SAYS TSI-150WCMB User manual
User Manual
TSI-150WCMB
WIRELESS SOUND TOWER
Please, read carefully this manual before to use this unit.
Keep safe this manual for future references.
Learn more about us
Follow us!
Saysgroup.com
@Saysoficial.ve
+58412 50 500 50 (Whatsapp)
@Says
eplosion
Boom
The picture is only provided for reference. Please refer to
actual the unit!
Accessories
Sound Tower Unit x1
Instruction Manual x1
Power Cable x1
Remote Control x1
Top panel operation
Caution
1:Power switch(AC play- Power off-DC play)
2:USB play back
3:Micro SD card play back
4:Aux-in (3.5mm PIN line cable)
5:MIC input,
6:Guitar input
7:Short press for Previous song,long press for fast backward
8: Play/pause under USB/TF/BT, auto search under FM mode. Long press this
button to enjoy TWS function.
Remote control
9:Next song: short press for next song,long press for fast forward.
10:Volume control. Long press volume+/- to increase/decrease the LED light
11MENU(control BASS/Treble),long press this button to restore factory settings
12:Microphone volume control
13:Mode switch
14:Microphone Echo +
15:Microphone Echo –
16:REPEAT one song, repeat all song
17:Press to get super bass effect
18:Microphone priority(when playing USB/TF and press this button,the microphone
volume will override songs in USB/TF)
19:Short press to Rec songs from microphone to USB/TF, long press to play recor-
ding,long press again to delete recording
20: EQ effect switch
1.Mute
Available to be mute at any mode
2.Previous Song
Under USB/TF card mode - previous song.
Under BT connection mode- previous song.
3.Mode
Press shortly to skip to Wireless BT/LINE
IN/USB/TF mode.
4.Record function
Under USB/TF card mode,press “REC” button
to record
5.Echo-
6.BASS+/-
7.EQ function
8.Microphone Volume+/-
9.Stand by
10.Pause&Play
11.Next song
Under USB/TF card mode - next song.
Under BT connection mode- next song.
12.Light mode
Operating instructions
Wireless BT Pairing Mode:
Press MODE or Blue button on the unit or the remote control until BT is selected.
1. Put the cell phone within 20 meters;
2.Activate the BT features on your cell phone so that the cell phone starts to
search for the BT device. Please refer to the users’ manual for details
3. Select the correct model No.(TSI-150WCMB)The device found by the cell
phone;
4. Shortly press PLAY/PAUSE button to play or pause music. Short press “ ” or
“ ” key to select the previous or next track.
●LINE IN MODE:
Press MODE button on the unit or the remote control until LINE is selected. Play
the music of the device connected to the LINE input.
● USB Mode:
1. After start up, press MODE to select “USB” and insert the USB device. The unit
will automatically read and play the music in the USB device.
2. Press “ ” key shortly to pause or play.
3. Shortly press “ ” key to the previous song.
4. Shortly press “ ” key to the next song.
TWS connection spec:
When you are playing a Sound Tower (host) under USB/TF/AUX/BT mode, at this
time you want another Sound Tower to share this song. You can turn on a new
Sound Tower, Long press “Play/pause”button,the LED display will show “SLAU”
and keep blinking, now it is searching the host. Once found host, this new Sound
Tower will connect automatically the host,and “SLAU” will not blink, At this time
2pcs Sound Tower are playing the same song.
The new join Sound Tower can operate:play/pause - previous song- next song-
Volume control
13.Repeat function
14.Record play
15.Record delete
16.Echo+
17.Microphone priority
18.Treble+/-
19.Main Volume
20.Number buttons
Under USB/TF mode to choose songs
Warranty and costumer service
The warranty does not apply in case of:
- Normal wear and tear of the product.
- Improper use, for example, overloading the device and the use of non-approved accessories.
- If the product has been tampered with; damaged, repaired by unauthorized persons or any
wrong use.
- Does not apply if there was use of force or any damage caused by external or internal influences.
- Damage caused by non-observance of the instruction manual, for example, connection to a network
improper power supply or failure to follow installation instructions.
- Device partially or totally dismantled.
- This warranty is limited to manufacturing defects.
Please attach your sales receipt to this manual and save it for future use if needed.
Proof of purchase is required under these warranty conditions.
Warranty and more information please contact us at:
0501-SAYS501 (0501-7297501)
PERSONALIZED ATTENTION
INSURED
WARRANTY
+58412 50 500 50 (Whatsapp)
Saysgroup.com
