Preface
The keyboard is a product for professional use in security systems. The keyboard is
applied to remotely control digital multiplexers, DVR, NVR, speed dome cameras and
IP Camera. It’s ergonomic construction guarantees comfortable operation for security
personnel.
•Protocol：PELCOD、PELCO-P、Panasonic、Samsung、AD（TYCO）、DH、VISCA
•Bute rate：1200、2400、4800、9600、19200 ；
•USB 2.0 HID protocol for IP Camera
Features:
•The keyboard can be applied to control CCTV systems, speed dome cameras, DVR,
NVR, IP camera , and personal computer monitoring terminal devices.
•Joystick: 3-axis+1button;
•LCD: two lines of 20 characters, backlight.
•28 keys, silicon rubber + keystroke, one million times long lifetime, backlight;
WARNING:
Do not use such solvent as gasoline or thinner to wipe the appearance to avoid damage;
use a piece of soft cloth dipped with alcohol or water to wipe it.
•Do not contact the keyboard with water or other liquids and keep the appearance
clean.
•The keyboard is only for indoor use. Never expose it in rain or moisture.
•The LCD might not perform normally below -10℃.
•Use the power adapter supply with the keyboard. If a substitute is required,
ensure the power supply is within 9-15V/1000ma.
•Keep away from fire.
•Avoid collision or friction with hard objects.

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
2
FAX: [phone]
IMPORTANT
This product is manufactured to comply with requirements of
following directives:
89/336/EEC, 92/31/EEC, 93/68/EEC
Equipment that can be connected：
Speed dome cameras : (baud rate : 2400, 4800, 9600）
PELCO-D,PELCO-P, Panasonic, AD (TYCO), Samsung, DH, Visca
Digital Video Recorders/Net Video Recorders: (baud rate: 9600）
Hikvision, Dahua, Dali, Hanbang, HighEasy,Ndatel,Hunt(Nichietsr)
Ip camera : USB2.0 (for CMS)
SPECIFICATION
Joystick：3 Axis+1button
Buttons: 28 ALPS button，2color led backlight；
Display: LCD, 2 line，20 characters, blue backlight
Dimensions: 355(L) × 150(W) ×155(H)mm
Weight: 1.47kg (w/o Power supply)
1.89 kg (with Power supply)
2.4kg (prepared for shipping)
Operating Temperature: -10°C - 70°C
Humidity: 30% - 90% (w/o condensation)
Adapter: AC100-240V-12VDC/1000mA
Power consumption: 2.7 W (not loaded line)
Connectors:
RJ45 : matrix or DVR (RS485+RS232)
RS485：connect camera，same as RS422TX，2000M
RS232：connect camera
USB-D: USB2.0 connect PC, server，NVR etc.

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
3
FAX: [phone]
Joystick : 3-Axis+1Button, High Resolution, Long Lifetime
Sensor: Optical Sensor, more than 2 million times；
High Resolution:X、Y axis ±80 Level；Z axis ±14 level
Flexible operate：bearing structure inside，flexible operate，
high sensitivity；
Button LED backlight:
Blue + Red，blue is the button backlight，red is the function
instruction
Joystick：
Direction Control ：More than 8 directions ，0-80 level
speed parameters；
Zoom Control：Button ZOOM：0-14 Level Speed
Simultaneous Control: Joystick control direction and zoom Simultaneously
Joystick Direction Control
Inclination angle Bigger, Pan tilt speed faster

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
4
FAX: [phone]
Zoom Control
ZOOM WIDE ZOOM TELE
Keystroke Backlight:
Two lights below each keystroke: blue and red. Blue is for backlight, and red is for function
indication.
Press one keystroke, the blue light will blink for 1 second, and then the red light for 2
seconds.
Press [DVR] and [CAM], the blue light will blink two times, and the red light will be
constant on to indicate the current status.

