Scheer RG300 User manual
MP-000096 - A
2
SCHEER CHURRASQUEIRAS E ACESSÓRIOS
Congratulations!
You just bought a barbecue grill with the highest technology, design and performance. Now it will
be much easier and quick to prepare your Churrasco. SCHEER CHURRASQUEIRAS thanks for your
choice.
For your barbecue to perform best, read this manual carefully and follow the instructions correctly. For
any information, or suggestions please contact us that as well - qualified professional will be happy to
assist you.
SCHEER CHURRASQUEIRAS E ACESS Ó RIOS LTDA
Phone : + 55 54 3224 3066 or USA +1 954 688 3031
Street: Roque Callege , 133 .
95041-440 - Caxias do Sul - RS - Braszil
scheer.com.br
MP-000096 - A
3
CONTENT
SCHEER CHURRASQUEIRAS E ACESSÓRIOS............................................................................2
IMPORTANT INFORMATION .............................................................................................................4
MAINTENCE AND OPERATOR INTRODUCTION...........................................................................4
SECURITY NORMS...............................................................................................................................5
TRANSPORT..........................................................................................................................................5
TAKING THE BARBECUE OUT OF THE PACKAGE CRATE.........................................................6
DESCRIPTION OF THE BARBECUE ..................................................................................................6
FEATURES .............................................................................................................................................7
RG 300 DETAILS ...................................................................................................................................8
INSTALLATION ....................................................................................................................................9
GAS INSTALLATION ...........................................................................................................................9
LUBRICATION ....................................................................................................................................11
FUNCTIONABILITY ...........................................................................................................................11
PUTTING THE SKEWER ON THE BARBECUE POSITION...........................................................11
GRILLING SKEWER MEAT...............................................................................................................12
PLACING THE FLAT GRILL..............................................................................................................12
CLEANING...........................................................................................................................................13
USEFUL INFORMATION ...................................................................................................................14
AFTER SALES INFORMATION.........................................................................................................17
ELECTRICAL SCHEME......................................................................................................................17
WARRANTY TERMS..........................................................................................................................18
LIMITED WARRANTY.......................................................................................................................19
MP-000096 - A
4
SCHEER CHURRASQUEIRAS E ACESSÓRIOS
IMPORTANT INFORMATION
- Keep this manual for future information in an easily accessible location.
- Installation of the product is the responsibility of the buyer. The installation must be carried out in
accordance with the manufacturer's instructions and carried out by qualified and competent persons.
- In case of repairs, only use assistance authorized by the manufacturer and ask for original or quality
spare parts.
- Failure to operate this equipment could endanger the product and the operator of the equipment.
- For technical assistance that is closest to you, contact a reputable dealer or directly with the
manufacturer.
- The manufacturer reserves the right to change this manual at any time.
- This equipment must be installed in accordance with the local regulations and codes of the destination.
- Keep this product out of the reach of children especially after use when the grill is cooling.
MAINTENCE AND OPERATOR INTRODUCTION
- This manual contains technical information for the correct installation and operation of this equipment.
The operator of the equipment has the duty and responsibility to follow the correct instructions.
- Before using this equipment, it is necessary to consult this manual. We recommend strict reading and
strictly following the instructions. Keep the manual in perfect condition.
- This manual is part of the equipment and should be stored in a location that is easily accessible and
known to all operators and is also available to anyone responsible for maintenance.
MP-000096 - A
5
SECURITY NORMS
- Read and understand all instructions contained in this Manual before operating your RG Barbecue
Grill;
- The RG Barbecue is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or by persons lacking experience and knowledge, unless instructed to
use the appliance or are under supervision of a person responsible for their safety;
- Always use the equipment with care and attention.
-Do not install and use in discovered locations.
-Use a hose certified by Inmetro with recording NBR 8613, in transparent PVC with yellow stripe and
expiration date.
-The pressure regulator must also comply with the NBR 8473 standard and be certified by Inmetro (not
included with the product).
