Savant IP Audio Deployment Guide

Document Number: 009-1571-02

Document Date: May 2019

Document Supports: da Vinci 9.1 and Higher

This document outlines the process for deploying Savant IP Audio music server components including physical installation, RacePoint

Blueprint conﬁguration, and web-based user interface setup. Products supported by this guide include:

• PAV-SIPA1SM

• PAV-SIPA50SM

• PAV-SIPA125SM

• PAV-AIM7C

• PAV-AOM8C

• PAV-AOMBAL8C

2 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

Important Safety Information - Read First....................................................................... 3

1. Introduction ............................................................................................................................ 4

2. Deployment Steps................................................................................................................ 5

3. Savant IP Audio Equipment Overview ......................................................................... 6

3.1 Box Contents and Speciﬁcations........................................................................... 6

3.2 PAV-SIPA1SM ................................................................................................................. 6

3.3 PAV-SIPA50SM ............................................................................................................. 7

3.4 PAV-SIPA125SM ............................................................................................................ 9

3.5 PAV-AIM7C .....................................................................................................................11

3.6 PAV-AOM8C..................................................................................................................12

3.7 PAV-AOMBAL8C .........................................................................................................13

4. Wiring and Connections ...................................................................................................14

4.1 RS-232 Wiring – PAV-SIPA50SM, PAV-SIPA125SM, PAV-AIM7C ...............14

4.2 Serial Control Wiring – PAV-SIPA1SM..................................................................15

4.3 IR Wiring ........................................................................................................................15

4.4 Speaker Wiring ............................................................................................................16

4.5 GPIO Connections ......................................................................................................16

4.6 Relay Connections......................................................................................................17

4.7 Network Connection .................................................................................................17

4.8 AC Power Connection...............................................................................................17

4.9 Checking and Replacing the Fuse........................................................................18

4.10Checking and Replacing the Fuse [PAV-SIPA1SM]........................................18

5. Installation..............................................................................................................................19

5.1 PAV-SIPA50SM ............................................................................................................19

5.2 PAV-SIPA125SM ......................................................................................................... 20

5.3 PAV-AIM7C/PAV-AOM8C/PAV-AOMBAL8C................................................... 20

5.4 PAV-SIPA1SM .............................................................................................................. 20

6. Blueprint Conﬁguration.....................................................................................................21

6.1 Basic Blueprint Layout..............................................................................................21

6.2 Adding a Savant IP Audio Device to a Conﬁguration...................................21

6.3 Assigning Inputs and Outputs (I/Os).................................................................22

7. Web User Interface (Web UI).........................................................................................23

7.1 Accessing the Web UI..............................................................................................23

7.2 Status Tab .....................................................................................................................23

7.3 Network Tab.................................................................................................................24

7.4 Inputs & Outputs Tab ...............................................................................................25

8. Expansion ..............................................................................................................................26

8.1 Adding an AVB/TSN Switch..................................................................................26

8.2 Blueprint Layout with 5 IP Audio devices........................................................ 27

8.3 Multi-Switch Blueprint Layout with 16 AVB devices ....................................28

9. Savant Music.........................................................................................................................29

10.System Monitor ...................................................................................................................29

10.1 AVB Info ........................................................................................................................29

10.2Adjusting Input Gain and Minimum / Maximum Volume ......................... 30

Appendix A: Network Requirements ................................................................................31

Appendix B: Retrieving and Setting IP Address ..........................................................32

Appendix C: DNS (Add, Remove, Query).......................................................................33

Appendix D: Uninterruptible Power Supply (UPS) .....................................................34

Important Notice......................................................................................................................35

Contents

For links to sections contained in this document, click the relevant entry in the table of contents below.

3 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

Important Safety Information - Read First

Before installing, conﬁguring, and operating Savant equipment or other

vendor equipment, Savant recommends that each dealer, integrator, installer,

etc. access and read all the required technical documentation. Savant

technical documentation can be located by visiting Savant.com.

Vendor documentation is supplied with the equipment.

Read and understand all safety instructions, cautions, and warnings in this

document and labels on equipment.

Safety Classiﬁcations in this Document

NOTE: Provides special information for installing,

conﬁguring, and operating the equipment.

IMPORTANT!

Provides special information that is critical to

installing, conﬁguring, and operating the equipment.

