Scaleo medical Poweo 140 Quick Up User manual

Poweo
®
140
&
180
Quick Up
Patient lifters
USER MANUAL

2 DOMU125_EN_v3_20221205_Poweo® Quick Up user manual
Content
WARNING AND SAFETY INSTRUCTIONS ......................................................................................................... 3
SYMBOLS AND PICTOGRAMS ......................................................................................................................... 5
GENERAL INFORMATION ................................................................................................................................ 6
Intended use .................................................................................................................................... 6
Contraindications ............................................................................................................................. 7
Instructions for assembly ................................................................................................................. 7
Installation of the suspension .......................................................................................................... 9
Commissioning the Poweo® 140 -180 Quick Up ............................................................................. 12
INSTRUCTIONS FOR USE ............................................................................................................................... 14
Security devices .............................................................................................................................. 14
Battery management ..................................................................................................................... 15
Maintenance of the battery ........................................................................................................... 17
The controls ................................................................................................................................... 18
Transferring with the Poweo® 140 -180 Quick Up .......................................................................... 19
CLEANING AND DISINFECTING ..................................................................................................................... 23
General guidelines ......................................................................................................................... 23
Recommended procedures for cleaning and disinfecting .............................................................. 23
PERIODIC INSPECTION AND PREVENTIVE MAINTENANCE ........................................................................... 25
Periodic control/ Preventive maintenance checklist ...................................................................... 25
Poweo® Service tool ....................................................................................................................... 27
TECHNICAL SPECIFICATIONS ........................................................................................................................ 30
Technical specifications of the Poweo® 140 – 180 Quick Up .......................................................... 32
Technical specifications of the accessories .................................................................................... 33
ELECTROMAGNETIC COMPATIBILITY (E.M.C) ............................................................................................... 35
COMPLEMENTARY SAFETY MEASURES ........................................................................................................ 37
WARRANTY ................................................................................................................................................... 39
LIABILITY ....................................................................................................................................................... 40
END OF LIFE AND RECYCLE ........................................................................................................................... 41
EC DECLARATION OF CONFORMITY ............................................................................................................. 42
CONTACT INFORMATION ............................................................................................................................. 44
!

DOMU125_EN_v3_20221205_Poweo ® Quick Up user manual 3
Warning and safety instructions
This user manual concerns the Poweo® 140 reference S16064 and the Poweo® 180 reference
S16068, equipped with an aluminum structure and the Quick Up suspension.
This user manual contains important safety instructions and information concerning
the use of the Poweo® 140 Quick Up and the Poweo® 180 Quick Up patient lifters.
Carefully read the manual before using the lifters.
The Poweo® 140 Quick Up is designed and manufactured in order to safely transfer
patients up to 140 kg and up to 180 kg with the Poweo® 180 Quick Up. Beyond this
weight, do not use this lifter. Contact SCALEO Medical, for advice on the best lifter
that satisfy your transfer needs.
It is NOT recommended to use others type of suspensions from others manufacturers
than the ones recommended for SCALEO Medical patient lifters. SCALEO Medical
refuses any liability in the case of an incident while using slings or other than those
made especially for their lifters.
Rigid stretchers and weighing systems are not compatible with the Poweo® 140 – 180
Quik Up.
Avoid transferring patients on thick carpeted floors. Ragged surfaces and any
obstacles may block the wheels. If the force is too important, the lifter could be
destabilized and can tip over, especially if the lifter is being used with maximum
weight capacity. In these cases, we recommend that you open the legs (if needed)
before the transfer.
Torn, cut, frayed or broken foams can fail, resulting in serious injury to the patient
and/or to the user. Only use the Quick Up suspension in good condition.
The Poweo® must NEVER be used to transfer, lift or transport people over slopes.
Like all patient lifters, the Poweo® is not a transport device. It must be used only for

4 DOMU125_EN_v3_20221205_Poweo® Quick Up user manual
short distance transfers and is not intended to replace wheelchairs or other types of transport
devices.
The maximum load can be lifted for about 1 minute. The delay between two lifts of
the maximum load shall be of approximately 10 minutes to let the actuator cool
down.
The first Poweo® 140 Quick Up was commercialized on March 16, 2020. The first Poweo® 180
Quick Up was commercialized on Juin 4th 2020. This user manual is protected by copyright. It
should not be handed over, or made available to, any unauthorized third party, without a prior
written consent from SCALEO Medical

