Schaller G110 User manual

78,0°F | 6,16% | 456kg/m
3
| -27,3td | 0,64aw | 51,9%r.H. | 14,8%abs | 100,4g/m
2
| 09m/s | 4,90Ugl | 163ym | 23,2°C | 78,8°F | 6,21% |424 kg/m
Messtechnik / humimeter.com
Analytic balance
Operating Manual
Moisture analyser G110
Analytic balance for determination of moisture
Schaller GmbH
Max-Schaller-Straße 99, A - 8181 St. Ruprecht an der Raab
Tel [phone] - 28899 , Fax [phone] - 28899 - 901
[e-mail], www.humimeter.com
Any technical changes reserved. Pictures do not show
possible changes that have been made on different models.
BuildingsFood
Climate Bionenergy Paper / BoardMaterial
V1.0_en
05.11.2019

Page 2
Table of contents
1 Technical data .................................................................................................... 3
2 Description of the device ................................................................................... 4
2.1 Basic device .....................................................................................................4
2.2 Display .............................................................................................................5
2.3 Keypad .............................................................................................................5
3 General information ........................................................................................... 6
3.1 Publication declaration .....................................................................................6
3.2 Proper use ........................................................................................................6
3.3 Improper use ....................................................................................................6
3.4 Warranty ........................................................................................................6
3.5 Monitoring of measuring devices .....................................................................7
4 Safety information ............................................................................................. 7
4.1 Symbols used in this manual ............................................................................7
4.2 User qualifications ............................................................................................8
4.3 Hazard warnings ..............................................................................................8
5 On receipt of your device ................................................................................. 10
5.1 Taking the device out of its packaging ............................................................10
5.2 Place of installation ........................................................................................10
5.3 Assembling the analytic balance .....................................................................11
5.4 Levelling the analytic balance .........................................................................12
5.5 Power supply .................................................................................................12
6 Preparation ..................................................................................................... 13
6.1 Preparation of sample ....................................................................................13
6.2 Tools and accessories for sample preparation .................................................13
6.3 Preparation of analytic balance ......................................................................14
7.1 Switching the device on .................................................................................14
7.2 Drying modes .................................................................................................14
7.2.1 Specifying the heat-up mode ....................................................................... 15
7.2.3 Setting the drying temperature .................................................................... 17
7.2.4 Setting the drying / measuring time (only in the time stop mode) ................ 17
7.3 Measurement .................................................................................................18
7.4 Adjustment / calibration .................................................................................18
7.5 Troubleshooting .............................................................................................20
8 Warranty ......................................................................................................... 20
9 Limitation of liability ........................................................................................ 21
10 Disposing of the device ................................................................................. 21
11 Notes ............................................................................................................. 22

Page 3
1 Technical data
Heating element Halogen lamp (1 x 400 W)
Drying temperature range 40 °C - 199 °C
Maximum weight 110 g
Minimum weight 0.02 g
Readability 0.005 g / 0.05 %
Measuring range moisture 0 - 100 %
Drying time 1 to 99 min. adjustable
Displayed values [%] moisture; [%] dry weight;
[g] remaining weight
Maximum sample size Ø 92 mm, height 20 mm
Calibration weight 100 g (F2)
Interface RS232
Display LCD
Dimensions 240 x 365 x 180 mm
Net weight 4.8 kg
Power supply 230V AC 50Hz
Scope of delivery Analytic balance G110, sample pan, mains cable,
100 g calibration weight, operating manual

Page 4
2 Description of the device
No. Description
1Heating hood
2Heating lamp
3Heat protection plate
4Sample pan
5Wind shield
6Insertion aid
7LCD display
8Keypad
9Height-adjustable foot
No. Description
10 RS-232 interface
11 Bubble level
12 Fan
13 Power supply socket
2.1 Basic device
1
2
3
9
8
4
5
6
7
10 11 12 13

Page 5
2.2 Display
Symbol Description
Heat-up mode Standard
Heat-up mode Quick
Heat-up mode Slow
Measuring / Stop mode
Drying temperature
Drying time
Percentage dry weight / dry matter %
Percentage moisture
Grammes
2.3 Keypad
Key Function
ON/OFF Power on / off
START / STOP Start / stop measurement
TARE Tare / Leave settings
MENU Settings
CONVERSION Switch between absolute and relative
measuring result
ENTER Conrm / go to next setting
RESET Return to weighing mode
DOWN Change settings
UP Change settings

