ADJUSTABLE TORCH ARM
Tools Needed for Assembly*
Flathead Screwdriver
9/16” Nut Drive
9/16” Nut Drive
9/16” Nut Drive
Warranty
All products manufactured by or for Sawyer Manufacturing Company are
guaranteed against defects due to faulty workmanship or materials for twelve
months from the date of purchase.
This guarantee is limited to the repair or replacement of any parts found to be
defecve, and no other liability, expressed, implied or conngent is assumed.
We appreciate your business!
Congratulaons on your new SAWYER product. We are proud to have
you as our customer and will strive to provide you with the best service
and reliability in the industry. This product is backed by our extensive
warranty and world-wide service network. To locate your nearest
distributor or service agency, please contact us at the phone number
and address listed on the boom of each page.
You are in good company!
Sawyer Manufacturing Company is the world leader in the design and
manufacture of pipeline and welding equipment since 1948. Sawyer
equipment has become a standard in the industry and connues to set
the benchmark for quality and durability.
This user operaon manual has been made to instruct you for the best
use and operaon of your Sawyer product. Your sasfacon with our
products is our main goal. Please read this enre manual carefully
nong all ps, notes and warnings. Safety always comes rst.
About Us
A. (2x) 9/16” nut
B. Spacer
C. Torch Holder Adjustment Knob
D. Posion Adjustment Knob
E. 37.5-0-37.5 Degree/Bevel Indicator
F. Bevel Indicator Square Nut
G. Torch Adjustment Knob
H. Torch Arm Assembly
I. (2x) Torch Arm Mounng Bolts
J. (2x) Washer *not pictured*
1/2” Wrench
WARNING: Moving parts can snag
and pull. Keep loose items clear.
! !
WARNING
WARNING: Refer to manufacturers
sengs for safety sengs.
! !
WARNING
*Not Included
Adjustable Torch
Holder Manual
Models 284C
For Quick Set Beveling
Model 205CS
Parts Diagram
*Note: Torch not included*

Sawyer Manufacturing Company
7799 S. Regency Dr., Tulsa, OK 74131 USA
F 918.834.0318
[e-mail]
P 918.834.2550
sawyermfg.com
V1.2
Installaon ADJUSTABLE TORCH ARM
1. Mount bolts (I) to Quick Set machine. (Fig. 1)
A. Place free oang spacer (B) onto bolt. (I)
Note: Long threads thread into Quick Set machine not
short threads
Tip: Do not thread ¼” past opening
Installaon
Operaon
CAUTION: Refer to manufacturers
sengs for safety sengs.
! !
CAUTION
Fig. 1
2. Mount torch arm assembly (H) to Quick Set machine. (Fig. 2)
A. Use 2 washers (I), & 2 9/16” nuts. (A)
Tip: use 9/16” nut drive.
*Please refer to the Quick Set manual for installaton of the Quick Set machine*
Fig. 1
I
Fig. 2
Fig. 3
Fig. 5
Fig. 6
Fig. 8
Fig. 9 Fig. 10
J
F
D
G
A
N
S
EW
1. Loosen and ghten adjustment knob to posion assembly on and o
pipe/tube. (Fig. 3)
Tip: This screw is to adjust free moon of torch arm.
*Please refer to the
Quick Set manual for
Operaon of Quick Set*
Fig. 4
B
J
Fig. 7
Torch Arm Setup
1. Adjust torch arm assembly. (H, Fig. 5)
A. By loosening the 9/16” nut. (A, Fig. 5) Adjust torch arm
assembly (H, Fig. 5) to most southern point.
Note: For short barrel torches, you may need to move the torch arm
assembly halfway between north & south.
B. Tighten 9/16” nut. (A, Fig. 5)
2. Bevel angle adjustment. (Fig. 6)
A. Loosen bevel indicator square nut. (F, Fig. 7)
B. Adjust to desired bevel angle. (Fig. 6)
C. Tighten bevel indicator square nut. (F, Fig. 7)
Tip: Use ½” wrench.
3. Posion adjustment. (Fig. 8)
A. Loosen posion adjustment knob. (D, Fig. 8)
B. Move assembly to desired posion.
C. Tighten posion adjustment knob. (D, Fig. 8)
4. Install torch inside torch holder.
A. Loosen torch adjustment knob. (G, Fig. 10)
B. Install torch inside torch holder.
C. Tighten torch adjustment knob. (G, Fig. 10)
Tip: For best cung have a neutral ame
Open blow-through tab
te: Red hoses= fuel
E
H
H
