Satlink WS-6936 User manual

THE PROFESSIONAL EQUIPMENT
USER’S MANUAL
THE PROFESSIONAL EQUIPMENT
WS-6936

Product Description
1.Guide
1.1 Face Panel & Button
1.2 Power On/Off
1.3Power Supply & Battery
2. Menu
2.1 DVB-S
2.2 DVB-T
2.4 System Setup
Product Description
2
3
4
4
4
5
24
2.3 Multimedia 21
CONTENTS
CONTENTS
2.5 Spectrum-S
5.Product Standard Package
THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
3.Specifications
26
36
39
4.Warnings
37
2.1.1 Quick Search
2.1.2 Satellite Install
17
2.2.1 Quick Search
2.2.2 Freq-Checking
20
16
10
5
Signal Finder Professional Combo| 1
It is a battery powered hand held Satellite adjustment meter demodulating
DVB-S and DVB-T Signal. It's veryconvenient for installer to catch the
signal quickly andaccurately and adjust the antenna to the best position.
It's with microprocessor controller, reliable and stable performance.
When it's turned on, channel picture, Signal Strength and Signal
Quality can be showed on LCD Screen a fter you set up your local
DVB-S or DVB-T Parameter. Also, it enables you to select large
menu window for data figure which is helpful for adjustment.
It shows Azimuth and Elevation, CBER/VBER, Singal Quality, Signal
Strength and signal lock sound forDVB-S, And for DVB-T channel
picture, Signal Strength and Signal Quality can be showed on LCD
Screen after you set up your local DVB-T Parameter. Also, it can at most
show five channels' signal at the same menu which is very helpful
for adjustment.
For DVB-S it can detect very faint signal, and supports antenna power
OFF/13V/18V selectable and it's with auto-protection for LNB short-
circuit.
For DVB-T it can detect very faint signal, and supports antenna power
OFF/5V/12V/15V/24V selectable and it's with auto-protection
for antenna short-circuit.
It includes both AV IN and AV OUT for Camera, monitor…etc
It's used with 12V Power Adaptor when you need to use
external power.
It includes high capacity Lithium Battery 8.4V 3000mAh
which works for more than 4 hours after it's fully charged.
2.6 Spectrum-T 29
2.7 Shortcut Buttons 32

1.GUIDE
1.1Face Panel & Button
THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
Signal Finder Professional Combo| 3
2 | Signal Finder Professional Combo
NO. Name Function
1 MENU To show main menu or return to previous menu
2 F1 Function Button
3 F2 Function Button
4 F3 Function Button
5 F4 Function Button
6 EXIT To cancel selection or exit from current menu
7 ▲▼ OK Arrow for Cursor Moving
OK for Confirming
8 Mute Soun d On/Off Switching
9 SCAN Quick search for DVB-S
10 M.INFO Show 5 channels signal information for DVB-T
11 INFO Show information of current program
12 0-9 Numerical Button To input numer for setting parameters
13 Power Connection port Port for power charging
14 USB Port Port for Upgrading or connecting to multimedia
15 Antenna IN Connecting to the antenna for DVB-T
16 Power Switch Power Switch for machine power
17 LNB IN Connecting to the dish for DVB-S
18 AV OUT AV OUT
19 AV IN AV IN
20 Power Indicator Light The light is on when meter is turned on
21 22K Switch Indicator Light 22K Switch is on when it lights
22 13/18V Indicator Light To show H/V switch output
23 Signal Lock Indicator Light Locked signal when it lights
24 Charging Indicator Light The light is on when it’s charging and
off when charging is completed.
25 Flashlight holes flashlight

1.2 Power On/Off
To turn on the meter when Power Switch moves to I
position.
To turn off the meter when Power Switch moves to 0
position.
Please turn off the meter to charge the meter in time
when system information for showing low power popes
up.
1.3Power Supply and Battery
It's used with 12V 1.5A Power Adaptor. It charges
through external power when battery is out of power.
It's used with 8.4V 3000 mAH Lithium Battery. It needs
6 hours charging time by connecting power adaptor with
external power or car charging. After it's full charge, it
works for more than 5 hours (It also depends on the load
of external antenna).
2.MENU
Press “ MENU” key to enter into main menu, and
2.1.1Quick Search
THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
Notice: For initial charge, please make battery fully-
charged(We suggest it charge for 8 hours).
use Arrow key to move cursor, and then press “OK” key to
select sub-menu.
2.1 DVB-S
select DVB-S and press OK to enter DVB-S system
Signal Finder Professional Combo| 5
4 | Signal Finder Professional Combo

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
2.1.1 .1 Satellite Name
To select the satellite name for receiving signal
2.1.1.2 LNB Type
Select LNB Type
2.1.1.3 LNB Low Freq/ LNB High Frequency
Use the numerical button to input Freq Value of LNB
2.1.1.4 Frequency
Us the numerical button to input Freq Value of Frequency.
U se the n u m er ic a l b ut t o n to i np u t Va l u e fo r
S YM B O L R AT E
2.1.1.5 Symbol Rate
2.1.1.6 Polarity
Chose Polar Mode(OFF/13V/18V)
Press OK to the sub-menu
Signal Finder Professional Combo| 7
6 | Signal Finder Professional Combo
2.1.1.7 SCR function:
Pls enter Quick Search in menu,LNB Type choose Unicable
Then move to second page.Channel N0,Select the machine
is connected to the corresponding SCR LNB port and
frequency.At this point set to complete SCR . TP can
choose or enter the satellite data ,searching for signal.

