Introduction
Thank you for purchasing one of our upgrade products. This manual will tell you everything
you need to know of your Best of Two Worlds Power & Precision ECO (BOTW P&P ECO) upgra-
de power supply (PSU).
Environment
SBooster products are developed in the Netherlands and comply with the interna-
tional directives, including but not limited to the Restriction of Hazardous Sub-
stances (RoHS) in electrical and electronic equipment and the disposal of Waste
Electrical and Electronic Equipment (WEEE).
Safety
Do not remove the cover and never push objects of any kind into the BOTW P&P
ECO through its openings as they may short-out parts that could result in a fire or
electric shock.
Use care not to spill liquids into any part of the BOTW P&P ECO. Liquids can cause
a failure, shortcut and/or a fire hazard.
DC tips Adapter kabels
The BOTW P&P ECO can (internally) be set to 7 different mains voltages. The mains voltages
are 100/110/115/120/220/230/240V AC. A sticker with the mains voltage setting can be
found on the back of the PSU, see Fig 1. For a maximum performance of the BOTW P&P ECO it
is important that the mains voltage setting is correctly. This means that a BOTW P&P ECO,
which is set to 230V AC, cannot be used (directly) on a mains voltage of 220V AC or 240V AC.
If the mains voltage of the BOTW P&P ECO does not match your local mains voltage, please
contact us. We will inform you about the procedure how you can safely set the mains voltage
of your BOTW P&P ECO PSU to the correct value.
Fig. 1
Mains voltage
Pagina 2
Feet
The feet of the BOTW P & P ECO are fixed with a self-
lock system. To install the feet, take the foot bet-
ween your thumb and forefinger and press the foot
in place. Keep pressing and turn the foot a couple of
times slowly. The feet are properly installed when
you can easily turn them without popping out.
Installation
The BOTW P&P ECO replaces the stock supplied
adapter of your audio device. Check the correct set-
ting of the mains voltage Fig. 1 and the DC output
setting Fig. 2 before you connect the BOTW P & P
ECO to your audio device.
ontens of the package
• 1 x BOTW P&P ECO PSU
• 1 x Mains cable
• 1 x DC tips
• 1 x Manual

BOTW P&P ECO 5V – 6V 6V—1.75A ACC 5V—3A
BOTW P&P ECO 9V – 10V 10V—1.25A ACC 9V—2.35A
BOTW P&P ECO 12V – 13.2V 13.2V—2.25A ACC 12V—3A
BOTW P&P ECO 15V – 16V ACC 16V—1.85A 15V—2.5A
BOTW P&P ECO 18V – 19V 19V—1.85 ACC 18V—2.25A
BOTW P&P ECO 24V Led off Led mid Led high
D output setting BOTW P&P E O
The BOTW P&P ECO PSU is provided with a three-position switch in order to set the output
voltage of the PSU. The output voltages (DC output setting) of the PSU are printed on the top
of the enclosure. The three-position switch to set the output voltage is located in the gray
circle at the side, see fig.2. To set the output voltage to the desired value it is best to use a
tweezer.
Overview D output settings BOTW P&P E O
Note: It is the responsibility of the user to check if the power supply is set to the
correct DC output voltage. SBooster is not liable for misuse of the power supply.
SBooster refuses every liability for damage to equipment due to an incorrect DC
output voltage setting of the PSU.
onnecting the BOTW P&P E O
The On/Off switch is located at the rear panel of the BOTW P&P ECO. Make sure the power
supply is turned “Off” before you connect the mains plug into the AC outlet. Connect the
BOTW P & P ECO with the matching DC plug to your audio device and turn the BOTW P&P
ECO “On”. The green LED on the front will light up and your audio device will boot or turn
on.
The ACC is an accessory setting. Use this setting only with original SBooster accessories like the
SBooster Ultra upgrade.
The BOTW P&P ECO is supplied with a variety of DC tips and adapter ca-
ble(s). The polarity of the DC tips is; outer side (-) negative and the inner
side (+) positive. For the polarity of the supplied adapter cable(s), please
check the polarity on the label of the adapter cable.
D Tips &
adapter cables
Pagina 3
Fig. 2

Heat
The transformer and other electronic components of the BOTW P&P ECO are very effi-
cient. A relatively small amount of power will be converted into heat. In case of a (heavy)
load (> 75% rated output current) the power supply will run warm, this is normal.
The openings in the enclosure are provided for ventilation to ensure reliable operation of
the BOTW P&P ECO and to protect it from overheating. These openings must never be
blocked or covered.
The BOTW P&P ECO should be situated away from heat sources such as radiators, heat
registers or other products that produce heat.
Break in period
As with many other audio equipment, the BOTW P&P ECO needs some time to “break in”.
This break in period is an automatic process and starts when the BOTW P & P ECO is
connected to your AC outlet and switched “On”. The break in period will be at least 100
hours. After 4 weeks the BOTW P&P ECO will be fully burned in. For the break in period
it is not necessary to leave your audio device 24/7 playing.
The fastening bolt of the transformer is located on the bottom side of the
enclosure. This bolt can become very hot. Be careful with moving the BOTW
P&P ECO after you have used the power supply for a heavy load.
Warranty
SBooster warrants the BOTW P&P ECO to be free from defects resulting from faulty ma-
nufacture or faulty components for a period of 24 months. If your product needs to be
returned within the warranty period, please do so through the retailer from whom you
purchased the product. During the warranty period, your product will repaired without
charge if the defect is covered by our warranty terms and conditions, excluding shipping
costs.
Modifications
Changes or modifications to the electronic design of the BOTW P&P ECO can invalidate
the compliance to the safety standards. SBooster refuses every liability regarding dama-
ges, which has been subject to unauthorized modifications or to misuse of the power
supply.
The BOTW P&P ECO PSU has to be connected to an audio device when the PSU is switched
“On”. If this is not the case, you must turn the power supply “Off”. When the BOTW P&P
ECO is switched “Off”, there is no power consumption.
With most audio devices the BOTW P&P ECO will be turned “On” 24/7. Should you turn
your audio device to standby then the power consumption of the power supply will be
set by your audio device. Switch the BOTW P&P ECO “Off” during your holidays. Unplug
the mains plug from the AC outlet if the PSU will not be used for a long period (Months)
of time.
Always use the On/Off switch if you want to turn “Off” the BOTW P&P ECO.
Turn the BOW P&P ECO always first “Off” before you pull the mains plug out
of the AC outlet. This prevents the chance of getting an electric shock from
the mains plug.
