Sapphire Sleep 300 User manual

Model 300 Adjustable Base User's Manual
P/N: SS300-XX
THIS MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE
Serial Number:
REV: 03/19

TABLE OF CONTENTS
1. Cover
2. Table of Contents
3. Limited Warranty
4. Features of the SS300 Adjustable Base
5. Important Safety Information
6. Quick Assembly Guide
7. Quick Assembly Guide (continued)
8. Components for Assembly and Operation
9. Power Cord Setup with Master Control Box
10. Attaching Adjustable Legs
11. Joining Two Adjustable Bases
12. Mattress Retainer Bar
13. Headboard & Footboard Brackets Installation (Optional Accessory)
14. Remote Control Frequency Set-up
15. Synchronizing Two Adjustable Bases
16. Remote Control Features
17. Test All Functions
18. Emergency Battery Back Up
19. Weight Recommendations and Limits
20. Operating Noises
21. Troubleshooting Guide
22. Troubleshooting Component Guide
2

10 Year Limited Warranty
FULL 1-YEAR WARRANTY: The SS300 Adjustable Base is warranted against defects in materials or workmanship for a period of one year from the date of purchase to the original purchaser.
During the first year, South Bay International will repair or replace, at no cost to the original purchaser, any defective part. This includes all authorized labor and transportation costs incurred with the
repair or replacement of any parts found to be defective.
2YEAR MOTOR WARRANTY: The SS300 Adjustable Base has a two year, full replacement warranty, parts, labor and transportation; on the motor should the motor(s) fail during the first two years
of this warranty from the original purchase date
5YEAR WARRANTY: During year 2 through year 5, from the original purchase date, South Bay International will replace any bed part, to the original purchaser, found to be defective. The part must
be returned within fourteen (14) days of receipt of the replacement part(s) or purchaser may be subject to charges for said part(s) to include, but not limited to freight charges Liability of South Bay
International is limited to the replacement of the defective part or parts ONLY with purchaser responsible for all service, installation and transportation costs of said part(s).
10 YEAR LIMITED WARRANTY: During year 6 through year 10 from the original purchase date, South Bay International will replace, per the terms and conditions set forth in this paragraph, any bed
part found to be defective. Purchaser shall pay 1/180 of the current replacement cost of the defective part multiplied by the number of months, after the fifth (5th) year, from the original purchase
date. This warranty applies only to replacement part(s). Purchaser may be subject to charges for said part(s) to include, but not limited to, freight charges. Liability of South Bay International shall
be limited to the replacement of the defective part(s) only with purchaser responsible for all service, installation and freight costs of said part(s)
ADDITIONAL TERMS ANO CONDITIONS: Warranty does not include reimbursement for inconvenience, removal, installation, set up, loss of use, shipping, or any other costs or expenses not
expressly covered in this warranty. This warranty does not apply:
• To damage resulting from misuse or abuse caused by the purchaser.
• To damage caused by the repairs or parts replacement by an authorized person.
• If the SS300 Adjustable Base has been mishandled (including during shipping), subject to physical abuse or an improper power supply, or otherwise operated in a manner inconsistent with
procedures outlined in the owner's manual and warranty.
• To damage to mattresses, bedding, cables, electrical cords, or accessories supplied by dealers.
• To modification of the SS300 Adjustable Base without prior written consent by South Bay International.
• To costs for unauthorized service calls for the purpose of educating the consumer about the SS300 Adjustable Base or locating properly functioning power outlets.
• If the recommended weight restrictions are exceeded.
• If used in any environment or a commercial setting for which it was notintended
Some states do not allow the exclusion of incidental or consequential damages; therefore the above limitation or exclusion may not apply This warranty gives the purchaser specific legal rights. The
Purchaser may have the other rights, which may vary from state to state. This warranty is valid in the 48 continuous states.
WORKING WEIGHT LIMITS: Although your SS300 Adjustable Base has been rigorously tested within the recommended limits in this publication, to maintain the highest quality standards,
exceeding the recommended weight limits may void your warranty. The recommended weight restriction is 750 lbs,and is calculated to include the weight of the mattress.
If for any reason at all you have any questions with regards to your product or limited warranty, please don't hesitate to call us at 877-622-6550.
3
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday

