Satir D600 User manual

D600 User Manual
Trademark Acknowledgments
• SATIR is trademark of SATIR Europe (Ireland) LTD.
• Microsoft, Windows and Windows logo is either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
• Other names and products not mentioned above may be registered trademarks or trademarks of their
respective companies.
Copyright © 2019 SATIR LTD. All rights reserved.

1
About this IR Camera User Guide
Symbols Used
This mark denotes issues that may affect the IR camera’s operation.
This mark denotes additional topics that complement the basic
operation procedures.
What do the icons listed in the Camera User Guide mean?
Information displayed on the LCD Display (p.14)

2
Thumb Index
Introduction of camera components.
Preparing the
IR Camera
Describes basic functions, learning how to turn
on/off the IR camera and work with the control panel
and LCD monitor.
Basic function
Describes working with the camera, from each
analysis settings to using the camera’s various
analysis tools.
Shooting
Explains how to review recorded images, erase
images and playback voice memos.
Playback and
erase
Explains how to transfer images or video to a
computer.
You must read this section before connecting your camera to a
computer.
Connection
and download

3
Table of Contents
Read This First....................................................................................................... 5
Front View................................................................................................... 9
Back /Bottom View................................................................................. 10
Prepare the IR Camera.........................................................................................11
Charge the Device...................................................................................11
Turn the Power On / Off.........................................................................12
Understand the Information on the Display....................................14
Set the date and time.............................................................................16
Local Settings.......................................................................................... 18
Language setting............................................................................ 18
Unit setting....................................................................................... 20
TV-OUT mode...................................................................................21
Quick Launcher............................................................................... 23
Basic Functions................................................................................................... 25
Use the LCD Display.............................................................................. 25
Select Menus and Settings.................................................................. 26
Reset the Settings to Default...............................................................28
Shoot....................................................................................................................29
IR Camera Adjustment.......................................................................... 29
Focus................................................................................................... 29
Display Mode................................................................................... 31
Image adjustment........................................................................... 35
Palette................................................................................................ 39
Auto Shutter..................................................................................... 41
Multifunction key............................................................................ 43
Turn the LED and Laser on/off....................................................45
Laser Dist.......................................................................................... 47
USB Mode......................................................................................... 49
Bluetooth...........................................................................................51
Measurement range....................................................................... 52

4
Freeze/Activate an image............................................................. 54
Emissivity table............................................................................... 55
Fulfill the Analysis Function................................................................57
Set object/global settings.............................................................57
Reset the default settings............................................................ 59
Analysis tools.................................................................................. 60
Alarm temperature..........................................................................69
Comparing temperature................................................................70
Remove analysis tools.................................................................. 72
Save the Image........................................................................................ 73
Attach Voice Memos Images............................................................... 75
Snapshot and Edit the image.............................................................. 77
Record/Replay the Video...................................................................... 79
Playback and Erase............................................................................................. 81
Open Images............................................................................................ 81
File Manager.............................................................................................83
Connection and Download..................................................................................86
Download the images............................................................................ 86
Connect to a video-compatible monitor...........................................87
Connect to a computer..........................................................................88
Real-time transfer................................................................................... 89
Use the Bluetooth headset...................................................................91
Appendix..............................................................................................................93
How to setup for optional Lens.......................................................... 93
Attach Optional Lens.............................................................................94
Remove Optional Lens..........................................................................96
Camera Care and Maintenance...........................................................97
Emissivity table....................................................................................... 98
Specification....................................................................................................104

5
Read This First
Test Shots
Before you try to shoot important subjects, we highly recommend
that you shoot several trial images to confirm that the IR camera is
operating and being operated correctly.
Please note that SATIR, its subsidiaries and affiliates, and its
distributors are not liable for any consequential damages arising
from any malfunction of an IR camera or accessory that results in
the failure of an image to be recorded or to be recorded in a format
that is machine readable.
Warning Against Copyright Infringement
Safety Precautions
Before using the camera, please ensure that you read and
understand the safety precautions described below. Always ensure
that the IR camera is operated correctly.
The safety precautions noted on the following pages are intended to
instruct you in the safe and correct operation of the IR camera and
its accessories to prevent injuries or damage to yourself, other
persons and equipment.
Please Read