DOMU125_EN_v3_20221205_Poweo ® Quick Up user manual 5
Symbols and pictograms
Symbols used in this manual:
This symbol is used to point out instructions and information related to safety in the working
environment, where injury may occur if the information is disregarded or ignored. Follow these
instructions and be careful and attentive at all times.
This symbol indicates important information regarding the use of the equipment. If not taken into
consideration, it may lead to damage or functional defects to the lifter or other equipment.
This symbol indicates important and useful information. If taken into consideration, it will help the
operator of the lifter to work efficiently. It may help simplify routines and to explain complicated
facts.
Symbols used in labels:
Symbol
Meaning
Manufacturer
Date of manufacturing
Device reference
Device serial number
Temperature range
Do not burn
Security pin: do not remove this pin
Periodically inspect this pin
Warning : read user manual for
instruction
Indoor use only
Symbol
Meaning
Read user manual for instruction
Direct current power source
Class II electrical protection type
B type applied parts
Danger : the hand may be pinched
Maximum load
In accordance with all applicable
European Directives
Contains potential wastes of
electrical or electronic equipment
Do not dissemble
40° C
10°C

6 DOMU125_EN_v3_20221205_Poweo® Quick Up user manual
General information
You have recently purchased a Poweo® 140 or a Poweo® 180 Quick Up patient lifter.
We would like to thank you for the trust you have placed in our company.
The Poweo® lifter is delivered in a carton box, including the
following:
1. A base with electrical opening of the legs
2. An equipped column
3. An arm
4. A « Quick Up » suspension
5. An electrical lifting actuator with mechanical emergency
lowering function
6. A removable battery with an emergency shutdown button
7. A remote control (not pictured))
8. This user manual (not pictured)
9. A battery charger (not pictured)
10. Special wrenches, screws and bolts for the assemblage (not
pictured)
Intended use
The Poweo® 140 -180 Quick Up are mobile passive patient lifters intended
to be used on horizontal floors to transfer patients that have a certain tonicity
on the upper limbs.
They are suitable for transfers patients from sitting to sitting positions. The Poweo® 140 safely
transfers a dependent person of up to 140 kg and the Poweo® 180 of up to 180 kg. They reduce
the risks of work-related injuries to the caregiver.
The Poweo® 140 -180 Quick Up are multipurpose and suitable for hospital and health centers
use.
5
1
2
4
3
6

DOMU125_EN_v3_20221205_Poweo ® Quick Up user manual 7
Contraindications
The Poweo® 140 -180 Quick Up are NOT intended to be used :
• On patients with curvature of the spine,
• On patients with muscle spasm,
• On patients without tonicity on the upper limbs,
• On patients weighing more than the safe working load of the patient lifter,
• To transfer patients for long distance,
• To transfer patients over slopes,
• To replace wheelchairs or other types of transport.
Instructions for assembly
Before unpacking the patient lifter, please make sure the package is not damaged. If that is the
case, immediately notify in written to the freight forwarder and contact SCALEO Medical.
These instructions for assembly concern the standard version of the Poweo® 140 and
180 Quick Up. For the instructions of special models, please contact SCALEO Medical.
Please follow the instructions of this manual to properly assemble the patient lifter. If
you note any missing or defective piece, do not use the lifter; contact your distributor
or SCALEO Medical.
Using the Poweo® patient lifters requires a good understanding of transfer systems,
assemblage and disassemble procedures. Contact SCALEO Medical if you require
further information.
Unpacking and assembling the Poweo® lifters requires two people.
SCALEO Medical tests and charges all batteries before packing, however, the batteries
must be completely recharged before the first use.
Our lifters and batteries are always delivered with the emergency stop button on the
“ON” position. Always remember to release the emergency stop button on “OFF”

8 DOMU125_EN_v3_20221205_Poweo® Quick Up user manual
position before operating or charging the unit.
To start: Unpack the lifter by removing all protection devices and taking the lifter out of its
carton box.
Step 1: Install the actuator
Install the actuator placing one end on the arm and one
end on the mast of the lifter, thanks to a hinge. Secure
the installation by introducing one spacer and fixing it
with two bolts, one at each side. Follow the same
procedure for the other end.
The bolts are coated by the “LOCTITE 243” to avoid the loss of screws during the lifting
operating mode.
The “LOCTITE 243” is a medium thread lock coated on the screws during the
manufacture for the future installation to the customers.
Tighten with a hexagonal wrench or the provided special wrench, without using too much force:
the screw head would be deteriorated and it would be impossible to dismount it later.
These operations are very important for the security of the patient and
caregivers.
Without the security pins, the column or the arm may fall and provoke
serious injuries. You must ensure that these pins are properly secured
and perform regular inspections: screws must ALWAYS be present and
in good condition. A label near the pins allows a quick identification for
inspection.
Step 2: Install the column on the base