CAUTION!

Provides special information for avoiding situations

that may cause damage to equipment.

WARNING!

Provides special information for avoiding situations

that may cause physical danger to the installer, end

user, etc.

Electric Shock Prevention

ELECTRIC SHOCK!

The source power poses an electric shock hazard that has the

potential to cause serious injury to installers and end users.

ELECTRICAL DISCONNECT:

The source power outlet and power supply input power sockets

should be easily accessible to disconnect power in the event of an

electrical hazard or malfunction.

Weight Injury Prevention

WEIGHT INJURY!

Installing some of the Savant equipment requires two installers to

ensure safe handling during installation. Failure to use two installers

may result in injury.

Safety Statements

Follow all of the safety instructions listed below and apply where

applicable. Additional safety information will be included where

applicable.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the

other. A grounding type plug has two blades and a third grounding

prong. The wide blade or the third prong is provided for your safety.

If the provided plug does not ﬁt into your outlet, consult an electri-

cian for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particular-

ly at plugs, convenience receptacles, and the point where they exit

from the apparatus.

11. Only use attachments/accessories speciﬁed by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table speciﬁed by

the manufacturer, or sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus combination to avoid

injury from tip over.

13. Unplug this apparatus during lightning storms or when unused for

long periods of time.

14. Refer all servicing to qualiﬁed service personnel. Servicing is re-

quired when the apparatus has been damaged in any way, such as

power supply cord or plug is damaged, liquid has been spilled or ob-

jects have fallen into the apparatus, the apparatus has been exposed

to rain or moisture, does not operate normally, or has been dropped.

15. To completely disconnect this equipment from the AC mains, dis-

connect the power supply cord plug from the AC receptacle.

4 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

1. Introduction

This document will guide the installer through the process of installing, conﬁguring, and adding Savant IP Audio devices to a RacePoint Blueprint®

conﬁguration.

Before You Begin

Read through this document in its entirety and ensure that the following required items are available:

Savant IP Audio device(s) .............................................................................................................................................................................................................................................

Unique ID (UID) of the Savant IP Audio device(s)...............................................................................................................................................................................................

(located on the back of the device)

Savant Host; licensed and running da Vinci software ........................................................................................................................................................................................

Savant Development Environment (SDE/MacBook)..........................................................................................................................................................................................

(Requires da Vinci 8.8 or higher; some components may require 9.1 or higher.)

Ethernet network meeting Savants requirements...............................................................................................................................................................................................

(See Appendix A: Network requirements)

5 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

2. Deployment Steps

Follow these steps to successfully deploy a Savant IP Audio device. This page can be used as a checklist to record which steps have been completed.

1. Review product speciﬁcations and connection details ...................................................................................................................................................................................

See Savant IP Audio Equipment Overview

2. Install the Savant IP Audio devices..........................................................................................................................................................................................................................

See Installation

3. Install Savant qualiﬁed AVB/TSN Network Switch (Optional)......................................................................................................................................................................

See Adding an AVB/TSN Switch

4. Add the Savant IP Audio devices into a RacePoint Blueprint® conﬁguration ......................................................................................................................................

See Adding a Savant IP Audio to a Conﬁguration

6 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

3. Savant IP Audio Equipment Overview

3.1 Box Contents and Speciﬁcations

For full Box Contents, Speciﬁcations, and detailed physical product installation information for each Savant IP Audio product listed in the subsections

below, refer to the relevant Quick Reference Guide for the component SKU, available on the Savant Customer Community.

3.2 PAV-SIPA1SM

Reset

Using a paperclip or similar, press and hold for 5 seconds to clear

statically assigned IP address, restart unit, and pull IP from DHCP.

If no statically assigned IP, this button does nothing.

Power LED

Green: Unit has power, operating normally.

Red: Unit in standby mode, most circuitry is powered down.

O: Unit not receiving power.

Status LED

O: Embedded processor resetting or booting ﬁrmware.

Green: Communication with Host established.

Blinking Green: System ready but no communication with Host.

Red: Firmware update failure, unit will reset.

Red Blinking: Firmware is running but has not received a DHCP IP

address.

Amber: Firmware update in progress.

Amber Blinking: Valid link-local IP address.

Hardware Failure: If hardware failure detected, red blink will

interrupt any other LED status state at 3-second intervals.

