Scheer MH Series Manual

installation and maintenance manual
revised 05/2021 - R3
MH 20 Micro L
MH 10/17
MH 15/23
MH 30/40
MH 10 Micro
heating systems of the extra class
MH-Serie
water-heaters

www.scheer-heizsysteme.de
Dear customer,
thank you for choosing to install our MH-series into your vehicle.
With your purchase of the MH-series, you ensured for yourself, to have a heating system with currently the
highest technological standard and lowest fuel consumption.
The innovative and award-winning technology of our products with the Blue Eciency® burner, will
provide you with an especially user and maintenance friendly operation. This system will give you comfort
and highly reduced emissions.
The successfully proven blue-burner-system in“Duo-Block“ building technique, as well as the simple
operation over the boiler control eld, are very ecient and environmentally friendly.
Please contact us for any questions or further information you need.
Your SCHEER-team
SCHEER
Heizsysteme & Produktionstechnik GmbH
Chausseestr. 16
D-25797 Wöhrden
Germany
Tel.: [phone]
Fax: + 49 (0) 4839 453
[e-mail]
www.scheer-heizsysteme.de
Note:
Always carefully follow SCHEER installation and repair instruction and heed all WARNINGS.
SCHEER rejects any liability for defects and damage, which are due to installation or repair by
unauthorized and untrained persons.
introduction
2

www.scheer-heizsysteme.de
table of contents
statutory regulations governing installation
warning and safety signs (denition)
installation
rst start-up
type / model
identication plate
technical data
overview MH-series
control box A
heating controller
pipe group (examples)
plate heat exchanger for hot freshwater (optional)
expansion tank (optional)
hybrid-heating with electric power (optional)
functionality electric heating
dimensions MH-series
overview MH micro
burner assembly MH micro
hybrid-heating with electric power
dimensions MH micro
control box MH micro
control box warning lights
fuel supply / fuel lter
combustion air supply
exhaust pipe
burner components
pipe group components
maintenance
• maintenance preparation
• maintenance intervals
• CO2–value and pump pressure adjustment
• boiler cleaning
• oil lter change
• mixing cartridge control
• oil nozzle replacement
electrical connections
electrical schematics of controller
electrical schematics of control box A 2-stage
electrical schematics of control box M
room thermostat (optional)
service-kits
service-protocols
4
5
5
6
7
7
7
8
8
9
10
10
10
11
11
12
13
14
14
14
15
15
16
17
17
18
21
23
23
23
24
25
25
26
27
28
28
29
29
30
40
41
......................................................................
................................................................................
...................................................................................................................
..................................................................................................................
.................................................................................................................
..........................................................................................................
................................................................................................................
...................................................................................................
...............................................................................................................
........................................................................................................
..................................................................................................
............................................................
............................................................................................
....................................................................
...........................................................................................
.................................................................................................
......................................................................................................
..............................................................................................
.................................................................................
.....................................................................................................
...................................................................................................
...............................................................................................
.................................................................................................
.................................................................................................
................................................................................................................
...................................................................................................
.............................................................................................
.............................................................................................................
........................................................................................
..............................................................................................
..................................................................
.........................................................................................................
........................................................................................................
..........................................................................................
............................................................................................
................................................................................................
...................................................................................
..................................................................
..............................................................................
.........................................................................................
.................................................................................................................
........................................................................................................
3

