Saveo Scan SAVEO-SCAN-M22D-BH User manual

Getting Started
Power Switch
Power switch is located on the
underside of the scanner.
On the underside of the scanner you will nd a small recessed
button.
Use a pen or paper clip to push the button until you hear a
notication sound.
Ensure power switch remains depressed after you release it.
Power on Saveo Scan
Switch on and Charge your Scanner
Please switch on your scanner (as illustrated) and place it in the
cradle to charge for 3~4 hours before rst use.
If you want to charge smartphone and scanner simultaneously,
please switch scanner to right “C” (charge mode) before placing
it in the cradle.
*Please remove the protective sticker from window
before use
Trigger/Power
On button
Wrist Strap
Universal Holder
Exit Window
Operating Elements
LED indicator
Charging Cradle
Switch for Operation Mode
and Charge Mode/Bluetooth
Mode
Micro USB Cable
Use Micro USB cable to connect
to smartphone/tablet
SAVEO-SCAN-M22D-BH
Extend retractable
arm
Press button and slide
outwards to extend the
arm
Attaching your smartphone to scanner using the
universal holder
Extend the retractable arm before placing phone in holder and
then pushing it rmly back against the phone.
Secure phone in
holder
Insert phone
Attach your smartphone
12 3
Connect phone to scanner with Micro USB
As USB connection locations vary on dierent models of
smartphone, the cable can be congured for your specic
model. For iOS devices, please attach the appropriate
adapter to connect to your device.

Connecting via USB OTG
Switch scanner to Operation Mode (Data trans-
mission via USB OTG)
Switch to left:
Operation Mode/
Data transmission
Conrm scanner is connected
Saveo Scan is detected by your smartphone as an external
keyboard. A message will appear on screen to notify you that a
USB device has been connected.
You are now connected. Start scanning.
Scan the Wired USB OTG Communication
barcodes below
Demo
%W%I%R
Demo
%E%R%A
Connecting via Bluetooth
Enable Bluetooth on your device
Go to your phone’s homescreen and nd “Settings”, then
“Bluetooth” and turn Bluetooth on.
Switch scanner to Charge Mode/Bluetooth Mode
Scan the Wireless BT Communication barcodes
below
Demo
%W%L%T
When Bluetooth is enabled, the LED will remain red until the
scanner has been paired with a Bluetooth device.
Switch to right:
Charge Mode/
Bluetooth
Mode
Demo
%E%R%A
Scan Bluetooth Prole Barcodes below
After you scan the Bluetooth prole barcodes below, your
scanner will become visible to Bluetooth enabled devices within
range.
Demo
%H%I%D
HID Prole
A1
A2
Demo
%B%R%C
Search for devices
Your phone will automatically search for devices, Saveo Scan will
appear as an external keyboard with a unique identier number
(R-xxxxxx).
Select R-xxxxxx
to connect
Please note: devices only need to be paired once. When they are within
Bluetooth range they will automatically attempt to connect to each other. If
you wish to pair to another device it is recommended you rst unpair this
device.
You are now connected. Start scanning.
4 5 6
Please note: The scanner should only be paired with one device
at a time. Before you pair your scanner to another device, please
rst unpair it from the device in use. Otherwise it will appear on
your list of “Available Devices” but will not connect. In this case,
please refer to “Unpairing your device” in this guide.
Select scanner from “Available
Devices”and wait for pairing
process to complete.
Devices are now
paired
Once “Connected” is
displayed, your device is
paired to the scanner. Your
scanner is now ready to use.