2.1.1.10TP Scan
Scan all programs of the current frequency, and
automatically store them after scanning, and then
return back to the previous menu.
2.1.1.11 Scan All
Scan all programs of all channels, and automatically store
them after scanning, and then return back to theprevious
menu.
THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
2.1.1.9 Set parameters, and press “OK” button to enter
the Sub-menu, and then adjust the dish according to the
interface parameters. 2.1.1.12 S/Q/#
Use ◄ ► button to select S/Q/#, and press “OK”
button to enter the Sub-menu, and then adjust the dish to
the best direction.
Signal Finder Professional Combo| 9
8| Signal Finder Professional Combo
2.1.1.8 Longitude
Use the numerical button to input Longitude of Satellite

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
Signal Finder Professional Combo| 11
10 | Signal Finder Professional Combo
2.1.2.1 S a t Manager
Press “OK” bu tton to en ter the Sub-menu, and then
set the state of the dish
2.1.2.1.1 Switch Type
Press ◄ ► button to choose Switch Type(NONE,
DisEqC1.0/1.1, DisEqC 1.2/USALS)
1、DiSEqC 1.0/1.1
Use ◄ ► button to select LNB1/LNB2/LNB3/LNB4
2.1 .2 Satellit e Install
Press “F1” button to enter the Sub-Menu，select satellite。
Press “OK” button to enter the Sub-Menu，Press “▲▼” Edit
parameter.

Press OK to finish setting DiSEqC1.0/1.1
THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
Signal Finder Professional Combo| 13
12 | Signal Finder Professional Combo
2、DiSEqC 1.2/USALS。
Press “F1” button to enter the Sub-Menu，and then make
operations according to the instructions ，Edit parameter。
Press “F2” button to enter the Sub-Menu，and then make
operations according to the instructions ，Edit parameter。
Use ▲▼ button to select Postion 01/Postion 02/Postion 03/
Postion 04

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
2.1.2.1.2 Toneburst
Pr ess ◄ ► but ton to choose Toneburst mode
(OFF/ON).
1、Switch Type on NONE
Signal Finder Professional Combo| 15
14 | Signal Finder Professional Combo
2、Switch Type on DiSEqC 1.0/1.1
2. 1 . 3 TP Ma n a g er
Press “ O K ” button to ente r t h e Sub-Menu, and t h e n
make o p e r a t ions acco r d i n g to to the inst r u c t i ons.

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
2.2 DVB-T
Press “ MENU” to enter into main menu, and use Arrow
key to move cursor, and Select DVB-T, andthen press
“OK” enter DVB-T system.
Press OK to enter the sub-menu
Signal Finder Professional Combo| 17
16 | Signal Finder Professional Combo
2.2.1.1Quick Search
2.2.1.1.1Country Setting
To select country to receive signal
2.2.1.1.2Channel
To select channel type to be received
2.2.1.1.3Frequncy
To set frequency for receiving signal by inputting frequency
value with numerical keys
2.2.1.1.4Bandwidth
To Select Bandwidth 6M/7M/8M based on your local region.

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
2.2.1.1.6 Antenna Setting
To select antenna power ON/OFF
2.2.1.1.7 Antenna Power
To select antenna power voltage（OFF/5V/12V/15V/18V/24V）
2.2.1.1.8
To set parameter, and press “ OK” to enter into sub-menu.
2.2.1.1.8.1 Scan
To scan all the channels of current frequency, and it auto-
restores the scanned channels, and then return to previous
menu.
Signal Finder Professional Combo|19
18| Signal Finder Professional Combo
2.2.1.1.8.2 Scan All
To scan all channels, and it auto-restores the scanned
channels, and then return to previous menu.

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
2.2.2.1 Move
Press ▲▼ button to move Cursor
2.2.2.2Select
Press ◄ ►button to local channel, and tick the box to select it.
2.2.2.3
Press OK button to enter into multichannel display.
Each screen display signal indicators of five channels, and
press ◄ ► button to PGUP or PGDOWN.
Signal Finder Professional Combo| 21
20 | Signal Finder Professional Combo
2.3 Multimedia
2.2.2Freq-Checking

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
2.3.1 Photo
Previewing the pictures in JPG format, and make operations
according to its instructions.
2.3.2 My Music
Play the Music in MP3 format, and then make operations
according to its instructions.
Signal Finder Professional Combo| 23
22 | Signal Finder Professional Combo
For Multim e d i a , the external memo r y s h o u ld be
inserte d i n t o U S B p o rt. Otherwise , “ D e v i ce not
support e d ” w i l l pop up on the window.

