TECHNICAL DOCUMENTATION
SCHAKO | Ferdinand Schad KG Telefon [phone]
Steigstraße 25-27 Fax [phone]
D-78600 Kolbingen www.schako.de | infoschako.de
PERFORMANCE DATA
Operating temperature: 10 - 50 °C
Differential pressure range: 20 - 750 Pa
Volumetric flow measurement range from 13 m3/h to
2195 m3/h
Minimum pressure difference 5 to 150 Pa
VLV55
for air velocity 0.5 to 5 m/s
VLV65
for air velocity 1 to 8 m/s
SPECIAL FEATURES
after moulded parts no inflow area required
optimised for air velocities from 0.5 m/s
high control accuracy at low pressures and air veloci-
ties
position-independent installation
resistant to pollution due to the design
TESTS AND STANDARDS
VDI 6022, Sheet 1: Hygienic requirements of ventila-
tion and air-conditioning systems
DIN EN 13779 (2007): Ventilation of non-residential
buildings
Leakage air: EN 1751 (2014-06)
DIN EN 1751, class 4: Leakage with damper blade
closed
DIN EN 1751, class C: Housing leakage
APPROVALS AND CERTIFICATES
RoHS 2002/95/EC
EMC 2004/108/EC
Low voltage 2006/95/EC
VLV55|VLV65
Volumetric flow controller

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
Table of Contents
Construction subject to change
No return possible Version: 2017-04-24 | Page 2
TABLE OF CONTENTS
Table of Contents................................................................................................................... 2
Overview of product versions................................................................................................ 3
Function................................................................................................................................. 3
Areas of application............................................................................................................... 4
Processing.............................................................................................................................. 4
Available sizes........................................................................................................................ 5
Useable volumetric flow ranges ............................................................................................ 5
Accessories ............................................................................................................................ 6
Dimensions of accessories..................................................................................................... 6
Available sizes of accessories................................................................................................. 6
Static minimum pressure difference ..................................................................................... 7
VLV55 - flow generated noise................................................................................................ 8
VLV55 - flow generated noise - relative sound spectrum...................................................... 9
VLV55 - radiated noise......................................................................................................... 10
VLV55 - radiated noise - relative sound spectrum............................................................... 11
VLV65 - flow generated noise.............................................................................................. 12
VLV65 - flow generated noise - relative sound spectrum.................................................... 13
VLV65 - Radiated noise........................................................................................................ 14
VLV65 - Radiated noise - relative sound spectrum.............................................................. 15
Duct silencer (-RS) - insertion loss ....................................................................................... 16
Controller selection ............................................................................................................. 17
Technical data of control components................................................................................ 17
Circuit diagrams - Belimo..................................................................................................... 18
Circuit diagrams - Gruner..................................................................................................... 21
Setting the operating potentiometers................................................................................. 22
Technical data of controllers and motors............................................................................ 24
Startup using PC-Tool .......................................................................................................... 26
Startup using the setting and diagnostic device ZTH EU (Belimo)....................................... 27
Startup using the setting device GUIV-A ............................................................................. 28
Smartphone app - Belimo Assistant .................................................................................... 28
Prior to assembly and commissioning ................................................................................. 29
Installation information....................................................................................................... 29
Maintenance and service..................................................................................................... 29
Legend ................................................................................................................................. 29
Order code........................................................................................................................... 30
Specification text ................................................................................................................. 31

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
Overview of product versions | Function
Construction subject to change
No return possible Version: 2017-04-24 | Page 3
OVERVIEW OF PRODUCT VERSIONS
VLV55|VLV65 with rubber lip seal
Round volumetric flow controller
Volumetric flow range 0.5-5 m/s (VLV55) or 1-8 m/s (VLV65)
With rubber lip seal (-GD1)
VLV55|VLV65 with flat flange
Round volumetric flow controller
Volumetric flow range 0.5-5 m/s (VLV55) or 1-8 m/s (VLV65)
With flat flange according to DIN 24154, class 5 (-FF1)
VLV55|VLV65 with METU flange
Round volumetric flow controller
Volumetric flow range 0.5-5 m/s (VLV55) or 1-8 m/s (VLV65)
With METU flange type AF, without tension ring (-MF1)
FUNCTION
A volumetric flow controller is used for pressure-independent
volumetric flow regulation in ventilation and air-conditioning
systems. It serves to keep the volumetric flow either constant
within specified limits (CAV) or to control it variably (VAV).
The housing, measuring nozzle and the controller with pressure
sensor form a closed control loop with feedback, allowing de-
mand-dependent, energy-saving air-conditioning of the single
rooms or areas of air-conditioning systems also at low duct
pressures and air velocities. When suitable controller types are
used, room or duct pressure regulation can be achieved.
For the measurement of the effective pressure, SCHAKO is us-
ing its measuring method by means of a standardised Venturi
nozzle made of aluminium to DIN EN ISO 5167. In front of the
Venturi nozzle and in the nozzle neck, the volumetric flow con-
troller is fitted with openings for pressure take-off. The result-
ing differential pressure (effective pressure) is measured and
evaluated by a universal or compact controller. The VLV meas-
urement principle allows measurement of small volumetric
flows. In comparison with measuring rods, measuring crosses
or measuring orifices having fewer measuring points, this gives
higher accuracy, allowing the inflow area required in front of
the volumetric flow controller to be omitted. This also allows
smaller measurement tolerances to be achieved.
The volumetric flow controllers of the VLV type are insensitive
to dirt caused by dust and can be installed and used inde-
pendently of their position. The mounting instructions docu-
mented by the manufacturer must be adhered to, as otherwise
the correct functioning of the volumetric flow controller is not
guaranteed. The volumetric flow controllers type VLV are not
suitable for air containing sticky and greasy particles (e.g.
kitchen exhaust air).

