Operating Manual
Always read this operating manual before using the humimeter PM5!
humimeter PM5
Paper moisture meter
for measuring the absolute moisture content of paper
Moisture meter
Version 1.2

humimeter PM5 Operating Manual
Page 2
Your humimeter PM5 at a glance
The main unit
No. Name
1 Button
2 Handle
3 Display
4 USB port (for charging the battery)
5 Reset button
6 LED battery indicator
2
3
4
1
5
6

Page 3
Rear of the main unit
No. Name
1 Infrared temperature sensor
2 Sensor bars
The display
No. Name
1 Product type
2 Moisture content in % (see 7.2 How moisture
content is defined for definition)
3 Display symbols
4 Temperature display
1
2
4
3
2
1

humimeter PM5 Operating Manual
Page 4
The display symbols
Symbol Name Symbol Name
Enter No
Up Change input level
Down OK
Back Change menu
Enter numbers Enter data
Enter letters View measurements
Continue / go right Delete measurements
Left On/off button, display
light
Yes Save measured value
Auto save Hold function
The buttons
The four buttons are designed for navigating the symbols shown on the display. Each
of the buttons’ functions will be explained in the description of the relevant symbol.
The buttons have different functions in the different menus.
The menus
The device has three different menus: product selection, Data Log and main menu.

Page 5
Product selection menu
No. Name
1 Change menu
2 Display illumination / device on/off
3 For changing the product type
Data log menu
No. Name
1 Change menu
2 Display illumination / device on/off
3 Save measured value
4 Show the last recorded values
Main menu
The main menu comprises the following menu items:
• Edit Logs:
Manual Logs, Auto Logs, Clear Logs
• Print Logs:
Last Log, All Logs, Clear Logs
• Send Logs:
Manual Logs, Auto Logs, Clear Logs
• Options:
Bluetooth, Date/Time, Log Time, Reinitialize, Language, Unlock, °C/°F, BL On
Time, Auto Off Time, Materialcalib., Online Send, Password, Reset
• Status
21 3
21 3 4

humimeter PM5 Operating Manual
Page 6
Table of contents
Your humimeter PM5 at a glance ������������������������������������������������ 2
The main unit ..........................................................................................................2
Rear of the main unit ...............................................................................................3
The display ...............................................................................................................3
The display symbols .................................................................................................4
The buttons .............................................................................................................4
The menus ...............................................................................................................4
1� Introduction ��������������������������������������������������������������������� 9
1.1 Information about this operating manual ................................................ 9
1.2 Limitation of liability ................................................................................ 9
1.3 Symbols used in this manual ................................................................. 10
1.4 Customer service .................................................................................. 10
2� For your safety �������������������������������������������������������������� 11
2.1 Proper use ............................................................................................11
2.2 Improper use ........................................................................................11
2.3 User qualications ................................................................................. 11
2.4 General safety information .................................................................... 12
2.5 Warranty ..............................................................................................12
3� On receipt of your device ��������������������������������������������� 12
3.1 Taking the device out of its packaging ................................................... 12
3.2 Making sure that all of the components have been included ................. 12
4� Using the device - Basics ���������������������������������������������� 13
4.1 Switching the device on ........................................................................13
4.2 Automatic calibration ............................................................................ 13
4.3 Selecting the product type .................................................................... 14
4.4 Taking a measurement .......................................................................... 14
4.5 Switching the device off ........................................................................ 14

Page 7
5� The measuring process ������������������������������������������������� 15
5.1 Taking a measurement .......................................................................... 15
5.1.1 Taking a measurement on a paper or cardboard roll ..............................15
5.1.2 Taking a measurement on a paper or cardboard stack ...........................17
6� Saving your readings ���������������������������������������������������� 18
6.1 Hold function - Freezing the displayed values ........................................ 18
6.1.1 Activating the hold function in the options menu .................................. 18
6.1.2 Using the hold function ........................................................................18
6.2 Saving your readings manually ..............................................................19
6.2.1 Saving individual readings .....................................................................19
6.2.2 Saving several readings (a measurement series) at the same time ..........21
6.3 Auto save function (time-based) ............................................................ 22
6.3.1 Activating the auto save function in the options menu .......................... 22
6.3.2 Auto save function: Saving measured values ......................................... 22
6.4 Viewing individual readings ................................................................... 24
6.5 Viewing individual readings from a series of measurements ...................24
6.6 Deleting all measured values (data log) ................................................. 25
6.7 Deleting individual measurement series ................................................. 25
6.8 Deleting individual values from a single series of measurements ............26
7� Product types ����������������������������������������������������������������� 27
7.1 Selecting the product type .................................................................... 27
7.2 How moisture content is dened .......................................................... 28
8� Using the LogMemorizer program ������������������������������ 29
8.1 Installing/Opening the program ............................................................. 29
8.2 Exporting measured values to a computer ............................................. 29
9� Checking the device’s status ���������������������������������������� 32
10. Conguringthedevice ������������������������������������������������� 32
10.1 Turning on Bluetooth ............................................................................ 32
10.2 Adjusting the date/time .......................................................................32

