Savch H Series User manual

SAVCH Programmable Logic Controller
H/M series PLC MPU
User Manual

Contents
1. Products receiving..................................................................................................................................... 3
2. Model description.......................................................................................................................................3
3. Product model list & dimensions............................................................................................................. 3
4. Indicator Description..................................................................................................................................4
5. Power Supply Specification......................................................................................................................5
6. Environmental Specifications for Product.............................................................................................. 5
7. Digital Input (DI) Specification................................................................................................................. 6
8. Digital Output (DO) Specification............................................................................................................ 6
9. Digital Input / Output (DI/DO) Wiring Diagram...................................................................................... 6
10. MPU Terminal Wiring Diagram.............................................................................................................. 7
11. Programming Cable Wiring.................................................................................................................... 8
12. Address Setting........................................................................................................................................8
13. Power Supply Wiring...............................................................................................................................8
14. Mounting and installation........................................................................................................................8

1. Products receiving
All products have been performed with strict test and inspection. After receiving the inverters, the following
checks shall be performed.
●To check that SAVCH inverter, an instruction manual is inside of the package
●To check whether model number correspond with model your purchase order.
●To check whether there are damaged parts during transportation and delivering. If there are, do not connect
with power supply.
If any of the above checkpoints are not satisfactory, contact your SAVCH ELECTRIC representative for a quick
resolution.
2. Model description
3. Product model list & dimensions
Ethernet Model
24VDC
Model
24VDC
Dimension
Figure No.
SMC-H16MRD-e
0.56A
SMC-H16MRD
0.53A
93×95×82mm
Size A
SMC-H16MTD-e
0.58A
SMC-H16MTD
0.55A
SMC-M16MTD-e
0.58A
SMC-M16MTD
0.55A
SMC-H24MRD-e
0.6A
SMC-H24MRD
0.57A
SMC-H24MTD-e
0.62A
SMC-H24MTD
0.59A
SMC-M24MTD-e
0.62A
SMC-M24MTD
0.58A
SMC-H32MRD-e
0.64A
SMC-H32MRD
0.61A
131×95×82mm
Size B
SMC-H32MTD-e
0.66A
SMC-H32MTD
0.63A
SMC-H40MRD-e
0.68A
SMC-H40MRD
0.65A
SMC-H40MTD-e
0.7A
SMC-H40MTD
0.67A
SMC-M40MTD-e
0.71A
SMC-M40MTD
0.68A

Ethernet Model
24VDC
Model
24VDC
Dimension
Figure No.
SMC-H60MRD-e
0.78A
SMC-H60MRD
0.75A
177×95×82mm
Size C
SMC-H60MTD-e
0.8A
SMC-H60MTD
0.77A
SMC-M60MTD-e
0.81A
SMC-M60MTD
0.78A
Ethernet Model
220VAC
Model
220VAC
Dimension
Figure No.
SMC-H16MR-e
10.2W
SMC-H16MR
9.6W
93×95×82mm
Size A
SMC-H16MT-e
10.9W
SMC-H16MT
10.3W
SMC-M16MT-e
10.7W
SMC-M16MT
10.1W
SMC-H24MR-e
11.3W
SMC-H24MR
10.7W
SMC-H24MT-e
11.7W
SMC-H24MT
11.1W
SMC-M24MT-e
12.3W
SMC-M24MT
11.7W
SMC-H32MR-e
13.1W
SMC-H32MR
12.5W
131×95×82mm
Size B
SMC-H32MT-e
12.7W
SMC-H32MT
12.1W
SMC-H40MR-e
13.3W
SMC-H40MR
12.7W
SMC-H40MT-e
14.7W
SMC-H40MT
14.1W
SMC-M40MT-e
14.9W
SMC-M40MT
14.3W
SMC-H60MR-e
17.1W
SMC-H60MR
16.5W
177×95×82mm
Size C
SMC-H60MT-e
17.8W
SMC-H60MT
17.2W
SMC-M60MT-e
17.9W
SMC-M60MT
17.3W
4. Indicator Description
①PWR: Power indicator,green. Continuous ON - Power good; OFF - Power error.
②RUN: Running indicator,green. Continuous ON - PLC is in running state; OFF - PLC was shutdown.
③COM: Communication indicator,green. Flickering - PLC is in communicating state, the flicker frequency
indicates the speed of the communication; OFF - No communication.
④ERR: Error indicator .double (red. yellow), as follows