Features of the SS 300 Adjustable Base
Head and foot up/down positions
Head and foot massage at 3 intensities
USB charging ports
14 button wireless remote control
Under bed lighting
Pre-programmed positions: anti-snore, zero gravity, and flat position
Programmable positions: I, II and Ill
Six legs with customizable heights
Undercarriage is made with reinforced steel components for strength and durability
Emergency backup battery box
Mattress foot retainer bar
Contact customer service to purchase accessories:
Amazon Alexa dongle for voice control
Head and footboard brackets
Note: This base is designed to fit within a standard bedframe.
Thelegs must be installedonto the adjustable base; the base willnot operate properly without them. Legs
MUST beaMINIMUM of 6" toallow
for articulating clearance. IMPORTANT: Using ONLY one 3" segment of the leg will result in damage to the base, void the warranty for
improper use and may causedamage to the floor. Ensure all 6 legs are installed prior to use.
4
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday

Important Safety Information
5
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
PLEASE READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE USE AND ASSEMBLY
Safety Information:
Only use the adjustable bed base for its intended use as described in this manual. Follow the guidelines below for your safety, the safety of others and to avoid risk of
electrical shock, fire, burns or injury:
•
Avoid fingers in pinch-points.
•
Two or more adults is strongly recommended for moving and assembling of adjustable bed
base. Plug adjustable bed base into a surge protector (not included) or directly into a suitable
wall outlet.
•
If the plug does not fit your outlet, contact a qualified electrician to install a suitable outlet. Unauthorized modification or failure to use a proper power source
•
or surge protector will void the electrical portion of your
warranty. Keep power cords away from heated surfaces.
•
To safely disconnect, ensure the base is in a flat position with all motors off. and unplug from power source.
Always unplug the base from the electrical outlet before cleaning or servicing.
•
Discontinue use of the bed base and contact a qualified service center if: it has a damaged cord or plug, is not working properly, or has been dropped into
water. Do not place the adjustable bed base or any of its components near or in water.
• Do not drop or insert objects into any opening. Never operate the base when the air openings are blocked.
•
Do not open or tamper with control box, motors, or remote (with the exception of battery compartments) - this will void the
warranty. Do not use accessories/attachments that are not recommended by the manufacturer.
•
Exceeding this weight restriction could damage the bed and/or cause injury and will void the warranty.
•
Do not operate the adjustable bed base when a person or animal is underneath the adjustable bed base.
Mattresses may move or shift on bases - use caution.
VIOLATING ANY OF THE SAFETY INFORMATION WILL VOID THE WARRANTY AND MAY RESULT IN INJUR Y
In-Home Use:
The adjustable base is designed solely for in-home use. This base was not designed as a hospital bed and is not designed to meet hospital standards.
Do not use this base with TENT TYPE oxygen therapy equipment or near explosive gases.
Operation and Supervision:
Closesupervision is required when the bed base is used by or near children, animals, convalescents or disabled persons. Immediately dispose of all packing materials as
they may pose a smothering risk to small children and pets. To avoid injury,do not allow children or small pets to play on or under the adjustable bed base.