Page 6
3 General information
The G110 analytical balance is designed for determining the moisture content
of liquid, porous and solid materials using the thermogravimetric method. The
balance can also be used to weigh all solids and liquids.
3.2 Proper use
Impacts and overloading exceeding the stated maximum load
(max) of the device, minus a possibly existing tare load, must be
strictly avoided. This could cause damage to the integrated balance.
Do not use the instrument in explosive atmospheres.
The balance is not explosion-protected. The instrument must not be
opened, dismantled or modified in any way. This can lead to incor-
rect weighing results, safety defects and destruction of the balance.
The instrument may only be operated in accordance with
the specifications described in this manual.
3.3 Improper use
The warranty does not apply to:
• Overload of the balance (maximum weight)
• Damage resulting from non-observance of the operating manual
3.1 Publication declaration
This version of the manual replaces all previous versions. This manual may not
be reproduced, edited, duplicated or distributed without the written permission
of Schaller GmbH.
Subject to technical and documentary changes. All rights reserved. The opera-
ting manual has been compiled with due care. Schaller GmbH accepts no lia-
bility for omissions or errors. The determination of valid measurement results,
conclusions and measures derived therefrom are the sole responsibility of the
user. Schaller GmbH accepts no liability for the accuracy of the measured values
or measurement results displayed. Schaller GmbH accepts no liability for any
damage resulting from the use of the measured values.

Page 7
3.4 Monitoring of measuring devices
In order to guarantee the metrological characteristics of the integrated balance
in the framework of quality assurance, we recommend checking the calibra-
tion of the balance at regular intervals.
The interval and the method of this check must be defined by the responsi-
ble user of the balance. Test weights are available from Schaller GmbH. A test
weight of 100 g is included in the scope of delivery.
• Damage resulting from improper use
• Products that have been opened and/or modified
• Mechanical damage and damage caused by measuring material, liquids
etc.
• Damage resulting from improper installation or electrical installation

Page 8
4.3 Hazard warnings
Warning!
• Carefully read this operating manual before setup and com-
missioning.
• The operation of the moisture analyser is restricted to trained
competent specialist staff.
• The moisture analyser may not be used in a hazardous area.
• Never use the moisture analyser in an explosive environment.
• The moisture analyser is used to analyse the moisture content
of materials. This instrument must be used exclusively for this
purpose. Any other usage may cause a risk to personnel, da-
4.2 User qualifications
Persons using this device must have read, understood and fol-
low the instructions provided in the operating manual.
General safety symbol:
Non-observance can cause personal injury and/or damage to the
device.
Warning of hot surface:
Non-observance can cause burns.
Fire or explosion:
Spontaneously flammable substances, highly flammable gaseous
substances, moisture-sensitive substances or flammable liquids.
Poisoning:
Substances which contain toxic or corrosive components, produce
toxic gases during drying, cause irritation (eyes, skin, respiratory
system), nausea or death.
4 Safety information
4.1 Symbols used in this manual
The symbols used have the following meanings:

Page 9
Hot surfaces
• Maintain sufficient space in the environment of the instru-
ment to prevent heat build-up.
• Careful when removing the sample. The sample itself, the
sample dish and the heating unit may be very hot.
• Use the sample retainer at all times as it allows safe working
and prevents burns.
• The case (e. g. the ventilation grids) may heat up considerably
during operation.
Fire or explosion
• Never place combustible materials on, under or next to the
instrument, as the environment of the instrument heats up to
a high temperature.
• Explosive, easily flammable samples and samples that go
into a chemical reaction when subjected to heat, may not be
analysed with the moisture analyser.
• If in doubt, conduct a risk analysis.
• Do not use the moisture analyser in an explosive environment.
• Never leave the analytical scale unattended during the
analysis process.
Poisoning
• Sample materials that contain toxic or corrosive ingredients,
produce toxic gases when drying or cause irritation must only
be dried with a special extraction system in place.
mage to the instrument or other material damage.
• The moisture analyser should be used only for the drying of
aqueous substances.
• Never make any modifications or design changes to the
equipment. Always use original spare parts and accessories.
• Make sure that liquids cannot penetrate the interior of the
device.
• If you spill liquid on the device, disconnect it immediately.
• Ensure correct installation of all components.

Page 10
5 On receipt of your device
5.1 Taking the device out of its packaging
Immediately after unpacking, check the integrity and completeness of the de-
vice and the scope of delivery.
Do not discard the packaging! In case of shipping the device, only use the ori-
ginal packaging.
5.2 Place of installation
Choose an appropriate place of installation, considering the following points:
• Wind and air draft protected
• Approximately constant ambient air temperature
• Ambient air humidity between 40 % and 75 %
• Not in the vicinity of flammable or explosive materials
• Distance to heat-sensitive materials
• Dust-protected
• Stable surface
• Not in the vicinity of radiating electrical devices (electrical radiation)
Danger!
• Do not leave the packaging material careless. It could
become a dangerous toy for children.
• The device is not a toy and should not be handled by children.
• This device can be dangerous if it is used by untrained persons
or used improperly. Observe the personnel qualifications.

