SBL 125601-SBL User manual

01
Colorful Neon LED Flex strip
125601-SBL

02
Parameter
01
02
07
08
09
11
12
10
06
03
04
05
Model
Input voltage
Power
LED Type
Color temperature
LEDs/m
Waterproof
Warranty
Unit
PCB Width
Working temperature
Product size
DC24V
HL- B-5050RGB-56D-24V
12W/M
5050 RGB 3in1
RGB
56LEDs/m
3 years
IP67
0.5m
10mm FPC
-20~+50℃
26x14mm
Applications
Decorative lighting for exhibition shelves, advertising light ,box and hotel etc.
Backlight for edge lighting / signage.
Holiday decorative lights, residential and outdoor lighting.
Bridge, garden, road and car lighting etc.
Long-distance project but with inconvenient wiring.

03
High light efficiency, unique optical light distribution structure design, uniform surface with-
out shadow, no glare, no light spots, soft light.
High light transmittance, food grade environmentally friendly silicone material, good flexibili-
ty, simple and stylish appearance, exquisite and unique.
Soft and can be optionally bent to any shape with Graceful figure.
IP67 waterproof, with salt-tolerant, acid and alkali, anti-gas corrosion, fire, UV resistance.
Easy to connect and install, seamless docking, shearing everywhere, using DC24V voltage,
safe and reliable.
LM80 test certification, UL, CE, ROHS certification.
Features
Accessories
End Caps Front Connection with 4PIN pin

Clip
04
Installation Notes
1. select the appropriate buckle according to the product installation environment,
prepare the screws.
2. Adjust the buckle to the proper position and secure the buckle with the screw.
3. The product has a light-emitting surface facing outward, embedded in the buckle to
complete the installation.

NOTICES
05
The products are low voltage, you must use the power supply. Please do not directly
connect the product to high voltage, which will damage the light bar and even cause an
accident.
Please read the product manual carefully before using the product. Must be installed by
professionals to ensure safe use.
The light-emitting surface of the product is directional and can only be bent in one direc-
tion. Please install and use the product according to the direction of the product to avoid
damage to the LED strip.
Please do not strongly twist or pull the product. Do not pierce the product colloid with
sharp objects.
The product may be soiled during use and can be wiped clean with a cotton cloth damp-
ened with water or alcohol.
Appearance
Notices