Speaker Output Single zone speaker output. Uses included 4-pin connector. Supports 8 ohm or 4 ohm speakers.

Analog Audio Output 2-channel preamp analog stereo output (Left and Right) Direct line-level 2.1V output

Analog Audio Input 2-channel analog stereo input (Left and Right) RCA line-level input 2.1 VRMS in; 22k ohms input impedance.

Digital Audio Input Digital optical audio (TOSLink) input. Supports up to 192kHz/24-bit digital audio in; PCM stereo format only.

IR Control Ports (3x) IR control ports. Uses 6-pin IR connector to send IR control signal to devices with IR input or via IR ﬂasher (5V

tolerant only). See IR Wiring section below for important precautions before making connections.

Serial Control Ports (2x) 3-pin serial ports used to transmit and receive serial binary data to/from serial controllable devices. Uses included

6-pin connector. See Serial Connections section below for pin-out information. CTS/RTS handshaking NOT supported.

Ethernet Port

8-pin RJ-45 auto-negotiating network connection port. Supports Audio Video Bridging (AVB).

Activity LED- green blinking: activity (Tx/Rx), o: no activity.

Link LED – green solid: link established, o: no link established.

Input Power 100/240V AC (50/60 Hz) 3.6A maximum.

Fuse: 250V 5A fast-acting fuse; ﬁeld replaceable.

7 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

3.3 PAV-SIPA50SM

Front Panel

Power LED

Green: System has power and is operating normally.

Red: System is in standby mode. In standby mode, most of the controller

circuitry is powered down.

O: System is not receiving power.

Status LED

Green Blinking: Embedded system is ready, but no communication has been established with the host.

Green: Host has established communications with the embedded system.

Red Blinking: Embedded ﬁrmware is running, but has not received a DHCP IP Address.

Red: Host has determined the ﬁrmware needs to be updated, but a problem occurred during the process that will initiate a reset.

Amber Blinking: Embedded system has a valid link-local IP Address and is connecting to the host.

Amber: Host is updating the embedded ﬁrmware.

O: Embedded processor is resetting, or is powered up, and is booting the embedded ﬁrmware.

Hardware Failure: If a hardware failure occurs, the status LED indication will be interrupted every three seconds with a solid red

indication. For example, if the LED is blinking green when a hardware failure occurs, the LED will alternate between blinking green

and solid red at three-second intervals.

RS-232 LED Green: RS-232 serial port activity.

O: No RS-232 serial port activity.

IR LED Green: IR port signal activity.

O: No IR port activity.

On/O button

On: Fully enables all internal power rails and processor.

O: Disables most internal power rails and processor, but not internal AC/DC power supply.

Hold On/O button for about 5 seconds to place into standby mode. The Power LED turns red.

Hold On/O button for about 1 second to take system out of standby mode. The I/O power switch on the back of unit must be On

(I) to enable this function. To turn the power o for the entire system, press the I/O power switch on the rear panel to O (O).

Reset button

Resets the network.

Hold Reset Button for 5 seconds while powered On to clear network settings. Status LED will blink Red rapidly when reset is

complete.

Zone Protection Red: Protection mode has been enabled to protect a zone / channel; Typically indicates thermal protection, clipping or over current.

O: Protection mode has not been enabled.

8 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

Rear Panel

Speaker

Connections

(4) Speaker output zones

Uses 4-pin Speaker Connectors

NOTE:Compatible with 8 ohm or 4 ohm speakers.

Analog Preamp

Output

(1) Analog stereo line output (Left & Right).

Direct Line Level 2.1-VRMS Output.

Analog Inputs (2) Analog stereo inputs, RCA line-level inputs;

22 kΩinput impedance.

Digital Audio Out (1) Digital optical preamp output, line-level 96kHz/24-bit output, ﬁxed volume.

Digital Audio In (2) Digital optical audio inputs. Supports up to 96kHz/24-bit digital audio in; PCM stereo format only.

(4) IR Ports

Uses 4-pin IR Connectors to send IR signals to control devices with an IR input or IR receiver via an IR ﬂasher (5V tolerant only).

See IR Wiring section for important precautions regarding IR functionality before making any connections.

RS-232

(2) RS-232 Ports

8-pin RJ-45 port used to transmit and receive serial binary data to and from serial controllable devices.