DOMU125_EN_v3_20221205_Poweo ® Quick Up user manual 9
Step 3: Secure the installation with the provided screw
and turn it inside the column, without tightening it.
It is VERY important to properly secure the assemblage:
the stability of the hoist highly depends on a strong link
between the base and the mast.
The screw is equipped with a thread lock to prevent the
screw from loosening. Install the screw on two or three
tread without completely tightening.
Step 4:
a) Install the clearance removal wedge and tighten the screw so that the column comes to
press on the front part of the base.
b) Then tighten the main screw to secure the assembly.
Installation of the suspension
Step 5: Attach the suspension with the security pin.
Final result:

10 DOMU125_EN_v3_20221205_Poweo® Quick Up user manual
Attach the suspension to the arm of the lifter by inserting the security pin as shown below:
a) Insert the suspension onto the arm of the lifter b) Pass through the
security pin
c) Secured the assembly by introducing the washer as shown on the pictures here below:
Poweo® lifters can be offered featuring the Suspension Quick Release, that allows to
easily exchange the suspension of the lifters. The
installation with the quick locks (optional) does not
require the use of tools. By pressing the red button, the fixing is
done quickly. The red button should return to its initial position:
fixation assured.

DOMU125_EN_v3_20221205_Poweo ® Quick Up user manual 11
Do some rotational tests before using with a patient
Step 8: Slide the battery into its compartment.
Before using the Poweo® make sure that the emergency
button is on “OFF” position. Turn the button clockwise to
release it.
Position the battery on the support, and guide it for
the best electrical contact between the battery and
battery support contacts.
Step 9: Connect the remote control.
Connect the remote control with the plug and make sure that the wire
connection is aligned with the mast remote control port. Once aligned,
press on the wire to insert the plug.
Step 10: Test the lifter
Try lifting and lowering, opening and closing the legs to make sure that everything is in order.
Step 11: Remove the battery and recharge it.
ON position of the
emergency button: the
lifter is not powered
OFF position of the
emergency button: the
lifter is powered

12 DOMU125_EN_v3_20221205_Poweo® Quick Up user manual
Before first use, the battery must imperatively be 100% charged. Please refer to the “Battery
management” section for this operation. Your lifter will be ready for use as soon as the battery
is charged.
Your lifter will be usable as soon as the battery is charged
Whenever possible, keep the carton box and packing accessories for later
transportations.
Commissioning the Poweo®140 -180 Quick Up
SCALEO Medical provides a universal power supply adapted to any voltage/frequency
value. Before charging the battery, you will need to check that the plug provided fits
to your local AC outlet.
If the place of use was informed before ordering, SCALEO Medical will provide the right
type of AC cord.
Before each use check the correct installation of the lifter and of its accessories, verify proper
operation before use with a patient.
The control points presented below only take a few minutes and allow you to ensure a safe
use of your Poweo® patient lifter:
• Make sure that no part is damaged or show signs of wear,
• Check the tightness of all the safety screws and pins,
• Inspect accessible screws and make sure none are loose,
• Check the lights on the remote control: battery indicator should be solid green;
maintenance indicator should be off,
• Check the features: raise and down the arm, leg opening and emergency stop.
In case of malfunction or doubt about the proper operation, do not use the Poweo®
patient lifter. Inform your technical service, your distributor, or contact us at the
address on the back of this manual.

DOMU125_EN_v3_20221205_Poweo ® Quick Up user manual 13
The Poweo® patient lifters are designed to be used in room temperature, +10 to +40°C.
This should be taken into consideration when transporting the lifter; and therefore,
keeping it in a temperate part of the vehicle. Alternatively, the lifter must rest in a
temperate room until the equipment has achieved proper working temperature.