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
Areas of application | Processing
Construction subject to change
No return possible Version: 2017-04-24 | Page 4
AREAS OF APPLICATION
for supply and return air systems with low pressures
and low air velocity
for constant CAV or variable VAV installations
for positive control Vmin, Vmid, Vmax, "OPEN" or "CLOSED"
For volumetric flow and linear pressure control
at ambient temperatures 0° to +50°C,
requirement: measuring air 0...+50°C/5...95% rH,
non-condensing
for regulating the air velocity in the duct in
the range of 0.5...8 m/s
VLV55 for air velocity 0.5 - 5 m/s
VLV65 for air velocity 1 - 8 m/s
Minimum pressure difference of 5 - 150 Pa
When using volumetric flow controllers in roof central units, in
extreme cases, condensation can build up in the measuring
pipes of the volumetric flow controller as a result of the large
temperature differences between the air flowing through the
volumetric flow controller and the surrounding air. This con-
densation may affect or damage the sensor. This is why for this
field of application care must be taken to insulate the housings
of the volumetric flow controllers and the measuring hoses (to
prevent condensation) and to mount the controllers in such a
way that any condensate formed on the outside of the measur-
ing hoses can run downward and be drained (without entering
the sensor).
When connecting SCHAKO components to customer installa-
tions, any compatibility problems are beyond our scope of re-
sponsibility and must be solved on site.
Tests and standards
The volumetric flow controller VLV-… has been tested by the
designated body in accordance with the following regulations:
Completed tests
VDI 6022, Sheet 1: Hygienic requirements of ventilation and
air-conditioning systems
DIN EN 1751: Ventilation for buildings - Air terminal devices -
Aerodynamic testing of damper and valves
DIN EN 13779 (2007): Ventilation of non-residential buildings
Applied standards
Leakage classification: DIN EN 1751 (2014-06)
RoHS 2002/95/EC
EMC 2004/108/EC
PROCESSING
Housing
Galvanised sheet steel (-SV)
Galvanised sheet steel with DD coating (-DD)
Housing leakage according to DIN EN 1751, class C
Damper blade
Galvanised sheet steel (-SV)
Galvanised sheet steel with DD coating (-DD)
Damper axle
Passivated steel
Brass
Damper blade seal
made of EPDM, silicone-free, halogen-free
airtight sealing design to DIN-EN 1751, class 4
Ring chamber sealing
made of EPDM, silicone-free, halogen-free
Damper bearing
Plastic bearing
Measuring sensor
round Venturi nozzle made of aluminium
to DIN EN ISO 5167 (-SV)
round Venturi nozzle made of aluminium
to DIN EN ISO 5167 with DD coating (-DD)
Model
round model, for round ductwork connection to DIN EN 1506,
with damper blade seal for airtight sealing to DIN EN 1751,
class 4
VLV55 for air velocity 0.5 to 5 m/s
VLV65 for air velocity 1 to 8 m/s
Controller
LMV-D3-MP-SO, 5 Nm (-A001)
LMV-D3-MF-SO, 5 Nm (-A006)
227VM-024-05, 5 Nm (-A061)
Other controllers available on request

