CR-158 COUPON PRINTER OPERATIONS MANUAL
AMENDMENTS
Revision
Date
Description
Issued by
A
15/06/2015
First issue
CH
B
11/06/2015
Contact Details
CH
C
28/10/2015
Contact Details, Dip Switches
CH
D
01/04/2016
Contact Details, Dip Switches, Testing,
Serial Connection, Protocols, Barcode
Types
RS
Innovative Technology assume no responsibility for errors, omissions, or damages
resulting from the use of information contained within this manual.
This manual set and the information it contains is only applicable to the model stated
on the front cover, and must not be used with any other make or model.
Any features such as buttons or connectors that feature on the product but are not
mentioned in this manual are currently unused and serve no function.

GA02041
3
CR-158 COUPON PRINTER OPERATIONS MANUAL
Contents
AMENDMENTS ...............................................................................................................2
COPYRIGHT ....................................................................................................................4
LIMITED WARRANTY ......................................................................................................4
CONNECTING THE PRINTER ...........................................................................................5
Power & Pulse Connection ........................................................................................5
USB Data Connection.................................................................................................5
Serial Connection.......................................................................................................6
DIP SWITCHES, BUTTONS & STATUS LEDS .....................................................................6
Dip Switches & Buttons .............................................................................................6
LED Status Lights........................................................................................................7
BEZEL OPTIONS & FIXING POINTS..................................................................................8
TECHNICAL SPECIFICATIONS ..........................................................................................9
DC Voltage .................................................................................................................9
Supply Current...........................................................................................................9
Interface Logic Levels ................................................................................................9
Functionality ..............................................................................................................9
Performance ............................................................................................................10
Environment ............................................................................................................10
FIELD SERVICE ..............................................................................................................10
Inserting a roll of paper ...........................................................................................11
Removing the paper guide ......................................................................................12
Removing the print head roller assembly ...............................................................12
Micro SD card slot and battery compartment.........................................................13
CREATING TEMPLATES & TESTING...............................................................................13
Ticket Template Manger..........................................................................................13

GA02041
4
CR-158 COUPON PRINTER OPERATIONS MANUAL
COPYRIGHT
This manual set is Copyright © Innovative Technology Limited. No part of this
publication may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission
from Innovative Technology Limited. The contents of this manual may be subject to
change without prior notice.
LIMITED WARRANTY
Innovative Technology Limited warrants each of its hardware products to be free
from defects in workmanship and materials under normal use and service for a
period commencing on the date of purchase from Innovative Technology Limited
or its Authorized Reseller, and extending for the length of time stipulated by
Innovative Technology Limited.
If the product proves defective within the applicable warranty period, Innovative
Technology Limited will repair or replace the product. Innovative Technology
Limited shall have the sole discretion whether to repair or replace, and any
replacement product supplied may be new or reconditioned.
The foregoing warranties and remedies are exclusive and are in lieu of all other
warranties, expressed or implied, either in fact or by operation of law, statutory or
otherwise, including warranties of merchantability and fitness for a particular
purpose.
Innovative Technology Limited shall not be liable under this warranty if it’s testing
and examination disclose that the alleged defect in the product does not exist or
was caused by the customer's or any third person's misuse, neglect, improper
installation or testing, unauthorized attempts to repair, or any other cause beyond
the range of the intended use. In no event will Innovative Technology Limited be
liable for any damages, including loss of profits, cost of cover or other incidental,
consequential or indirect damages arising out the installation, maintenance, use,
performance, failure or interruption of an Innovative Technology Limited product,
however caused.