CTS/RTS handshaking availability based on component proﬁle. See RS-232 Connections section for pin-outs.

Ethernet

8-pin RJ-45 female.

10/100/1000 Base-T auto-negotiating port with Link/Activity LEDs

Supports Audio Video Bridging (AVB)

Ethernet Activity LED Green Blinking: Activity (Rx/Tx)

O: No Activity

Ethernet Link LED Green Solid: Ethernet Link is established

O: Ethernet link is not established

USB USB 2.0 Type A

(Reserved for future Use)

Fuse 250V 3A Slow Blow fuse ﬁeld replaceable.

Power Input 100/240V 50/60 Hz 2.7A

I/O

(power switch)

I(On): Powers On the controller.

O(O): Powers O the controller.

9 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

3.4 PAV-SIPA125SM

Front Panel

Reset

Resets the network.

Hold Reset Button for 5 seconds while powered On to clear network

settings. Status LED will rapidly blink red when reset is complete.

On/O

On: Fully enables all internal power rails and processor.

O: Disables most internal power rails and processor, but not internal AC/DC power supply. Hold On/O button for about 5

seconds to place into standby mode. The Power LED turns red. Hold On/O button for about 1 second to take system out of

standby mode. The I/O power switch on the back of unit must be On (I) to enable this function. To turn the power o for the entire

system, press the I/O power switch on the rear panel to O [O].

Power LED

Green: System has power and is operating normally.

Red: System is in standby mode and most of the controller circuitry is powered down.

O: System is not receiving power.

Status LED

Green Blinking: Embedded system is ready, but no communication has been established with the host.

Green: Host has established communications with the embedded system.

Red Blinking: Embedded ﬁrmware is running, but has not received a DHCP IP Address.

Red: Host has determined the ﬁrmware needs to be updated, but a problem occurred during the process that will initiate a reset.

Amber Blinking: Embedded system has a valid link local IP Address and is connecting to the host.Amber: Host is updating the

embedded ﬁrmware.O: Embedded processor is resetting, or is powered up, and is booting the embedded ﬁrmware.

Hardware Failure: If a hardware failure occurs, the status LED indication will be interrupted every three seconds with a solid red

indication. For example, if the LED is blinking green when a hardware failure occurs, the LED will

alternate between blinking green and solid red at three-second intervals.

Relay LED Green: Relay port activity.

O: No Relay port activity.

GPIO LED Green: GPIO port activity.

O: No GPIO port activity.

Zone Status

Green: Zone in use.

Red: Protection mode has been enabled to protect a zone/channel; typically indicates thermal protection, clipping or over current.

O: Zone is o and protection mode has not been enabled.

10 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

Rear Panel

Speaker

Connections

(4) Speaker output zones.

Uses 4-pin Speaker Connectors.

NOTE: Compatible with 8 ohm or 4 ohm speakers.

Digital Audio Out (1) Digital optical preamp output,

line-level 96kHz/24-bit output, ﬁxed volume.

Digital Audio In (2) Digital optical audio inputs.

Supports up to 96kHz/24-bit digital audio in; PCM stereo format only.

Analog Preamp

Output

(1) Analog stereo line output (Left & Right).

Direct Line Level 2.1-VRMS Output.

Analog Input (2) Analog stereo inputs (Left & Right),

RCA line-level inputs; 22 kΩinput impedance.

Ethernet

8-pin RJ-45 port

10/100/1000 Base-T auto-negotiating port. Supports Audio Video Bridging (AVB).Activity LED:

Green Blinking: Activity (Rx/Tx)

O: No ActivityLink LED:

Green Solid: Ethernet Link is established (any speed).

O: Ethernet link is not established.

(6) IR Ports

Uses 6-pin IR Connectors to send IR signals to control devices with an IR input or IR receiver via an IR ﬂasher (5V tolerant only). See

IR Wiring section for important precautions regarding IR functionality before making any connections.

Relay

3-pin Control Connector.

See Relay Wiring for pinouts.

Normally Open (NO) Normally Closed (NC) to control devices requiring basic on/o operation. DC Voltage Max: 30V DC 1A.

GPIO

3-pin Control Connector

See GPIO Wiring for pinoutsGPIO Input: When conﬁgured as an input the processor will look for a low (<0.8V DC) or a high (>2.4V

DC) state. Minimum 0V DC / Maximum 12V DC.

