Savant SMS-001A-00 User manual

IMPORTANT!Initial Startup Requirements!
Before Powering on the SMS:
•Verify that the SMS is connected to a network router or switch.
•Verify that all audio outputs are connected.
Before Configuring the SMS:
•Update the SMS-001A to the latest version of firmware.
Refer to the Savant Media Server Single Source Deployment
Guide located on the Savant Community for more information.
Box Contents
(1) Savant Media Server Single Source (SMS-001A-00)
(1) 12V DC Power Supply with Multi-country plugs
(1) RCA Y Adapter Cable - 3.5 mm (1/8 in) Stereo to Dual RCA
(1) Vesa Pattern Mounting Bracket (75 mm and 100 mm)
(1) Quick Reference Guide (this document)
Specifications
Environmental
Environmental
Temperature
32° to 104° F (0° to 40° C)
Humidity
10% to 90% Relative Humidity
(non-condensing)
Cooling
10 CFM
Maximum BTU
65 BTU/hr
Dimensions and Weight
Dimensions and Weight
Height
2.0 in (51.5 mm)
Width
4.59 in (116.6 mm)
Depth
4.41 in (112 mm)
Weight (Net)
6 lbs (2.7 Kg)
Rack Space
2U (See RCK-5000)
Power
Power
Power Supply
12V DC
120-240V AC 36W
Storage
Storage
Internal
35 GB Solid State Drive
Audio
Audio
Stereo Audio Out
2 Channel
Compliance
Compliance
Safety and Emissions
FCC Part 15 | CE | C-Tick | CCC
RoHS
Compliant
Minimum Supported Release
Minimum Supported Release
Savant OS
da Vinci 6.0.1
Front Panel
USB 3.0
Single USB 3.0 port: Used to connect to
external USB hard disk drive for playback of
local content. (HDD not included)
Rear Panel
Power
Connector
12V DC 36W power connector.
Cooling
Vents
Provides cooling for the internal components.
WARNING! DO NOT block vents in order to
maintain proper cooling.
Ethernet
8-pin RJ-45 10/100/1000 Base-T Gigabit auto-
negotiating Local Area Network (LAN) port
with Link/Activity LEDs.
Green LED indicates link status
Yellow LED indicates Ethernet activity
Data Rate
LED
Off:10 Mbps data rate
Yellow: 100 Mbps data rate
Link LED
Off:Ethernet link is not established.
Green Solid: Ethernet link is established.
Green Blinking: Ethernet activity is occurring
USB 2.0
Dual USB 2.0 ports: Used to connect to
external USB hard disk drive for playback of
local content. (HDD not included)
Audio Out
3.5 mm (1/8 in) Stereo jack for line level audio
output: Use included RCA Y adapter cable to
connect to Savant SmartAudio chassis or
amplifier.
Note:
Connections not identified in the diagram above are not functional
within a Savant Configuration/Installation.
SMS-001A-00 | 009-1195-03 | 150316
SMS-001A-00 | 009-1195-03 | 150316
45 Perseverance Way, Hyannis, MA 02601
Copyright © 2015 Savant Systems, LLC
1
of
2
savant.com | 508.683.2500
Savant® Media Server Single Source
Quick Reference Guide
For Product Info

Top Panel
Power
Button
Press to power the SMS-001A On or Off.
Blue indicates that the unit is powered on.
HDD LED
Solid or Flashing indicates SSD activity. Will
increase to solid with more activity.
Refreshing IP Connection
•Cycle Power
•Hot Plug the Ethernet (LAN) Connection
Installation Considerations
The SMS-001A should be installed on a solid, flat, level surface such
as a table or an RCK-5000 2U rack shelf using the rubber feet that
are shipped with the product.
Cable and Wire
The SMS-001A has multiple connections on the back panel. Savant
recommends that the input and output cables are clearly labeled.
Label the cables with their destination or source. Modifications will
be easier in the future.
Audio Connections
The analog audio output of the SMS-001A is typically connected to
the audio source input of a Savant Audio Matrix and Controller such
as the SSA-4004 or SSA-4012.
Configuration Prerequisites
NOTE:
All connections are required before configuring the Savant Media
Server. Verify that all Audio and IP cables are connected before
configuring the SMS-001A.
Cleaning and Maintenance
The internal parts of the SMS-001A are electronic and require no
maintenance. You can clean only with a dry cloth. Do not use any
spray-type, abrasive cleaners on the media server.
Important Safety Instructions
DD"8
Operation-Manual2
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding-type plug has two blades and a third
grounding prong. The wide blade or the third prong is provided
for your safety. If the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use at tachments/accessori es specied by the manu facturer.
12. Use only with a cart, stand, tripod, bracket, or table
specied by the manufa cturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally,
or has been dropped.
15. Use the mains plug to disconnect the apparatus from the mains.
16. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
17. DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR
SPLASHING AND ENSURE THAT NO OBJECTS FILLED
WITH LIQUIDS, SUCH AS VASES, ARE PLACED ON THE
EQUIPMENT.
18. THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN
READILY OPERABLE.
TO PREVENT ELECTRIC SHOCK DO NOT REMOVE TOP OR
BOTTOM COVERS. NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
TOCOMPLETELYDISCONNECTTHISEQUIPMENTFROM THE
AC MAINS, DISCONNECT THE POWER SUPPLY CORD PLUG
FROM THE AC RECEPTACLE. THE MAINS PLUG OF THE
POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE.
WATCH FOR THESE SYMBOLS:
The lightning bolt triangle is used to alert the user to the
risk of electric shock.
The exclamation point triangle is used to alert the user to
important operating or maintenance instructions.
IMPORTANT
DD-8 ampliers require Class 2 output wiring.
MAGNETIC FIELD
CAUTION! Do not locate sensitive high-gain equipment such as
preampliers or tape decks directly above or below the unit. Because
this amplier has a high power density, it has a strong magnetic eld
which can induce hum into unshielded devices that are located
nearby. The eld is strongest just above and below the unit.
Ifanequipment rackisused, werecommend locating theamplier(s)in
the bottom of the rack and the preamplier or other sensitive
equipment at the top.
FCC Compliance Notice
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:(1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation. Any changes or modifications of this product,
not approved by the manufacturer will void the user’s authority to
operate the equipment.
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
Additional Information
Refer to the following documents located on the Savant
Community for additional information.
•Savant Media Server Single Source Deployment Guide