www.scheer-heizsysteme.de
WARNING!
To prevent misuse and the associated hazards, render your old device unusable before disposing of it. To do
this, disconnect the device from the mains supply and remove the mains connection cable from the device.
For the disposal of the device, observe the regulations applicable in your country and in your municipality.
1.1. legal regulations governing installation.
The heaters of the MH-series are type-tested and approved in accordance with the ECE Directives ECE R122
with the EG permit number: 000517 (ECE R122).
Installation is governed above all by the provisions in Annex VII of the ECE Directives.
Note:
The provisions of these Directives are binding within the territory governed by ECE Directives and
should similarly be observed in countries without specic regulations.
Extract from ECE Directives R122 Annex VII.
4. The heater must have a manufacturer’s label showing the manufacturer’s name, the model number and
type together with its rated output in kilowatts. The fuel type must also be stated and, where relevant, the
operating voltage and gas pressure.
7.1. A clearly visible indicator light within the operator’s eld of view shall inform when the combustion heater
is switched on or o.
Extract from ECE Directives R122 - Part I:
5.3. Regulations for installing combustion heaters and electrical heaters in vehicles.
5.3.1. Scope
5.3.1.1. According to section 5.3.1.2. heaters must be installed by the requirements of section 5.3..
5.3.2. Location of the heater
5.3.2.1. Parts of the vehicles body and other components in the immediate vicinity of the heater must be
protected against excessive heat and the danger of contamination by fuel and oil.
5.3.2.2. The internal combustion heater must not pose a re hazard even when overheated. This requirement
is deemed to have been met if care is taken during installation to ensure an adequate distance from all parts, as
well as adequate ventilation and if re-resistant materials or heat shields are used.
5.3.2.3. In class M2 and M3 vehicles must not be installed in the passenger cabin. A device in a sealed cover,
which also meets the requirements set out in section 5.3.2.2, may be used, however.
5.3.2.4. The plate or a duplicate of the plate mentioned in Annex 7 section 4 must be still tted in such way that
it is still clearly legible when the heater has been installed in the vehicle.
5.3.2.5. When positioning the heater, all reasonable precautions must be taken to minimize the risk of personal
injury or damage to items in the vehicle.
legal regulations governing installation
Disposal of old divices
The discarded device must be disposed of at the end of its service life in accordance with national regulations.
It is recommended to contact a company specialized in disposal or to contact the disposal department of your
municipality.
4

www.scheer-heizsysteme.de
Warning and safety instructions (explanation)
Switching on the heating system without heating water can destroy the heating system!
WARNING!
Note:
The feed temperature of the heated heating water can be freely selected before commissioning.
To avoid frost damage, the heating system must be lled with an anti-freeze liquid.
The heating system must be drained of service water as necessary.
CAUTION!
classication of the signal word according to ANSI Z535.4
signal word identication of hazard
NOTICE
Notice: [this header is] preferred to address practices
not related to personal injury. Used for property
damage.
CAUTION! Caution: Indicate[s] a hazardous situation which, if not
avoided, could result in minor or moderate injury.
WARNING! Warning: Indicate[s] a hazardous situation which, if not
avoided, could result in death or serious injury.
DANGER! Danger: Indicate[s] a hazardous situation which, if not
avoided, will result in death or serious injury.
The following table explains the used colors, words and their meaning used in this manual.
CAUTION! It is essential to note with the micro variants:
1. The max. ow rate of heated domestic water must be set with the key supplied before commissi-
oning. After that the opening must be closed with the cover that is also supplied. (See photo of the
MH-Micro set-up on p. 10)
2. When heating the machine (option), the user must controll that the heating system does not
reach temperatures higher than 75 ° C
3. For the purpose of equipotential bonding, a connection must be established between the hea-
ting system and the vehicle body. The connection must be made using a cable connection to the
screw marked on the heating system and a cable of at least 2.5mm².
installation
WARNING! Electric current hazard!
The device may only be operated on properly installed single sockets with protective contact.
Do not pull the power cord out of the socket by pulling the cable.
Always grasp the housing of the power plug.
The burner elements and connections have 230 V voltage.
•
Repeated emtying of fueltank can cause damage to the burner!
If the heater is operated without fuel it can cause damage (e. g. on the oil nozzle).
NOTICE
5

