Introduction
1
1 INTRODUCTION
1. 1 About the BC1X00 product range
The Metrodata Baseband Converter product range offers a transparent interface conversion
between HSSI and EIA-644 LVDS. There are two products in the family, the BC1000 offers
a HSSI DTE interface for connection to a Satellite Modem or other such HSSI DCE device,
whilst the BC1100 provides a HSSI DCE interface for connection to a Router, or other such
HSSI DTE device.
The Baseband Converter operates at data rates up to 51.84MBits and as such enables users
to fully utilise their LVDS interface capabilities.
One application is with an LVDS Serial Encryptor. In order to interface the LVDS to real world
devices, the BC1X00 offers conversion to the HSSI standard as shown below:
Figure 1. 1 BCX00 application
The BC1X00 range of converters has been designed to be plug and go, conforming to
appropriate standards, physically very compact, and rack mountable in sets of 2 using a
dual face plate, or 18 units in a rack mount kit for large installations.
Metrodata are continually developing new models, so if the interface combination required
is not listed in this guide, please contact Metrodata Sales Dept.
1. 2 Safety
Where electrical signal cabling is connected to BC1X00 models, do not connect to cabling
which would be required by BS6701 to be equipped with over-voltage protection.
The following ports are designated SELV (Safety Extra Low Voltage) within the scope of EN
41003:
HSSI port
EIA-644 LVDS DTE port
These ports should only be connected to SELV ports on other equipment in accordance with
EN60950 clause 2.3.
ROUTER
BC1100
Crypto
Satellite
Modem
BC1000
Satellite dish
HSSI
HSSI LVDS LVDS
RED SIDE
BLACK SIDE
LVDS

Introduction
2
1. 3 Electromagnetic Compatibility
In order to ensure EMC compliance all electrical signal and data cables and connectors must
use a screened connector shell with a screened cable. The cable screen must be terminated
to the screened connector shell and not connected to any pins of the connector. Failure to
use the correct connector may compromise EMC compliance.
1. 4 EN55022 Declaration
BC1X00 units are a Class A product. In a domestic environment it may cause radio
interference in which case the user may be required to take adequate measures.
1. 5 FCC Declaration
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at its own expense.
1. 6 RoHS Compliance
The BC1X00 is compliant with the EU RoHS directive 2002/95/EC. The RoHs directive bans
the use of six hazardous materials in products placed on the market after July 1st 2006. The
six banned materials are Lead, Mercury, Hexavalent Chromium, Polybrominated Biphenyls,
Polybrominated Diphenyl Ethers and Cadmium.
To ensure product reliability, the RoHS directive exempts Network Infrastructure Equipment
including the BC range, allowing the use of standard leaded solder; as such the BC range is
manufactured using leaded solder.
1. 7 Power Supply
The BC1X00 is powered by an internal mains-fed power supply. The mains input voltage is
100-250VAC, 50/400Hz with a maximum current of 50mA. The units are fitted with an
internal 1A fuse. Mains power is connected via an IEC inlet on the rear panel.
An alternative -48VDC power supply is available on all units as a custom order item. The
supply definition of the DC supply is minus 36 to minus 72 VDC, 200-100 mA. DC power is
supplied via a 3 pin Buccaneer socket fitted to the rear panel. A Buccaneer plug is supplied
with the unit for customer’s own wiring. The connections are labelled on the rear panel of the
BC1X00 as shown in the schematic below.
Figure 1. 2 Buccaneer DC socket
Pin1
-48V
Pin3
0V
L
_
_

Introduction
3
The power consumption of each model in the range is shown below, together with the current
consumption over the operating voltage ranges.
The BC1X00 must be connected to mains safety earth for correct operation. The BC1X00
power supply should be connected to a supply socket that is physically located close to the
unit and is easily accessible.
Safety Notes: Excessive voltages are present inside the unit. There are no user serviceable
parts inside the unit, and the cover should not be removed by unqualified personnel. The unit
must not be exposed to damp or condensing conditions.
Product Watts Power
Consumption
Current Range mA
for 100-250 VAC
Current Range mA
for -40 to -72 VDC
BC1X00 6.0 50 - 25 200 - 100

BC1X00 hardware
4
2 BC1X00 HARDWARE
2. 1 BC1X00 rear panels
All connections to and from the BC products are made through the rear panel, examples of
which include both DC and AC models are shown below:
Figure 2. 1 BC1X00 range rear panels showing DC and AC models
2. 2 Unpack and inspect the equipment.
The carton should contain a single Metrodata BC1X00 model and for UK shipments only, a
power cable. If there is any visible damage, do not attempt to connect the device. Contact
your Supplier or Metrodata Technical Support for advice and assistance. The rear panels of
typical BC1X00, units are shown above in this section.
Note that the current rating shown on the rear panel label is the maximum current, which
corresponds to the lowest input voltage.
Made in
UK
HSSI DCE (To Router)
EIA-644/LVDS DTE
Pin1
-48V
Pin3
0V
L
_
_
Made in
UK
HSSI DTE (To Modem)
EIA-644/LVDS DCE