14 DOMU125_EN_v3_20221205_Poweo® Quick Up user manual
Instructions for use
Security devices
Emergency stop:
The Poweo® patient lifters are equipped with an emergency stop button that
will turn off the lifter when pressed.
The emergency stop button is located on the top of the battery on the
Poweo® 140 -180 Quick Up. Once pressed It must be turned clockwise to
release it.
Emergency lowering devices:
In case the remote control does not operates correctly, an emergency electric
lowering is still possible by activating the hidden button located behind the
yellow label of the base.
Perforate the center of the yellow sticker and press the hidden button with a
small screwdriver and the patient lifter will perform an emergency lowering.
Maintain the pressure on the button to obtain the desired height.
In case of a complete failure of the electronics, a mechanical emergency
lowering is available.
Activate the RED lever/trigger on the actuator by pulling it upward, and
maintain the position until the actuator reaches the desired height.
Lowering speed will depend on the charge and the pressure on the trigger. In case of
use, make sure that a chair or a bed can receive the patient when he is being lowered.
According to the ISO EN 10535 standard, the Poweo® will NOT operate with a patient
weighing more than its maximum safety load capacity.

DOMU125_EN_v3_20221205_Poweo ® Quick Up user manual 15
The opening of the legs is also secured: in the case of a contact between a leg and an
obstacle, the legs will automatically stop moving. The leg opening movement stop is
therefore a warning for the user: it means that the security device is operating, so the
transfer of the patient is not secured.
Battery management
The Poweo 140-180 Quick Up are equipped with SCALEO® electronics, a NiMh battery and the
Poweo® charger, which contains advanced safety features, including electronic protections
against short circuits, over voltages and over temperature. If one of these parameters exceeds
the specified value, the battery will stop working, preventing the user from overheating and the
risk of fire.
When the LED indicator of the remote control turns red, it means that the battery needs to be
recharged. There is still enough power to perform at least one patient lowering.
When the battery discharge threshold is reached, the user is alerted by a beep. If the battery
does not recharge quickly, the display on the control box turns off and the up / down function
will not work.
Charging the battery
In accordance with current regulations, the Poweo® does not work while the battery is
being charged directly into the patient lifter.
If the emergency stop button is pressed, the battery will not charge.
The removal of the SCALEO® battery from the patient lifter does not require any manipulation.
It simply needs to be removed by pulling it towards you. Its shape prevents it from being
accidentally connected backwards or improperly, either in the patient lifter or in the external
charger.
The SCALEO® battery is exclusively charged using the external charger which is supplied by
default.

16 DOMU125_EN_v3_20221205_Poweo® Quick Up user manual
To charge the SCALEO® battery :
1. Connect the charger to the
AC outlet,
2. Place the battery in the
battery charger,
3. Once the battery is detected
in the charger, the LED
indicator lights up.
The Poweo® 140 - 180 Quick Up will
take from 2h30 to 5 hours to
completely recharge to 100% an empty battery.
For intensive daily use a daily recharge will be necessary.
The batteries cannot be overcharged. However, to ensure better performance and
longevity, it is recommended to let them rest for a few minutes after charging and
before use. It is also important to fully charge the battery.
Upon request, the charger's power connector can be delivered protected by a plug that
ensures additional protection of the charger against splashing water. Remove this plug
for charging, and be sure to replace it after recharging.
To charge the patient lifter, use only the supplied cable: charging a battery with an
unsuitable cable can cause the cable and/or battery to overheat and damage all
components, or cause a fire.
After each charge, be careful to unplug the power cord without pulling it to avoid
damaging the cord.
It is recommended to have 2 batteries to replace the discharged battery with the
charged one. Therefore, Poweo® will remain functional at all times.
Emergency button
Battery label
Battery status
indicator
Charge
status
label

DOMU125_EN_v3_20221205_Poweo ® Quick Up user manual 17
The external charger
The external charger allows you to charge one battery while a second battery in being used.
The LED indicator of the SCALEO charger displays the status of the recharge. Depending on the
color of the LED the user can monitor the different status.
Maintenance of the battery
Never recharge batteries in extreme temperatures. If the temperature is too high, the
battery charger may stop functioning for security reasons. If this occurs, place the
battery and the charger in a cool place, wait a few minutes so the security device let
the charge begin, and try again to recharge the battery.
If you plan to not use your lifter for a long time (≥ 1 month), proceed as follows to
keep your batteries in good conditions:
• Fully recharge your battery,
• Push the emergency button to OFF position,
• Remove the battery from its compartment,
• Store your battery charged in a cool, dry, well ventilated area,
• Check periodically (every month) the status of charge of the batteries: even if they are
disconnected batteries tend to discharge.
Compliance with these precautions will help you keep your batteries longer and use your
equipment in the best conditions. Failure to follow these instructions will void the
CHARGER LED COLOR
MODE
Yellow - ●
The battery is not connected to the charger
Yellow- ●
Reset and battery analysis
Orange - ●
Fast recharge
Alternately green and yellow - ● / ●
Compensation charge
Green - ●
Slow charge/end of recharge
Alternately green and orange - ● / ●
Error or battery overheat