www.scheer-heizsysteme.de
installation
rst start-up
•
Not following the required installation conditions will lead to the loss of all warranty and liability
claims!
• Installation must comply with governing statutory regulations listed on page 4.
• If the water heater is to be operated in a separately installed heating system, prior to installation an
installation planning report must always be submitted to SCHEER for approval. If this approval is not
obtained, all warranty and liability claims will be void.
NOTICE Cancelation of all warranty and liability claims!
Improper installation or improper repair can cause a re or the leakage of deadly carbon monoxide
leading to serious injury or death.
• The person to install and repair the heating system must have completed a SCHEER training course.
• Always follow all installation and repair instruction.
• Heed all warning and safety signs.
• All required technical documentations, tools, and equipment must be available in the vehicle for
installation and repair.
DANGER! Death or serious injury due to improper installation or repair.
SCHEER rejects any liability for defects and damage, which are due to installation or repair by unau
thorized and untrained persons.
Refer to the safety instructions in the operating and maintenance manual!
Read and understand all operating and maintenance instructions before starting the heater.
After installing the heater bleed the water system and the fuel supply system carefully. Follow the instructions
supplied by the vehicle manufacturer for this purpose.
Check the electrical connections for the correct polarity.
Conduct a test run of the heater to check all the water and fuel connections for leaks and ensure that they are
tight and secure. In case of an error during the test run or normal operation refer to the trouble-shooting table
and x it.
Tighten all pipe union connections after the rst full heat up operation. Please send a copy of the start-up pro-
tocol to SCHEER.
NOTICE
•
Installation position:
The heater must be installed in as low a position as possible to allow the heater and circulating pump to be
bled automatically. This is particularly important as the circulating pump is not self-priming.
The heater may also be installed in a box. The installation box must have sucient external ventilation to
ensure that a maximum temperature of 85 °C (185 °F) is not exceeded inside the box.
Keep in mind the space required for servicing accessibility (for instance for removing the combustion cham-
ber).
NOTICE Check the installation situation of the relevant vehicle type.
6

www.scheer-heizsysteme.de
The model and identication plate must be protected from damage and must be clearly visible when the hea-
ter is installed (otherwise a dublicate model and identication plate must be used)
technical data
identication plate
Abb.: Typenschildbeispiel
MH 10 Micro MH 20 Micro L MH 10/17 MH 15/23 MH 30/40
operating power kW 10 20 10/17 15/23 30/40
dimenensions (w / h / d) ** cm 35*** / 36 / 61 35*** / 36 / 74 38 / 44 / 59 41 / 38 / 64 49 / 44 / 70
weight kg 51 55 55 60 95
eciency % 94 94 93 93 94
fresh water heating integrated water heating optional (combi) plate heat exchanger
boiler volume l 17 17 18 23 37
fuel diesel / heating oil and GTL/BTL (CEN prEN 15940)
oil nozzle 0.18 / 80°SCD 0.25 / 80°SCD 0.30 / 60°SCD 0.35 / 60° SCD 0.65/ 60° SCD
rated voltage V 230 230 230 230 230
rated power consumption * W/h 31 31 34 36 36
exhaust temperature °C
°F
170 - 210
338 - 410
170 - 220
338 - 428
150 - 210
302 - 410
145 - 205
293 - 401
145 - 205
293 - 401
diesel consuption l/h 0,12* 0,17* 0,15* 0,23* 0,43*
* assumption: 10 min. burner operation within one heating hour including boiler circulating pump. Without pumps for other heating circuits.
** dimensions without control box / pipe group / expansion tank
*** The control box is removable and can be installed in a position of up to approx. 1 meter away from the heating system
Made in Germany
HEIZGERÄT Typ: MH 10/17
Spannung / EL Leistung 230V / 250W
Wärmestrom max. 17 kW
Brennsto Diesel / Heizöl
zul. Betreibsüberdruck 3 bar
Artikel. Nr. Ausf. Fabr. Nr.
Inbetriebnahmejahr 2021
E1 122R-000517
E1 ECE-R10-058096
identidation plate example
E1E1
The MH water heaters are approved for the fuels„diesel“ and„heating oil“ as well as GTL/BTL. Other fuels must
be approved by the manufacturer SCHEER before use. The heaters are designed for 230 volts.
The connection in the vehicle is to be fed by the vehicle‘s battery via an inverter approved for road trac within
the scope of the ECE regulations.
Alternatively, the heater can also have a 230 V direct feed (e.g. direct feed from the campsite).
7

www.scheer-heizsysteme.de
overview MH-series
control box A for MH-Series
expansion tank (optional)
fresh air connection for
room air independence
(optional)
control box
Emptying / Filling
Item No.
control box A 0754481
STL release
button
STL indicator
Burner demand
hot water (optional)
Radiators (optional)
Underoor heating (optional) Tank-Control
(if the tank is empty - lights up
red) (optional)
electric heating (optional)
oilpump
Control unit
blower Blower keypad
Flame detector
Air pressure switch
Ignition transformer
Mixing device
Resetbutton for the
burner
8