6
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
Quick AssemblyGuide
NO TOOLS REQUIRED FOR ASSEMBLY
STEP 1: Unpack the adjustable base by carefully cutting the plastic bag to remove the adjustable base. Unfold the
base carefully as the parts for assembly may have shifted during shipping. Remove the silver retainer bar and
cardboard boxes attached to the base. See Components for Assembly and Operation on Page 8.
STEP 2a: CAREFULLY turn the adjustable bed base on its side (it may require two people to do this) and ensure that
all wires are connected. They might have become disconnected during shipment, See Power Cord Setup with Master
Control Box on Page 9. NOTE: Only put batteries into the Emergency Back-Up battery box during an electrical outage
and after the power cord is unplugged from the wall.
STEP 2b: If the headboard and footboard attachment kit was purchased please refer to Headboard & Footboard
Brackets Installation (Optional Accessory) on Page 13 and begin installation of brackets. Also if using the Split King
Base, locate the Connector Brackets and refer to the instructions for Joining Two Adjustable Bases on Page 11
for installation.
STEP 3: Locate the legs and choose one of the three heights of the leg, See Figure A on page 8. Make sure the leg
with the plastic cup is touching the floor. Screw the six legs into the pre-drilled holes by hand, See Attaching Adjustable
Legs on Page 10. The legs must be installed onto the adjustable base; the base will not operate properly without them.

7
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
Quick AssemblyGuide
STEP 4a: Locate the wireless remote control and insert 3 AAA batteries (included). The remote control is
pre-programmed to work with the adjustable bed. If you have more than one adjustable bed, each remote control and
adjustable bed set should be pre-programmed to work separately. This will prevent both beds from being controlled by
one wireless remote control. See Remote Control Frequency Setup on Page 14 if you have more than one wireless
remote control/base combination.
STEP 4b: If you would like to synchronize a split base together See Synchronizing Two Adjustable Bases on Page 15.
STEP 5: Install the mattress retainer bar, refer to the instructions for the Mattress Retainer Bar on Page 12.
STEP 6: CAREFULLY place the bed back on all six legs and plug the base into a power outlet
STEP 7: Test all functions instructions on Page 17. If the bed fails to work once plugged in, reset the remote control
frequency using the instructions on Page 14.
STEP 8: Place a mattress on the adjustable base once the bed is plugged in and functioning correctly. NOTE: Use a
memory foam, latex or acceptable hybrid at least 8" inches in height.

8
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
Components forAssembly and Operation
A: (6) Four-piece adjustable legs
B: (1) Wireless back-lit remote with (3) AAA batteries included per base
C: (1) Foot retainer bar with (2) wing-nuts per base
D:(1) Simultaneous SynchronizationCable (Onlyincluded withTwin XL/CKS bases)
E (1) Back-up battery pack
F: (1) AC/DC power adapter per base
G: (1) Power cord: Input voltage 100-240V per base
H: (1) Split King Base Connecting Bracket (Only included with Twin XL/CKS bases)

9
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
PowerCordSetupwithMasterControlBox
AC/DC Power Adapter
Master Control Box Power Cord
Input Voltage 100-240V
Battery Back Up Box

10
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
AttachingAdjustable Legs
The legs must be installed onto the adjustable base; the base will not operate properly without them. Legs MUST be a MINIMUM of 6" to allow for articulating clearance.
IMPORTANT: Using ONLY one 3" segment of the leg will result in damage to the base, void the warranty for improper use and may cause damage to the floor.
Ensure all 6 legs are installed prior to use.

11
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
Joining Two Adjustable Bases

12
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
Mattress Retainer Bar
To Install the mattress retainer bars:
STEP 1: Locate the chrome mattress retainer bar in the packaging.
STEP 2: At the foot of the base, there are two openings to insert the mattress retainer bar. Slide the large retainer bar
into the opening at the foot of the bed.
STEP 3: Secure the retainer bar with the included wing-nuts. This will hold the mattress retainer bar in place.
See Figure 1 and Figure 2 below.
Figure 1 Figure 2

13
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
Headboard & Footboard Brackets Installation (Optional Accessory)

14
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
Remote Control Frequency Set-up
This process is used when the remote control is not communicating with the bed (the base is not responding by moving when the
remote control is activated).
STEP 1: Unplug the adjustable base that is not being programmed.
STEP 2: While the bed that is being programmed is plugged in, remove the battery cover on the back of the remote control.
STEP 3: Double click the switch on the control box. At this time, the light will illuminate.
STEP 4: Press and hold button on the back of the remote. The light will begin to flash.
STEP 5: Both lights on the Control Box and Remote will be continuous, then simultaneously turn off. For Cal King and King Split sets
please see additional step below. If the bed is not a split set replace the cover of the remote - pairing is complete.