GPIO Output: When conﬁgured as an output, the port provides a binary output of 0-12V DC 150mA max.

RS-232 8-pin RJ-45 port used to transmit and receive serial binary data to and from serial controllable devices. CTS/RTS handshaking

availability based on component proﬁle. See RS-232 Connections section for pin-outs.

USB USB 2.0 Type A (reserved for future use)

Power Input

100/240V AC (50/60 Hz) 5.7AFuse: 250V 10A slow blow fuse; ﬁeld replaceableI/O (power switch):

I (On): Powers On the chassis.

O (O): Powers O the chassis.

11 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

3.5 PAV-AIM7C

Front Panel

Power LED

Green: System has power and is operating

normally.

O: System is not receiving power.

Status LED

O: Embedded processor is resetting, or is powered up, and is booting the embedded ﬁrmware.

Green: Host has established communications with the embedded system.

Green Blinking: Embedded system is ready, but no communication has been established with the host.

Red: Host has determined the ﬁrmware needs to be updated, but a problem occurred during the process that will initiate a reset.

Red Blinking: Embedded ﬁrmware is running, but has not received a DHCP IP Address.

Amber: Host is updating the embedded ﬁrmware.

Amber Blinking: Embedded system has a valid link-local IP Address and is connecting to the host.

Rear Panel

Reset

Resets the network settings of the device. Hold Reset Button for 5

seconds while powered on to clear network settings. Status LED will

rapidly blink red when reset is complete.

RS-232

8-pin RJ-45 port used to transmit and receive serial binary data to and

from serial controllable devices.

CTS/RTS handshaking availability based on

component proﬁle. See RS-232 Connections section for pin-outs.

(6) IR Ports

Uses 6-pin Control Connectors to send IR signals to control devices with an IR input or IR receiver via an IR ﬂasher (5V tolerant

only). See IR Wiring section for important precautions regarding IR functionality before making any connections.

Digital Audio In

(Optical)

(2) Digital optical audio inputs.

Supports up to 96kHz/24-bit digital audio in; PCM stereo format only.

Digital Audio In

(Coaxial)

(2) Digital coaxial audio inputs.

Supports up to 96kHz/24-bit digital audio in; PCM stereo format only.

Analog Inputs (3) Analog stereo inputs, RCA line-level inputs; 22 kΩinput impedance

Ethernet

8-pin RJ-45 port

10/100/1000 Base-T auto-negotiating port with Link/Activity LEDs.

Supports Audio Video Bridging (AVB).

Ethernet

Activity LED

Green Blinking: Activity (Rx/Tx).

O: No Activity.

Ethernet Link LED Green Solid: Ethernet Link is established.

O: Ethernet link is not established.

Power Input 5V DC 3A

12 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

3.6 PAV-AOM8C

Front Panel

Power LED

Green: System has power and is operating

normally.

O: System is not receiving power.

Status LED

O: Embedded processor is resetting, or is powered up, and is booting the embedded ﬁrmware.

Green: Host has established communications with the embedded system.

Green Blinking: Embedded system is ready, but no communication has been established with the host.

Red: Host has determined the ﬁrmware needs to be updated, but a problem occurred during the process that will initiate a

reset.

Red Blinking: Embedded ﬁrmware is running, but has not received a DHCP IP Address.

Amber: Host is updating the embedded ﬁrmware.

Amber Blinking: Embedded system has a valid link-local IP Address and is connecting to the host.

Rear Panel

Reset

Resets the network settings of the device. Hold Reset Button for 5

seconds while powered on to clear network settings. Status LED will

rapidly blink red when reset is complete.

USB USB 2.0 Type A (reserved for future use).

GPIO

3-pin Control Connector

See GPIO Wiring for pinouts

GPIO Input: When conﬁgured as an input the processor will look for a low (<0.8V DC) or a high (>2.4V DC) state. Minimum 0V DC /

Maximum 12V DC.

GPIO Output: When conﬁgured as an output, the port provides a binary output of 0-12V

DC 150mA max.

RCA Output (8) Analog stereo line output (Left & Right)

Direct Line Level 2.1-VRMS Output

Ethernet

8-pin RJ-45 port

10/100/1000 Base-T auto-negotiating port with Link/Activity LEDs.