6
Warnings
Avoid damaging eyesight
Warning: Do not trigger the laser pointer in human or animal eyes.
Exposure to the laser produced by the laser pointer may damage
eyesight.
Do not disassemble
Do not attempt to disassemble or alter any part of the equipment that is
not expressly described this guide.
Stop operating immediately if it emits smoke or noxious fumes
Failure to do so may result in fire or electrical shock. Immediately turn
the IR camera’s power off, Unplug the power cord from the power
outlet. Confirm that smoke and fume emissions have ceased.
Stop operating immediately if it is dropped or the casing is
damaged
Failure to do so may result in fire or electrical shock. Immediately turn
the IR camera’s power off, Unplug the power cord from the power
outlet.
Do not use substances containing alcohol, benzene, thinners
or other flammable substances to clean or maintain the IR
camera
The use of these substances may lead to fire.
Remove the power cord on a regular periodic basis and wipe
away the dust and dirt that collects on the plug, the exterior of
the power outlet and the surrounding area
In dust, humid or greasy environments, the dust that collects around
the plug over long periods of time may become saturated with humidity
and short-circuit, leading to fire.

7
Do not handle the power cord if your hands are wet
Handling it with wet hands may lead to electrical shock. When
unplugging the cord, ensure that you hold the solid portion of the plug.
Pulling on the flexible portion of the cord may damage or expose the
wire and insulation, creating the potential for fires and electrical shocks.
Do not cut, alter or place heavy items on the power adapter
cord
Any of these actions may cause an electrical short circuit, which may
lead to fire or electrical shock.
Use only the recommended power accessories
Use of power sources not expressly recommended for this IR camera
may lead to overheating, distortion of the IR camera, fire, electrical
shock or other hazards.
Use only recommended accessories
Disconnect the compact power adapter from both the IR
camera and power outlet after recharging and when the IR
camera is not in use to avoid fires and other hazards
Continuous use over a long period of time may cause the unit to
overheat and distort, resulting in fire.
Exercise due caution when screwing on the separately sold
tele-lens, close-up lens
If the lens is loosened and fallen off, the glass shards may cause an
injury.
If your camera is used for prolong periods, the IR camera body
may become warm
Please take care when operating the IR camera for an extended period
as your hands may experience a burning sensation.

8
Prevent Malfunction
Avoid damaging the detector of the IR camera
Warning: Do not aim the IR camera directly into the sun or at other
intense heat source which could damage the detector of the IR
camera.
Avoid Condensation Related Problems
Moving the IR camera rapidly between hot and cold temperatures may
cause condensation (water droplets) on its external and internal
surfaces.
You can avoid this by placing the IR camera in the plastic safety case
provided and letting it adjust to temperature changes slowly before
removing it from the case.
If Condensation Forms Inside the IR Camera
Stop using the camera immediately if you detect condensation. Further
use may damage the IR camera. Remove the memory card, (if
applicable) and unplug power source, from the IR camera and wait until
moisture evaporates completely before resuming use.
Right Reserved
SATIR reserves the right to change the functions and configurations of
our products without prior notice.

9
Component Guide
Front View
LCD Display
Visual camera
Illuminator
User-Defined trigger
Laser Range Finder (LRF)
IR lens

10
Component Guide
Back /Bottom View
OK Key
Power indicator
Power Button
Freeze/Activate
Cancel
Auto adjust
Focus Mode
USB Port
Video output

11
Prepare the IR Camera
Charge the Device
Device has built in battery, when Low battery status symbols
display on User Interface, Please see different battery status
symbols below, as well as steps to charge the device.
Battery Status Symbols
The following icons indicate the battery status on the LCD display.
Sufficient battery charge
Low battery
Recharge the device
How to charge device
Charge the Device
Only use recommended chargers to recharge the device's battery.
To recharge your camera, you can connect the USB cable to the
USB port at the bottom of the camera and connect the charger to the
other end. Then connect the charger to an electrical outlet.

