SC&T IP09K User manual

1
IP CABLING TRANSMISSION
ITEM NO.: IP09K Long Reach IP over CAT5e Extender
The IP09K is born to break the limitation of Ethernet transmission of 100M and extends any networking
devices up to 800M over cost-effective CAT5e cable. Furthermore, the IP09K is completely transparent to
protocols, codes, and applications, ensuring its great compatibility with any TCP/IP device and its
management software. It is a perfect solution for extending TCP/IP signal to extra remote camera.
Features:
To send and extend TCP/IP signal over CAT5e/6 cable
Distance support: 500 meters at 100Mbps, 800 meters at 10Mbps
Support 10BASE-T, 100BASE-TX, 100BASE-T1 standard.
Support Auto MDI/MDI-X.
Support Full duplex and half duplex mode.
Support EEE Energy-Efficient Ethernet.
Built-in 1.5KV (Line to Line) surge protection.
Transmission Distance Chart:
The transmission distance report below is tested through the COMMSCOPE 57535-2 (CAT5e
24AWG) cables.
Mode
Data Rate
Transmission Distance
100BASE-TX
100Mbps
130M
100BASE-T1
100Mbps
300M
Long Reach 100
100Mbps
500M
10BASE-T
10Mbps
250M
Long Reach 10
10Mbps
800M
※The distance may vary by installation conditions, quality of cables, and the performance of
connecting devices.
※10BASE-T / 100BASE-TX and Long Distance 100Mbps mode use 2 pair wire to transmit
※100BASE-T1 and Long Distance 10Mbps mode use 1 pair wire to transmit only

2
Installation:
(1) Point to Point Transmission
(2) Multi-Camera Video Transmission
(3) Wifi Acess Point Extending Transmission
(4) Extra Long Distance Transmission
(5) Extra Long HDMI Transmission

3
Panel Review:
No.
Interface
Functionality
1
RJ45 Connector
Port 1；To connect networking devices or another IP09
(Refer to Description 1,2,3)
2
RJ45 Connector
Port 2；To connect networking devices or another IP09
(Refer to Description 1,2,3)
3
RJ45 LED
To indicate the network connection status
(Refer to Description 4)
4
Power Jack
To connect DC12V 0.5A adapter
5
Power LED Indication
To indicate the power status (Refer to Description 5)
6
Status Indication
□
1Status : Port 1 mode indication (Refer to Description 6)
□
2Status : Port 2 mode indication (Refer to Description 6)
7
DIP Switch
To select the desired mode (Refer to Description 7)
Description:
1. Link speed of port 1 and 2 must be sync, or they are not able to activate network
connection.
2. Once the port 1 and 2 remain unlinked, the IP09 will automatically turn to Power Saving
mode.
3. RJ45 Pinout
(PIN TIA/EIA-568B)
PIN
Wire Color
1
Orange-white
2
Orange
3
Green-white
4
Blue
5
Blue-white
6
Green
7
Brown-white
8
Brown

4
4. RJ45 LED
Data Rate
LED On
LED Off
LED Blinking
100Mbs
Enable
Disable
Data Transferring
10Mbps
Enable
Disable
Data Transferring
5. Power LED Indication
Green On
Green Off
Light Breathing
Power On
Power Off
Power Saving
6. Status Indication
Blue On
Blue Off
Light Blinking
Blink twice
Long Reach
Ethernet
100BaseT-T1
Hardware Failure
7. Dip Switch Setting:
7.1. Auto Mode / Default (Highly Recommended)
Dip switch 1-2-3-4 all up (OFF)
Auto Mode enable auto negotiation which automatically set up the link speed and
transmssion protocol.
7.2. Auto+EEE Mode
Dip switch 1 down (ON), 2-3-4 up (OFF)
Auto+EEE mode supports Energy-Efficient Ethernet based on Auto Mode.
7.3. Advanced Mode
Please refer to the chart below to manually set up the Link Speed, and Modes
No.
Mode
↑OFF
↓ON
1
LINK SPEED
10Mbps
100Mbps
2
ETHERNET
Disable
Enable
3
100BASE-T1
Disable
Enable
4
LONG DISTANCE
Disable
Enable
※Link speed of 10Mbps is not supported on 100BASE-T1 mode
Auto-Negotiation Priority:
Priority
Mode
1 (Highest)
Long Distance 100Mbps
2
100BASE-T1
3
Long Distance 10Mbps
4
100BASE-TX Full Duplex
5
100BASE-TX Half Duplex
6
10BASE-T Full Duplex
7 (Lowest)
10BASE-T Half Duplex

5
IP09K Package Included:
2 x IP09.
2 x DC12V 0.5A Power Adapter.
2 x accessory bag (4 x Screw, 4 x Hole Plug)
Specification:
Rev. A 200110
ITEM
IP09
Standard
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3bw 100BASE-T1 Ethernet
IEEE 802.3 Nway Auto-Negotiation
IEEE 802.3x Full Duplex Operation And Flow Control
IEEE 802.3az Energy Efficient Ethernet
Data Rate
10 Mbps / 100 Mbps
Distance (Max)
100BASE-TX 130M / 10BASE-T 250M
100BASE-T1 300M
Long Distance 100 500M / Long Distance 10 800M
Ethernet Connector
RJ45 x 2
Power Supply
5V ~ 12V Regulated
Power Consumption
1W
Power Adapter
DC 12V 500mA Regulated
Dimensions (mm)
49 x 91.8 x 25
Weight (g)
120