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
5
FAX: [phone]
Brief Instructions
Definition:
CAM: Camera
DVR/ESC Digital video recorder/ESC
PRESET: Preset positions
SET: Set presets
DEL: Delete Presets
HOME: Home place
TOUR: Tours
SCAN: autopan Scans
MENU: keyboard Menu or Camera menu
SAVE: Save picture or record video
PAUSE: Pause, frame stop
RUN: Run or Play
ON: Auxiliary on
OFF: Auxiliary off
FAR: Focus Far
NEAR: Foucs Near
OPEN: Iris Open
CLOSE: Iris Close
PATTERN: Patterns

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
6
FAX: [phone]
Brief Instructions:
Clear LCD: Press [0] for 2 seconds
Switch Camera channel: Number+CAM
Switch DVR ID Number+DVR (in CAM model)
DVR to CAM: CAM
CAM to DVR: DVR or “number+DVR”
Call Presets: Number+preset
Set Presets: Number+SET
Delete Presets: Number+DEL
Call Tours: TOUR or “number+TOUR”
Call Scans: SCAN or “number+SCAN”
Run Patterns: Number+RUN
Save Patterns: Number+SAVE
Stop Patterns: Number+PAUSE
Auxiliary On: Number+ON
Auxiliary Off: Number+OFF
Open Camera Menu: MENU→8888
ESC In DVR model, Press “ DVR” button =ESC
DVR

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
7
FAX: [phone]
Symbol Explanation:
Power Stop Record Pause/Frame Play
Multi-Screen Shift Backward Forward Fast Backward Fast
Forward
LCD Display:
LCD Display
Camera Operate Model
DVR Operate Model
CAM: 001
>> 0000 MON:001
Camera ID
Input Number Area
Monitor ID
CAM：001
>> 0000
CAM: 001
>> 0000 DVR:001

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
8
FAX: [phone]
Camera Operation:
CAM Mode: Press [CAM] to enter CAM mode.
Switch Camera channel：Number (1-255)+CAM
PTZ Control:
Control camera directions: up, down, left, and right.; 0-64 level speed (PELCO protocol),
0-100 level speed (other protocols).
Lens Control:
Zoom: Zoom In (Tele)
Zoom Out (Wide)
Focus: NEAR
FAR
IRIS：OPEN
CLOSE
Simultaneous Control:
Joystick control direction and zoom
(1) Input preset number “0-255”
Simultaneously
Auxiliary Control:
Control such front surveillance equipment as lights, wiper, spray, heater, and fan. Max.
255 auxiliary equipment for each camera (PELCO protocol).
Auxiliary on: Number+ON
Auxiliary off: Number+OFF
Call Presets:
(2) PRESET

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
9
FAX: [phone]
Set Presets:
(1) Input preset number “0-255”
(2) SET
Delete Presets:
(1) Input preset number “0-255”
(2) DEL
Call Tours:
Two ways:
1. Default tour: Press [TOUR] or call TOUR 1.
2. Multiple tours:
1) Input tour number “0-16” (Max. 255) or refer to
camera manual.
2) TOUR
Call Scans:
Two ways:
1. Default scan: Press [SCAN] or call SCAN 1.
2. Multiple scans:
1) Input scan number “0-16” (Max. 255) or refer to
camera manual.
2) SCAN
Patterns
Run Patterns:
Input number “0-4” (Max. 255) or refer to camera manual.
RUN
Save Patterns:
Input number “0-4” (Max. 255) or refer to camera manual.
SAVE
Stop Patterns:
Input number “0-4” (Max. 255) or refer to camera manual.
(1) PAUSE

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
10
FAX: [phone]
Open Camera Menu:
The menu operation methods are different from different cameras, Please refer to camera
manuals.
Standard protocol operation method:
Method 1:
Press [MENU]
Input Password: “8888”
Press [MENU] again to exit password input ot exit menu .
Method 2:
The above method might not suitable for some cameras. Please refer to camera
manuals.
For example: The way to open the menu of camera with PELCO protocol is
“95+PRESET”.
Enter Camera Menu= 95+preset
Please refer to camera manuals for the OSD menu operations.
MENU
>> Password ****
CAM:001 MENU
>> 0000