- When using LPG gas the cylinder is also built according to the ABNT 8460 standard, and for this
equipment the minimum mass is 13 kg.
The power cord should be examined regularly for possible damage.
If it is damaged, it must be replaced by the manufacturer, authorized agent.
TRANSPORT
-Receiving the package crate
- Check for any signs of knocks, drops or malfunctions check with the persons responsible for the
transport and contact the Scheer sales department.
- The risks of transportation are the customer's responsibility. Any claim for damages during
transportation must be made at the time you receive the product, it must be communicated to the carrier
and also to the manufacturer of the product.
- As soon as you remove the product from the packaging, make a visual inspection to check for possible
damage during transportation.
- We recommend special care during this inspection to identify possible damage during transport.
MP-000096 - A
6
TAKING THE BARBECUE OUT OF THE PACKAGE CRATE
1ST Remove the top wood
2nd Remove the sides
DESCRIPTION OF THE BARBECUE
Parts & Accessories
1 residential gas barbecue
Skewers (quantity corresponding to the number of skewers corresponding to barbecue)
1 manual
NOTE: The skewers and accessories normally are shipped separately from the Barbecue.
Capacity (it depends on the grill master skills and restaurant concept):
5 skewers: Serves from 8 to 12 people
7 skewers: Serves from 12 to 16 people
MP-000096 - A
7
FEATURES
Stainless steel AISI304 brushed or AISI430 brushed (as requested) and carbon steel.
AC input with automatic switching 100-240V ~ 50 / 60Hz
Degree of Protection: IPX 3
Class Construction: Class 1
Rotating system 24DC motor (electrical supply 12 DC)
03 Infrared gas burners for 5 skewers
04 Infrared gas burners for 7 skewers
Skewers with stainless steel blades.
Types of Gas Used:
LPG or Natural Gas (as requested)
Gas Consumption:
Gas: Each burner consumes 190 grams of gas per hour.
Rated Power per Burner:
8,900 BTU
Energy consumption:
Electricity: 0,03 kWh
MP-000096 - A
8
RG 300 DETAILS
Measure A
5 Skewers 56cm
7 skewers 66cm
1. 1 Water tray
2. –
3. On off switcher
4. Gas valves
5. Infrared burner
6. Gas injector
7. Removal hood
MP-000096 - A
9
INSTALLATION
- The installation should be done in such a way that the top of the barbecue is ventilated in an airy
environment. Never block the top with furniture or any other material as the equipment will not operate
properly and there is a risk of fire.
The appliance should be installed away from other appliances.
CAUTION: - Do not use in open locations. Do not install and use exposed to weather.
- On the RG300 model there is no hydraulic installation, only a water tray.
-For electrical installation and recommended a separate electric circuit with a 5A circuit breaker
exclusive to the barbecue.
Always seek the assistance of a qualified professional.
(Electrician of your confidence) to make any kind of modification / adequacy in the electrical network.
GAS INSTALLATION
- The installation must be made taking into account the number of burners of the Barbecue. Each 2,250
kcal infrared burner is powered by an injector nozzle with a hole for LPG gas or for Natural Gas, thus
consuming each burner 190 grams of gas per hour.
Each burner corresponds: 8,900 BTUS.
RG 300
MP-000096 - A
10
- Gas tube P-13
Provides a maximum of 500 g of LPG gas per hour;
For installation, a gas and hose valve certified by INMETRO must be used;
Make sure that the gas supply hose is protected from heat and agents that could damage it.
- P-45 gas tube
The P-45 is used in Buildings (piped gas), it provides a maximum of 1 kg of gas per hour. The regulator
to be used is the Yellow Alliance, Model 76510, Low Pressure, Single Stage Regulator.
- Natural gas
Consult the technical specifications of the barbecue and call a gas technician (preferably the same as
the contracted gas company).
Obs1: The regulator should be close to the grill for better performance (maximum 3 meters away).
If the same food pipe other equipment such as stoves, ovens, etc.
