Sawo Innova User manual

CONTROLS
ENGLISH
INSTRUCTIONS MANUAL
STAINLESS STEEL TOUCH CONTROL
TOUCH CONTROL

Table of Contents
1.
1.1
Introduction of the Innova Controls 3
Precautions 3
2. Direction of Use
2.1 Turning on the Control Unit 4
2.2 Switching the Heater or Steamer On 5
2.2.1 Temperature 6
2.2.2 Relative Humidity 6
2.2.3 Session Time 7
2.2.4 Fan 7
2.2.5 Sauna Session 7
2.2.6 Steamer Session 7
2.3 Switching the Control Unit On/Off 8
4
9
2.4.1 Settings 9
2.4.3 Pre-run Timer for Domestic Saunas
9
2.4.4 Pre-run Timer for Public Saunas with Weekly Timer 11
2.4.2 Pre-run Timer 9
13
2.3.1 Cabin Light 8
2.4 Pre-run Timer
2.5 Changing the Settings
14
2.6 Other Innova Control Features
14
2.6.1 Key Lock
Technical Diagram 15
2.7.1 Steamer 17
2.7.2 Humidity & Temperature in Sauna 17
2.7.4 Water Refill
17
2.7.3 Cabin Drying
18
17
2.7 Combi Features

2
5. Troubleshooting
4. Assembly and Installation 20
21
21
22
4.4.1 Sensor Location with Heaters Mounted on the Wall 22
4.4.2 Sensor Location with Heaters Mounted on the Floor 23
4.9 Installation for Separate Control Panel 25
27
4.1 Control Unit to Heater Connection Diagram
4.2 Power Controller
4.3 Contactor Unit
20
3. Remote and Alarm Connections 19
19
3.1 Emergency Alarm
3.2 Remote On
19
4.5 Maximum Session Time 23
4.6 Door Sensor (Optional) 24
4.7 Fan (Optional) 24
4.8 Dimmer (Optional) 24
4.10 The Control Unit Main Switch 26
6. Symbol Reference 28
4.4 Sensors

English
1. Introduction of the Innova Controls
Congratulations on your purchase of Innova Control Unit!
1.1 Precautions
3
Innova Control Unit is developed to enhance your sauna bathing with a
variety of features. It can adjust temperature, humidity, ventilation and
light option in your sauna. The Innova Control Units are available on a
separate or built-in mounting on the Power Controller Board.
The following information provides you with instructions on adjusting
the settings of the control unit. Please, read this instruction manual
carefully before using the control unit. Familiarization of the key
functions will give you a more enjoyable sauna experience.
1.
2.
3.
4.
5.
6.
Only a qualified electrician is allowed to make the electrical connec-
tions and repairs on the unit. Use original parts only.
Disconnect the Power Controller and the Contactor Unit from the
electrical circuit before installation, opening the lid of the power
controller or contactor unit and repair.
Check power supply rating before installation.
Check the correct location of the sensor in the installation section of
the manual. It is very important to place the temperature sensor
correctly as it closeness of the air ventilation cools down the sensor
and may lead to overheating.
The control unit can be operated on a room temperature 0-40°C. Do
not install the control unit inside the sauna room!
Do not pour water in the control unit or clean it with wet cloth. For
cleaning purposes, use a cleaning cloth that has been only slightly
moistened with a mild soapy solvent (dish detergent).

2. Direction of Use
2.1 Turning on the Control Unit
4
Then, the control unit will go to OFF mode, where you can switch on the heater, use
lights, activate key lock and go to assy-mode
When turning on the power controller, Innova Touch will a turn on
and automatically go to off-mode.
Turn heater on/off
OFF-mode
Cabin light on/off
Easy-mode
Settings
Timer
Current week and time
WHEN USING COMBI HEATER
PRESS TO ACTIVATE HEATER.
LONG PRESS TO SHUT DOWN
DISPLAY OFF-MODE
LONG PRESS TO EXIT EASY-
MODE
PRESS TO DISABLE
HEATER ON-MODE
PRESS TO ADJUST
TEMPERATURE
LIGHT ON/OFF
STEAMER ON/OFF
PRESS TO ADJUST SESSION TIME
PRESS TO ADJUST
TEMPERATURE &
HUMIDITY
*
****
In easy mode some of the buttons are hidden. This feature makes Innova easy and fast to use. Long press the
hidden easy-button for 10 seconds to activate easy-mode. In easy-mode it is still possible to use the heater,
steamer and adjust cabin light.

