note: The spacers can be reused.
Chassis Base

— 18 —
CHASSIS ELECTRICAL PARTS LIST
CAUTION: To Protect against electrical shock and for continued product safety, refer to SAFETY PRECAUTIONS,
and PRODUCT SAFETY NOTICE on Page 2.
PRODUCT SAFETY NOTICE
PRODUCT SAFETY SHOULD BE CONSIDERED WHEN A REPLACEMENT IS MADE IN ANY AREA OF A RECEIVER.
COMPONENTS INDICATED BY A STAR () IN THIS PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATE
COMPONENTS IN WHICH SAFETY CAN BE OF SPECIAL SIGNIFICANCE. IT IS PARTICULARLY RECOMMENDED
THAT ONLY PARTS DESIGNATED ON THE FOLLOWING PARTS LIST BE USED FOR COMPONENT REPLACEMENT
DESIGNATED BY A STAR. NO DEVIATIONS FROM RESISTANCE,WATTAGE, AND VOLTAGE RATINGS MAY BE MADE
FOR REPLACEMENT ITEMS DESIGNATED BY A STAR.
Schematic
Location Part No. Description Schematic
Location Part No. Description
Note: Schematic part location numbers may not always match with the part descriptions.
The part descriptions are correct and should be used.
CAPACITORS
NOTES:
Read description of the Capacitor as follows:
(Example)
CERAMIC 100P K 50V
Rated Voltage
Tolerance Symbols:
less than 10PF
A . .Not specified
B . .±0.1PF C . .±0.25PF
D . .±0.5PF F . .±1PF
G . .±2PF R . .+0.25 - 0PF
S . .+0 - 0.25PF E . .+0 - 1PF
more than 10PF
A . .Not specified
B . .±0.1% C . .±0.25%
D . .±0.5% F . .±1%
G . .±2% H . .±3%
J ..±5% K . .±10%
L ..±15% M . .±20%
N . .±30% P . .+100 - 0%
Q . .+30 - 10% T . .+50 - 10%
U . .+75 - 10% V . .+20 - 10%
W .+100 - 10% X . .+40 - 20%
Y . .+150 - 10% Z . .+80 - 20%
Rated Value: P...Pico Farad U...Micro Farad
Material:
CERAMIC . . . . . .Ceramic
MT-PAPER . . . . .Metalized Paper
POLYESTER . . .Polyester
MT-POLYEST . .Metalized Polyester
POLYPRO . . . . .Polypropylene
MT-POLYPRO . .Metalized Polypropylene
COMPO-FILM . .Composite Film
MT-COMPO . . . .Metalized Composite
STYRENE . . . . . .Styrene
TA-SOLID . . . . . .Tantalum Solid
AL-SOLID . . . . . .Aluminum Solid
ELECT . . . . . . . .Electrolytic
NP-ELECT . . . . .Non-Polarized Electrolytic
OS-SOLID . . . . .Aluminum Solid with Organic
Semiconductive Electrolytic
C002 403 296 9502 ELECT 100U M 16V
403 391 5102 ELECT 100U M 16V
C003 403 184 8402 ELECT 4.7U M 25V
403 391 5706 ELECT 4.7U M 25V
C006 404 087 2702 ELECT 470U M 25V
C007 404 087 2702 ELECT 470U M 25V
C021 403 345 6605 CERAMIC 1U Z 10V
C022 403 224 5903 CERAMIC 3300P K 50V
C023 403 345 6605 CERAMIC 1U Z 10V
C024 403 224 5903 CERAMIC 3300P K 50V
C026 403 364 5900 CERAMIC 0.22U K 16V
C027 403 364 5900 CERAMIC 0.22U K 16V
C028 403 364 5900 CERAMIC 0.22U K 16V
C029 403 364 5900 CERAMIC 0.22U K 16V
C041 404 087 2702 ELECT 470U M 25V
C108 403 184 8501 ELECT 2.2U M 50V
403 398 6508 ELECT 2.2U M 50V
C109 403 235 6203 CERAMIC 0.01U Z 50V
C112 403 224 6306 CERAMIC 0.033U Z 50V
