SatLab SL800 User manual

`
1
SL800 GNSS RTK System User Manual
User Manual Revision
SatLab SL800 GNSS Receiver
Revision Date
Revision
Number
Description
1st Nov 2017
1
SL800 User Manual (Release V1.0)

`
2
Table of Contents
Introduction ............................................................................................................................................4
Recommendation................................................................................................................................4
Safety Tips...........................................................................................................................................4
Limitation of Liability ..............................................................................................................................4
Related Information............................................................................................................................4
Your suggestions.................................................................................................................................4
Chapter 1.................................................................................................................................................5
Product Introduction...............................................................................................................................5
Introduction ........................................................................................................................................6
SL800 Features....................................................................................................................................6
Precautions .........................................................................................................................................6
Chapter 2.................................................................................................................................................7
Product operating instructions ...............................................................................................................7
Receiver appearance...........................................................................................................................8
Power key function ...........................................................................................................................10
LED indicator function.......................................................................................................................11
Battery Installation............................................................................................................................12
Working mode setting ......................................................................................................................12
Static measurement..........................................................................................................................13
Static data download ........................................................................................................................14
NFC function .....................................................................................................................................14
Chapter 3...............................................................................................................................................15
Operation of SL800 using SurvCE..........................................................................................................15
Quick Start Guide for SurvCE ................................................................................................................16
Running SurvCE.................................................................................................................................16
GPS Rover Configuration Menu ............................................................................................................18
Current tab........................................................................................................................................18
Comms tab ........................................................................................................................................19
Receiver tab ......................................................................................................................................21
RTK tab..............................................................................................................................................22
Monitor/Skyplot tab .............................................................................................................................24
Chapter 4...............................................................................................................................................26
Technical Specification..........................................................................................................................26
GNSS Specification ............................................................................................................................27

`
3
Chapter 5...............................................................................................................................................30
Interface and main accessories.............................................................................................................30
Small five-core lemo interface..........................................................................................................31
Receiver lithium battery ...................................................................................................................32
Power Adapter..................................................................................................................................33
USB data cable ..................................................................................................................................33
Height measuring plate.....................................................................................................................34
Schedule 1 - Factory default parameters..........................................................................................35
Schedule 2 Key Parts Information.....................................................................................................35

`
4
Introduction
The SatLab SL800 is a first generation SatLab Network GNSS receiver. This manual will explain how to
install and operate the receiver.
Recommendation
For you to make better use of the SatLab SL800 receiver, SatLab recommends that you read this
manual carefully. If you still need further information please visit SatLab’s official website:
www.satlabgps.com
Safety Tips
Note: The Note contents is for the general operation of the receiver which requires
special attention, please read carefully.
Warning: The warning content will generally provide very important information. If
the receiver is not operated in accordance with the warnings, it could cause damage,
loss of data, or even endanger your personal safety.
Limitation of Liability
Before use, please be sure to read the instruction manual, which will help you make better use of this
product. If you do not follow instructions when operating the receiver, or fail to understand the
requirements of the specification and the proper use of this product, any resulting loss or damages
resulting from the misuse are limited to the terms of SatLab’s International Warranty ‘Limitation of
Liability’ clause.
SatLab is committed to continuous improvement of product functionality and performance, and
accordingly reserves the right to make changes to the product and contents of this manual without
prior notice.
We have reviewed the contents of this publication in conjunction with the hardware and software to
ensure consistency, however, this does not exclude the possibility of errors. The User's Guide is for
reference only, if it deviates from the actual product then the actual product version prevails.
Related Information
For more information on the SatLab SL800 series GNSS receiver please visit www.satlabgps.com
‘Resources and Support’.
Your suggestions
If you have any suggestions and comments relating to the SatLab SL800 GNSS receiver, please contact
us through email at [e-mail]
Your feedback on the quality of our products will be greatly appreciated.

`
5
Chapter 1
Product Introduction
This section describes:
■Introduction
■Product Features
■Precautions

`
6
Introduction
SL800 is a small intelligent RTK receiver built with a compact design and rugged magnesium
alloy enclosure. It supports multi-constellation, multi-frequency GNSS technology, dual-mode
long-distance Bluetooth and NFC for fast and efficient connectivity. The receiver provides
reliable and accurate measurement capability, ensuring the user a perfect customer
experience.
SL800 Features
•A new generation of small intelligent RTK receiver, equipped with a new and efficient
intelligent real-time GNSS platform;
•Latest multi-constellation, triple frequency GNSS technology;
•Ultra-miniaturized zero-phase antenna;
•Built-in 4.0 standard long distance dual-mode Bluetooth, backward compatible with
Bluetooth 2.1 standard;
•Built-in 8GB high-capacity data storage;
•Compatible with any industrial grade Handheld controller or Tablet PC;
•NFC (Near Field Communication) flash pairing connection;
•New small body, magnesium alloy structure.
Precautions
(1) The product shall be operated and stored within the specified ambient temperature range.
(2) Do not place the receiver in a humid, corrosive environment.
(3) To ensure the signal quality of the satellites tracked, the SL800 should be operated where
possible clear of obstacles and with clear sky vision.
(4) Avoid where possible environments with strong electromagnetic interference, such as TV
towers, microwave stations, high voltage transmission lines and other equipment.
(5) In order to avoid or reduce the occurrence of multi-path, the receiver should be operated
away from electromagnetic ‘reflective’ features such as high-rise buildings, water surfaces
etc.

`
7
Chapter 2
Product operating instructions
This section describes:
■Receiver appearance
■Power key function
■LED function
■Battery installation
■Working mode settings
■Handbook differential data chain
■Static measurement
■Static data download
■Firmware upgrade
■NFC function

`
8
Receiver appearance
SL800 consists of three parts: the antenna cover, the lower housing and the control panel.
Figure 2-1 Receiver appearance
The Control panel contains a power button and three LED lights, respectively; satellite
indicator LED, power LED (red and green), communication status LED (red and green).
1 - Power button 2 - Power LED 3 - Satellite LED 4 - Signal LED
Figure 2-2 Control Panel

`
9
The bottom of the receiver has a 5 pin lemo interface, USB interface and protective plugs. The
5 pin lemo interface is used for the connection of the receiver with an external data link
and/or an external power supply. The USB interface is for external equipment connection,
firmware upgrade, static data download, and for charging the receiver battery.
If not being used, please cover the 5 pin lemo and USB connectors with the protective plugs
in order to maintain waterproof and dustproof status.
Figure 2-3 Receiver Interface
1. 5/8 thread mounting screw 2. Battery compartment 3. 5 pin lemo interface
4. Mini USB interface 5 - Protection plug

`
10
Power key function
Power key function: power on/off, work mode switch, power query, automatic setting of
the base station, and resetting of the motherboard.
Function
Action
Boot
Press power button for 1 second, all lights
come on and receiver boots.
Shut Down
Long press power button for 3 seconds, all
lights flash twice, release the button to turn
off.
Base Station setting
Receiver off, long press power button for 6
seconds, all lights flash twice, release the
button, the receiver will automatically set
Base Station mode.
Work Mode switch
Double click the power button to enter
Working Mode. Each double click will cycle
between Static and RTK mode.
Status Inquiry
Click power button, power light flashed red
to show power status.
Reset Motherboard
Receiver powered on, press and hold
power button for more than 6 seconds, all
three lights will flash, release button to
reset motherboard
Table 2.1 Power Key Function Details