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
11
FAX: [phone]
The Keyboard LCD Display：
Camera operate mode
DVR operate mode
USB 2.0 Interface：
(1) Protocol：USB2.0 HID
(2) Operating system：Windows XP /Windows 7
(3) Production Name：3D Joystick Keyboard
(4) Factory ID: 054c
(5) Production ID: 0268
USB PTZ Protocol：
USB Protocol=XL / Pelco-D
Pelco-D USB Protocol Setup
①USB Protocol : Pelco-D （No5：=PelcoD）
②Camera Protocol : Pelco-D usb (No3:=PelcoDusb)
image setup function (in keyboard menu of No6:Camera Image)
XL USB Protocol Setup:
The Keyboard LCD Menu No5：USB Protocol=XL
CAM：001
>> 0000
CAM: 001
>> 0000 DVR:001

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
12
FAX: [phone]
Matrix control：
①DVR PROTOCOL= Matrix
②Connect the keyboard RJ45 Port
1．GND
2．NC
3．RS485+ / A / TX+
4．RS485- / A/ TX-
5．RS232-TX
6．RS232-RX
7．GND
8．DC12V IN+
Matrix
CAM:001
>> 0000 MON:001
Matrix output change
Camera ID

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
13
FAX: [phone]
SONY camera using explanation:
1) MENU+9999 enter MENU
2) Protocol=VISCA
3) Baud rate =9600
4) Every camera’s Protocol and Baud rate :VISCA，9600
Eg：Control two Sony cameras
Set CAM-1，CAM-2 VISCA，9600 individually
Turn On: ON
Turn Off: OFF
Screen Information on：99+ON
Screen Information off：99+OFF
Left Right Change：200+ON
Left Right Normal：200+OFF
Up Down Change：201+ON
Up Down Normal：201+OFF
Back light Compensate [ ]
Image Freeze [ ]
Image Mirror [ ]
Run Auto Cruise 1+SEQ”
White Balance Model:
Press [TOUR] Model switch
Six White Balance Models:
Auto
Indoor
Outdoor
One Push WB
ATW
Manua
Screen Information Display Instruction
AUTO WB auto white balance
INDOOR Indoor white balance
OUTDOOR Outdoor white balance
ONE TRIGGER Trigger white balance
ATW WB Auto tracking white balance
MANUAL Manual white balance
WB R GAIN Manual white balance，red gain
WB B GAIN Manual white balance，blue gain
Adjusting Method: Button + Right （ ＋） ， image color deeper
Button + Left （－ ）， image color lighter

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
14
FAX: [phone]
Manual white balance ：
“Model”=“Manual”
Press “SEQ”, three manual adjusting parameters:
R Gain、B Gain、RB Stop
•Manual white balance R Gain:
(1)Under Manual white balance Model，press SEQ button，screen show “R Gain”
(2) Button + Right （＋ ）， red deeper，Button + Left （ －） ， red lighter
•Manual white balance B Gain:
(1) Under Manual white balance Model，press SEQ button，screen show “B Gain”
(2) Button +Right （ ＋） ， blue deeper，Button +Left （ －） ， blue lighter
•Manual white balance RB Stop:
(1) Under Manual white balance Model，press SEQ button，screen show “Gain Stop”
ONE PUSH White Balance
Under ONE PUSH WB Model，press “SEQ” button
SONY BRC-300/300P/HD1 cameras’MENU Operate Method
Enter Camera Menu: MENU+8888
Enter Next Menu：Joystick up/down
Return Previous Menu or Exit：MENU+8888
Cursor Up Down：Button + up/down
Modify Parameter：Button + Left/Right
Eg：Move Down Menu Cursor
press button on the top of joystick and move down

