SC&T DR01 User manual

Smart Cabling & Transmission Corp.
V1.0
DVI Repeater
User Manual
Model : DR01
DVI Repeater

1
User Manual
DR01
Introduction
DR01 is a DVI repeater that extends the length of DVI cable to reach to a remote projector or monitor. It
automatically equalizes and compensates for connected DVI cable losses. The repeater can also use an
external power adapter to reach further distance up to 50M..
Features
Support Resolution up to 1080p & 1920 x 1200px.
Signal extension up to 50M..
Installation view

2
User Manual
DR01
Specification
ITEM NO.
DR01
Support
Max. Video Resolution
1920 x 1200@60Hz
Video Bandwidth
1.65 GHz
Transmission Distance
50M
Ports & Interfaces
Video Input
1 x 29-pin DVI-I (Digital Only)
Video Output
1 x 29-pin DVI-I (Digital Only)
Power
Power Supply
DC 5V 1A
Power Consumption
220mA (Max)
Ambient Temperature
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
67 x 53 x 27mm
Weight
110g