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
Available sizes | Useable volumetric flow ranges
Construction subject to change
No return possible Version: 2017-04-24 | Page 5
Detail X
AVAILABLE SIZES
NW
[mm]
øD
[mm]
d (55)
[mm]
d (65)
[mm]
L
[mm]
Weight
[kg]
100 98 53 63 330 1.5
125 123 67 79 370 1.9
160 158 86 102 420 2.5
200 198 108 128 480 3.4
250 248 136 160 570 4.8
315 313 171 203 690 7.0
NW 100 - NW 315 sealing airtight to DIN-EN 1751, class 4.
Dimensions
VLV55 / VLV65
USEABLE VOLUMETRIC FLOW RANGES
VLV55 VLV65
NW V Vmin Vmax V
min V max
(mm) (0.5 m/s) (5 m/s) (1 m/s) (8 m/s)
100 m³/h 13 132 26 211
l/s 437 7 59
125 m³/h 21 210 42 334
l/s 658 12 93
160 m³/h 35 346 69 554
l/s 10 96 19 154
200 m³/h 55 546 109 874
l/s 15 152 30 243
250 m³/h 86 859 172 1374
l/s 24 239 48 382
315 m³/h 137 1372 274 2195
l/s 38 381 76 610
ATTENTION: Important for parameterisation of the VLV
The table corresponds to the complete measuring range.
When the air volume drops below Vmin, the correct function-
ing of the volumetric flow controller is no longer guaranteed.
If only Vmax is specified in the order, a variable volumetric
flow controller will be delivered. The Vmin value will be set to
the value specified in the catalogue.
If only one air volume is specified in the order (as Vmin or Vkon-
stant), then the volumetric flow controller will be delivered as
a constant volumetric flow controller. The volume specified
in the order is set to the Vmin value, and the Vmax value is set
to 100%.
The air volumes Vmin and Vmax and the operating mode 0/2-10
V can be changed directly at the controller within the nomi-
nal volumetric flow.
For the parameter setting of the control components, an air
density of 1.2 kg/m³ has been taken into account.
If no values are specified in the order, the controller will be
programmed with the values of the complete measuring
range. The following calibration curves are taken into ac-
count:
--- VLV55 ... 5 m/s;
--- VLV65 ... 8 m/s.
The first adjustment of the Vmin, Vmax and Vnenn operating volu-
metric flows is done prior to delivery ex works in accordance
with customer specifications (calibration for delivery address).
When these values are set, the functions of all volumetric flow
controllers are also checked.

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
Accessories | Dimensions of accessories
Construction subject to change
No return possible Version: 2017-04-24 | Page 6
ACCESSORIES
METU flange (-MF1)
on both sides, duct flange type AF.
Flat flange (-FF1)
on both sides, according to DIN 24154/5.
Rubber lip seal (-GD1)
on both sides, special rubber.
Duct silencer (-RS)
Rigid model
Outer jacket and perforated sheet made of galvanised sheet
steel
mineral wool filling
DIMENSIONS OF ACCESSORIES
METU flange (-MF1)
Tension ring (provided by the customer)
VLV
Metu flange (-MF1)
Counter flange (provided by the customer)
Flat flange (-FF1), on both sides
to DIN 24154/5
Rubber lip seal (-GD1)
Detail X
Duct silencer (-RS)
AVAILABLE SIZES OF ACCESSORIES
-FF - Flat flange
NW øD ød1 ød2 ød L LOA t
100 98 154 129 7 340 4 3
125 123 177 155 7 360 4 3
160 158 222 194 7 410 6 4
200 198 263 235 7 450 6 4
250 248 313 286 7 500 6 4
315 313 388 356 9.5 600 8 5
-RS - Duct silencer
NW L øD øD2
P (mm)
50 100
100 340 98 200 300
125 360 123 225 325
160 410 158 260 360
200 450 198 300 400
250 500 248 350 450
315 600 313 415 515

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
Static minimum pressure difference |
Construction subject to change
No return possible Version: 2017-04-24 | Page 7
STATIC MINIMUM PRESSURE DIFFERENCE
VLV55
NW vkV V ∆pt min V
(m/s) (m3/h) [l/s] (Pa) ±%
100
0.5 13 4 5 15
2 53 15 15 10
4 105 29 75 7
5 132 37 100 5
125
0.5 21 6 5 15
2 84 23 20 10
4 167 46 75 7
5 209 57 110 5
160
0.5 35 10 5 15
2 139 38 15 10
4 277 77 60 7
5 346 96 100 5
200
0.5 55 15 5 15
2 218 61 20 10
4 436 121 60 7
5 546 152 100 5
250
0.5 86 24 5 15
2 344 96 20 10
4 687 191 60 7
5 859 239 90 5
315
0.5 137 38 5 15
2 549 153 20 10
4 1097 305 65 7
5 1372 381 90 5
VLV65
NW vkV V ∆pt min V
(m/s) (m3/h) [l/s] (Pa) ±%
100
1 26 7 5 15
3 79 22 25 10
6 158 44 90 7
8 210 58 150 5
125
1 42 12 5 15
3 125 35 25 10
6 250 70 90 7
8 334 93 140 5
160
1 69 19 5 15
3 208 58 20 10
6 416 116 50 7
8 554 154 90 5
200
1 109 30 5 15
3 328 91 20 10
6 655 182 65 7
8 874 243 100 5
250
1 172 48 5 15
3 515 143 15 10
6 1031 286 55 7
8 1374 382 85 5
315
1 274 76 5 15
3 823 229 20 10
6 1646 457 55 7
8 2195 610 90 5

