SC&T TTP111HDLF User manual

Smart Cabling & Transmission Corp. V1.0
Twist Pair Passive
User Manual
Model : TTP111HDLF
HD-TVI/AHD/HDCVI/CVBS Video Balun with Pigtail
(F Connector)

1
User Manual
TTP111HDLF
Introduction
TTP111HDLF is a video balun that can use a single cost-effective twisted pair cable to extend HD-TVI/ AHD/
HDCVI/ CVBS signal and power, with the transmission distance up to 400M and the resolution up to 4K
(8MP).
The pigtail design allows you to have an easier, faster connection experience.
Besides, the balun has built-in ESD, EFT, and surge protection components, allowing the unit to have a
longer product lifespan.
Features
Signal extension up to 400M over UTP CAT5e/
Female BNC to terminal block with pigtail design.
No power required.
Compact size, and rack mountable.
Built-in ESD, EFT and transient protection..
Installation View
HD-TVI
AHD
HDCVI
CVBS
1080P 250M
5MP 200M
1080P 250M
4MP 200M
1080P 300M
5MP/4K 200M
400M
The distance may effected by the quality of cable, camera, DVR. This installation should be made by a
qualified service person and should conform to all local codes.
Panel View

2
User Manual
TTP111HDLF
Specification
ITEM NO.
TTP111HDLF
Support
Video Format
HD-TVI, AHD, HDCVI, CVBS
Max. Video Resolution
8MP (4K)
Transmission Distance
400M (Max) over UTP (Unshielded Twisted Pair) CAT5e/CAT6
Bandwidth
50Hz-60MHz (-3dB)
Ports & Interfaces
Video Input
1 x BNC Female (1V p-p, 75Ω)
Video Output
1 x Terminal (RJ45)
Protection
ESD Protection
30 KV(Air), 15 KV (Contact), IEC 61000-4-2
EFT Protection
40A(5/50ns), IEC 61000-4-4
Lightning Protection
2A (8/20μs), IEC 61000-4-5
Response Time
<1 nS
Ambient Temperature
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
15.5 x 16.8 x 143mm
Weight
20g