5English
1.
2.
3.
2.2 Switching the Heater or Steamer *ON
WARNING
Always check that there are no combustible
materials, like towels, above the heater, nor
inside the safety distances, before switching
the heater on! The safety distances are stated
in the heater manual.
Heater and steamer are turned off
by pressing the heater-icon. After
this Innova will automatically go to
off-mode.
Alternatively, the user can switch the
steamer on by pressing the steamer
icon in the ON mode. Those features
that have animated logo are currently
active. If you want to turn on/off the
steamer*, press the steamer icon.
The heater can be switched on by
pressing the heater on icon in OFF
mode.
OFF-mode
ON-mode * not available in all models
Heater on
Steamer*
on/off Temperature and humidity
% visible when using H/R sensor

Once the heater has been
switched on, ON mode will be
displayed. The user can change the
settings simply by pressing the relevant
icon on the display and using the up and
down arrows.
2.2.1 Temperature
2.2.2 Relative Humidity
Steam on/off
Room Temperature
Light on/off
Fan on/off
Session Time
Heater on/off
Relative humidity
Temperature Unit = Celcius
Temperature Unit = Fahrenheit
6
Press the temperature icon to change the
temperature with up and down arrow keys.
After setting the preferred temperature,
user can go back to the previous state with
saved settings by pressing the OK button.
If no keys are pressed within 5 seconds
after pressing the temperature button, the
changes are saved and innova will go back
to previous state.
To change the relative humidity (not in all
models), press the humidity icon and use
the up and down arrow keys to change it.
After setting the preferred humidity, user
can go back to the previous menu with
saved settings by pressing the enter button.
45
113
50%
Up and Down
Arrow Keys
The Up and Down Arrow Keys are repetitive.
This means that holding down the up or down
key will cause the set-point value to in- or
decrease with a specific rate. This rate also
increases when holding the key for a longer
time.
If no keys are pressed within 5 seconds
after pressing the temperature button, the
changes are saved and innova will go back
to previous state.
ON-mode

English
7English
2.2.3 Session Time
Press the fan icon (not in all models),
to set the fan speed, in the range of 5% -
100%. After setting the preferred speed,
user can go back to the previous menu
with saved settings by waiting for 5
seconds to automatically return or pressing
the OK button to return immediately.
2.2.4 Fan
FAN
OFF
FAN
ON
2.2.5 Sauna Session
2.2.6 Steamer Session(available in combi models)
Press the session time icon to change it
with up and down arrow keys. After setting
the preferred session time, user can go
back to the previous menu with saved
settings by pressing the enter button.
If no keys are pressed within 5 seconds
after pressing the session time button, the
changes will be saved innova returns back
to previous state.
If the session time is changed within the
first 5 minutes after starting, the set values
are saved as a start value for the next
session.
When the session time expires, a high tone
buzzer notifies the user. Then the control
unit goes to off mode or cabin drying (only
with steamer).
The session can be finished earlier than
originally set by pressing the heater on/off
button.
The control unit goes to off mode or cabin
drying (only with steamer).
If the user attempts to put an invalid input,
short, low tone buzzer can be heard to alarm
the user.
100%
01:00
When fan is on, the icon is animated.
By pressing the fan icon again the fan
will stop and the animation of the icon
stops.
When the heater is on, the sauna icon is
animated. You can turn off the heater by
pressing the sauna icon. After pressin
innova will go to off mode/cabin dry mode.
When steam session is activated, the
steamer symbol is animated. If user
presses again the animated steamer
symbol, steamer is turned off and the
session will continue as a normal sauna
session.