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
VLV55 - flow generated noise |
Construction subject to change
No return possible Version: 2017-04-24 | Page 8
VLV55 - FLOW GENERATED NOISE
VLV55
NW
VK
(m/s)
V
(m3/h)
V
[l/s]
∆pt= 50 Pa
LWA [dB(A)]
∆pt= 100 Pa
LWA [dB(A)]
∆pt= 150 Pa
LWA [dB(A)]
∆pt= 200 Pa
LWA [dB(A)]
∆pt= 250 Pa
LWA [dB(A)]
100
0.5 13 4 29 33 36 41 43
2 53 15 44 50 54 56 58
4 105 29 44 54 59 62 64
5 132 37 --- 56 61 65 67
125
0.5 21 6 35 38 43 45 48
2 84 23 49 54 58 59 61
4 167 46 47 58 63 65 67
5 209 57 --- 56 63 67 69
160
0.5 35 10 38 45 46 50 51
2 139 38 51 57 60 62 63
4 277 77 50 60 64 67 68
5 346 96 --- 58 65 68 71
200
0.5 55 15 41 45 47 49 51
2 218 61 49 59 59 66 68
4 436 121 49 59 64 67 70
5 546 152 --- 59 65 68 71
250
0.5 86 24 42 50 56 60 62
2 344 96 50 59 63 66 69
4 687 191 51 60 64 67 70
5 859 239 --- 63 65 68 71
315
0.5 137 38 44 48 52 54 57
2 549 153 52 60 64 66 69
4 1097 305 53 61 65 69 71
5 1372 381 --- 63 67 70 72
--- = value below the static minimum pressure difference

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
VLV55 - flow generated noise - relative sound spectrum |
Construction subject to change
No return possible Version: 2017-04-24 | Page 9
VLV55 - FLOW GENERATED NOISE - RELATIVE SOUND SPECTRUM
NW100
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-6 -8 -6 -1 -4 -13 -18 -25
NW125
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-8 -9 -5 -1 -3 -12 -19 -26
Size 160
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-6 -7 -3 -1 -4 -9 -17 -27
NW200
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-6 -5 -1 0 -7 -11 -18 -26
NW250
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-1 -2 1 -1 -7 -10 -18 -28
Size 315
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-3 -1 3 -1 -6 -10 -18 -28
Differential pressure range: 0 - 300 Pa
Air velocity: 0.5 - 5.0 m/s
KL= correction value; relative sound power level, relative to LWA
KLW = LWA + {KL}
C A L C U L A T I O N E X A M P L E
VLV55 design data
NW 160 mm | V=247 m³/h |
p=100 Pa | LWA = 60 dB(A)
Hz 63 125 250 500 1000 2000 4000 8000
KL-6 -7 -3 -1 -4 -9 -17 -27
Calculate sound values according to formula
KLW(relativ) = LWA + {KL}
gives
Hz 63 125 250 500 1000 2000 4000 8000
LWA 60 60 60 60 60 60 60 60
KL-6 -7 -3 -1 -4 -9 -17 -27
KLW 54 53 57 59 56 51 43 33

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
VLV55 - radiated noise |
Construction subject to change
No return possible Version: 2017-04-24 | Page 10
VLV55 - RADIATED NOISE
VLV55
NW
VK
(m/s)
V
(m3/h)
V
[l/s]
∆pt= 50 Pa
LWA [dB(A)]
∆pt= 100 Pa
LWA [dB(A)]
∆pt= 150 Pa
LWA [dB(A)]
∆pt= 200 Pa
LWA [dB(A)]
∆pt= 250 Pa
LWA [dB(A)]
100
0.5 13 4 --- --- --- --- ---
2 53 15 --- --- 25 28 30
4 105 29 --- 27 30 33 34
5 132 37 --- 32 34 36 38
125
0.5 21 6 --- --- --- --- ---
2 84 23 --- 25 --- 29 30
4 167 46 25 28 32 33 36
5 209 57 --- 33 35 38 42
160
0.5 35 10 --- --- --- --- 25
2 139 38 --- 28 31 33 36
4 277 77 --- 34 37 39 40
5 346 96 --- 38 40 42 44
200
0.5 55 15 --- --- --- 25 26
2 218 61 --- 33 36 39 41
4 436 121 --- 41 45 47 49
5 546 152 --- 43 46 49 52
250
0.5 86 24 --- --- --- 27 31
2 344 96 --- 34 36 39 41
4 687 191 --- 40 43 45 47
5 859 239 --- 41 43 46 48
315
0.5 137 38 --- 33 35 38 40
2 549 153 --- 45 46 48 50
4 1097 305 --- 45 47 48 50
5 1372 381 --- 44 46 50 52
--- = values below 25 dB(A)