Supports Audio Video Bridging (AVB).

Ethernet

Activity LED

Green Blinking: Activity (Rx/Tx).

O: No Activity.

Ethernet

Link LED

Green Solid: Ethernet Link is established.

O: Ethernet link is not established.

Power Input 5V DC 3A

13 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

3.7 PAV-AOMBAL8C

Front Panel

Power LED

Green: System has power and is operating

normally.

O: System is not receiving power.

Status LED

O: Embedded processor is resetting, or is powered up, and is booting the embedded ﬁrmware.

Green: Host has established communications with the embedded system.

Green Blinking: Embedded system is ready, but no communication has been established with the host.

Red: Host has determined the ﬁrmware needs to be updated, but a problem occurred during the process that will initiate a

reset.

Red Blinking: Embedded ﬁrmware is running, but has not received a DHCP IP Address.

Amber: Host is updating the embedded ﬁrmware.

Amber Blinking: Embedded system has a valid link-local IP Address and is connecting to the host.

Rear Panel

Reset

Resets the network settings of the device. Hold Reset Button for 5

seconds while powered on to clear network settings. Status LED will

rapidly blink red when reset is complete.

USB USB 2.0 Type A (reserved for future use).

GPIO

3-pin Control Connector

See GPIO Wiring for pinouts

GPIO Input: When conﬁgured as an input the processor will look for a low (<0.8V DC) or a high (>2.4V DC) state. Minimum 0V DC /

Maximum 12V DC.

GPIO Output: When conﬁgured as an output, the port provides a binary output of 0-12V

DC 150mA max.

Balanced Audio

Outputs (8) Analog Stereo Balanced Line Output (Left & Right). Direct Line Level 4.2-VRMS.

Ethernet

8-pin RJ-45 port

10/100/1000 Base-T auto-negotiating port with Link/Activity LEDs.

Supports Audio Video Bridging (AVB).

Ethernet

Activity LED

Green Blinking: Activity (Rx/Tx).

O: No Activity.

Ethernet

Link LED

Green Solid: Ethernet Link is established.

O: Ethernet link is not established.

Power Input 5V DC 3A

14 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

4. Wiring and Connections

The Savant IP Audio control connections send data to control a device and receive data to display current status on the user interfaces or trigger a system

action. Each port type may support multiple protocols that are determined by the logical connection within Blueprint.

4.1 RS-232 Wiring – PAV-SIPA50SM, PAV-SIPA125SM, PAV-AIM7C

The PAV-SIPA50SM, PAV-SIPA125SM, and PAV-AIM7C all use the same RS-232 wiring. Refer to the diagram and information below for pinout and wiring

instructions.

RS-232 Pinout

RJ-45 to DB9 Serial Control Adapters

Refer to the RS-232 Conversion to DB9 and RS-422/485 Pinout Application Note located on the Savant Customer Community for more information on

RJ-45 to DB9 adapters.

IMPORTANT!

If using RJ-45 to DB9 adapters not supplied by Savant:

• Ensure that any wires required for communication/control are terminated within the adapter.

• Ensure that all wires NOT required for communication/control are NOT terminated in the connector.

• Ensure that the unused wires in the connector are cut to prevent them from shorting out, as they are still terminated in the RJ-45 connector on the

controller side.

HELPFUL INFORMATION:

• Savant recommends planning control connections and protocols to be used prior to building any cables and connecting equipment. This will ensure

that devices will respond to commands and will not be damaged by an incorrect cable conﬁguration.

• When installing wire in screw down terminals, strip a 1/4 inch of insulation from each wire and twist the strands together. This will allow for the

exposed wire to be inserted into the terminal up to the insulation eliminating stray strands that may cause shorting.

NOTES:

• CTS/RTS handshaking is supported for ﬂow control based on the proﬁle used in the conﬁguration.

• IP Audio devices do not support RS-422/485

15 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

4.2 Serial Control Wiring – PAV-SIPA1SM

Serial control connections for the PAV-SIPA1SM are made using the 6-pin connectors supplied with the device. Wires slip into the holes and are secured

using the screw located at the top of the connector.