C114 403 408 6207 NP-ELECT 10U M 16V
C601 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C603 403 224 6306 CERAMIC 0.033U Z 50V
C605 403 224 6306 CERAMIC 0.033U Z 50V
C606 403 235 1109 CERAMIC 270P J 50V
C607 403 224 6009 CERAMIC 4700P K 50V
C608 403 224 6009 CERAMIC 4700P K 50V
C609 403 224 6009 CERAMIC 4700P K 50V
C618 403 296 9502 ELECT 100U M 16V
403 391 5102 ELECT 100U M 16V
C619 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C631 404 087 2702 ELECT 470U M 25V
C632 404 087 2702 ELECT 470U M 25V

— 19 —
Schematic
Location Part No. Description
C633 403 279 0106 CERAMIC 0.1U Z 25V
C634 403 279 0106 CERAMIC 0.1U Z 25V
C641 404 084 2903 ELECT 1000U M 16V
C644 403 309 1400 CERAMIC 1.0U Z 10V
403 336 5600 CERAMIC 1.0U Z 10V
C645 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C647 404 087 2702 ELECT 470U M 25V
C656 403 279 0106 CERAMIC 0.1U Z 25V
C657 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C658 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C659 403 279 0106 CERAMIC 0.1U Z 25V
C661 404 084 2903 ELECT 1000U M 16V
C663 403 309 1400 CERAMIC 1U Z 10V
403 336 5600 CERAMIC 1U Z 10V
C666 404 087 2702 ELECT 470U M 25V
C671 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C672 403 279 0106 CERAMIC 0.1U Z 25V
C673 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C674 403 279 0106 CERAMIC 0.1U Z 25V
C676 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C677 403 279 0106 CERAMIC 0.1U Z 25V
C678 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C679 403 279 0106 CERAMIC 0.1U Z 25V
C681 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C682 403 279 0106 CERAMIC 0.1U Z 25V
C683 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C684 403 279 0106 CERAMIC 0.1U Z 25V
C686 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C687 403 279 0106 CERAMIC 0.1U Z 25V
C688 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C689 403 279 0106 CERAMIC 0.1U Z 25V
C803 403 279 0106 CERAMIC 0.1U Z 25V
C804 403 279 0106 CERAMIC 0.1U Z 25V
C806 403 279 0106 CERAMIC 0.1U Z 25V
C811 403 387 5109 ELECT 220U M 6.3V
403 394 9305 ELECT 220U M 6.3V
C851 403 235 0607 CERAMIC 100P J 50V
C852 403 345 6605 CERAMIC 1U Z 10V
C854 403 309 1400 CERAMIC 1U Z 10V
403 336 5600 CERAMIC 1.0U Z 10V
C861 403 393 2109 CERAMIC 4.7U K 6.3V
C862 403 393 2109 CERAMIC 4.7U K 6.3V
C876 403 309 1400 CERAMIC 1U Z 10V
403 336 5600 CERAMIC 1.0U Z 10V
C877 403 279 0106 CERAMIC 0.1U Z 25V
C886 403 235 6203 CERAMIC 0.01U Z 50V
C1001 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C1002 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C1005 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C1007 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C1008 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C1201 403 235 6203 CERAMIC 0.01U Z 50V