Remember that the regulator indicated above must be EXCLUSIVELY intended for the barbecue.
Gas installation
Obs2: NATURAL gas installation.
Compatible with RG Line Barbecue.
For NATURAL gas installation, consult your local distributor, always remembering that the grill works
at low pressure.
The guns and the pipe of the barbecue will already be adapted to these types of fuel, when requested by
the client.
MP-000096 - A
11
LUBRICATION
The Scheer Barbecues are free of lubrication.
FUNCTIONABILITY
- Put 10 to 13 liters of water inside the barbecue. On the RG300 models place water with
a hose or container.
- Turn the gas valve to release the gas and press the ignition button to turn on the infrared
burner. Make sure that the burner has turned on and is red, otherwise turn off the gas
valve to lock the gas flow. And get in touch with Scheer.
PUTTING THE SKEWER ON THE BARBECUE POSITION
Place the tip of the skewer into the groove of the spinner, after fitting the sheave on the support hook or
support bracket.
MP-000096 - A
12
GRILLING SKEWER MEAT
- Cut the meat into pieces or so that it is compatible with the skewer. For traditional
grilling we recommend using only coarse salt to season the meat, but you can also
marinate your favorite meat in several types of seasonings and sauces. Spray the meat on
the skewers and place on the grill when it is turned on. The barbecue will provide the
best result for your barbecue. For tips and recipes go to scheer.com.br.
PLACING THE FLAT GRILL
NOTE: This barbecue has 3 butterflies that can be removed with your hands to remove
the top hooks from the barbecue. These hooks are removed when you choose to make
grills.
1. Remove the thumbscrews with your hands;
2. Use the side friezes to support the grill;
3. Insert the grill into the grill and enjoy a delicious grilled.
If you do not have a grid, contact Scheer right now and buy yours!
scheer.com or +55 54 3224 3066.
"X" Butterflies located at the point marked with a star, but on the inside
MP-000096 - A
13
FLAT GRILL
CLEANING
1. Before performing cleaning procedures, make sure that the equipment is turned off.
2. Perform cleaning after use, but allow the machine a few hours rest to cool naturally.
3. Do not use sharp objects such as knives, metal spatulas, etc. to clean the barbecue.
4. Use only a damp cloth with degreaser.
5. The machine can not be flushed.
Never service this product without proper protection.
This equipment works with hot surfaces.
Before cleaning and checking the product, unplug the power cord for your safety.
Make sure that the water with fat is discarded in a box of fat.
MP-000096 - A
14
USEFUL INFORMATION
g
accidents;
equipment may cause accidents and loss of manufacturing warranty;
suitable glove.
ren and pets away from the grill when it is in use.
ecue by wearing clothes made with synthetic fabrics, as in case of an accident
they can cause serious burns to the skin;
Lim Clean the grill after use;
the barbecue without water inside the tank.
to contact the manufacturer or your dealer.
e on top of the gas grill because the infrared burners can not be
muffled.
- Burner is not working or running weak:
Replace the burner with another burner to make sure the problem is in the burner and not in the
nozzle.
MP-000096 - A
15
If the problem persists, remove the burner and clean the nozzle (the injector is the gas flow limiter),
such as a needle
MP-000096 - A
16
b - When the burner has a completely blue color:
Make sure that the burner does not swallow fire, the flame will appear inside the burner next to the
injector making a strange noise, close the gas that feeds this burner battery, wait for the fire to burn
out and light it again, if the problem persists call the Scheer assistance.
c - When you light the fire, over time due to strong calorie, power to crack or break the stone, what
to do in this case?
Replace with a new burner.
d - When the burner screen is belly-shaped or damaged:
Change the screen, this will give a much longer life for your burner.
MP-000096 - A
17
Caution: The malfunction of the gas system may influence the taste of the meat.
The meat may become dry and dark in appearance, affecting the taste of the meat.
AFTER SALES INFORMATION
-How to get technical assistance
First option is to contact the sales person.