4.3 IR Wiring

The PAV-SIPA1SM, PAV-SIPA50SM, PAV-SIPA125SM, and PAV-AIM7C all feature available ports for passing IR control to component devices. Follow the

diagram and notes below for the model of IP Audio device being installed to wire any IR control connections to component devices.

PAV-SIPA50SM PAV-SIPA1SM / PAV-SIPA125SM /PAV-AIM7C

IR connections are made using 4-pin IR connectors supplied with

the device. The wire slips into the hole and locks with a screw

located at the top of the connector.

IR Pinout

NOTE:

While not shown in the

diagram, IR connections 3

and 4 follow the same wiring

as 1 and 2.

IR connections are made using 6-pin IR Connectors supplied with the

device. The wire slips into the hole and locks with a screw located at the

top of the connector.

IR Pinout

NOTE:

While not shown in the diagram, IR

connections 4 to 6 follow the same

wiring as 1 to 3.

NOTES:

• CTS/RTS handshaking for ﬂow control is not supported with the PAV-SIPA1SM.

• RS-422/485 is not supported with the PAV-SIPA1SM.

IMPORTANT! IR Wiring Precautions

• Ensure that all IR emitters are within 15 feet (4.6 meters) of the controller’s location.

• Use of 3rd party ﬂashing IR emitters with Talk Back is not recommended. These types of emitters can draw voltage away from the IR signal, which

may degrade IR control performance.

16 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

4.4 Speaker Wiring

The PAV-SIPA1SM, PAV-SIPA50SM, and PAV-SIPA125SM use the same Speaker wiring. Speaker wiring is made using 4-pin Speaker Connectors supplied

with the IP Audio devices. The wire slips into the hole and locks with a screw located at the top of the connector. Speaker connectors accept up to

12AWG speaker cable.

4.5 GPIO Connections

The PAV-SIPA125SM, PAV-AOM8C, and PAV-AOMBAL8C have GPIO ports which share the same wiring. General Purpose Input/Output (GPIO) ports are

binary I/O ports used by Savant controllers to trigger actions within the system. GPIO actions may be conﬁgured to control a device, such as turning

on an ampliﬁer (output), or detecting a device state change (input) to perform a triggered workﬂow. Pin 2 is used for input or output depending on

conﬁguration.

GPIO Pull Down Resistor (PD) Usage

GPIO pins are conﬁgured as inputs and are pulled high to 12V while the host is booting up. To make the

GPIO signal low during a host reboot and/or a power cycle, attach the GPIO 1 pin to the PD pin. The PD

pin is a 1K ohm pull down resistor (to signal ground) which keeps the GPIO output below 0.8V during

processor boot times.

NOTES:

• Wire order shown does not represent any wiring standard. It may be dierent than other models.

• While not shown in the diagram above, Zones 2 to 4 follow the same wiring as Zone 1.

HELPFUL INFORMATION:

GPIO functionality for Savant Controllers is deﬁned by the associated Proﬁle used within RacePoint Blueprint. All further programming (State Trigger

conﬁguration for example) must also be done within Blueprint. For further information on programming of GPIO and relay ports, refer to the Relay

and General Purpose Input/Output Proﬁles - Application Note, available on the Savant Customer Community.

17 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

4.6 Relay Connections

The PAV-SIPA125SM features a relay port, used to control components via a normally open (NO) or normally closed (NC) relay.

4.7 Network Connection

Savant IP Audio devices use a standard RJ-45 port complying with IEEE 802.3 Ethernet standards. This port also supports Audio Video Bridging (AVB)

or Time Sensitive Networking (TSN) over Ethernet (AVB/TSN, IEEE 802.1).

4.8 AC Power Connection

Read and follow all warnings and instructions related to the AC power connection below.

SURGE PROTECTION!

Use a surge-protected circuit for all components and power supplies requiring 100/240V (AC 50/60 Hz) source power.

ELECTRICAL DISCONNECT!

The source power outlet and power supply input power sockets should be easily accessible to disconnect power in the event of an electrical hazard or

malfunction.

Power Management Recommendations

Savant recommends a pure sine wave uninterruptible power supply (UPS) with the ability to shut down the Savant Host before the battery runs out of

power. Never remove power from the Savant devices before shutting them down. See Appendix E for more information.