C1202 403 235 6203 CERAMIC 0.01U Z 50V
C1204 403 296 9502 ELECT 100U M 16V
403 391 5102 ELECT 100U M 16V
C1206 403 408 6207 NP-ELECT 10U M 16V
C1600 403 309 1400 CERAMIC 1U Z 10V
C1601 403 309 1400 CERAMIC 1U Z 10V
 C1602 404 096 0508 MT-POLYEST 0.1U M 275V
 C1603 404 096 0508 MT-POLYEST 0.1U M 275V
C1604 403 370 1507 CERAMIC 0.1U K 50V
C1605 403 222 1303 CERAMIC 1000P K 1K
403 262 1806 CERAMIC 1000P K 1K
403 271 9602 CERAMIC 1000P K 1K
C1606 403 222 1303 CERAMIC 1000P K 1K
403 262 1806 CERAMIC 1000P K 1K
403 271 9602 CERAMIC 1000P K 1K
C1607 403 370 1507 CERAMIC 0.1U K 50V
C1608 404 075 5005 ELECT 470U M 200V
404 096 2700 ELECT 470U M 200V
C1609 403 235 5404 CERAMIC 1500P K 50V
C1610 403 370 1507 CERAMIC 0.1U K 50V
C1611 403 420 8401 ELECT 47U M 50V
C1612 403 235 4902 CERAMIC 470P K 50V
C1613 403 222 1303 CERAMIC 1000P K 1K
403 262 1806 CERAMIC 1000P K 1K
403 271 9602 CERAMIC 1000P K 1K
C1614 403 419 9501 ELECT 1000U M 35V
C1615 403 419 9501 ELECT 1000U M 35V
C1617 403 419 9501 ELECT 1000U M 35V
C1618 403 222 1907 CERAMIC 2200P K 1K
403 232 0204 CERAMIC 2200P K 1K
403 263 6305 CERAMIC 2200P K 1K
C1619 403 222 1303 CERAMIC 1000P K 1K
403 262 1806 CERAMIC 1000P K 1K
403 271 9602 CERAMIC 1000P K 1K
C1620 403 222 1303 CERAMIC 1000P K 1K
403 262 1806 CERAMIC 1000P K 1K
403 271 9602 CERAMIC 1000P K 1K
C1621 403 180 1605 MT-POLYEST 0.1U K 400V
C1622 403 419 9303 ELECT 1000U M 25V
Schematic
Location Part No. Description

— 20 —
Schematic
Location Part No. Description Schematic Location Part No. Description
C1623 403 419 9303 ELECT 1000U M 25V
C1624 403 419 9402 ELECT 680U M 25V
 C1625 404 088 2909 CERAMIC 1000P M 250V
C1626 404 084 3405 ELECT 1000U M 25V
C1628 404 084 2408 ELECT 470U M 6.3V
 C1629 404 088 2909 CERAMIC 1000P M 250V
 C1630 404 088 2909 CERAMIC 1000P M 250V
C1632 403 233 0807 ELECT 10U M 50V
C1831 403 279 0106 CERAMIC 0.1U Z 25V
C1832 403 387 5307 ELECT 47U M 6.3V
403 392 1202 ELECT 47U M 6.3V
C1899 403 279 0106 CERAMIC 0.1U Z 25V
C1962 403 393 2109 CERAMIC 4.7U K 6.3V
C1963 403 393 2109 CERAMIC 4.7U K 6.3V
C2001 403 279 0106 CERAMIC 0.1U Z 25V
C2002 403 235 6203 CERAMIC 0.01U Z 50V
C2003 403 279 0106 CERAMIC 0.1U Z 25V
C2004 403 387 5307 ELECT 47U M 6.3V
403 392 1202 ELECT 47U M 6.3V
C2006 403 279 0106 CERAMIC 0.1U Z 25V
C2007 403 224 5804 CERAMIC 2200P K 50V
C2008 403 387 5307 ELECT 47U M 6.3V
403 392 1202 ELECT 47U M 6.3V
C2009 403 235 6203 CERAMIC 0.01U Z 50V
C2011 403 279 0106 CERAMIC 0.1U Z 25V
C2012 403 224 5507 CERAMIC 22P J 50V
C2013 403 234 9809 CERAMIC 18P J 50V
C2014 403 224 5705 CERAMIC 1000P K 50V
C2016 403 235 6203 CERAMIC 0.01U Z 50V
C2017 403 235 6203 CERAMIC 0.01U Z 50V
C2018 403 279 0106 CERAMIC 0.1U Z 25V
C2019 403 387 5109 ELECT 220U M 6.3V