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
VLV55 - radiated noise - relative sound spectrum |
Construction subject to change
No return possible Version: 2017-04-24 | Page 11
VLV55 - RADIATED NOISE - RELATIVE SOUND SPECTRUM
NW100
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL1 -1 -9 -8 -7 -5 -9 -11
NW125
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL4 2.4 -7 -3 -7 -7 -9 -14
Size 160
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL3 2 -3 -5 -6 -8 -9 -10
NW200
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-3 -4 -8 -6 -7 -6 -7 -9
NW250
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL2 0 -2 -5 -8 -6 -8 -11
Size 315
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-3 -4 -2 -4 -8 -7 -7 -18
Differential pressure range: 0 - 300 Pa
Air velocity: 0.5 - 5.0 m/s
KL= correction value; relative sound power level, relative to LWA
KLW = LWA + {KL}
C A L C U L A T I O N E X A M P L E
VLV55 design data
NW 160 mm | V=247 m³/h |
p=100 Pa | LWA = 34 dB(A)
Hz 63 125 250 500 1000 2000 4000 8000
KL3 2 -3 -5 -6 -8 -9 -10
Sound values calculated according to formula
KLW(relativ) = LWA + {KL}
gives
Hz 63 125 250 500 1000 2000 4000 8000
LWA 34 34 34 34 34 34 34 34
KL3 2 -3 -5 -6 -8 -9 -10
KLW 37 36 31 29 28 26 25 24

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
VLV65 - flow generated noise |
Construction subject to change
No return possible Version: 2017-04-24 | Page 12
VLV65 - FLOW GENERATED NOISE
VLV65
NW
VK
(m/s)
V
(m3/h)
V
[l/s]
∆pt= 50 Pa
LWA [dB(A)]
∆pt= 100 Pa
LWA [dB(A)]
∆pt= 150 Pa
LWA [dB(A)]
∆pt= 200 Pa
LWA [dB(A)]
∆pt= 250 Pa
LWA [dB(A)]
100
1 26 7 38 43 46 48 51
3 79 22 48 53 57 59 61
5 130 35 48 57 62 65 66
8 210 58 --- --- 62 66 69
125
1 42 12 41 45 49 51 53
3 125 35 50 58 61 63 64
5 210 60 47 59 63 67 70
8 334 93 --- --- 65 69 71
160
1 69 19 45 49 53 54 57
3 208 58 50 58 63 65 67
5 345 95 51 59 64 67 69
8 554 154 --- 61 65 68 71
200
1 109 30 46 52 54 57 58
3 328 91 49 59 63 66 68
5 545 150 51 60 64 67 69
8 874 243 --- 60 67 69 72
250
1 172 48 49 54 56 59 61
3 515 143 49 59 63 66 68
5 860 240 52 60 64 67 69
8 1374 382 --- 62 67 69 71
315
1 274 76 50 55 58 60 62
3 823 229 52 60 64 67 70
5 1370 380 54 62 65 68 70
8 2195 610 64 67 69 72 74
--- = value below the static minimum pressure difference

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
VLV65 - flow generated noise - relative sound spectrum |
Construction subject to change
No return possible Version: 2017-04-24 | Page 13
VLV65 - FLOW GENERATED NOISE - RELATIVE SOUND SPECTRUM
NW100
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-7 -8 -5 -2 -3 -12 -18 -25
NW125
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-9 -8 -5 -2 -3 -10 -17 -25
Size 160
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-7 -7 -3 -1 -4 -9 -17 -26
NW200
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-5 -3 0 -1 -6 -11 -18 -27
NW250
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-4 -2 1 -2 -6 -9 -16 -25
Size 315
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-1 0 1 -2 -5 -9 -16 -27
Differential pressure range: 0 - 300 Pa
Air velocity: 0.5 - 5.0 m/s
KL= correction value; relative sound power level, relative to LWA
KLW = LWA + {KL}
C A L C U L A T I O N E X A M P L E
VLV65 design data
NW 200 mm | V=545 m³/h |
p=100 Pa | LWA = 60 dB(A)
Hz 63 125 250 500 1000 2000 4000 8000
KL-5 -3 0 -1 -6 -11 -18 -27
Sound values calculated according to formula
KLW(relativ) = LWA + {KL}
gives
Hz 63 125 250 500 1000 2000 4000 8000
LWA 60 60 60 60 60 60 60 60
KL-5 -3 0 -1 -6 -11 -18 -27
KLW 55 57 60 59 54 49 42 33