humimeter PM5 Operating Manual
Page 8
10.3 Selecting a language .............................................................................33
10.4 Activating options .................................................................................34
10.5 Deactivating options ............................................................................. 35
10.6 Selecting °C/°F ......................................................................................35
10.7 Reducing the device’s power consumption ............................................ 36
10.7.1 Conguring the display illumination time .............................................. 36
10.7.2 Conguring automatic switch-off ......................................................... 36
10.8 Conguring the material calibration function ........................................ 36
10.9 Changing the password ........................................................................37
10.10 Resetting the device to its factory settings ............................................. 38
11� Cleaning and maintenance ������������������������������������������� 38
11.1 Charging the integrated battery ............................................................ 38
11.2 Resetting the hardware/device ..............................................................39
11.3 Replacing the sensor bars ...................................................................... 40
11.4 Checking the calibration ....................................................................... 40
11.5 Calibrating the moisture meter ............................................................. 41
11.5.1 Automatic calibration ..........................................................................41
11.5.2 Starting the calibration manually .......................................................... 41
11.6 Care instructions ...................................................................................42
11.7 Cleaning the device .............................................................................. 42
12� Faults ������������������������������������������������������������������������������ 43
13� Storage and disposal ���������������������������������������������������� 45
13.1 Storing the device .................................................................................45
13.2 Disposing of the device .........................................................................45
14� Device information ������������������������������������������������������� 46
14.1 EC declaration of conformity ................................................................. 46
14.2 Technical data ....................................................................................... 47

Page 9
1. Introduction
1.1 Information about this operating manual
This operating manual is designed to enable you to use the humimeter PM5 safely and
effectively. It is part of the device, has to be stored nearby and must be easily accessi-
ble to users at all times.
All users are required to carefully read and make sure that they have understood this
operating manual before using the humimeter PM5. All of the safety and operating
instructions detailed in this manual have to be observed to ensure the safety of the
device.
1.2 Limitation of liability
All of the information and instructions provided in this operating manual have been
compiled on the basis of the current standards and regulations, the state of the art,
and the extensive expertise and experience of Schaller GmbH.
Schaller GmbH does not accept any liability for damage associated with the following,
which also voids the warranty:
• Non-observance of this operating manual
• Improper use
• Inadequately qualified users
• Unauthorised modifications
• Technical changes
• Use of unapproved spare parts
This fast measuring procedure can be affected by a range of different factors. For this
reason, we recommend periodically checking the device’s measurements with a stan-
dardised oven-drying method.
We, as the manufacturer, do not accept any liability for any incorrect measurements
and associated consequential damage.

humimeter PM5 Operating Manual
Page 10
1.3 Symbols used in this manual
All of the safety information provided in this manual is shown with a corresponding
symbol.
ATTENTION
It is essential to observe this warning. Non-compliance can lead to damage to
property or equipment.
iInformation
This symbol indicates important information that enables users to use the de-
vice more efficiently and cost effectively.
CAUTION
It is essential to observe this warning. Non-compliance can lead to injury.
1.4 Customer service
For technical advice, please contact our customer service department at
Schaller GmbH
Max-Schaller-Straße 99
A - 8181 St.Ruprecht an der Raab
Telephone: [phone]
Fax: [phone] - 901
E-mail: [e-mail]
Internet: www.humimeter.com
© Schaller GmbH 2018