There are two operating modes on the scanner, Data transmis-
sion mode and Data Storage Mode.
Scan the appropriate barcodes when switching between these
two modes.
Please note: Switching between modes will wipe the scanner’s
internal memory.
Operating Modes
Data Transmission Mode (Default)
Our Default setting is Data Transmission mode. In this mode data
will be sent to smartphone/tablet directly.
To enter Data Transmission Mode please scan the follwing
barcodes.
Demo
%E%R%A
Demo
%M%A%F
Enter Data Transmission Mode
Green/Orange LED ashes followed by 3 beeps.
Demo
%M%A%N
Data Storage Mode
In this mode, data will be saved directly to scanner’s memory.
Scan Transmit Memory Data to receive data stored on scanner’s
internal memory.
Enter Data Storage Mode
Green/Orange LED ashes followed by 3 beeps.
Demo
%E%R%A
To enter Data Storage Mode please scan the follwing barcodes.
7 8 9
Demo
%E%R%A
Clean Memory Data
Green/Orange LED ashes
followed by 3 beeps.
Demo
%R%E%C
Transmit Memory Data
Green/Orange LED ashes
followed by 3 beeps.
Transmit Memory Data
Scan the following barcode to receive data stored in the
scanner’s internal memory..
After data is transmitted to your device it remains on the
scanner’s internal memory. Scan the following barcode to clear
the memory if you do not wish to send this data again.
Reset Conguration to Defaults (scan from A1 to A4)
A1
A2
Reset to Defaults
Demo
%E%R%A
When the battery power is too low, the Orange LED will ash
and beep once. Scanner should be charged immediately. If
scanner shuts down it is recommended to charge it fully then
power it back on.
Under power-saving mode, there will not be an LED
indication when charging.
Orange LED ON Full charged
Orange LED (Flashing) Charging / Low battery
Red LED ON Oine / Out of Range
Green LED ON Good read
Orange LED ON Good read (Batch mode)
LED Indicator Information
LED Indicator
Demo
Current Battery Level
Scan to receive the current
battery level
Scan the following barcode to send battery level information
to your device. The format is outlined in the table below.
%^4^% 80% - 100%
%^3^% 55% - 80%
%^2^% 30% - 55%
%^1^% 10% - 30%
%^0^% under 10%
Battery Level Status
A3
A4
Demo
%H%I%D
Demo
%B%R%C
Sound Settings
Scan the barcodes to select whether or not the decoder issues a
beep signal after a good decode. If selecting Do Not Beep after
Good Decode, beeper signals are issued during parameter menu
scanning and to indicate errors.
Enable (default)
Disable

Power saving mode is enabled by default and will put the
scanner to sleep after 1 minutes inactivity. To wake up the
scanner press the trigger.
Demo
%P%D%T00
Disable
Scan to disable power saving
mode
Demo
%P%D%T01
Below are the barcodes to disable/enable power saving mode.
Power Saving Mode
Reading Mode
The default setting for reading mode is Single Scan. To choose
another mode please scan the appropriate barcodes below.
Motion Sensor: Full
Auto Mode
In this mode the scanner attempts
to decode when it senses motion.
Single Scan (Default)
In this mode the scanner attempts
to decode when the scan button
is pressed.
Demo
Demo
10 11
Transmission Speed
Transmission speed is dependent on your device. In order not to
lose data please choose the correct speed. Mid Speed is the
default.
Mid Speed
Transmission
(Default)
High Speed
Transmission
Low Speed
Transmission
Demo
%B%T%H
Demo
Demo
%B%T%L
Before connecting the scanner to another device it is
recommended you rst unpair from the current device.
Go to the Bluetooth menu on your phone and select the
option menu for scanner from list of paired devices.
Choose “Forget this Device”/”Unpair”
Unpairing your device
12
1 Minute
Enter Power Saving Mode
after 1 minutes inactivity
5 Minute
Enter Power Saving Mode
after 5 minutes inactivity
15 Minute
Enter Power Saving Mode
after 15 minutes inactivity
30 Minute
Enter Power Saving Mode
after 30 minutes inactivity
Mobile Phone/Display Mode
This mode improves bar code reading performance with target
bar codes displayed on mobile phones and electronic displays.
Disable (default)
Enable