Page 11
2
1
3
4
5
Unpack the delivered parts aud assemble them as illustrated.
1.) Start with the heat protection plate (1).
2.) Insert the wind shield (2) in the way the notch in the side wall faces the
user.
3.) Place the handle of the insertion aid (3) in the notch of the wind shield (2).
4.) Place the sample pan retainer (4) in the middle of the measuring cham-
ber. Make sure that the cone of the sample pan retainer rests in the guide
properly.
5.) Then put the sample pan (5) onto the sample pan retainer.
5.3 Assembling the analytic balance

Page 12
5.5 Power supply
Before connecting the device to the mains, make sure that the mains voltage is
230V AC and 50Hz and an earth connection is provided.
Operating the balance at a lower or higher voltage may destroy the device.
5.4 Levelling the analytic balance
In order to obtain accurate and repeatable measuring results, it is important to
align the balance accurately using the level indicator and the two setting wheels.
Turn the foot screws until the air bubble of the water balance is in the prescribed
circle.

Page 13
6 Preparation
6.1 Preparation of sample
Always prepare only one sample for the measurement. This prevents the sample
from exchanging moisture with the ambient air. In case several samples have to
be taken at the same time, put them into airtight containers.
Before the sample is spread on the aluminium pan, the empty aluminium pan
should be placed on the balance and the balance should be tared (display of
0.000 g).
Now spread the sample on the sample pan evenly and in a thin layer to get re-
producible results. Recommended layer thickness: 2 to 5 mm.
An uneven application of the sample causes inhomogeneous heat distribution
in the sample to be dried. This means that the sample is dried incompletely or
that the drying time is increased. Due to piling material, the upper layers will
heat up more strongly, which will cause combustion or incrustation. An exces-
sively high thickness of the layer or possible incrustations prevents the moisture
from leaving the sample. The residual moisture makes the measurement results
non-verifiable and non-reproducible.
6.2 Tools and accessories for sample preparation
The tools and instruments used for sample preparation have a huge effect on
the accuracy and reliability of the measurement. You should avoid tools with
heat-conducting properties, i. e. which are able to transfer heat to the sample.
Improper handling and preparation of the sample will falsify the end result of
the measurement.
Re-using a sample pan can falsify the end result of the measurement because
of the adhering residues. Therefore, always take care to use only well-cleaned
aluminium pans.

Page 14
6.3 Preparation of analytic balance
Switch on the balance at least 30 minutes before starting a measurement. This
ensures that the balance is at operating temperature.
Before each measurement, check that the sample pan is empty and remove any
kind of pollution if present.
7 Operation / Measuring procedure
7.1 Switching the device on
Press the „ON/OFF“ button for switching the device on. After switching on, the
last used settings are called up. These settings are shown on the display.
7.2 Drying modes
Press the „Menu“ key to get to the drying mode selection screen. Here you can
select different drying modes and set up new ones.
On the left-hand side of the display flashes a number which indicates the
memory location. Here you can retrieve up to 16 different memory locations,
using the arrow keys „UP“ and „DOWN“. The saved drying parameters are
displayed along with the selected memory location.
If you wish to use the drying parameters of a certain memory location, press the
„TARE“ key. The analytic balance will then take over the drying parameters and
you can start the measurement.
If you want to save some new drying parameters to a memory location, select
the memory location and confirm by pressing the „ENTER“ key.

Page 15
7.2.1 Specifying the heat-up mode
After the selection of the memory location, the drop icon will flash in the upper
side of the display.
Here you can select one out of three heat-up speeds.
Standard heat-up mode
This is the default mode which is suitable for most sample types.
In this heat-up mode, 120 °C are reached after approx. 4 minutes.
Quick heat-up mode
This mode is suitable for samples with a high moisture content.
In this heat-up mode, 120 °C are reached after approx. 1 minute.
ATTENTION: When using this heat-up mode, there might be in-
creased temperatures in the drying chamber for a short period as
the sensor and the control need some time to regulate the tempe-
rature.
Slow heat-up mode
This mode is suitable for samples with a low moisture content.
In this heat-up mode, 120 °C are reached after approx. 8 minutes.
ATTENTION: When using this heat-up mode, it is particularly
important that the drying time of the sample is adapted to the
drying mode as otherwise the drying process could be terminated
(time expired) although there is still some residual moisture in the
sample.
Select the desired heat-up mode using the arrow keys „UP“ and „DOWN“. To
confirm the selected heat-up mode, press the „ENTER“ key.