8
Power “ON / OFF”
The backlight is turned off after 1 minute of inactivity (no key pressed). after 60 minutes of
inactivity (no key pressed) and no pending drain, autofan or active autosession display will turn off.
Switch OFF Timer
OFF Mode
2.3 Switching The Control Unit On/off
Cabin light “ON / OFF”
Cabin lights can be switched on and off by pressing
Cabin Light button even when the control unit is in
OFF-state. If dimmer feature is available, you can
adjust the brightness with arrow buttons. Confirm
any changes by pressing OK-button. If no buttons
are pressed in five seconds, any changes will be
saved and display returns to it’s previous state.
2.3.1 Cabin Light
100

9English
2.4 Pre-run Timer
The Innova Touch control unit has a weekly
timer that can be programmed for every day
of the week.
For domestic sauna use, the weekly timer is
not allowed*). Only one pre-run timer
setting can be made at a time. The pre-run
time is limited to a maximum of 6 hours for
domestic saunas.
By Default, the Pre-run Timer
is set for Domestic Sauna
use.
NOTE
2.4.2 Pre-run Timer
2.4.3 Pre-run Timer for Domestic Saunas
After pressing the timer icon in the OFF-
mode, the following screens will be shown
displaying existing pre-run settings
OFF Mode
2.4.1 Settings
WARNING
Always check that there are no combustible
materials, like towels, above the heater, nor
inside the safety distances, before switching
the heater or pre-run timer on! The safety
distances are stated in the heater manual.
*) IEC 60335-2-53
Timer
When small timer icon
appears, there is 1 or
more active timer
settings at the moment
*
Press to set temperature, fan power* and steam*
Returns to
OFF-sate
Adjust time
from arrows
Change selected field
Confirm changes
and return to
OFF-mode
Activate steamer
*
*
**
*
*
This feature is only available for public saunas,
used in condominiums, hotels or other similar
places.
Press timer icon to enter the preset timer settings.
To change any preset timer settings, move on to next screen by pressing
ON-button. Turn off any timer settings by pressing OFF-button and return to
OFF-mode.

10
Move back
to OFF-state
Activate steamer*
Timer On
Small clock icon
appears when timer
is active
IF FAN FEATURE IS AVAILABLE*
ONLY WITH COMBI HEATER*
IF R/H SENSOR IS AVAILABLE*
*
*
*
*
*
**
*
*
*
Confirm and save settings
by pressing OK button
*
Timer Off
When no small clock
icon on the screen,
no active timers
Press to set temperature, fan power* and steam*
Adjust time
from arrows
Change selected field
Confirm changes
and return to
OFF-mode
By pressing OFF-button you can cancel all active
timers and go back to OFF-mode. By pressing
ON-button you will move on to changing timer
settings. Cancel all active timers by pressing the
OFF button.
You can activate steamer by pressing the
steamer icon. By pressing time you can move
the cursor from hours to minutes and change
the time value from arrow buttons. To adjust
temperature, steamer* or fan*, press the
“sauna” text. Adjust values as preferred and
move to next screen by pressing OK or waiting 5
seconds. Confirm changes and save the timer by
pressong OK and return to OFF-mode.
*Available settings may vary between
models
When adjustments to time and
settings are done, save timer by
pressing OK button.
If small timer icon is visible, it means that
there is an active timer setting at the
moment.

