Satechi X-pointer SMART User manual

XPR200 User Manual v1.2
(Bluetooth4.0 BLE USB Dongle)
ChoisTechnology Co., Ltd.

1. Product Features
※ In order to use this product, smart device has to support the latest Bluetooth 4.0 BLE.
X-pointer SMART(XPR200) is wireless PC remote control which we are able to use with smart phone
supported Bluetooth 4.0.
If you use the product with X-pointer Mobile(XPS130, XPS200), it can be used as wireless laser presenter.
X-pointer SMART supports Plug and play.(It is available without installing program.)
This is the first mobile phone remote control in the world free from inconvenience such as network set-up.
- Turns your smart device into wireless keyboard, mouse and touch pad of PC
- PC remote control by using smart device
- Full supported presentation function with X-pointer app
- Laser pointing function as it is used with X-pointer Mobile(XPS130, XPS200)
- Supported various function through update for X-pointer app

2. Product Composition
No.
Item
Q’ty
①
XPR200
1EA
②
Usermanual
1EA

3. Product Instructions
<Preparation before use>
First, download X-pointer app(X-pointer SMART) from APP store.
(You could search for app as keyword “X-pointer”)
※ App will be supported in Play store later.
<How to use>
1. Insert X-pointer SMART(XPR200) into USB port of PC.
2. LED in dongle lights up after X-pointer SMART is recognized in PC.
3. Turn on Bluetooth from set-up of smart equipment.
4. Practice X-pointer app.
5. Achieve equipment registration once you finish the user’s process.
6. After registration, if you select “X-pointer SMART”, smart device is connected with product.
7. LED in dongle lights out after connecting X-pointer app and Bluetooth.
8. Ready to use various function for X-pointer SMART
9. PC control using smart device app is possible.
<LED per dongle condition>
Situation
LED
Recognized USB device
Light up
(LED color is green)
Connected USB device
Light out
Received date
Light up and out

<Construction for use>

4. Cautions
Accidents caused by user negligence is not covered by warranty.
Please note the below contents.
1) Do not apply excessive shock, reorganize at your option or use the device for purpose other
than its intended use.
2) Do not expose the device for a long time in direct rays of the sun caused discoloration.
3) Be careful so that liquid such as water, beverage does not enter the device.
4) Keep the device stored between -10~50°C, operating temperature is 10~40°C.
5) Operation will not be able to smooth where many wireless instruments are used.

5. Product Specifications
Division
Contents
CLASS
Bluetooth 4.0 BLE USB HID dongle
Wireless use
distance(m)
Max 30 m (Open Field)
Wireless transmission
device
Bluetooth 4.0 BLE
Frequency
2,402~2,480Mhz
Channels
40CH
Output Power
less than 4mW
Modulation
GFSK
Interface
(PC)
USB 1.1/2.0
Operating system
Windows 2000, XP, Vista, 7, 8, Mac OS X
Power supply
Use for USB power supply( 5 VDC )
Current consumption
Less then 25mA
Weight
10g
Dimension
12 mm X 26 mm
Operating range
Temperature : between 10～50℃, humidity : less than
75%
Storage range
Temperature : between -10～+50℃, humidity : less than
75%
Compatible app
App store : X-pointer SMART
(Supported in play store)

6-1. Certification
The product received certification in accordance with Korea Communications Commission, KCC Regulation.
“This wireless equipment does not service relative to life security since it has possibility for
electric wave confusion.“
1) Product name(Model no.) –X-pointer SMART (XPR200)
2) Certification no. FCC ID : RVBXPR200
3) Company name : Chois Technology Co., Ltd.
4) Manufacturer / Country of origin : Chois Technology Co., Ltd. / The republic of Korea
5) Production date : Marked on box

6-2. Certification
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures :
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
“Note : The manufacturer is not responsible for any Radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.”

7. Customer Support
We will kindly help you in case you have problems or there is something to improve
on the product or its use. Please refer to our contact information as below.
E-mail : [e-mail] TEL : [phone]
Homepage : www.X-pointer.com FAX : [phone]

8. Warranty
Product name
Model number
Serial number
Purchase date
Purchasing office
Customer name
Contact number
E-mail
Address
Consumer injury type
Compensation detail
Within warranty period
After warranty period
Normal use state
In case defect is occurred
Repair for free
Repair for value
In case same defect is occurred two times
Repair for free
Repair for value
In case same defect is occurred more than
three times
Exchange
Repair for value
Consumer’s negligence and
mistake
Breakdown by user’s mistake
Repair for value
Repair for value
Breakdown by product’s optional disassembly,
reorganization of structure, capacity or function
Repair for value
Repair for value
▣Consumer injury compensation standard
(※ After you buy the product, please register a member and product in www.choistec.com.)
1) We are certifying that the product is for ChoisTechnology Co., Ltd.
2) This product has been released through formal approval, quality supervision and inspection regulation.
3) ChoisTechnology Co., Ltd. is in compliance with consumer injury compensation rule by Ministry of Strategy and Finance.
4) This product’s quality warranty period is 1 year, we will repair or replace it for free within 1 year if the product is found to be defective not
user’s mistake.
5) As for below situation within warranty period, it is fixed for value.
- Damage by user’s mistake
- Breakdown and damage through product’s optional disassembly, reorganization of structure, capacity or function
- Trouble and injury for use other than it’s intended purpose
- Breakdown by carelessness such as fall or flooding
- Failure by natural disaster(earthquake, fire, flood damage, the falling of a thunderbolt)
※ Caution : If you need service, please give us the warranty, since it is not to be re-issued, please pay attention to keeping.
(Please register a member at www.X-pointer.com of our website so that you could inquiry although you lose the warranty.)

RF Exposure Statement (2.1091) :
FCC RF Radiation Exposure Statement: This equipment complies with FCC RF Radiation exposure limits set forth for an uncontrolled environment.
This device and its antenna must not be colocated or operating in conjunction with any other antenna or transmitter.
This equipment should be installed and operated with a minimum distance of 0 centimeter between the radiator and your body.
