Saunders WHISKER CAT SILO 427332 User manual

If you have assembly questions or need a replacement part, please contact Sauder directly at
www.sauder.com or 800-445-1527.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
WHISKER CAT SILO
[e-mail] | 1.877.250.7729 | Mon-Fri, 9am-5:30pm EST

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Hardware Usage Guide
Assembly Steps
Français
Español
Safety
Warranty
No. 2 Phillips Screwdriver
Tip Shown Actual Size
REGISTER YOUR NEW
PRODUCT ONLINE
For immediate service,
our website is available 24
hours per day, 7 days per
week, to order replacement
parts, access assembly tips,
register your product and
view Sauder products.
www.sauder.com/service
THANK YOU FOR PURCHASING THE WHISKER CAT SILO!
I am thrilled that Whisker and Sauder furniture have partnered
together to bring you the highest-quality pet furniture. At
Whisker, we design and deliver refined pet accessories that
delight both pets and people. Whisker and Sauder products
are made with environmentally responsible materials and
world-class manufacturing processes. Together, our companies
are bringing pet parents a premium line of stylish yet functional
pet furniture that is built to last. Enjoy!
Jacob Zuppke, President & CEO of Whisker
3
3
4
5-9
10-11
12-13
14
15
427332 whiskersupport.com Page 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge to
help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
427332whiskersupport.com Page 3
A SHELF (2)
B BACK PANEL (4)
C FRONT PANEL (2)
DLEG(4)
E CUSHION (1)
AB
C
D
E
A
D
DD
C
B
B
B
Hardware Identification
åThe screw is shown actual size. You may receive extra hardware with your unit.
WOOD DOWEL - 24
2
CAM SCREW - 12
1HIDDEN CAM - 12 3
FELT DISC CARD - 1
49/16" PAN HEAD SCREW - 16 5
åNOTE: The PANELS (B and C) are
interchangeable. They can be
placed in any position on your unit.

427332 whiskersupport.com Page 4
Hardware Usage Guide
HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam DowelCam Screws
Turn the CAM SCREW
or gently tap the
CAM DOWEL until the
shoulder is against the
surface of the part.
1.
3.
Insert the CAM SCREW or CAM DOWEL into
the HIDDEN CAM. Tighten the HIDDEN CAM.
1
2
2.
Arrow
Push a HIDDEN CAM into
the part. The arrow in
the HIDDEN CAM must
point toward the hole in
the edge of the board.
Hole
Hidden Cam

Step 1
View our assembly video at
www.whisker.com/support
å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching
your unit or the floor.
å Push six HIDDEN CAMS (3) into the SHELF (A).
å Turn four CAM SCREWS (1) into the exact holes shown in the PANELS (B and C).
å Repeat this step for the other SHELF (A) and remaining PANELS (B and C).
1
(12 used)
C
B
3
A
3
3
3
3
3
(12 used)
427332whiskersupport.com Page 5

Step 2
å NOTE: You have the option of placing the
PANELS (B and C) in any position on your unit.
å NOTE: Position the SHELVES (A) and PANELS (B
and C) with the bottom surfaces being even
as shown.
å Insert eight WOOD DOWELS (2) into one BACK
PANEL (B) and one FRONT PANEL (C).
å Fasten the PANELS (B and C) to the SHELVES (A).
Tighten four HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the PANELS
insert into the SHELVES.
A
C
B
Surface with
HIDDEN CAMS
A
Surface with
HIDDEN CAMS
Edge without HIDDEN CAM
(8 used)
2
2
These surfaces
must be even.
427332 whiskersupport.com Page 6
Go on, spoil 'em a little.

Step 3
å Insert eight WOOD DOWELS (2) into two BACK PANELS (B).
å Fasten the BACK PANELS (B) to the SHELVES (A). Tighten four HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the PANELS insert into the SHELVES.
å Insert eight WOOD DOWELS (2) into one BACK PANEL (B) and one FRONT PANEL (C).
å Fasten the PANELS (B and C) to the SHELVES (A). Tighten four HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the PANELS insert into the SHELVES.
(16 used)
2
2
A
A
A
A
B
B
B
C
2
2These surfaces
must be even.
These surfaces
must be even.
427332whiskersupport.com Page 7

Step 4
A
A
D D
D D
å Fasten the LEGS (D) to the SHELVES (A). Use
sixteen 9/16" PAN HEAD SCREWS (5).
å NOTE: You should start each SCREW a few
turns before completely tightening any of them.
9/16" PAN HEAD SCREW
(16 used in this step)
5
427332 whiskersupport.com Page 8

Step 5
å Peel the FELT DISCS from the FELT DISC CARD (4) and place them on the bottoms of
the LEGS (D).
å Carefully stand your unit upright, and insert the CUSHION (E) into the unit as shown.
å NOTE: Please read the back pages of the instruction booklet for important
safety information.
å This completes assembly. Clean with a damp cloth. Wipe dry.
4
E
25 lbs.
35 lbs.
DD
DD
427332whiskersupport.com Page 9
And to celebrate, why not share your success story at whisker.com or

Noter la date d’achat
de cet élément et
conserver le livret
pour future référence.
Pour contacter Sauder
en ce qui concerne
cet élément, faire
référence au numéro
de lot et numéro de
modèle en appelant
notre numéro
sans frais.
Lot nº : ____________
Date de
l'achet : ____________
Utilisez les instructions d’assemblage en français
avec les schémas étape par étape du manuel
d’instruction en anglais. Chaque étape en français
correspond à la même étape en anglais. Comparer
la “Liste de pièces” ci-dessous avec la “PART
IDENTIFICATION” du manuel en anglais pour vous
familiariser avec les pièces avant l’assemblage.
REMARQUE : CE MANUEL D’INSTRUCTIONS CONTIENT
D’IMPORTANTES INFORMATIONS RELATIVES À
LA SÉCURITÉ. À LIRE ET CONSERVER POUR TOUTE
RÉFÉRENCE FUTURE.
LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
NOUS CONTACTER EN PREMIER
AVANT D'EFFECTUER TOUT RETOUR AU MAGASIN.
Nous faisons de notre mieux pour nous assurer que
votre meuble arrive dans d’excellentes conditions. Nos
représentants du service Clientèle sont aimables et prêts à
vous aider au cas où une pièce aurait été endommagée ou
manquerait (ou si vous aviez besoin d’aide pour
l’assemblage). Composez ce numéro d’appel gratuit:
1.877.250.7729
Du lundi au vendredi, de 9 heures du mATIN à
5:30 heures du soir (horaire Côte Est)
(sauf jours fériés)
Si une pièce a besoin d’être remplacée, la pièce de remplacement
sera envoyée dans les 48 heures. (Sauf week-ends et jours fériés)
SILO POUR CHAT
MODèLE 427332
1 VIS D'EXCENTRIQUE............... 12
2 CHEVILLE EN BOIS.................24
3
EXCENTRIQUE ESCAMOTABLE 12
4 FICHE DE TAMPONS
EN FEUTRE..................................1
5 VIS TÊTE GOUTTE DE
SUIF 14 mm.............................. 16
A TABLETTE ...................................2
B PANNEAU ARRIÈRE ...................4
C PANNEAU AVANT.......................2
D PIED .............................................4
E COUSSIN......................................1
REMARQUE : Les PANNEAUX (B et C)
sont interchangeables. Ils peuvent
être placés dans n'importe quelle
position sur votre unité.
427332 whiskersupport.com Page 10