After pressing ON button you will go to adjust
timer settings. Days that have “ ” indicator
have an active timer. By long pressing that days
icon for 3 seconds you can cancel all active
timers from that particular day. By pressing on
any of the week days you can adjust the timer
settings of that day.
Press the timers to change selected field.
Timers that have “ ” indicator are currently
active. Activate/inactivate timer by pressing the
-button
Press the hammer icon to change settings of
the selected timer. By pressing ESC button you
can cancel any changes and return to OFF
mode.
English
11
2.4.4 Pre-run timer for public saunas with weekly timer
EACH DAY HAS
THREE TIMERS
CHECK MARK TELLS YOU
WHICH DAYS HAVE ACTIVE
TIMERS AT THE MOMENT
“ ” = ACTIVE TIMER
PRESS TO CHANGE
SELECTED FIELD
CONFIRM CHANGES
AND RETURN TO
OFF-STATE
ADJUST VALUES
WITH ARROWS
OK BUTTON CONFIRMS
CHANGES AND
RETURNS TO DAY
VIEW
ACTIVATE/DEACTIVATE
SELECTED TIMER
TIMERS CAN NOT BE SET
TO OVERLAP WITH EACH
OTHER
Timer
When small timer icon
is visible, there is active
timers at the moment
OFF-mode
NOTE
OK BUTTON CONFIRMS
CHANGES AND RETURNS
BACK TO WEEKLY
VIEW
*
*
*
*
*
*
*
*
*
*
*
*
*
*
Press timer icon to set timers
Then you can continue to adjust timer settings by
pressing OK. If you want to retunr back to OFF mode
and turn off all timers press OFF button.
Weekly timer is only available if max session time
setting has adjusted to be 12 hours or more(page
22). If max on time has been set to 12 hours,
automatic restart can only happen after 6 hours of
the previous automatic start(IEC 6-335-253).
Before setting any preset timers, make
sure that current day and time are
correct from the settings menu(2.5).
MOVE BACK
TO OFF-STATE
CHANGE SELECTED
FIELD
MODIFY SELECTED TIMER BY
PRESSING THE HAMMER ICON

12
Confirm time and settings
by pressing OK button
*
After changing setting you can confirm changes by pressing OK button and return to
daily view --> weekly view --> Off mode.
Confirm changes
for the active day
by pressing OK button
Timer on
When small clock icon
is visible, there is active
preset timers at the moment
Confirm changes to all timers
by pressing OK button
*
You can activate steamer by pressing the
steamer icon. By pressing time you can
move the cursor from hours to minutes and
change the time value from arrow buttons.
To adjust temperature, steamer* or fan*,
press the “sauna” text. Adjust values as
preferred and move to next screen by
pressing OK or waiting 5 seconds. Confirm
changes and save the timer by pressong OK
and return to OFF-mode.
*Available settings may vary between
models
Activate steamer*
IF FAN FEATURE AVAILABLE*
ONLY WITH COMBI HEATER*
IF R/H SENSOR IS AVAILABLE*
*
*
*
*
**
*
*
Press to set temperature, fan power* and steam*
Adjust time
from arrows
Change selected field
Confirm changes
and return to
OFF-mode
*

13 English
2.5 Changing the settings
Heater ON/OFF
OFF mode
Lights ON/OFF
Easy mode
Settings
Timer
Current week day and time
2.
1.
3.
4.
5.
6.
7.
From OFF mode you can access to settings, timer, Easy mode and turn on lights and
heater
Long press settings button for 5 seconds to access settings menu. In settings menu you can navigate between settings by
using arrows Right and Left, and change the displayed setting by using arrows Up and Down unless mentioned otherwise
below. After changes are done confirm them by navigating to Save&Exit screen and press SAVE. If you want to discard all
changes press ESC.
Pressing the weekday, hours or minutes button you can set the
correct time and day. In case of electricity blackout the day and
time keep runnin and there is no need to set them again.
Check what is the power of your heater and adjust the value
on screen accordingly in kilowatts.
When auto cabin light is activated, the lights will turn on
automatically when the heater is turned on. If this function is
disabled you can use the cabin light manually.
Auto fan feature is for drying your sauna room after sauna
session. You can adust the desired exhaust fan time. Fan will
turn on automatically after sauna session has ended.
You can adjust the LCD contrast.
Active balckout memory restores control to its previous state before power failure.
For example, if heater was on before power failure, the heater will automatically
continue from the previous state.
You may set the temperature scale either Celsius or Fahrenheit.