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
VLV65 - Radiated noise |
Construction subject to change
No return possible Version: 2017-04-24 | Page 14
VLV65 - RADIATED NOISE
VLV65
NW
VK
(m/s)
V
(m3/h)
V
[l/s]
∆pt= 50 Pa
LWA [dB(A)]
∆pt= 100 Pa
LWA [dB(A)]
∆pt= 150 Pa
LWA [dB(A)]
∆pt= 200 Pa
LWA [dB(A)]
∆pt= 250 Pa
LWA [dB(A)]
100
1 26 7 --- --- --- --- ---
3 79 22 --- --- 26 28 30
5 130 35 --- 25 30 32 35
8 210 58 --- --- 35 39 40
125
1 42 12 --- --- --- --- ---
3 125 35 --- --- 26 29 30
5 210 60 --- 30 33 34 36
8 334 93 --- 38 40 41 42
160
1 69 19 --- --- 25 28 31
3 208 58 --- 33 36 38 40
5 345 95 --- 39 41 43 45
8 554 154 --- 44 46 47 48
200
1 109 30 --- 25 29 32 34
3 328 91 --- 35 38 40 42
5 545 150 --- 38 42 44 46
8 874 243 --- 43 46 48 50
250
1 172 48 --- 26 30 34 36
3 515 143 --- 37 40 42 44
5 860 240 --- 40 43 45 47
8 1374 382 --- 45 47 49 51
315
1 274 76 --- 26 29 35 38
3 823 229 --- 38 42 42 44
5 1370 380 --- 40 44 44 47
8 2195 610 --- 47 50 50 51
--- = values below 25 dB(A)

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
VLV65 - Radiated noise - relative sound spectrum |
Construction subject to change
No return possible Version: 2017-04-24 | Page 15
VLV65 - RADIATED NOISE - RELATIVE SOUND SPECTRUM
NW100
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL1 0 -8 -6 -5 -5 -10 -13
NW125
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL2 1 -5 -2 -8 -7 -9 -12
Size 160
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL0 -1 -6 -4 -7 -7 -8 -10
NW200
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL0 -2 -6 -4 -7 -7 -7 -11
NW250
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL-1 -2 -5 -6 -9 -6 -7 -12
Size 315
Relative sound spectrum (dB)
Correction value KL
Frequency (Hz)
Hz 63 125 250 500 1000 2000 4000 8000
KL0 -2 -2 -6 -8 -6 -7 -19
Differential pressure range: 0-300 Pa
Air velocity: 0.5 – 5.0 m/s
KL= correction value; relative sound power level, relative to LWA
KLW = LWA + {KL}
C A L C U L A T I O N E X A M P L E
VLV65 design data
NW 200 mm | V=545 m³/h |
p=100 Pa | LWA = 38 dB(A)
Hz 63 125 250 500 1000 2000 4000 8000
KL0 -2 -6 -4 -7 -7 -7 -11
Sound values calculated according to formula
KLW(relativ) = LWA + {KL}
gives
Hz 63 125 250 500 1000 2000 4000 8000
LWA 38 38 38 38 38 38 38 38
KL0 -2 -6 -4 -7 -7 -7 -11
KLW 38 36 32 34 31 31 31 27

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
Duct silencer (-RS) - insertion loss |
Construction subject to change
No return possible Version: 2017-04-24 | Page 16
DUCT SILENCER (-RS) - INSERTION LOSS
L1=500
De(dB/Okt)
P=50 - fm(Hz) P=100 - fm(Hz)
NW
63
125 250 500
1000 2000 4000 8000
63
125 250 500
1000 2000 4000 8000
100 3 6 10 16 22 30 14 13 5 13 15 19 33 31 25 15
125 3 5 9 14 20 24 12 11 4 10 13 18 29 25 18 12
160 2 4 7 12 18 19 10 9 3 9 11 16 26 19 14 10
200 1 3 6 10 16 15 7 6 3 7 9 15 25 17 11 9
250 1 2 4 9 15 11 4 3 2 6 8 14 23 15 9 7
315 1 1 3 8 12 8 3 2 2 4 7 13 20 12 7 5
L1=950
De(dB/Okt)
P=50 - fm(Hz) P=100 - fm(Hz)
NW
63
125 250 500
1000 2000 4000 8000
63
125 250 500
1000 2000 4000 8000
100 5 12 23 36 50 50 34 21 7 19 28 40 50 50 50 32
125 4 11 21 33 50 50 32 19 6 17 25 34 49 50 36 22
160 3 8 15 23 34 9 18 14 5 12 18 28 41 48 26 16
200 2 5 11 18 30 24 14 11 4 10 15 24 35 41 22 13
250 2 4 9 15 27 18 11 9 3 8 13 20 31 35 20 11
315 1 3 6 12 24 14 7 6 2 6 8 15 26 7 14 8
P = packing thickness in mm
L1=1450
De(dB/Okt)
P=50 - fm(Hz) P=100 - fm(Hz)
NW
63
125 250 500
1000 2000 4000 8000
63
125 250 500
1000 2000 4000 8000
100 8 22 44 50 50 50 46 28 - - - - - - - -
125 7 20 39 50 50 50 39 25 - - - - - - - -
160 6 14 27 42 48 42 26 18 6 17 30 47 50 49 30 18
200 4 6 15 29 42 30 17 14 5 14 26 42 50 46 28 16
250 3 4 10 20 37 24 13 11 4 12 22 36 46 43 25 14
315 2 4 8 16 34 19 10 7 2 8 15 27 35 32 17 9
L1=1950
De(dB/Okt)
P=50 - fm(Hz) P=100 - fm(Hz)
NW
63
125 250 500
1000 2000 4000 8000
63
125 250 500
1000 2000 4000 8000
100 9 30 50 50 50 50 50 38 - - - - - - - -
125 8 26 50 50 50 50 50 33 - - - - - - - -
160 - - - - - - - - 8 23 39 50 50 50 41 25
200 - - - - - - - - 7 19 34 50 50 50 37 21
250 - - - - - - - - 6 16 29 48 50 49 33 18
315 - - - - - - - - - - - - - - - -

