Sapho TM62 User manual
Display description
Activated mode Bath filled with water Empty bath
All functions off Actual time + both dots flashing
All functions off Actual time + one dot flashing
Filling Counting time since the start of filling the bath with water
Drying Drying time countdown 20-0s
Disinfectant
backwash
StreamClean
Letter H(Hygiene) and the cycle countdown (4
min:10s-0s) are shown. The Flashing letter H
means insufficient disinfectant solution (it is
necessary to refill the disinfectant solution into
the disinfectant tank).
Enabled massage Actual time – bath water temperature –
run time of the first enabled function are
rotated every 3 seconds
Heating enabled –
heating off
Lower horizontal line of the first sign
flashes when the water temperature is
shown. If the water temperature in the
bath is above the set temperature or if
the hydro-massage is disabled, the
heating is off.
Heating enabled –
heating on
The lower horizontal line of the first
sign (when the water temperature is
shown) and a dot between the first and
the second sign flash.
3
User’s manual for operating hydrotherapeutic massage
system Lux – Whirlpool, Airpool, Combipool
10+
SAPHO Hydro & Air s.r.o.
Mělnická 87
250 65 Líbeznice
Manufacture and sale of hydrotherapeutic systems
www.sapho-hydroandair.cz
www.hydromasaze.cz
e-mail: [email protected]
servis tel.: +420 283 090 770
tech. podpora tel.: +420 283 090 770
tech. podpora tel.: +420 283 090 759
tel.: +420 774 715 012
fax.: +420 283 090 771
This electronically controlled system is among the
best on the hydrotherapy market. The Lux system is
electronically controlled including electronically
controlled water massage (control of pump
revolutions is a unique function of this system) which
gives you a maximum experience from the bath and
maximum therapeutic effect.
The TM62 controller has the following functions (functions are optional according to the system
configuration):
•Hydro (water) massage
•Air massage (eventually Hydro and Air combined)
•Pulsation
•Electronically controlled compressor (Airpool) and pump (Whirlpool)
•Disinfectant backwash system StreamClean / with automatic filling (filling is optional)
•Illumination (LED/halogen)
•Chromotherapy
•Water heating
•Electronic control with display gives you possibility to set actual time, massage time and water
temperature.
Description of controller buttons
Button description (function after pressing the button)
Figure Bath filled with water Bath without water
Illumination halogen/LED
1. press – turn illumination on
2. press – turn illumination off
Chromotherapy
1. Press the control button shortly (<1s)
(activation of chromotherapy from disabled
mode) to enable chromotherapy, that
shines with the last selected colour (the
colour that shone at the moment when the
chromotherapy was last turned off).
2. Press the control button for a longer while
(about 2s) (in the disabled mode). When
the button is released, the chromotherapy
goes into the cyclical colour change mode,
another short press of the button stops the
cycle at the desired colour
3. You can enter cyclical colour change mode
directly when in disabled mode by quickly
double pressing the button.
The chromotherapy can be disabled only in the
selected colour mode (not in the cyclical colour
change mode) by shortly pressing the button.
StreamClean backwash
Double pressing the button (from safety
reasons) activates the disinfectant system with
backwash of hosepipes
Cycle after double pressing the button
1. The disinfectant solution pump runs for
30s.
2. After 5s from the start of the
disinfectant solution pump, the pressure
water valve is enabled for 25s and the
whole system is being backwashed with
a mixture of water and disinfectant
solution.
3. The pressure water and the disinfectant
solution pump are turned off; water
flows freely from the nozzles into the
bath and the disinfectant solution works
for 60s.
4. The pressure water is turned on for 40s.
It rinses the system thoroughly with
clean water.
5. The pressure water is turned off; water
flows freely from the nozzles for 60s
6. The drying (compressor) is turned on
for 60s; the system is dry and ready to
be used.
1
Button description (function after pressing the button)
Figure Bath filled with water Bath without water
Water heating
1. press – turn water heating on (water
heating works only when hydro-massage
is turned on)
2. press – turn water heating off
Double press (when massage systems are
turned off) to change the set temperature of the
thermostat (the set value is flashing); the
temperature can be adjusted by pressing and
buttons. Another double press sets the
temperature. The default value is set to 36°C.
Central system shut down
Press for a long time to turn off all functions
Setting the thermostat temperature
Double press to change the set temperature (the
set value is flashing), the temperature can be
adjusted by pressing and buttons. Another
double press sets the temperature. The default
value is se to 36°C.
Central system shut down
Press for a long time to turn off all functions
Hydro-massage
1. press – turn on water massage
2. press – turn on water massage cycling
3. press – turn off water massage
Double press (when the massage systems are
turned off) to set the length of massage (5min.
appears)
increases the time in steps (5,10,15,20 and
again 5)
decreases the time by 1min.
Bath filling
Enables the automatic bath filling with water at the
temperature set on the thermostat and to the height
of a water level sensor (approximately at the lower
edge of the safety overflow). The maximum filling
time is set to 10min as a safety measure against
overflowing. If you need to add water into an
already filled bath, it necessary to use bath taps or
shower.
Airpool (air massage)
1. press – turn on air massage
2. press – turn on air massage cycling
3. press – turn off air massage
Double press (when the massage systems are
turned off) to set the length of massage (5min.
appears)
increases the time in steps (5,10,15,20 and
again 5)
decreases the time by 1min
Drying
Enables drying of air massage distribution system
with slow start of compressors. The drying time is
set to 20s.
Repressing the button again turns off the drying
earlier.
Setting revolutions of compressor or pump
Increases intensity of water/air massage. If
both water and air massages are running, sets
intensity of the last started.
Setting actual time
1. Double press (hours are flashing) to adjust
the value using , .
2. Double press to accept the set value
Setting revolutions of compressor or pump
Decreases intensity of water/air massage. If
both water and air massages are running, sets
intensity of the last started.
Setting actual time
1. Double press (minutes are flashing) to
adjust the value using , .
2. Double press to accept the set value
Notice The maximum bath time is set to 20min. This is also a recommended length of a massage. After
that, you have to turn the massage on again by pressing the appropriate button.
Soft reset In case of a non-standard behaviour of the electronic controller, press and hold and press ,
then release both buttons. If the problem has not been solved, it is necessary to unplug the power
to the bath and after a while plug it in again.
Hard reset In case the Soft reset has not helped to solve the non-standard behaviour of the electronic
controller, disconnect the power to the bath and reconnect it after a while.
