SCARAB MINOR Euro 3
Page 2 Operator’s Manual Original Issue - 19 August 2003
GENERAL INFORMATION
WEIGHTS, DIMENSIONS AND CAPACITIES
Gross Vehicle Weight (GVW) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Refer to VIN plate
Unladen Weight (Standard)* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.49 tonnes
Unladen Weight (Hi-Tip)*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.61 tonnes
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4230 mm
Front Overhang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1148 mm
Rear Overhang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1053 mm
Wheelbase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2020 mm
Overall Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1650 mm
Overall Height (hopper lowered) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2360 mm
Overall Height (hopper raised) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3213 mm
Turning Circle (curb to curb) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8.50 metres
Hopper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.0 m3- Hi-tip 1.6 m3
Fuel Tanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 litres
Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.90 litres
Coolant. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 litres
Hydraulic Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 litres
Water Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 450 litres - Street Wash Conversion = 1000 litres
Brake System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.70 litres
High-pressure Water Pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.55 litres
* Dependent upon specification
TOWING & TRANSPORTATION
SERIOUS DAMAGE TO TRANSMISSION WILL RESULT IF VEHICLE IS TOWED WITH PROP-SHAFT
CONNECTED.
If towing is considered necessary, it is imperative that the prop shaft is removed before any
attempt to tow the vehicle.
When transporting the vehicle, it shall be secured to the transporter by means of suitable
straps as follows:
Front Wheels............................One Strap per Wheel to a REARWARD lashing point.
Rear Wheels.............................One Strap per Wheel to a FORWARD lashing point.
Front of Body...........................One Strap each end of Front Bumper to a FORWARD lashing
point.
Rear of Body............................One Strap over each Rear Spring Hanger to an OPPOSITE
REARWARD lashing point.
IDENTIFICATION PLATES
The SERIAL NUMBER PLATE is located on the outside rear face of the cab, at floor level to the
right hand side. All Scarab Minors have a four-digit number with the prefix H.
The VIN PLATE is located above the serial number plate.
The CHASSIS NUMBER is stamped on the top face of the right hand chassis rail beneath the
cab/tank.
The LOAD APPORTIONING VALVE (LAV) PLATE is located on the outer face of the left or right
hand chassis rail (according to driving position).
drivemanVM.fm Page 2 Tuesday, August 19, 2003 11:53 AM

SCARAB MINOR Euro 3
Amdt.1 - 19 August 2003 Operator’s Manual Page 3
TABLE OF CONTENTS
Para Title Page
General Information .........................................................................................................2
Table Of Contents (this page).........................................................................................3
Health and Safety Advice................................................................................................4
Operator’s Routine Maintenance...................................................................................5
Scarab Parts & Service Providers.....................................................................................6
Tilting the Cab....................................................................................................................8
Key Maintenance Procedures.........................................................................................9
Cleaning the Suction Fan...........................................................................................8
Suction Nozzle Clearances.......................................................................................10
Setting up the Brushes & Skirts..................................................................................10
Fluid Levels..................................................................................................................12
Recommended Lubricants & Consumables..........................................................13
Manual Greasing.......................................................................................................14
Description of Sweeping Controls.................................................................................15
Limitations of Use.............................................................................................................17
Operating Procedure - Drive Mode..............................................................................17
Operating Procedure - Sweep Mode...........................................................................18
Reducing Noise Levels & Fuel Consumption..........................................................19
RDS Sweeper Monitors ...................................................................................................20
Wander Hose...................................................................................................................20
Hopper Operating Procedure.......................................................................................21
Rear Door.........................................................................................................................22
Using the Low-pressure Water Pump ............................................................................22
Using the High-pressure Water Pump............................................................................23
Oil Level ......................................................................................................................24
Draining ......................................................................................................................24
Explanation of Operating Symbols................................................................................24
Supplementary Information (Dual Sweep & Street Wash Controls)..........................26
Figures Page
Fig. 1 Main Features of the Scarab Euro 3 Minor .................................................... 7
Fig. 2 Cab-tilt Locking Mechanism ........................................................................... 8
Fig. 3 Inspecting & Cleaning the Suction Fan......................................................... 9
Fig. 4 Suction Nozzle Clearance - Factory Set-up................................................. 10
Fig. 5 Brush Tilt Adjustment....................................................................................... 10
Fig. 6 Front Brush Adjustment................................................................................... 11
Fig. 7 Quick-release Brush Hub Alignment............................................................. 12
Fig. 8 Cab Interior Arrangement - Fluid Reservoirs................................................ 13
Fig. 9 Engine & Hydraulic Tank Fluids...................................................................... 13
Fig. 10 Manual Grease Point Locations.................................................................... 14
Fig. 11 Control-panel Layout (LHD) .......................................................................... 15
Fig. 12 Driving Controls............................................................................................... 17
Fig. 13 Control-panel Layout (LHD) .......................................................................... 18
Fig. 14 The Scarab ‘Wizard’ Sweeper Monitor ........................................................ 20
Fig. 15 RDS Monitor..................................................................................................... 21
Fig. 16 Use of the Blanking Plate............................................................................... 22
Fig. 17 Correct Use of the Hopper Prop................................................................... 23
Fig. 18 Low-pressure Water Pump Arrangements................................................... 24
Fig. 19 High-pressure Water Pump Arrangements.................................................. 25
Fig. 20 Dual Sweep & Street Wash Controls ............................................................ 28