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
Controller selection | Technical data of control components
Construction subject to change
No return possible Version: 2017-04-24 | Page 17
CONTROLLER SELECTION
Type Size Controller Product
LMV-D3-MP NW100 - 315 Compact Belimo
LMV-D3-MF NW100 - 315 Compact Belimo
227VM-024-05 NW100 - 315 Compact Gruner
Other controllers available on request. Make Belimo,
Gruner, Sauter, Siemens and Delta Controls possible.
TECHNICAL DATA OF CONTROL COMPONENTS
Measured value collection and control function
The volumetric flow controllers of the Belimo make, type LMV-
D3-MP/-MF Compact and the Gruner make, type 227VM Com-
pact are delivered by SCHAKO as standard with the operating
mode (Y signal, U5 signal) 2-10 V DC. When activated by 2 V DC,
the Vmin volume is controlled, the smallest possible Vmin volume
that can be controlled can be seen from the "Volumetric Flow
Range" tables.
NOTE: When the air volume drops below the Vmin shown in the
table, the correct functioning of the volumetric flow controller
is no longer guaranteed!
Positive control damper "CLOSED"
Airtight sealing to DIN EN 1751 is achieved on site either via a
positive control "CLOSED" by means of a switch or a relay, or
via an actuator signal of 0 V DC applied to the input Y (all Com-
pact controllers equipped with the operating mode 2-10V DC).
Accordingly, the drive will likewise close the flap in operating
range 2 - 10 V DC (however, this does not apply to the operat-
ing range 0-10 V DC), and the VAV control will be inactive. To
do so, it must be ensured that the actuator signal is < 0.1 V DC.
This is why in rooms where defined pressures are active (e.g. la-
boratories), the damper should be closed via a digital on site
switching contact.
If the Compact controllers of the Belimo make must be deliv-
ered with the operating mode 0-10V DC on customer request,
please note that a positive control "CLOSED" can only be ef-
fected via a switching contact with diode.
If the compact controllers of the Belimo make are used to-
gether with the type VRP-VFP-300 in the master/slave mode or
in parallel mode, then only the 2-10 V DC operating mode is
usually possible.
Positive control damper "OPEN"
Supports smoke extraction or is used as a safety position. The
volumetric flow controller is in this case inactive, and the
damper is driven to the mechanical open position.
Vmin control to a minimum volumetric flow
Depending on requirement or by not assigning them, individual
areas can be set to stand-by operation. In this way, minimum
room flushing with greatly reduced energy expenditure is
achieved.
Vmax control to a maximum volumetric flow
Individual or several rooms are supplied for a short period with
a maximum volumetric flow. This allows, for example, a room
through-ventilation or efficient heating to be effected.
Continuous operation
As a function of the continuous driving signal and the pro-
grammed operating range (0-10 V DC or 2-10 V DC), the volu-
metric flow controller will regulate the volumetric flow linearly
between the setpoint values Vmin ...Vmax.
Constant operation
If terminal 3 (Y driving signal) has not been assigned, the air vol-
ume set on the Vmin potentiometer will be set to a constant vol-
ume.
Two-stage volumetric flow rate control
Stage 1: If terminal 3 (Y command signal) has not been
assigned, the air volume set on the Vmin potenti-
ometer will be set to a constant volume.
Stage 2: If AC 24 V is applied to terminal 3 (Compact con-
troller) or terminal 7 (VRD3-SO, VRP-VFP-300),
the VSR will keep the value set on the Vmax po-
tentiometer constant. With a switch or a contact
in a connection line a "secondary volume flow
control" is possible.