GA02041
5
CR-158 COUPON PRINTER OPERATIONS MANUAL
CONNECTING THE PRINTER
The printer has three available connections: 7 pin connector, USB or RJ45 socket.
POWER &PULSE CONNECTION
The 7-pin connector at the centre, rear of the device is for power and for controlling
the device via a pulse interface. From left to right, the pins are:
1 –Red –+12-24V DC
2 –Black –Ground
3 –Brown –Coin In Pulse Signal
4 –Orange –Note In Pulse Signal
5 –Yellow –Pay Out Trigger Pulse Signal
6 –Green –Ticket Out Output
7 –Blue –Error Out Output
USB DATA CONNECTION
The USB connection is used to host a COM port on a connected PC, allowing the device
to be communicated with through the SSP protocol. Information on this protocol can
be found in a separate document (Innovative Technology manual GA138). SSP can be
used to configure and control the device, as well as to download certain files onto the
device via the SSP update process. The device is connected in this way like any other
USB peripheral, and no special cables should be required.
USB
7-Pin
Connector
RJ45

GA02041
6
CR-158 COUPON PRINTER OPERATIONS MANUAL
SERIAL CONNECTION
This connector (RJ45) is used for RS232 communication. Pot ‘O’ Gold should be
connected here, using an RJ45 1 to 1 eight pin patch lead sold separately.
DIP SWITCHES, BUTTONS &STATUS LEDS
DIP SWITCHES &BUTTONS
Dip Switch
Functionality
1
2
3
4
Off
Partial Cut
On
Full Cut
Off
Off
Off
Secondary Interface* and SSP. Button 1 Prints Test
Ticket. Button 2 Switches between SSP and The
Secondary Interface.
Off
Off
On
SSP Interface. Button 1 Prints Test Ticket. Button 2
No Action
On
Off
Off
Pulse Interface. Button 1 Prints Daily Report.
Button 2 Re-Prints
On
Off
On
Pot ‘O’ Gold Interface. Button 1 Prints Test Ticket.
Button 2 no action.
On
On
Off
Reserved for future interface. Button 1 prints test
ticket. Button 2 no action.
On
On
On
Reserved for future interface. Button 1 prints test
ticket. Button 2 no action.
*The secondary interface must be set using Ticket Template Manager Configurator.
Dip Switches
Button 1
Button 2
LEDs

GA02041
7
CR-158 COUPON PRINTER OPERATIONS MANUAL
LED STATUS LIGHTS
The device has 3 LEDs - green, yellow and red - which are used to display the status of
the device. The standard statuses are displayed as follows:
Slow pulsing yellow
Printer idle
Slow pulsing yellow and solid red
Printer idle, paper low
Slow pulsing green
Printer idle, SSP enabled
Slow pulsing green and solid red
Printer idle, SSP enabled, paper low
Fast pulsing green
Printing
Fast pulsing green, yellow, red
Printer initialising after power off/reset
The LEDs are also used to display error states. These are shown by a number of slow
red flashes, followed by a number of yellow flashes. The number of each colour of
flash indicates the error as shown in the table below:
Yellow
1
2
3
4
5
Red
1
-
Initialisation
failed
No print
head
-
-
2
No paper
-
Load fail
-
-
3
-
-
-
Cut fail
Unknown
jam
4
Unknown
error
-
-
-
-

GA02041
8
CR-158 COUPON PRINTER OPERATIONS MANUAL
BEZEL OPTIONS &FIXING POINTS
There are currently two types of bezel available, see below;
EUR Bezel
US Bezel
4 x fixing points (x2 on each side)
4 x fixing points (on bezel)
Note: refer to technical drawings for further installation details.

GA02041
9
CR-158 COUPON PRINTER OPERATIONS MANUAL
TECHNICAL SPECIFICATIONS
DC VOLTAGE
Minimum
Nominal
Maximum
Absolute limits
11 V
12 V
26 V
Supply ripple voltage
0 V
0V
0.5 V @ 100 Hz
SUPPLY CURRENT
Standby
100 mA
Printing
2 A
Peak
4.8 A
INTERFACE LOGIC LEVELS
Logic Low
Logic High
Inputs
0 V to 0.5 V
+3.7 V to +12 V
Outputs (2.2 kΩ pull-up)
0.6 V
Pull-up voltage of host interface
Maximum current sink
50 mA per output
FUNCTIONALITY
Printing Method
Direct Thermal Printing
Dot Pitch
0.125 mm
Resolution
384 dots per line
Print Width
48mm
Print Speed
100mm/s
Ticket Print and Present
< 3 Seconds
Barcode Types
Interleaved 2 of 5, Code 128, QR Code and others by
request
Graphic resources
2MB on-board SPI Flash. A micro SD card slot is available
for storage of extra fonts and images
Interface: User
Ticket print button, Feed button, 4 dip-switches. LEDs:
Ready, Paper, Fault
Interface: Protocols
eSSP, Pulse, Pot ‘O’ Gold, Line by Line, ccTalk
Interface: Electrical
Open collector, True RS232, USB
Interface: Physical
USB (direct to printer)
7 –way power, pulse and “Pot ‘O’ Gold”
RJ45 serial connector
Support tools
The firmware and interface protocol are upgradeable via
USB. Ticket Template Manager software allows design of
own ticket templates