15
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
Synchronizing Two Adjustable Bases
This process programs two adjustable bases to be controlled at the same time by either remote control. This allows for
synchronized control of the two bases.
STEP 1: Unplug base from power source.
STEP 2: Connect the male end of the simultaneous synchronization cable into the splitter for each control box, use any
open slot on the splitter. Do not disconnect any other cords connected to the splitter, this will cause other features on
the base to malfunction.
STEP 3: Plug base back into the power source.
STEP 4: Check to ensure all cords are securely attached. Both remotes will now operate both bases simultaneously.
Master Control Box Master Control Box
Splitter Sync Cord Splitter

16
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
Remote Control Features
HeadMassage:3 Intensities
FootMassage:3 Intensities
Under bed Light
Head Up/Down
Programmable Position 1
Head & Foot Massage:3 Intensities
Anti-Snore
Zero Gravity Position
Foot Up/Down
Flat Position
Programmable Position 3
Programmable Position 2
Programming button I, II, or Ill: Get into desired adjustable base position, hold button for 5 seconds.
This customized position is now saved.

17
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday
TestAllFunctions
• Head & foot up/down positions
• Head & foot massage at three intensities
• USB charging ports for power
• Pre-programmed positions: anti-snore, zero gravity, and flatposition
• Programmable positions: I, II, and Ill buttons
• Under Bed Lighting

Emergency Battery Back Up
In case of a power failure, the SS300 Adjustable Base features an emergency backup feature that allows you to
return the bed to the flat position without power.
Step 1: Unplug the adjustable base.
Step 2: Locate the Emergency Battery Back Up Box that is attached to the power cord.
Step 3: Insert four 9 Volt alkaline batteries (not included) into the battery box.
Step 4: Press and hold the emergency button on the body of the control box to flatten the bed.
Step 5: Immediately remove the four 9-volt batteries after the base is returned to the flat position. The four 9-volt
batteries must be removed before power is restored to the adjustable bed base.
NOTE: Leaving in the 9 Volt batteries in the Emergency Battery Back Up Box after power has been
restored will cause the electrical components to short out and damage the master controller.
18
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday

Weight Recommendations and Limits
The recommended weight restriction for the SS300 Adjustable Base is 750 pounds, which is calculated to include the
weight of the mattress. In order to calculate the weight limit, subtract the weight of the mattress from 750 pounds. The
bed will support the recommended weight limits if distributed evenly across the base. This product is not designed to
support or lift the total maximum weight limit by the head or the foot section only. Consumers should not enter or exit
the bed with any portion of the adjustable bed base in the raised position. Always return the adjustable bed base to a
flat position before entering or exiting the bed. Do not sit on the head or foot section of the bed while the bed is in a
raised position. If the weight limit is exceeded on the head or foot mechanism, the master controller will stop all
functions. Exceeding the recommended weight restrictions could damage the bed and void the warranty.
19
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm PDT Monday - Friday

Operating Noises
The SS300 Adjustable Base comes with a massage feature. The massage function emits a noticeable tone during
operation. As the massage intensity level is increased, the tone will intensify. The noise will be less audible on a
carpeted floor and a bit more noticeable when on a hard floor surface.
During typical operation, the wheels, which allow the bed to articulate, will make contact with the steel platform
supports of the base creating a contact noise. When entering, exiting or shifting weight on the base, this contact noise
may be audible as the wheels make contact with the steel platform supports of the base. This is normal.
20
Need Assistance? Call us at 1-877-622-6550 from 8:00am to 5:00pm POT Monday - Friday