12
Prepare the IR Camera
Turn the Power On / Off
The control panel back light is illuminated while the camera is powered
on.
1
To hold the camera correctly in
your hand, grip the handle
while keeping the device
upright, with your thumb
placed above the control panel
and your index finger on the
User-Defined trigger.
2
Press and hold the power
Button for 3 seconds.
3
After approximately 10
seconds, a startup image will
appear on the screen.
Turn the Power On / Off
Power
Button

13
4
Turn off the camera.
Hold the power button for 3 seconds.
•
Select "OK" on the shutdown prompt window. Once the
Control Panel is no longer illuminated the device is
powered off.

14
Prepare the IR Camera
The display has a field of vision of 100% of the actual shooting image.
Please see the details for Main User Interface below:
Main User Interface
Explanation：
1
Battery Status Icon
2
Temperature unit；Emissivity；Distance；Time
3
Span(Touch/Select to Modify)
4
Color scale
5
Level(Touch/Select to Modify)
6
SATIR trademark(Touch/Select to open the main menu)
7
Quick launcher (Touch/Select to open the shortcut menu)
Understand the Information on the Display
7
3
5
4
2
6
1

15
About the system settings
Language
Select the language of the menus and messages
Update
Update operating system
Date & Time
Set the system date and time display ,set time
zone and screensavers
Control
Select the video output mode / Activate LED
Torch / Activate Laser Range Finder / Set USB
Mode / Set the multifunction key
Unit Setting
Set the format of the displayed temperature or
distance unit of the camera:
°C or °F, Meter or Foot
Power
Manager
Set screen saver time / Set power off time

16
Prepare the IR Camera
Set the date and time
You need to set the Data / Time when the IR camera is turned on for the
first time.
1
Press the [C] key or Touch/Select the icon.
2
Press the UP or DOWN arrow on the
omni selector to highlight the
[Settings] menu and press OK key to
enter.
Alternatively, touch/select the
[Settings] Icon to open the menu.
3
Press the UP or DOWN arrow on the
omni selector to highlight the
[System] menu and press OK key to
enter. Highlight and select [Data &
Time] setting.
Alternatively, touch/select the
[System] Icon to open the menu and
touch/select [Date & Time] setting.
Set the date and time

17
4
Use touchscreen, select [Set Date]
option:
•
Slide up and down the date
item to modify the date;
•
After modifying select [OK] to
save, changes or select
[Cancel] to abandon changes.
5
Use touchscreen, select [Set Time]
option:
•
Slide up and down the time
item to modify the time;
•
After modifying select [OK] to
save, change or select
[Cancel] to abandon changes.
6
Use touchscreen, select [Set
Timezone] option:
•
Slide up and down the time
zone item to modify the time
zone;
•
After modifying select [OK] to
save, change or select
[Cancel] to abandon changes.

18
Prepare the IR Camera
In this menu item, you can set style of the built-in menu system.
Language setting
1
Press the [C] key or touch/select the icon.
2
Press the UP or DOWN arrow
on the omni on the selector to
highlight the [Settings]
menu and press OK key to
enter.
Alternatively, touch/select the
[Setting] Icon to open the
menu.
3
Press the UP or DOWN arrow
on the omni selector to
highlight the [System]
menu and press the [OK] Key,
then select [Language].
Alternatively, touch/select the
[System] Icon to open the
menu and touch/select
[Language] setting.
Local Settings

19
4
Local setup:
•
Using the touchscreen,
slide up and down to select
a language;
•
After modifying select [OK]
to save, changes or select
[Cancel] to abandon
changes.