GA02041
10
CR-158 COUPON PRINTER OPERATIONS MANUAL
ENVIRONMENT
Parameter
Min
Max (Design Guide)
Operating temperature (Ambient)
+5°C
+60°C
Humidity
5%
95% Non-Condensing
PERFORMANCE
Parameter
Min (mm)
Max (mm)
Coupon Type
Thermal roll media
Roll Outer Diameter
75
Roll Core Diameter
12.5
Coupon Length
210
Coupon Width
58
Coupon Thickness
0.1
Print Head Reliability
320,000 coupons
Approved Paper can be purchased from SaXXot Germany GmbH
using part number LB02014. 9930550514
click here for order

GA02041
11
CR-158 COUPON PRINTER OPERATIONS MANUAL
FIELD SERVICE
INSERTING A ROLL OF PAPER
To insert a new roll of paper, remove the
roll mandrel from the printer (reverse of
C).
Position the roll so that the paper edge
comes from below the roll (B).
Insert the mandrel into the roll of paper.
The spool of the mandrel should be on
the left hand side of the roll (as shown,
A).
Push the mandrel (with roll) down onto
the clips until secure (C).
With the unit powered on, feed the
paper into the mechanism (D). When
the paper triggers the sensor, the unit
will auto-feed the paper. Remove the
excess paper when the unit has
completed the paper feed.
If required, you can now do a test print (see Dip Switches & Buttons).
A
C
B
D

GA02041
12
CR-158 COUPON PRINTER OPERATIONS MANUAL
REMOVING THE PAPER GUIDE
For maintenance or clearing a paper jam, the paper guide may need to be removed.
EUR Bezel
US Bezel
For the EU bezel, squeeze latches
inwards and lift paper guide.
For the US bezel, simply lift upwards to
remove.
REMOVING THE PRINT HEAD ROLLER ASSEMBLY
The print head roller assembly can be removed to allow access for cleaning and
removal of jammed paper. Firstly remove the paper guide (see 8.2).
Pull the release handle
on the print mechanism
to release the roller
assembly. The roll
assembly can be fitted
back in place with a
‘push fit.’ Note: Fit the
roller assembly before
reinserting the paper
guide and paper roll.

GA02041
13
CR-158 COUPON PRINTER OPERATIONS MANUAL
MICRO SD CARD SLOT AND BATTERY COMPARTMENT
The micro SD card slot and battery compartment are located on the left hand side of
the unit. The battery is accessed via the removable cover.
Inserting a micro SD card expands the memory of the printer, allowing extra fonts,
images and coupon templates to be stored.
The battery powers the units internal real time clock, which can be used to provide
and date and time stamp on coupons.
Note: Battery Type: CR1225, 3 Volt, 50mAh (BA00100)
CREATING TEMPLATES &TESTING
TICKET TEMPLATE MANGER
To fully maximise the potential of the CR-158 printer and its printing capabilities, and
to test the unit fully, we recommend you install Ticket Template Manager.
Ticket Template Manager is a software tool that allows users to create and edit
ticket/receipt designs, and upload them to Innovative Technology printer products.
To Connect to Ticket Template Manager, the CR-158 must be set to SSP.
PULSE
Tickets must be Pre-loaded onto the CR-158 when using the Pulse interface. Printers
purchased in the Pulse interface will have templates Pre-loaded for testing. These
templates can be updated or changed using Ticket Template Manager.
Micro SD card
slot
Battery cover