Second option contact the manufacturer.
ELECTRICAL SCHEME
1K5
.1uF-X2
33uF-400
18K
22K-100V
10KB
KA1M0565RTU
,47uF PC817A
11V
1000uF
.01uF .01uF
390R
82K
1N4007
1N4937
12R
100uF
1N4937 MUR460
MOTOR
IRFZ44N
82K
TRAFO 12V
EE30-14
220R
LIGA-DESLIGA
LM555HC
MP-000096 - A
18
WARRANTY TERMS
The RG300 models have 24 months against any manufacturing defects from the date of purchase
invoice, which becomes part of this warranty certificate.
Before buying this product, make sure it is in perfect condition, free of visible defects and with all
accessories available and working.
For any request for technical assistance in the period described above from the date of purchase, it is
mandatory to forward the product to the same store where it was purchased. The shop will receive and
forward the product to Scheer grills, informing in writing, along with this certificate of guarantee, the
consumer complaint with the greatest amount of detail possible, facilitating the recognition of the
possible defect. If the product has a manufacturing defect the round trip shipping of the product will be
paid by the manufacturer. If the product has no manufacturing defect, the freight will be returned by the
dealer, who will analyze and decide with the consumer who will be responsible for the expense.
It is necessary to forward the copy of this certificate of guarantee, fully completed, stamped and signed
by the dealer, proving the date of purchase along with the product.
Scheer grills will analyze the product and it will be repaired or replaced at the discretion of the company
within 30 days from the arrival of the product to our factory and return it to the dealer.
In the event that the product does not present a manufacturing defect, it will be returned to the dealer in
the same state. Scheer grills will not perform service or maintenance of products with debit for
consumers or dealers, but only services linked to warranty for manufacturing defects, entirely free.
Replacement parts will usually be provided to resellers.
Save this certificate. It should be forwarded to Scheer Grills along with the product in case you need to
make use of this warranty. Do not send this original, provide a copy and keep this one in your possession.
MP-000096 - A
19
Ask your reseller to fill out the information below at the time of purchase.
Scheer Reference: ............................................... .................................................
N. Series: .............................................. .................................................. (I.e.
Consumer: ................................................ .................................................. (I.e.
Address: ................................................ .................................................. ............
Zip Code: .............................. City and State: .............. .............................................
Dealer (business name): ............................................ ........................................
Address: ................................................ .................................................. (I.e.
Zip Code: .............................. City and State: .............. .............................................
No. of Invoice: ............................................ Date .......... / ............ / ..................
Stamp and Reseller's Signature
.................................................. ....................
It is important to observe this requirement: Failure to prove the warranty period, through the properly completed
certificate, will mean the return of the product to the dealer, without repair because it is impossible to verify the
date of purchase.
The dealer's insistence on shipment of the product without the warranty certificate will give Scheer grills the right
to return it to the merchant with freight to pay, without repair.
Scheer grills does not authorize the exchange of products in the store for a new unit without, without the process
provided in this guarantee is followed.
LIMITED WARRANTY
During the warranty period the Scheer Grills guarantees their products against manufacturing defects for the first
purchaser. This warranty is non-transferable and requires reasonable proof of purchase. We strongly recommend
that you retain the purchase invoice or invoice. These warranty obligations are limited to the following:
Warranty does not cover products that have been altered or damaged due to normal wear and tear, rust, improper
use, disassembly of parts, internal or external caused by heat. Scheer grills does not authorize any concerted
attempt by the user without the prior written permission of the manufacturer.
For assistance with Scheer products please contact the store where the purchase was made or directly with our
company through the site scheer.com.br. Scheer grills will not be responsible for shipping costs to the store or to
the factory without prior authorization. Scheer grills is not responsible for accidents caused by improper use of
equipment, abuse, neglect, neglect or other ways unfit for basic care. Please pay special attentionto the instruction
manual to avoid damage to products or accidents.
Table of contents
Other Scheer Grill manuals