Page 11
2. For your safety
The device complies with the following European directives:
• Restriction of Hazardous Substances in Electrical and Electronic Equipment
(RoHS)
• Electromagnetic compatibility (EMC)
The device corresponds to state-of-the-art technology. However, it is still associated
with a number of residual hazards.
These hazards can be avoided through strict observance of our safety information.
2.1 Proper use
• Easy to use device for quickly measuring the moisture content of stacks and rolls
of cardboard. The device can be used to perform measurements on rotating
rolls.
• Easy to use device for quickly measuring the moisture content of stacks and rolls
of paper. The device can be used to perform measurements on rotating rolls.
• The device must only be used for taking measurements on the products defined
in the following sections of this manual (see 7. Product types).
2.2 Improper use
• The device must not be used in ATEX.
• The device is not suitable for measuring the moisture content of corrugated
board.
• The device is not suitable for measuring the moisture content of individual
sheets.
• The device is not waterproof and must be protected from water and fine dust.
• The device is not suitable for measuring the moisture content on statically
charged rotating paper rolls.
2.3 User qualifications
The device must only be operated by people who can be expected to reliably take the
measurements. The device must not be operated by people whose reaction times may
be slowed due to, e.g. the use of drugs, alcohol or medication.
All persons using this device must have read, understood and follow the instructions
provided in the operating manual.

humimeter PM5 Operating Manual
Page 12
2.4 General safety information
The following safety information has to be observed at all times to avoid damage to
objects and injury to people:
• Please contact your dealer if any parts of the device have become loose or dam-
aged.
All of the device’s technical features have been inspected and tested before delivery.
Every device has a serial number. Do not remove the tag with the serial number.
2.5 Warranty
The warranty does not apply to:
• Damage resulting from non-observance of the operating manual
• Damage resulting from third-party interventions
• Products that have been used improperly or modified without authorisation
• Products with missing or damaged warranty seals
• Damage resulting from force majeure, natural disasters, etc.
• Damage from improper cleaning
• Batteries older than six months
3. On receipt of your device
3.1 Taking the device out of its packaging
• Take the device out of its packaging.
• Next, make sure that it is not damaged and that no parts are missing.
3.2 Making sure that all of the components have been included
Make sure that all of the components have been included by checking the package
contents against the following list:
• humimeter PM5
• USB mini B cable
• USB stick with software
• Plastic case with test plate

Page 13
• Operating manual
Optional accessories:
• Battery operated portable thermal printer (described in a separate operating
manual)
• Bluetooth module (described in a separate operating manual)
4. Using the device - Basics
4.1 Switching the device on
• Press the button for 3 seconds.
»The display will then show the status indicator (see 9. Checking the device’s
status) for about 3 seconds.
4.2 Automatic calibration
»The display will then show the message Adjust?
(figure 1).
1. Lift the device up into the air with both hands,
holding onto both handles. When doing so, there
must be a minimum of 0.5 metres of empty space
behind the sensor bars (figure 2).
2. Confirm by pressing .
»The display will now appear as shown in figure 3.
»The bar will run upwards. The device must be held
up in the air throughout this entire process,
»which only takes a couple of seconds to complete.
»Once completed, the device will show the measur-
ing window (see "Product selection menu" Page 5).
1
2
3

humimeter PM5 Operating Manual
Page 14
4.3 Selecting the product type
To do so: The device has to be in the product selection menu.
For an overview of the different product types and the criteria for selecting them,
please refer to 7. Product types.
Press the or button to move from one product type to the next Or
1. Press the or button for 2 seconds to open the product type overview.
(figure 4).
2. Use the arrow keys to move from one product type
to the next
3. and keep any of them pressed to scroll through the
types.
4. Confirm your selection by pressing .
»The product type you selected will now be shown at the top of the display.
4.4 Taking a measurement
• For information on how to take a measurement, see section 5. The measuring
process.
4.5 Switching the device off
To do so: The device has to be in the product selection or Data Log menu. It is not
possible to switch off the device when it is in the main menu.
• Press the button for 2 seconds.
4

Page 15
5. The measuring process
5.1 Taking a measurement
5.1.1 Taking a measurement on a paper or cardboard roll
To do so: The roll has to have a radius of at least 100mm.
The correct product type must have been selected.
1. Take hold of the device handles on both sides and
press it against the long side of the roll with a
pressure of approx. 4 kg (figure 5).
2. When doing so, both of the three sensor bars’
ends must be firmly resting on the paper or card-
board (figure 6). Make sure that the sensor bars are
in a straight line.
»Measurements taken at the front of a roll are not
reliable (figure 7).
»Taking a measurement on a rotating roll: Pressing
the device against the roll at an angle can damage
the paper/board.
3. The device will now instantly display the moisture
content and material temperature on the display.
4. For an average moisture content reading or to identify sections on the roll that
are too moist or dry, simply move the device along the entire length of the roll.
»Once the reading has been taken, it can be saved on the device (see 6. Saving
your readings).
5
6
7

humimeter PM5 Operating Manual
Page 16
CAUTION
Risk of burns
Risk of burning fingers on hot material parts. When taking a measurement on a
rotating roll, the sensor bars can become very hot.
►Do not touch the sensor bars after taking a measurement on a rotating roll.
CAUTION
Electrostatic discharge
On fast running machines there is the risk of an electrostatic discharge via the
device.
►Do not measure statically charged paper rolls.
ATTENTION
Damage to the paper or cardboard
Pressing the device against the rotating roll at an angle can damage the paper/
cardboard.
►Press the sensor bars against the material in a straight line.