Page 16
7.2.2 Specifying measurement / stop mode
After the selection of the heat-up mode, the bar icon will flash in the upper side
of the display. Here you can select between three measurement /stop modes.
Constant measuring value
In this measurement / stop mode, the measurement is stopped
automatically when the measuring value is constant over a certain
period of time.
Manual / user stop mode
In this measurement / stop mode, the measurement can be ended
by the user. To do so, press the „START / STOP“ key.
ATTENTION: Depending on the temperature, combustion of the
sample can easily occur in this measurement / stop mode. This
mode should only be used if constant monitoring can be guaran-
teed. The advantage of this mode is that the sample can be dried
for a long time to allow moisture to escape which is located very
deep in the sample.
Time stop mode
In this measurement / stop mode, the measurement is stopped
automatically when the set measuring / drying time has passed.
ATTENTION: The maximum measuring / drying time you can set is
99 minutes.
The desired measurement / stop mode can be selected by means of the arrow
keys „UP“ and „DOWN“. To confirm the selected measurement / stop mode,
press the „ENTER“ key.

Page 17
7.2.3 Setting the drying temperature
After selecting the measurement / stop mode, the temperature indication will
flash in the upper side of the display.
Here you can set the drying temperature using the arrow keys „UP“ and „DOWN“.
The first setting can be made in steps of 10 %. After confirming with the
„ENTER“ key, the setting can be carried on in increments of 1 °C.
ATTENTION: During temperature regulation, temperature fluctuations of
approx. 4 °C can occur. Mind this when selecting the temperature to make sure
the sample does not scorch. Otherwise, the moisture reading will be falsified.
7.2.4 Setting the drying / measuring time (only in the time stop mode)
Depending on the previously set measurement / stop mode, the time indication
flashes in the upper side of the display.
The drying / measuring time can be set using the arrow keys „UP“ and „DOWN“.
To confirm the set drying / measuring time, press the „ENTER“ key.
ATTENTION: The maximum measuring / drying time you can set is 99 minutes.

Page 18
7.3 Measurement
Prepare the sample and place it in the drying chamber. Select the correct drying
program for your sample as described. Start the measurement by pressing the
„START“ key.
After the measurement, the measured values will be available until they are
deleted. Pressing the „CONVERSION“ key, you can switch between the weight
indication /dry matter indication in % and the indication of the moisture con-
tent in % during and after the measurement. After the measurement, the mea-
suring values last determined must be deleted from the memory. To do so, press
the „RESET“ key.
ATTENTION: Before placing the next sample on the sample pan, make sure that
the display shows 0.0 g respectively 0.00 g. If this is not the case, press the
„TARE“ key.
Hot surface!
• Do not touch the halogen lamps or the cover during or after
the measurement as this can cause severe burns.
• After the measurement, let the sample cool down before
touching it.
7.4 Adjustment / calibration
The moisture analyser consists of a weighing unit and a drying chamber. The
moisture measurement is carried out on the basis of the weight loss of the sam-
ple.
ATTENTION: The moisture analyser internally has a higher weighing resolution
than the one indicated. The moisture analyser uses the higher resolution which
is invisible to the user for calculation. This can result in deviations after the deci-
mal point when trying to reproduce the result.
The weighing unit can be adjusted by means of a 100 g external test weight
(min. M1). Special care must be taken when positioning the scales (as little
vibration as possible and balanced by means of the level). The adjustment of
the weighing unit should only be carried out after a heat-up time of at least
30 minutes.

Page 19
To do so, press and hold the „RESET“ key for approx. 6 seconds. The display
shows „-CAL-“.
After the “-CAL-” indication, “100.00 g” will flash.
Now place the 100 g calibration weight in the middle of the weighing platform.
The indication will change from “100.00 g” to “=====”.
When the indication changes from “=====” back to “100.00 g”, remove the
weight from the weighing platform. After this, the display will show “=====”
again and change to “0.00 g” automatically.
The adjustment of the balance is now finished.

Page 20
8 Warranty
The warranty period is 6 months for business to business transactions and
2 years for consumer transactions, subject to compliance with the above-men-
tioned handling of the analytical balance, beginning on the day of delivery. This
service refers to all essential defects of the device which are demonstrably due
to material or manufacturing defects.
It is carried out by a replacement delivery of a faultless device or by free repair
of the device, depending on our choice. A claim to an extended warranty period
does not arise from this. During the warranty period, all defects must be notified
in writing immediately after their occurrence. In addition to a description of the
defect, also state the serial number of the device. Any additional costs such as
interruptions of operation, working hours, freight, customs charges are exclu-
ded from this service.
The warranty does not apply to:
Transport damage, improper handling, wilful destruction, any modification of
the device, unauthorized opening of the device.
Error code Error cause Possible solution
Err 1 Sample weight below 1 g
Put more than 1 g of the sample on
the balance and start the
measurement.
Err 2 Temperature setting below +40 °C Restart the balance.
Err 3 Measuring time setting below
30 seconds Restart the balance.
Err 4 Halogen lamp problem Please contact our technical support.
Err 5 Time setting for slow heat-up mode
below 3 minutes Restart the balance.
Err6 Temperature sensor broken Please contact our technical support.
7.5 Troubleshooting