HELPFUL INFORMATION:

Relay functionality for Savant Controllers is deﬁned by physical wiring (which should follow

speciﬁcations for the controlled component), as well as the associated Proﬁle used within RacePoint

Blueprint. For further information on programming GPIO and/or relay ports, refer to the Relay

and General Purpose Input/Output Proﬁles - Application Note, available on the Savant Customer

Community.

18 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

4.9 Checking and Replacing the Fuse

Carefully follow the instructions outlined below to remove, check, and replace the IP Audio device fuses (see subsection 4.10 below for PAV-SIPA1SM).

ELECTRIC SHOCK HAZARD:

Disconnect the unit from AC power by removing the power cord from the AC outlet and the unit before replacing the fuse.

IMPORTANT:

The orientation of the cartridge within the unit and location of the fuse within the cartridge are crucial to proper operation. Make note of the

orientation of the cartridge and the fuse location within the cartridge before removing.

1. Disconnect the unit from AC power by removing the power cord.

2. Open the fuse cover on the AC power input using a ﬂat head screwdriver or similar thin ﬂat head

tool. This will allow access to the fuse cartridge.

3. Using a ﬂat head screwdriver or similar thin ﬂat head tool, gently loosen the cartridge and pull

the cartridge out of the unit slowly. As the cartridge is removed, make note of the orientation,

as it is important to proper operation.

4. Remove the old fuse from the cartridge and discard.

5. Gently place the new fuse in the cartridge and place the cartridge part way into the receptacle

aligning it as deﬁned in the diagram.

6. Gently press on the cartridge the rest of the way until it seats into the terminals at the rear of

the slot.

4.10 Checking and Replacing the Fuse [PAV-SIPA1SM]

The PAV-SIPA1SM uses a dierent model/design of fuse from the other IP Audio devices outlined in this document. Carefully follow instructions below to

check or replace fuse.

ELECTRIC SHOCK HAZARD:

Disconnect the unit from AC power by removing the power cord from the AC outlet and the unit before replacing the

fuse.

1. Disconnect the unit from AC power by removing the power cord.

2. Remove the fuse cartridge by pulling the tab marked in the image below.

3. Remove the old fuse from the cartridge and discard.

4. Gently clip the new fuse into the cartridge and slide the cartridge part way into the receptacle, ensuring that the

alignment is correct.

5. Press cartridge fully into receptacle, ensuring that it is seated and secure.

NOTE: If any resistance is encountered while seating the cartridge, DO NOT apply more pressure. Stop pressing the

cartridge, remove it, verify that the fuse is properly placed and fully seated, align cartridge carefully, and reinsert.

TIP: Mark the chassis and fuse holder with a marker in order to align when replacing.

NOTE: If any resistance is encountered while seating the cartridge, DO NOT apply more pressure. Stop pressing on the cartridge, remove it, verify the

orientation, and repeat step.

19 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

5. Installation

The PAV-SIPA50SM and PAV-SIPA125SM can be installed in a National Electrical Manufacturers Association (NEMA) rack.

5.1 PAV-SIPA50SM

Rack Installation

The PAV-SIPA50SM can be mounted in a 2U rack style enclosure and is compatible with all standard 19-inch NEMA rack mounts. The rack bracket needs

to be attached prior to placing in a rack.

Enclosure Installation

The PAV-SIPA50SM device can be mounted in a structured media panel. The enclosure brackets need to be attached prior to mounting. Savant

recommends using vented (louvered) enclosure doors.

20 of 35

Savant IP Audio Deployment Guide

009-1571-02 | 190508

5.2 PAV-SIPA125SM

Rack Installation

The PAV-SIPA125SM can be mounted in a 2U rack style enclosure and is compatible with all standard 19-inch NEMA rack mounts. The rack brackets need

to be attached prior to placing in a rack.

5.3 PAV-AIM7C/PAV-AOM8C/PAV-AOMBAL8C

These devices can be placed on a solid ﬂat surface such as a table or shelf. Also, they can be placed on any generic 1U NEMA rack shelf.

5.4 PAV-SIPA1SM

The PAV-SIPA1SM includes side-mounting brackets for installation in a structured media panel, enclosure, or on a wall. The unit can also be placed on

any ﬂat surface, such as a table or shelf, or can be combined with an optional rack mounting kit (RMB-SIPA12F-00) which allows 2 units to be placed side

by side in a standard 1U rack mounting.