Page 17
5.1.2 Taking a measurement on a paper or cardboard stack
To do so: The stack has to have a minimum height of 50 mm. The paper must have a
minimum size of 150 mm x 150 mm. The correct product type must have been select-
ed.
1. Take hold of the device handles on both sides and
press it onto the top of the stack with a pressure of
approx. 4 kg (figure 8).
»Measurements taken at the outers sides (front
sides) of a stack are not reliable (figure 9).
2. When doing so, both of the three sensor bars’
ends must be firmly resting on the paper or
cardboard. Make sure that the sensor bars are in a
straight line.
»The device will now instantly display the moisture
content and material temperature on the display.
3. To obtain a reliable average moisture content reading, move the device over the
stack and take readings at different points.
»Once the reading has been taken, it can be saved on the device (see 6. Saving
your readings).
iInformation - Measuring accuracy
This rapid and non-destructive measuring procedure allows you to quickly take
moisture readings at a number of different points. When saving the individual
readings, the device will automatically calculate the readings’ average (see
6.2.2 Saving several readings (a measurement series) at the same time).
iInformation - Incorrect readings
Always make sure to select the correct product type for the material you are
measuring. This prevents taking incorrect readings (see 12. Faults).
8
9

humimeter PM5 Operating Manual
Page 18
6. Saving your readings
6.1 Hold function - Freezing the displayed values
The device can be configured in such a way that the information being shown on the
display will freeze at the touch of a button until a new button is pressed. This function
can be very useful when e.g. taking readings in spaces where it is not possible to see
the display (e.g. overhead).
6.1.1 Activating the hold function in the options menu
To do so: The device has to be switched on and be in the product selection menu.
1. Press twice or hold for 2 seconds.
2. Select Options. To do so, press or and con-
firm by pressing .
3. Select Log Time (figure 10). To do so, press or
and confirm by pressing .
4. Select Hold (figure 11). To do so, press or
and confirm by pressing .
»The setting has been saved.
5. Press to leave the Options menu.
6. Press to leave the main menu.
6.1.2 Using the hold function
To do so: The device has to be switched on and be in the Data Log menu.
• Press .
»The current reading will be frozen. All of the four
symbols will now be displayed as (figure 12).
• To reactivate the frozen display, simply press any
button.
10
11
12

Page 19
6.2 Saving your readings manually
All of the readings can be saved, edited and viewed on the device. The figure below
shows the overview screen of a single saved series of measurements.
No. Name
1 Name of the measurement series (editable)
2 Temperature (average)
3 Date & start time of the measurement series
4 Date & end time of the measurement series
5 Number of saved readings
6 Product type
7 Device name
8 Moisture content (average)
6.2.1 Saving individual readings
The device can be configured in such a way that the device will save a reading every
time a button is pressed. This option (manual save active) is the device’s default setting.
Activating the manual save function in the options menu
To do so: The device has to be switched on and be in the product selection menu.
1. Press twice or hold for 2 seconds.
2. Select Options. To do so, press or and con-
firm by pressing .
3. Select Log Time. To do so, press or and
confirm by pressing .
4. Select Manual (figure 13). To do so, press or
and confirm by pressing .
1
2
7
8
3
4
6
5
13

humimeter PM5 Operating Manual
Page 20
»The setting has been saved.
5. Press to leave the Options menu.
6. Press to leave the main menu.
Using the manual save option
To do so: The device has to be in the data Log menu (see "Data log menu" Page 5).
1. Press .
»The display will now appear as shown in figure 14
and the disc symbol will be preceded by the digit
one.
2. Press to enter a name for the saved reading
and to finish the measuring process.
»The display will now appear as shown in figure 15.
3. The data you have inputted can be overwritten at
any time (only if data has already been entered).
4. Inputting letters:
Press and hold to quickly scroll to the
required letter and either press it for 3 seconds or
press to confirm the selected letter (figure 16).
5. Inputting numbers:
Press and hold to quickly scroll to the
required number and either press it for 3 seconds
or press to confirm the selected number.
6. Moving forward/back:
Press to switch to another input level. Press or to move forward or
back.
7. Confirm your entry by pressing .
»The data you entered has been saved.
14
15
16