BC1X00 hardware
5
2. 3 LVDS EIA-644/LVDS interface
The LVDS interface is presented on a 25-way female D-type connector. The BC1000
presents a DCE interface on a female connector. The BC1100 presents a DTE interface on
a male connector. The rear panel connector layout is shown below:
Figure 2. 2 EIA/LVDS interface for BC1X00
Pin Signal name Symbol Direction
1 Shield
2 Send Data(A) SD(A) To DCE
3 Receive Data(A) RD(A) From DCE
4 Request to Send (A) To DCE
5 Clear to Send (A) From DCE
6 Data Set Ready (A) From DCE
7 Signal Ground Ground
8 Data Carrier Detect (A) RR(A) From DCE
9 Receive Timing(B) RT(B) From DCE
10 Data Carrier Detect (B) RR(B) From DCE
11 Terminal Timing(B) TT(B) To DCE
12 Send Timing(B) ST(B) From DCE
13 Clear to Send (B) From DCE
14 Send Data(B) SD(B) To DCE
15 Send Timing(A) ST(A) From DCE
16 Receive Data(B) RD(B) From DCE
17 Receive Timing(A) RT(A) From DCE
18
19 Request to Send (B) To DCE
20 Data Terminal Ready (A) To DCE
21
22 Data Set Ready (B) From DCE
23 Data Terminal Ready (B) To DCE
24 Terminal Timing(A) TT(A) To DCE
25

BC1X00 hardware
6
2 . 3. 1 HSSI DTE Port
The HSSI interface is presented on a 50-way sub-miniature rear panel connector as per EIA-
613 with the layout shown in the table below.
Figure 2. 3 BC1X00 HSSI interface
Note: The Signals Loopback A/B/C and TM are not used by the BC1X00 with inputs ignored,
and outputs set to the normal operational state OFF.
Pin
(+)
Pin
(-)
Signal Signal name Direction
1 26 SG Signal Ground
2 27 RT Receive Timing(A) To DTE
3 28 CA DCE Available(A) To DTE
4 29 RD Receive Data(A) To DTE
5 30 LC Loopback C To DTE
6 31 ST Send Timing(A) To DTE
7 32 SG Signal Ground
8 33 TA DTE Available(A) To DCE
9 34 TT Terminal Timing(A) To DCE
10 35 LA Loopback A To DCE
11 36 SD Send Data(A) To DCE
12 37 LB Loopback B To DCE
13 38 SG Signal Ground
14 39
15 40
16 41
17 42
18 43
19 44 SG Signal Ground
20 45
21 46
22 47
23 48
24 49 Test Mode To DTE
25 50 SG Signal Ground

BC1X00 hardware
7
2. 4 Configure the BC1X00
The bit-switches on the underside of the unit must be set for the operation you require. The
options for setting up are described in the next section of this guide. Note that set-up
instructions are separately described for the BC1000 and the BC1100.
2. 5 Safety note on port connections
Ports that are identified as SELV in this guide must only be connected to SELV ports on other
equipment in accordance with EN60950 Clause 2.3.
2. 6 Connect the HSSI port.
The HSSI port of the BC1X00 is presented on an industry standard miniature 50 way
connector. The same connector is used for both the BC1000 DTE and BC1100 DCE ports.
HSSI is a fault tolerant interface and should not be damaged by connecting similar port
types- e.g. DTE to DTE or DCE to DCE. In such circumstances, however, normal operation
will not be possible.
2. 7 EIA-644/LVDS port
The LVDS port is presented on a 25-way D type connector. The BC1000 presents a DCE
interface on a female connector. The BC1100 presents a DTE interface on a male connector.
The LVDS interface may be damaged by incorrect connection.

BC1X00 hardware
8
2. 8 Optional rackmounting procedure
Rackmounting kits may be used to mount two BC1X00 units side by side in a 19” rack. The
kit, part number 80-05-256, has a recessed plate to permit cable or fibre bends to be made
within the envelope of the 19” cabinet. It has a cut out to provide access to all the connectors
on the rear panel of the BC1X00.
Figure 2. 4 Twin unit rack mounting
To install the BC1X00 first remove the two rear panel screws securing the unit lid. Fasten
the BC1X00 into the rack mount adaptor plate using the screws just removed. Then secure
the rack mounting plate complete with one or two BC1X00 units into the 19” rack using the
locating holes at the ends of the adaptor plate. Ensure that the bit switches are set correctly
before installing the rack mount kit.
2. 9 Power up the BC1X00.
The unit requires 100-250 VAC, 50-60 Hz AC supply. An alternative -48VDC power supply
is available as a custom order item for all models. See Section 2 for further details of power
consumption.
When the power supply is connected, the green PWR LED on the rear panel should be ON
to indicate that the unit is operational. If the LED is OFF, mains power is not being supplied
to the unit.
Recessed space to accommodate fibre bends
BC1100 BC1000
Part No: 80-05-256
Made in
U K
HSSI DCE (To Router)
EIA-644/LVDS DTE)
Pin1
-48V
Pin3
0V
L
_
_
Made in
U K
HSSI DTE (To Modem)
EIA-644/LVDS DCE)