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
15
FAX: [phone]
•Samsung protocol setup
Enter menu：(tow Method )
1) MENU+8888
2) 95+PRESET
Exit menu: ：（ tow Method)
1) 96+PRESET
2) Joystic left+joystick button
Enter in menu
Joystick right+joystick button
•Panasonic Protocol setup
1) Enter menu：(tow Method )
(1) MENU+8888
(2) 95+PRESET
Exit menu: ：(tow Method )
(1) 96+PRESET
(2) Joystic Left+joystick button
Enter in menu
Joystick Right+joystick button
Forward Joystick Up+joystick button
Next Joystick Down+joystick button
•AD Protocol
Enter Menu：(tow Method)
(1) MENU+8888
(2) 95+PRESET

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
16
FAX: [phone]
DVR Operate Method
Switch DVR Operate mode:
Switch DVR ID :
In camera mode: “number”+“DVR”
In DVR mode: “CAM”→“number”→“DVR” （number=DVR ID）
Exit DVR mode: press CAM
Symbol Explanation:
Power Stop Record Pause/Frame Play
Multi-Screen Shift Backward Forward Fast Backward Fast
Forward
Function key:
ESC = DVR
ENTER = SET
Picture switching = number 1-9
Multi-Screen switching =
Exit DVR mode = CAM
Move Cursor：joystick left or right,
Change parameter：joystick up or down
Enter Menu：“MENU”→8888→“ENTER”
back：ESC(DVR)
Multiple picture：“MULTI”，full、4view、9view、16view
Switch picture：“EDIT”；1-16 picture

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
17
FAX: [phone]
DVR/NVR Communication output port select:
RJ-45/Plug-6p
Operations of Hikvision DVR:
(1) Set DVR protocol =Hikvision in keyboard OSD.
(2) Connect with Hikvision DVR by RS485 communication cable under baudrate 9600.
DVR Setup
DVR Menu
Local Display ---Dvice ID=01
Serial Port settings: function
Baud rate “9600”
Data bits “8”
Stop bit “1” RS485
Verify "none" CommPort=Plug-6P
RJ-45
Plug-6P

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
18
FAX: [phone]
Connections with Hikvision DVR:
Method 1: CommPort=RJ45
Method 2: CommPort=RJ45
Operations of Dahua DVR:
The protocol is applied to Dahua DVR of RS485 and baud rate of 9600.
Keyboard Settings:
Set the DVR protocol as Dahua on the keyboard OSD.
DVR ID =1 (under CAM mode: "number 1"+ "DVR").

User Manual
London – United Kingdom
www.saten.co.uk
UAE – Dubai
Fourth Floor, 30-31 Furnival Street
[e-mail]
JAFZA - Al Aweer
Post code: EC4A 1JQ
TEL: [phone]
TEL: [phone]
19
FAX: [phone]
Dahua DVR settings:
(1) Menu→ System Settings→General Settings→Keyboard ID “1”
Serial Port settings: function "Network keyboard"
Baud rate “9600”
Data bits “8”
Stop bit “1”
Verify "none"
(2) Menu→ Shutdown→ Logout Menu User→Confirm, if without this step, the keyboard
can't enter into the "Setting" menu.
Notes: After finishing the settings, please pull out the Mouse with DVR, or some
functions can not control.
The function of the following keys is the same with the remote controller. Please refer to
the DVR manual for detail instructions.
"LOGIN" to enter, if there is no operation on the DVR for a while, then the DVR will exit
the login, at this this situation, you can't control the DVR, only to press the "LOGIN" key
again, then can control.
Multi-screen: single screen, four screens, nine screens, sixteen screens.
■STOP: stop recording,
MENU: enter the menu/ confirm
ENTER : confirm/ enter the menu,
REC: recording,
PLAY: play the recording
Number 0-9,: ESC to exit
Previous, next, slow forward, fast forward
Cursor movement: move joystick up, down, left, and right
