Saxby Omega Manual

• Push the labelled male and female connectors
togethertopowerthedemisterpad.
• Refitthemirrorfrontontothewallback.Ensurethat
thesealsarecorrectlylocatedbeforesecuring.
• To attach the shelf, undo the two plastic screws
underneaththebosses.Slotsheltinfullyandcarefully
retightenthescrewssotheshelfisgrippedfirmly.
• Replacefuse orcircuitbreaker andswitchon. Your
lightisnowreadyforuse.
• ActivateyournewLEDmirrorbyswipingyourhandin
frontofthesensor.
Commissioning Instructionleaflet
Omega Mirror
39237
www.saxbylighting.com
Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilities
exist.CheckwithyourLocalAuthorityorretailerforrecyclingadvice.
Recycling advice
Safety information
SaxbyLighting.BH233PE
• Werecommendcleaningwithasoftdrycloth.Do
notusesolventsorabrasivecleanersasthesecould
damagethefinish.
• Mirror–Useadampclothoraproprietyglass
cleaner.Donotuseabrasivematerialsasthesewill
damagethefinish.
Live Voltages may be present in this unit even when turned of or when completely disconnected.Foryoursafety,
alwaysswitchoffthesupplybeforechanginglightbulbs,orcleaning.
The mirror must be replaced immediately should it become cracked or damaged. This fitting must
not be used without the mirror in place.
• The shaver socket is powered by a 20W isolating
transformerandisonlyintendedforusewithelectric
shavers, electric toothbrush chargers and similar
products.
• Any appliance connected to the socket must not
exceed the 20W power output as this could cause
damageandoverheatingtooccur.
• Alwayscheck yourappliance instructionstoensure
thepowerrequirementsarelessthan20W.
• Simplyturnonthedemisterswitchontheside.The
demisterpadwillwarmthemirrorsurface.
• Thedemisting effectwillspread approximately10 -
20%furtherthanthepaditself.
Shaver Socket Instructions
Demister Operation
Iss.505072017
Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeand
satisfactoryoperationofthisproduct.Pleaseretaintheseinstructionsforfuturereference.
Warning
This is a Class 1 product and must be earthed
Pleasereadtheseinstructionscarefullybefore
commencinganywork.
Thisunitmustbefittedbyacompetentandqualified
electrician.
InstallinaccordancewithIEEWiringregulationsand
currentBuildingRegulations.
Topreventelectrocutionswitchoffatmainssupply
beforeinstallingormaintainingthisfitting.Ensure
otherpersonscannotrestoretheelectricalsupply
withoutyourknowledge.
Thislightfittingshouldbeconnectedtoafusedcircuit.
Ifreplacinganexistingfitting,makeacarefulnoteof
theconnections.
Thissystemcontainsnon-replaceablepartsand
cannotbeserviced.Ifdamageoccursthepartshould
bescrapped.
Thisproductisnotsuitablefordimming.
ThisproductisratedatIP44.
Thisproductcontainsademisterpad.Ifthispadis
damagedinanywaythenitshouldbereplacedbya
qualifiedelectrician.
Wasteelectricalproductsshouldnotbedisposedof
withhouseholdwaste.Pleaserecyclewherefacilities
exist.Checkwithyourlocalauthorityorretailerfor
recyclingadvice.
Specification
Voltage: 240V50Hza.c.
Lamp: 2x1.5WLED
IPrating: 44
Layout
• Planthedesiredlayoutofthisfittingcarefully,
ensuringthecableswillreachthedistancebetween
thejunctionboxandthelightfitting.
• Avoidlocatinganycablesinpositionsthatwould
causeahazard.Positioncablesandjunctionboxes
(notsupplied)awayfromareaswheretheymaybe
atriskfrombeingcut,trappedordamaged.
• Cablesinwallsmustbeprotectedusingsuitable
conduitorplastictrunking.
• Themainssupplycablemusthaveaminimumcross
sectionalareaof1.0mm².
• Thisproducthasspecialprotectionagainstthe
ingressofmoistureandisIP44rated.
Existingfittingsmustbecompletelyremovedbefore
installationofanewproduct.Beforeremovingthe
existingfitting,carefully note the position of each set
of wires.
• Undothescrewsholdingthefrontmirrorassembly
inplaceandsetaside.
• Holdthebackplateinplaceandmarkthepositionof
theholes.Ensurethattheproductislevel.
• Ensurethewalliscapableofholdingtheweightofthe
product.Takecaretoavoiddamaginganyconcealed
wiringandpipes.Thecorrectfixingsshouldbeused
forbrick,cavitywallsorplasterboard.
• Piercegrommetandpassthesupplycablethrough
theholeinthewallback.
• Fixtheproductintoposition.
Installation
Havingcorrectlyidentifiedthewiringfromyourexisting
lightfitting,pullthewirethroughtheholeandconnectto
theconnectionblockinsidetheproductinthefollowing
way:
Wiring
Check that...
• Youhavecorrectlyidentifiedthewires
• Theconnectionsaretight
• Noloosestrandshavebeenleftoutoftheconnection
block.
ThisproductissuitableforuseinZone
2andoutsideZonesofabathroom.
Seediagram.Ifthisunitisbeing
fittedinaroomcontainingabathor
shower,a30mARCDmustbeused,
inaccordancewithIEEregulations.