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
Circuit diagrams - Belimo |
Construction subject to change
No return possible Version: 2017-04-24 | Page 18
CIRCUIT DIAGRAMS - BELIMO
Circuit diagram - standard - controller
Compact controller - Belimo make - LMV-D3-MP / LMV-D3-MF
VAV with analogue command signal VAV with lock (CLOSED) MP bus activation with integrated
switch- Model2-10VDC (LMV-D3-MPonly)
Lock mode (CLOSED): In the 2…10 V
mode, the following function can be car-
ried out with a 0 - 10 V signal.
**Attention: Controller/DDC must be able
to pull the command signal to 0 V.
Cable designations
Com-
mand sig-
nal Y
Volumetric
flow
Function
< 0.1 V ** 0 Damper CLOSED,
VAV control inac-
tive
0.2...2 V Vmin Operating stage
Vmin active
2...10 V Vmin ... Vmax continuous opera-
tion
vmin ... Vmax
DC
AC
VAV command signal
DC
AC
VAV command signal
MP / actual value sig-
nal
CLOSED / VAV mode
switchover
CLOS ED VAV
DC
AC
MP address:
1…8
e.g.
window
contact
MP / actual value sig-
nal
on site
PC tool
on site
PC tool
on site
PC tool
No. Designation Wire colour Function
1 - 〦black 〦- Feed
2 + ~ red ~ + AC/DC 24 V
3 Y white VAV / CAV command signal
5 U orange - Actual value signal
- MP bus connection
}

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
Circuit diagrams - Belimo |
Construction subject to change
No return possible Version: 2017-04-24 | Page 19
CAV operation / positive contacts CAV function for …-MV-D3-MP/-MF
Mode
setting
--- 0...10 V 0...10 V 0...10
V 0...10 V
2...10 V 2...10 V 2...10 V 2...10
V 2...10 V
Signal
⊥0...10 V
∼∼ ∼
- 2...10 V +
Function 33 3 33
Damper
CLOSED a) CLOSED c) CLOSED*
V
min
...V
max
b) VAV
CAV - V
min
everything open - V
min
active
Damper OPEN e) OPEN*
CAV - V
max
d) V
max
Note:
Please ensure mutual locking
of the contacts!
Contact closed, function active
Contact closed, function active, in mode 2...10 V only
Contact open
* not available for 24 V DC supply
DC
AC
VAV command signal
MP / actual value sig-
nal
on site
PC tool

VLV55|VLV65 - Volumetric flow controller
TECHNICAL DOCUMENTATION
Circuit diagrams - Belimo |
Construction subject to change
No return possible Version: 2017-04-24 | Page 20
LED table of functions for LMV-D3-MP / LMV-D3-MF
Application Function Description / action LED pattern Adaptation
Address
⊕
⊕
LED 1 power
LED 2 status
N1 operation Status display - 24 V power supply o.k.
- VAV-Compact ready for operation
LED 1
LED 2
S1 service function Synchronisation Synchronisation started by:
a) Operating / service unit
b) Manual trigger device at the VAV-Compact
c) Power ON behaviour
LED 1
LED 2
S2 service function Adaptation Adaptation started by:
a) Operating / service unit
b) Key on the VAV-Compact
LED 1
LED 2
V1 VAV service VAV service
active
a) Press both keys «Adaptation» & «Address»
simultaneously
b) VAV service will be activated:
- until 24 V supply is switched off
- until both keys are pressed
again
- after 2 hours have passed
LED 1
LED 2
Lack of air Damper opens as actual volume is too low LED 1
LED 2
Target volume
reached
Control circuit balanced LED 1
LED 2
Air excess Damper closes as actual volume is too high LED 1
LED 2
B1 bus operation Addressing via MP
master
(Acknowledge-
ment at the VAV-
Compact)
a) Addressing has been triggered at the MP
master
LED 1
LED 2
b) Press addressing key
LED will switch to the communication display
as soon as the addressing process is complete.
LED 1
LED 2
B2 bus operation Addressing via MP
master (with se-
rial number)
Addressing at the MP master was triggered, LED
will switch to the communication display as soon
as the addressing process is complete.
LED 1
LED 2
B3 bus operation
communication
MP-PP display
Communication
Communication display via MP master or oper-
ating / service unit
LED 1
LED 2
green LED (power) is lit
yellow LED (status) is lit
yellow LED (status) is flashing
1.) Synch time
2.) Adaptation time
1.
)
→
Start
Start 2.
)
→
On event MP communication
Not address. MP communication
MP communication