Consult manage
Signify information type
ERR the state of the indicator
Normal
Without error
Not light
Normal,just prompt take
attention to the locked data
PLC have the component which
locked
Yellow flicker: On 0.2 seconds and
Off 0.8 seconds
Modificate the PLC hardward
configure
Problem in the soft setting ,permit
user keep on operate the user
program
Yellow flicker: On 0.2 seconds and
Off 0.8 seconds
Check module parallel bus
(check the RTC battery;
check extension module
power supply)
Communication abnormal between
modules, auto dislodge the
abnormal module, permit user keep
on operate the user program
Yellow flicker: On 0.8 seconds and
Off 0.2 seconds
Upgrade the fireware or
modify the user program
Fireware abnormal or user program
abnormal,can not operate the user
program
Red slowly flicker:indicator light
0.5s not light 0.5s
Maintain
Hardware error,user program con
not running
red constant light
5. Power Supply Specification
Item
AC Power Supply
DC Power Supply
Power Supply Voltage
100~240VAC
DC24V -15%~+20%
Power Supply Frequency
50~60Hz
——
Power Consumption
25VA MAX
——
Instantaneous Surge
20A 1.5ms MAX @220VAC
20A 1.5ms MAX @24VDC
Power Loss Time
20ms or less @220VAC
10ms or less
Fuse
2A, 250VAC
2A, 250VAC
5V Output Voltage (for CPU)
5V, -2%~+2%, 1.2A MAX
5V, -2%~+2%, 1.2A MAX
24V Output Voltage (for
output and extension)
24V, -15%~+15%, 500mA MAX
24V, -15%~+15%, 500mA MAX
24V Output Voltage (for input
and peripheral)
24V, -15%~+15%, 300mA MAX
Use external 24VDC power
supply
Insulation Type
Transformer isolation or
optoelectronic isolation
,1500VAC/1 minute
No Electrical isolation
Power Protection
DC24V output over current
DC input power polarity reverse,
over voltage
6. Environmental Specifications for Product
Item
Environment Specification
Temperature/Humidity
Operating temperature:0~+55℃Storage temperature:-25~+70℃
Humidity: 5~95%RH, No condensation
Vibration Resistance
10~57 HZ, amplitude=0.075mm, 57HZ~150HZ acceleration=1G, 10
times each for X-axis, Y-axis and Z-axis
Impact Resistance
15G, duration=11ms, 6 times each for X-axis, Y-axis and Z-axis
Interference Immunity
AC EFT:±2500V Surge:±2500V
DC EFT:±2500V Surge:±1000V
Over Voltage Resistance
1500VAC/1min between AC terminal and PE terminal, 500VAC/1min
between DC terminal and PE terminal
Insulation Impedance
≧5MΩbetween AC terminal and all input/output points to PE terminal
@500VDC

Item
Environment Specification
Ground
The third kind of grounding(Connecting to the ground of high voltage
system is prohibited)
Operating environment
Avoid dust, moisture, corrosion, electric shock and external shocks
7. Digital Input (DI) Specification
Item
Digital Input (DI)
Input Signal
No voltage contact or NPN/PNP
Action driving
ON>3.5mA OFF<1.5mA
Input Impedance
Input Impedance≈4.3KΩ
Maximum Input Current
10mA
Reaction Time
6.4ms DEFAULT, can be configured to 0.8~51.2ms
Insulation Type
Optoelectronic isolation for each channel
Input Indication
LED's lighting indicates ON, no light indicates OFF
Power supply
MPU internal power supply:DC power supply (SINK or SOURCE)
5.3mA@24VDC
8. Digital Output (DO) Specification
Item
Output point type : Relay - R
transistor output T
Maximum
load
Resistive Load
2A/1 point, 8A/4 points COM
0.5A/1 point, 2A/4 points COM
Inductive Load
50VA
5W/DC24V
Lamp load
100W
12W/DC24V
Minimum Load
10mA
2mA
Voltage Specification
Below 250VAC, 30VDC
30VDC
Drive Capability
Maximum contact capacity:
5A/250VAC
1A MAX, 10 seconds
Reaction Time
Off→On 10ms, On→off 5ms
Off→On 10μs，On→Off 120μs
Insulation Type
Mechanical isolation
Optoelectronic isolation for each
channel
Output Indication
LED's lighting indicates ON, no light indicates OFF
Power Supply
MPU internal 24VDC power supply
9. Digital Input / Output (DI/DO) Wiring Diagram
NPN Internal power NPN External power

PNP Internal power PNP External power
AC / DC Relay output DC NPN Transistor output
10. MPU Terminal Wiring Diagram

11. Programming Cable Wiring
Computer side (RS-232) DB9 female PLC side (COM1) 4 core S terminal male
12. Address Setting
Savch PLC with Ethernet port, the default IP address is: 192.168.1.111, subnet mask:
255.255.255.0, gateway: 192.168.1.1. Hardware DIP dial switch address range: 1-15,
the default address is 1. If you need to set a bigger address range, you can set on the
software after connection with PLC, it can be set on the PLC parameter option in the
software menu by checking on the "soft address" with the range of 1-254(the soft
address is prior to the hardware dial address).
13. Power Supply Wiring
There are two kinds of power supplies for PLC: AC input and DC input. Please pay particular attention to the
following notes:
•AC input voltage is 100~240VAC 50/60Hz unless otherwise stated. Connecting any one of the AC input
wires to the terminal-L and terminal-N on the MPU will be OK, but for safety's sake, please connect the
two wires (Live Wire & Neutral Wire) of AC input to terminal-L and terminal-N respectively.
•Any AC110V or AC220V connected to the +24V terminal or input points will permanently damage the
PLC.
Please use wires of 2.5mm or above for the grounding of the MPU.
14. Mounting and installation
The PLC should be secured to an enclosed cabinet
while mounting. For heat dissipation, make sure to
provide a minimum clearance of 50mm between
the unit and all sides of the cabinet. (See the
figure.)
Rail Mounting: Use standard 35 mm rail.
Screw Mounting: Each MPU or extension module
has two positioning screw holes, the diameter of
the hole is 4.5mm. Please refer to the dimension
figure for the location of the positioning holes and
their spacing.
To avoid over temperature and for a better heat
dissipation, do not mount PLC to a position near to
the bottom/top of the cabinet. Do not mount PLC in
vertical direction.
Extension Module Wiring: Connections between
extension modules and connections between
module and MPU are achieved through bus. An
extension cable will be configured to every
extension module, for the connection between two
different modules.
Connection methods: turn the right side of
extended interface (the last MPU or extension
module) over, plug the extension cable in the
extended interface, then press down the cover of
the extended interface to reset the interface, the
extended interface at the right side of the module
will be reserved for extension of the next module.
Connect all extension modules in turn in the same
way.