18 DOMU125_EN_v3_20221205_Poweo® Quick Up user manual
warranty of batteries that would come to fail due to lack of maintenance.
In case of an intensive use failing to meet the service factor of the lifter (2/10), a
"battery empty" false alarm may appear on the remote control. In this case do the
following:
• Remove the battery from its compartment,
• Wait 10 seconds,
• Put the battery back on its compartment.
This operation allows the electronics to reset and cancels the “false” alarm.
The controls
The Poweo® 140 – 180 Quick Up patient lifters have two controls: one remote control and one
fixed control panel installed on the column of the patient lifter. The user can activate the
functions of the lifter (up, down, opening of the legs, closing of the legs...) from both controls
indistinctly.
Both controls are equipped with "4 buttons": lifting, lowering, opening of the legs, closing of the
legs.
The 4 buttons controls for Poweo® 140 – 180 Quick Up
Hand control Control panel
Maintenance LED
Battery status LED
Lifting
Closing the legs
Lowering
Opening
the legs
Lifting
Lowering
Maintenance LED
Opening the legs
Battery status LED
Closing the legs

DOMU125_EN_v3_20221205_Poweo ® Quick Up user manual 19
Understanding the information of the remote control
The maintenance LED indicator is used to indicate a possible malfunction
AND the periodic inspection status. Therefore, it can display multiple consecutive status.
Example: in case of default AND periodical inspection date exceeded, the
LED displays alternately flashing RED and solid ORANGE.
Managing the maintenance LED status is easy:
• Continuous solid light = default.
• The light is continuous and the lifter is not operating = main fuse replacement is
necessary.
• Flashing light = periodical inspection management.
According to the EN 10535 standards the time period between periodical inspection default
values is 12 months. The periodical inspection time setting can be changed using the Poweo®
service tool software.
BATTERY LED
MAINTENANCE LED
● – Solid green = more than 10 cycles are
still possible.
● – Solid orange : default. Use the Poweo®
service tool software or call us for
maintenance.
● – Solid red : = less than 10 cycles left
before battery empty status.
● – Flashing orange: periodic inspection must
be performed within 2 months.
● – Flashing red : battery alarm (only one
cycle left before the battery is completely
empty).
● – Flashing red: periodic inspection has not
been performed in time.
Transferring with the Poweo®140 -180 Quick Up
Lifting and transferring from a sitting position
1. If the patient is sitting in a wheelchair, make sure to activate
the brakes.

20 DOMU125_EN_v3_20221205_Poweo® Quick Up user manual
2. Set the lifter so that the back of the patient is in contact with the back of the chair.
3. Place the suspension above the user until the lower edge of the foam is approximately 2
cm above the thighs of the patient.
4. Position the foams around the chest of the patient and ensure that they remain far
enough below the armpits.
Avoid placing them too high under the armpits
of the patient or too far in front or behind the
arms of the patient. The arms of the patient
must always remain outside of the suspension.
5. Lift one leg of the patient and slide the thigh support in place, either high on the thigh
near the groin or half way along the thigh. Repeat the
procedure with the other leg.
Depending on the chosen position of the thigh support there
will be more or less weight to be carried by the foams. When
the thigh supports are relatively high, there will be less
weight on the foams. When the thigh supports are in a lower
position, there will be more weight on the foams.
6. Adjust the length of the thigh sling so that the legs of the patient are lifted
simultaneously with the torso.
The selected position of the thigh slings and thigh supports directly affects the comfort
of the patient. Please make sure the patient is comfortably positioned before
proceeding to the transfer.
7. Using the remote control, lift the patient for a second, by pressing the "UP" button.
8. Ensure the suspension is well positioned around the patient and the patient is
comfortable. Repeat points 1 to 4 if necessary.
9. Lift the patient until the feet are over of the floor.
This manual suits for next models
1
Table of contents
Other Scaleo medical Lifting System manuals
Popular Lifting System manuals by other brands

Rotary
Rotary 1000 SERIES Operation & maintenance manual

POWERTEX
POWERTEX PAPH-S1 Series user manual

Harmar Mobility
Harmar Mobility Single-Fold Ramp Installation and owner's manual

liftup
liftup EasyLift V3 PLUS user manual

Invacare
Invacare Aquatec ORCA user manual

Jema Autolifte
Jema Autolifte JA4000FP Installtion, Operation and Maintenance Instructions