14
2.6.2 Key lock
2.6 Other Innova contorl features
8.
10.
11.
12.
13.
14.
Only in Combi heater
ONLY WHEN
AUTODRAIN IS DETECTED
LONG PRESS TO SEE ACTUAL USAGE
9.
Software version has two parts, Interface Software Version and the Controller Board
Version.
Counters displays the usage of time and kilowatt of the
heater/steamer. This info is necessary to evaluate need of
preventive maintenance and compute electricity consump-
tion. Pressing reset button will reset both counters, previous
data cant be retrieved. Long pressing reset button for 10
seconds to see actual usage. Actual usage counter can not
be reseted.
Reset all settings back to factory settings by pressing reset
button. Confirm resetting by pressing OK button. Restoring
factory settings wont reset kWh and ON hours counters.
Set the correct kilowatt value of the Combi steamer to the control(see kilowatt
information on your steamer). Change the value with arrows.
Cabin dry setting will help you to dry up your sauna room after a steam session.
After steam sesson the display will automatically start cabin dry. During cabin dry
the set value for room temperature is 70 C and fan power 100%. Cabin drying
takes 30 minutes. You can cancel on going drying by pressing ESC button. NOTE:
if cabin dry is enabled, max on time for steam session is reduced by 30 minutes if
max on time is set to 4, 6 or 12 hours.
When auto drain is enabled, it will automatically drain the water inside the combi
tank after use. In case of power interruption, it will continue to drain when
detecting high water level in the tank. If there is draining pending, this icon will
be shown on the screen:
Once everything has been set, you may press SAVE to save all the changes, or by
pressing ESC to discard all changes.
When power controller is turned ON again, the
Key Lock will remain either ON or OFF as it was
before power controller was turned OFF.
To lock/unlock screen, press more than 10
seconds the settings icon. Lock will appear on the
screen when key lock is activated: . When key
lock is activated, you can still turn the heater
ON/OFF and use the cabin lights. If any unauthor-
ised actions are made, “KEY LOCK” text will appear
on the screen for 5 seconds.

24
4.6 Door Sensor (Optional)
In other than household use, it is recom-
mended to install door sensor. The door
sensor disables all pre-run operations if the
door is opened while the pre-run count-
down is active.
The door sensor also ensures that the door
is not open for long periods of time when
the heater is on. If the heater is on and the
door is open for more than 15minutes, an
alarm and “DOOR” will be displayed to warn
the user. The heater will be switched off
automatically.
4.7 Fan (Optional)
The fan function can only be activated if the
fan feature is present on the control unit.
Ensure that the fan motor to be controlled is
either shaded pole or permanent split
capacitor motor. The maximum power
is100W with 230 VAC.
4.8 Dimmer (Optional)
It is possible to use any suitable lamp of your
choice in the sauna room. However, if the
dimmer feature is present on the control unit
and wished to be used, only incandescent
lamp is suitable.
Note!
If door sensor is not installed, “Door switch”
terminals(D-D) must be connected with each
other by a jumper wire. See figure 1. Note,
connection is not present in the drawing.

15 English
Technical Diagram
Fig. 1
(R) L1
(S) L2
(T) L3
N
PE
Tank
Level Empty Fill
PE
R-in S-in T-in N N N N N UBU V W
U V W
NN UBA
U N N
N2 in
Light
NSTBY
TANK LEVEL
NSTBY
DRAIN
FILL
FAN
EMPTY
W2 1 1 D 1 3
V
N3 4 4D
BROWN
BROWN
BLUE
WHITE
WHITE
BLACK
Temp Fuse
TS1 TS1
TS2 TS2
T/H Sensor T/H Sensor
T/H Sensor T/H Sensor
Temp Fuse
BLACK
2 4
T/H Sensor
2,3 kW - 15 kW
5 core cable
Primary
Supply
160 mA
Sauna Heater
RJ12 - Data Cable
1 meter
4 meters
Ground
Power Supply
The cable must be
HO7RN-F type or its
equivalent.
100 W
Light Fan
For Heaters more than 15 kW (see Contactor Manual)
Control Unit Main Switch
BROWN BLACK BLUE
1 1 0 1
Fuse Glass
Fan & Combi
500 mA
Fuse Glass
Light
500 mA
Fuse Glass
Sensors
Combi SteamerSteam Mate
FUS TSFUS TS
1
42
3
FUS TS
1
42
31
4
TS1 TS2
Temperature
Sensor
with Fuse
Optional
Temperature &
Humidity Sensor
Optional
Temperature Sensor
for Bench Area
Touch SST
Contactor Unit Heater >15 kW
Jumper For
Maximum Session Time
4h
6h
12h 24h
(hours)
1
JPB1
JPB1
F1
F3
F2
Do not connect both
Optional Sensors same
time. Only one of the
optional sensors at a
time is allowed.
400 V 3N~
50-60 HZ
Max. 15.0 kW
Adjust this jumper
to change max.
session time. 6hrs
is factory default.
18h
BLUE
BLUE
Note:
Note:
If no door sensor is installed, "Door
switch" terminals in the Power Controller
must be connected with each other by a
jumper wire from terminal D to terminal D.
16
WHITE