www.scheer-heizsysteme.de
NOTICE
warning lamp: burner
If the lamp lights, it was triggered by a malfunction of the burner.
• Press and hold the burner suppressor button briey for about 1 second, not longer than 3 seconds.
• The warning lamp of the burner will turn o and the burner is reset.
If the burner should switch to malfunction twice, please have a repair carried out by your specialist com-
pany.
ACHTUNG
Heating controller MH-Serie MH micro
Symbol for heat request
Actual value boiler temperature
• Use and keys to set the value in the specied range of values.
• Conrm settings with P
NOTICE
warning lights
warning lamp: safety-temperature-limiter (STL)
If the lamp lights, the (STL) was triggered by a too high operating temperature of the heat-
ing water
• Let the heating system cool down.
• Push the reset (STL) button in. (followed by a click sound)
• The heating system is ready to start again.
In case the (STL) is triggered again, let the system be repaired by a SHEER trained person.
pressureless system
heating: Set point 70°C Hysteresis 10°C
Domestic water: Set point 70°C Hysteresis 5°C
pressure system with expansion vessel
heating: Set point 70°C Hysteresis 5°C
Domestic water: Set point 78°C Hysteresis 5°C
9

www.scheer-heizsysteme.de
pipe group examples (This article does not apply to the micro versions)
The pipe group is congured by SCHEER according to customer requirements.
All materials used for the plate heat exchanger comply with the denition of DIN 1988 to be suitable for
fresh water. The copper and solder used in the production is Alloy 316 quality.
To minimize the possibility of corrosion we recommend to stay within the following quality limits of the hot
fresh water:
pH value: 7 - 9
electr. conduction: 50 - 600 µS/cm
Chloride: < 50 ppm
Iron: < 0,5 ppm
free Chlorine: < 0,5 ppm
Manganese: < 0,05 ppm
Carbon dioxide: < 10 ppm
Sulfate: < 100 ppm
Phosphor: < 2 ppm
Ammonia: < 0,5 ppm
max. particle size: 0,5 mm
plate heat exchanger for hot domestic water (optional)
water drain
plate heat exchanger
expansion tank (optional)
Item No.
MH 10/17, MH 15/23 125203
MH 30/40 061210
NOTICE
Drain the plate water heater completely for long downtimes or at risk of freezing.
10

www.scheer-heizsysteme.de
Hybrid process
1. The 230V power supply for the electric heater must be supplied with power.
2. For each switch, 1kW or 2kW (see label) are activated together, the corresponding switch lights up.
The burner is blocked.
3. The electric heating is controlled via the heat request signal from the thermostat.
The indicator LEDs above the switch indicate whether the electric cartridge is currently heating.
230 V
Hybridsocket
230 V
heating system socket
•
As long as the electric heater is switched on, the burner remains blocked, even if the power supply to the
electric heater is interrupted. If the electric heater is switched on, the boiler thermostat indicates a heat
request, but the LED indicator does not light up, the power supply to the electric heater is interrupted.
NOTICE
fuse16A fuse 6A
MH Micro
MH
hybrid-heating with electric power (optional)
The heating system can be equipped with an electrical heater.
After activating the switch„electrical heater”the burner operation will be paused. All control and protection
settings of the system will remain the same.
Item No.
electric power 2 kW 036385
electric power 3 kW 036386
cover cap 036388
Hybrid electric heating
How electric heating works
11

www.scheer-heizsysteme.de
Abmessungen MH-Serie
703
103
197
630
626
MH30, MH40 und MH30/40
MIT ROHRGRUPPE COMBI UND REGELUNGSBOX
Stand: 20.11.2020
MH 30/40
197
103
538
571 638
MH15/23
MIT ROHRGRUPPE COMBI UND REGELUNGSBOX
Stand: 20.11.2020
MH 15/23
measurements in mm
MH 10/17
511
197
103
571 574
Hybrid
MH10 und MH10/17
MIT ROHRGRUPPE COMBI UND REGELUNGSBOX
Stand: 18.11.2020
dimensions MH-series
12