403 394 9305 ELECT 220U M 6.3V
C2021 403 279 0106 CERAMIC 0.1U Z 25V
C2022 403 235 6203 CERAMIC 0.01U Z 50V
C2023 403 235 6203 CERAMIC 0.01U Z 50V
C2024 403 235 6203 CERAMIC 0.01U Z 50V
C2026 403 279 0106 CERAMIC 0.1U Z 25V
C2027 403 387 5109 ELECT 220U M 6.3V
403 394 9305 ELECT 220U M 6.3V
C2028 403 279 0106 CERAMIC 0.1U Z 25V
C2029 403 235 6203 CERAMIC 0.01U Z 50V
C2031 403 235 6203 CERAMIC 0.01U Z 50V
C2032 403 235 6203 CERAMIC 0.01U Z 50V
C2033 403 235 6203 CERAMIC 0.01U Z 50V
C2034 403 235 6203 CERAMIC 0.01U Z 50V
C2036 403 235 6203 CERAMIC 0.01U Z 50V
C2037 403 235 0409 CERAMIC 68P J 50V
C2038 403 387 5109 ELECT 220U M 6.3V
403 394 9305 ELECT 220U M 6.3V
C2039 403 279 0106 CERAMIC 0.1U Z 25V
C2041 403 235 6203 CERAMIC 0.01U Z 50V
C2042 403 235 6203 CERAMIC 0.01U Z 50V
C2043 403 235 6203 CERAMIC 0.01U Z 50V
C2044 403 279 0106 CERAMIC 0.1U Z 25V
C2046 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C2047 403 235 6203 CERAMIC 0.01U Z 50V
C2048 403 235 6203 CERAMIC 0.01U Z 50V
C2049 403 235 6203 CERAMIC 0.01U Z 50V
C2051 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C2052 403 279 0106 CERAMIC 0.1U Z 25V
C2053 403 235 6203 CERAMIC 0.01U Z 50V
C2054 403 387 4904 ELECT 100U M 6.3V
403 394 1309 ELECT 100U M 6.3V
C2056 403 279 0106 CERAMIC 0.1U Z 25V
C2057 403 279 0106 CERAMIC 0.1U Z 25V
C2058 403 279 0106 CERAMIC 0.1U Z 25V
C2061 403 235 0607 CERAMIC 100P J 50V
C2098 403 279 0106 CERAMIC 0.1U Z 25V
C2099 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C2101 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C2102 403 234 9700 CERAMIC 12P J 50V
C2103 403 234 9601 CERAMIC 15P J 50V
C2104 403 234 9908 CERAMIC 27P J 50V
C2106 403 364 7508 CERAMIC 10P J 50V
C2107 403 235 0409 CERAMIC 68P J 50V
C2108 403 396 6302 CERAMIC 0.47U Z 16V
C2121 403 396 6302 CERAMIC 0.47U Z 16V
C2122 403 234 9700 CERAMIC 12P J 50V
C2123 403 234 9601 CERAMIC 15P J 50V
C2124 403 234 9908 CERAMIC 27P J 50V
C2126 403 364 7508 CERAMIC 10P J 50V
C2128 403 279 0106 CERAMIC 0.1U Z 25V
C2141 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C2142 403 364 7508 CERAMIC 10P J 50V
C2143 403 364 7508 CERAMIC 10P J 50V
C2144 403 234 9601 CERAMIC 15P J 50V
C2146 403 364 7508 CERAMIC 10P J 50V
C2148 403 396 6302 CERAMIC 0.47U Z 16V
C2161 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C2162 403 364 7508 CERAMIC 10P J 50V
C2163 403 364 7508 CERAMIC 10P J 50V
C2164 403 234 9601 CERAMIC 15P J 50V
C2166 403 364 7508 CERAMIC 10P J 50V
C2168 403 396 6302 CERAMIC 0.47U Z 16V
C2181 403 175 7209 ELECT 10U M 16V
403 391 5508 ELECT 10U M 16V
C2182 403 364 7508 CERAMIC 10P J 50V
C2183 403 364 7508 CERAMIC 10P J 50V
C2184 403 234 9601 CERAMIC 15P J 50V
C2186 403 364 7508 CERAMIC 10P J 50V
C2188 403 396 6302 CERAMIC 0.47U Z 16V