17
2.7.2 Humidity & Temperature in the Sauna
2.7.3 Cabin Drying
2.7.1 Steamer
2.7 Combi Features
These features for steamer are only appli-
cable with Combi heaters.
If during the steamer session the operation
mode is changed to heater only, there will
be no drying time at the end of the session.
You can abort cabin drying by pressing the
ESC button.
High humidity and high temperature are not
allowed simultaneously in the sauna room.
When sauna session is switched to steamer
session, sensors will check that the
temperature or the relative humidity inside
the sauna room is not too high.
If the temperature or relative humidity is
too high, the steamer will not be activated.
Steamer activation depends on the second
sensor, the bench sensor. If it is a tempera-
ture sensor only, and the bench tempera-
ture in the sauna room is 56°C or more, the
steamer cannot be activated. The user can
choose the relative time for the steamer to
be on, within 30-100% of the session time.
However, if the second sensor is combined
temperature / humidity sensor, the
maximum bench temperature for the
steamer to activate is 80°C, as long as the
relative humidity in the sauna room is not
too high. With the combined sensor, the
user can choose the relative humidity inside
the sauna room.
The standard drying time is set for 30
minutes at 70°C. If the fan is connected
with the control unit, it will be running at
100%, during the cabin drying. The cabin
drying is set to begin 10 minutes after the
steamer session. Therefore, the actual
drying time is 20 minutes.
English

18
When the water level is low, a low tone
interval beep and “Fill” will be displayed to
alarm the user.
The water tank can be filled manually or
automatically (autofill) depending on the
steamer model.
The auto Combi heater has a solenoid valve,
which will automatically react to the low level
of water. The water inlet will open to fill up
the tank and steamer session can be
continued without intervention.
In the manual fill, the alarm beeps and “Fill”
2.7.4 Water Refill
will be displayed as long as the user fills the
tank. If the water tank dries, a high tone
interval beep and “Dry” display will alarm
the user. In the display a faucet icon and
“Fill” text will be alternating each second.
The steamer will automatically be switched
off now, only the heater will be working.
Always check that the water supply is open
before using the automatic refill Combi
heater!
FILL TEXT WILL APPEAR WHEN
WATER LEVEL IS LOW
YOU CAN MUTE THE ALARM
BY PRESSING FILL TEXT/FAUCET ICON
SCREEN WILL DISPLAY FILL TEXT AND
FAUCET ICON WHEN THE WATER TANK
IS EMPTY
FILL TEXT WILL BE DISPLAYED
WHEN WATER LEVEL IS LOW
ALARM SOUND CAN BE MUTED
BY PRESSING THE FILL/FAUCET
ICON

19 English
3. Remote and Alarm Connections
Used for automated households. The remote signal is a
potential free contact. The sauna heater switches on
when contact is closed and remains on until contact is
opened.
When the sauna heater is remotely controlled, settings
use from previous session are applied. Other buttons are
locked. Only the light, Fan and Steamer buttons can be
set.
3.2 Remote On
The innova control has a provision for emergency alarm
system. Alarm button must have potential free
momentary or latching contacts.
Long press OK button to remove the alarm.
3.1 Emergency Alarm
(Back of the user’s panel)
Insert RJ Cable
(Remote)
0.5 mm2
WIRE:
(Alarm)
0.5 mm2
WIRE:
(Back of the user’s panel)
Touch Control
Stainless Steel Touch Control
Insert RJ Cable
(Remote)
0.5 mm2
WIRE:
(Alarm)
0.5 mm2
WIRE:
In order to access alarm and remote
control terminals, you need to remove
user board from its plastic casing.
NOTE