www.scheer-heizsysteme.de
overview MH Micro
control box
hybrid
air vent
oil lterheating
water
exhaust gas
fresh air supply
Output
domestic
water
mixer for setting the ow temperature of
the heating water (behind the cover
Input
domestic
water
max. ow rate of heated domestic water
must be set before commissioning
CAUTION! It is essential to note with the MH micro variants:
1. The max. ow rate of heated domestic water must be set with the key supplied before commissio-
ning. Then the opening must be closed again.
2. When heating the machine (option), the user must controll that the heating system does not
reach temperatures higher than 75 ° C.
3. For the purpose of equipotential bonding, a connection must be established between the hea-
ting system and the vehicle body. The connection must be made using a cable connection to the
screw marked on the heating system and a cable of at least 2.5mm².
overview MH micro
Item No.
MH 10 micro 10 kW 0774820
MH 20 micro L 20 kW 077480
The hot water is heated by using a ow process within
the boiler body.
The boiler circuit pump is always activated.
Pipe connection machine
heating (optional)
Resetbutton for the burner
13

www.scheer-heizsysteme.de
overview MH Micro
dimensions of MH micro
Burner assembly MH micro
Control unit
0201029
Air pressure switch
015188
Mixing device
Ignition transformer
012100
oilpump
011759 blower
018510
blower keypad
0160290
Oil pump motor
015138
Hybrid electric heating
Hybrid electric heating
The hot water heating system can be operated hybrid with electric
energy.
ca. 13cm
Extension
MH 10 micro front view MH 20 micro L side view
Disassembly
direction for
the burner
During installation, make sure that the burner and its hood can be dismantled. Approx. 30 cm are required for
this.
• NOTICE
MH 20 micro L, length + 13 cm
73,3 cm
14

www.scheer-heizsysteme.de
Polarity: This lamp must light up green
continuously. If not turn the powersupply
plug and connect with the correct pola-
rity. Reverse polarity protection prevents
the DC voltage supply (exchange of
negative and positive pole) or AC volta-
ge supply (exchange of outer conductor
and neutral conductor) of a device wrong
polarity (reverse polarity) and can thereby
minimize possible damage.
NOTICE
NOTICE
warning LED: burner
If the lamp lights, it was triggered by a malfunction of the burner.
• Press and hold the burner suppressor button briey for about 2 second, not longer than 3 seconds.
• The warning lamp of the burner will turn o and the burner is reset.
If the burner should switch to malfunction twice, please have a repair carried out by your specialist com-
pany.
control box M
Item No.
control box M-
single stage 0754486
control box MH micro
electric-
heating
burner on / lock
burner request
electric-
heating
active
on / o Polarity LED
STL LED
heating controller
Symbol for heat request
Actual value boiler temperature
• Use and keys to set the value in the specied range of values.
• Conrm settings with P
controlbox warning lights
NOTICE
warning lamp: safety-temperature-limiter (STL)
If the lamp lights, the (STL) was triggered by a too high operating temperature. of the heating
water.
• Let the heating system cool down.
• Push the reset (STL) button in. (followed by a click sound)
• The heating system is ready to start again.
In case the (STL) is triggered again, let the system be repaired by a SHEER trained person.
15

www.scheer-heizsysteme.de
•
oil lter Item No. 0405200
cartridge Item No. 040104
Failure to observe the installation condition can lead to malfunction or damage of equipment.
• Automatic bleeders always have to be installed above the level of the oil pump.
• At least 50% of the length of the fuel line should be ascendingly mounted.
• Do not interchange the feed and return connection!
Risk of malfunction or damage of equipment!
NOTICE
fuel supply / fuel lter
Note:
To maintain warranty the fuel burner must be equipped with an oil lter for a
one-pipe system with return line, an automatic bleeder, and a micro lter. (see
below)
The supplied silicone hose for the ventilator leads the air to the burner for com-
bustion. This avoids diesel odors.
The fuel is taken from the vehicle fuel tank or from a separate fuel tank.
Use fuel lines with a internal diameter of 6 mm (max. 10 mm) for the connec-
tion between the fuel tank and the oil lter.
Dierent diameters with the approval of the manufacturer only.
Unsupported fuel lines must be secured to prevent them from sagging.
•
Repeated emtying of fueltank can cause damage to the burner!
If the heater is operated without fuel it can cause damage (e. g. on the oil nozzle).
NOTICE
Antifreeze liquid for heating water
Automatic venting for heating water
ecological antifreeze, BIO-GLYKOL
- Ready-mix with minimum antifreeze -24°C
- Temperature stability 214°C
- Completely biodegradable
- Signicantly longer shelf life than propylene glycol
Item No.
30 liter canister 190090
1 liter bottle 190091
Antifreeze components:
-1.3 propanediol (100% plant derived)
- HTX1 approval for food related areas
- CO2 reduced
with hose connection
Item.-No.: 190088
with 1/2“ male thread
Item No.: 190089
16