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
Signal Finder Professional Combo| 25
24 | Signal Finder Professional Combo
2.4.3 SW Update
To upgrade SW or Data through USB port.
To store the upgrading file in the external memory, and
2.4 System Setup
2.4.1 OSD Language
Set OSD Language
2.4.2 KB-BackLight
Button backlight delay slect switch
（OFF、5 Second、10 Second、20 Second）
insert it into USB port, and then enter upgrade menu.
To select the file, it will automatically return back to the
2.4.4 Set Default
Press “OK” button to set Factory Default.
2.4.5 GMT Usage
Set the GMT parameter

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
Signal Finder Professional Combo| 27
26 | Signal Finder Professional Combo
2.5.1 Frequency is the difference value between the
downstream frequency and local frequency and the value
range is 950---2150MHz.
To set parameters according to requirements, and then
press OK button to enter the chart of spectrum.
2.5.2 When the screen appears the spectrum, press "F1"
button to change bandwidth and press"F2" to change the
polarity.press "F3"t to select 22K ON/OFF.
2.5.3 To select the beginning frequency to scan and press
"F4" button then press OK button.
Press OK button and then enter spectrum-s parameter to set
menu.parameter
2.5 Spectrum-S

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
Signal Finder Professional Combo| 29
28| Signal Finder Professional Combo
2.5.4 Press button to move the cursor to the end
frequency of the scanning.
2.5.5Press "OK" and "F4" button to enter the selected
frequency range to scan the programs. When finished, exits
2.6 Spectrum-T
Press"ok" keyboard, enter DVB-T spectrum item
Choose pre-store data( country -channel - bandwith
- antenna power supply), press"OK" enter
spectrum working interface.

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
Signal Finder Professional Combo| 31
30 | Signal Finder Professional Combo
2.6.1 Press F1, choose DVB-T whole paragraph frequency
scanning or choose the country's current channel scanning
2.6.2 Press F2, display to be selected as the center
frequency 50MHz bandwith for the spectrum
2.6.3 Press F3 , lock selected frequency , and
displays the frequency' spectrum of indicators

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
2.7.3Press “F2” button to enter Sub-menu when
playing programs, and make operations according
to its instructions.
Signal Finder Professional Combo| 33
32 | Signal Finder Professional Combo
2.7 Shortcut Buttons
2.7.1 Press “OK” button to enter the Sub-menu when it's
playing programs, and make operations according to its
instructions.
2.7.2 Press “F1” button to enter TV List.
Press “ ”over 3 second OFF/ON flashlight.
F1
flashlight holes

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
Signal Finder Professional Combo| 35
34 | Signal Finder Professional Combo
The mark with “ ”is the opitional functional item.
2.7.5 Press “F4” button to enter the Sub-menu when it's
playing programs, and make operations according to its
instructions.
2.7.6 press INFO keyboard, show the current program
information
2.7.7 Under DVB-T status, press M.INFO keyboard, enter
Freq-checking menue
2.7.8 press MUTE keyboard , enter mute status.
2.7.9press Scan keyboard, enter QUICK SEARCH , and
And restore the default database.
2.7.4 Press “F3” button to enter the Sub-menu for
Audio Channel, to change Audio PID and Sound mode.

THE P ROFESSIONAL EQUIPMENT------------------|USER’S MA N UAL | THE PROFESSIONAL EQUIPMENT------------------|USER’S M A NUA L|
You are using Lithium ion batteries and Nickel metal hydride
batteries in the machine now, so Please don't work under
high temperature or high pressure conditions. If the follo-
wing items happened, abnormal chemical reaction may occur
which will lead to the battery overheat, emit smoke, ignite
and/or burst.
(1)incinerate and dispose the battery in fire or heat it;
(2)pierce the battery with a nail or other sharp objects, strike
it with a hammer or step on it;
(3)immerse the battery with water or connect the positive(+)
and negative(-) terminals with a metal objects such as
necklaces, hair pins ,etc.
Warning:
Notice:
The battery is only applicable to the charger which
supplied or appointed by the manufacturer of this machine.
The charging time should be minimum 5 hours for the first
time, and it should not be charged over 12 hours after the
first time.
Please keep your machine off when the battery is charging.
The battery should be stored within a temperature range of
0℃ to 40℃.
When stored for a long period, charge the battery at least
Signal Finder Professional Combo| 37
36 | Signal Finder Professional Combo
Specifications