www.scheer-heizsysteme.de
combustion air supply
Permitted dimension for the combustion air supply:
- inner diameter: 50 mm (MH 30 and larger: 80 mm), micro: 75mm
- maximum permitted line length: 10 m
- maximum bends: 270 °
exhaust pipe
The exhaust pipe opening must not point in the direction of travel.
The exhaust pipe opening must be located so that it cannot become clogged with mud or snow.
Use exible or rigid alloyed steel pipes that are heat and acid resistant for the exhaust system. Secure the
exhaust pipe with a hose clamp, for example. Read the statutory regulations for other requirements.
•
The exhaust line must be insulated, if it is installed near heat-sensitive parts of the vehicle or inside a box.
The exhaust opening can not be located underneath the combustion air intake! Do not install the exhaust
pipe opening in a proximity of less than 50 cm to the combustion air intake.
CAUTION!
Under no circumstances may the combustion air be taken from areas occupied by people. It must be
located so that it can not become clogged with dirt or snow and can not suck in splash water.
DANGER !
exhaust pipe
(exible) Item No.
Ø 35 14-N000
Ø 50 14-N246
Ø 80 14-N078
Isolation hose Item No.
Ø 35,50 14-N176
Ø 80 14-N177
Air intake hose Item No.
MH Micro DN 75 014120
Exhaust pipe
end piece Item No.
Ø 35 0754695
Ø 50 075469
•
The combustion air intake must not be installed above the exhaust or closer than 50 cm. In case of the
operation of the burner dependent on the ambient air (i.E. inside a box), ensure adequate fresh air supply
to the heater box of the vecicle. Concentric air / exhaust system (LAS) is possible.
If the heater is installed in an enclosed box a ventilation opening measuring at least 50 cm2is
required.
If the heater is installed in a general installation space near the vehicle‘s fuel tank, the combustion air
must be taken in from the outside and the exhaust fumes discharged into the atmosphere. The openings
must be splash-water-proof.
NOTICE
17

www.scheer-heizsysteme.de
oil pump motor
oil pump motor capacitor
Item No.: 015138 Item No.: 010294
oil pump
two-step oil pump
Item No.: 011759
• A current under 200 V may lead to a stand still of the oil pump motor!
• Replace the capacitor if the capacity diers more than 5% (lower than 2,85 µF ).
burner components
blower
Item No.
MH 015112
MH Micro 018510
blower keyboard
The blower keyboard automatically adjusts the speed of the blower according to the atmospheric pressure
(location of the vehicle) and thus sets an optimum combustion quality.
Item No.
MH 10/17 016026
MH 15/23 016027
MH 30/40 016028
MH 10 micro 0160290
MH 20 micro L 0160291
Item No.
MH 011759
MH Micro 011236
one-step oil pump
Item No.: 011236
18

www.scheer-heizsysteme.de
ame tube
ignition electrodes
Item No.
MH micro 015110
MH 10/17 015110
MH 15/23
MH 30/40 015140
Art.-Nr.
MH 10/17 015329
MH 15/23
MH 30/40 015331
MH micro 015332
air pressure switch
Item No.: 015188
ignition transformer
air pressure switch
Item No.
MH 010276
MH Micro 012100
The air pressure switch controls the burner fan and is connected to the solenoid
valve of the oil pump. The solenoid valve opens only when there is sucient air
pressure provided by the fan to start the combustion process.
The ame detector evaluates the burner ame condition by its icker fre-
quency through the light detector tube of the mixing cartridge.
ame detector (not for the MH mirco)
Operating status display:
LED: o ame detector not active
LED: ashes safety test conducted, ame detector is active, no ame detected
LED: on (ickers) safety test conducted, ame detector is active, ame detected
19

www.scheer-heizsysteme.de
controller
Note:
The lockout reset button is the key operating element for resetting, activat-
ing / deactivating, and diagnostics.
The multi color signal lamp behind the clear cover of the lockout reset
button is the key indicating component for visual diagnostics and interface
diagnostics.
Item No.
MH 10/17 0201026
MH 15/23
MH 30/40 0201026
MH micro 0201029
20
