6
INHALTSVERZEICHNIS
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Sicherheit und Hinweise �������������������������������������������������������
Technische Daten �����������������������������������������������������������������
Anzeigen- und Tastenerklärung ��������������������������������������������
Montage ��������������������������������������������������������������������������������
Funk-Handsender Programmierung
Rohrmotor: Adresse zuweisen ���������������������������������������������
Programmiermodus starten ��������������������������������������������������
Funk-Handsender mit Rohrmotor koppeln ���������������������������
Rohrmotor-Drehrichtung prüfen �������������������������������������������
Drehrichtung ändern �������������������������������������������������������������
Endlage oben einstellen �������������������������������������������������������
Endlage unten einstellen �������������������������������������������������������
Programmiermodus beenden �����������������������������������������������
Zwischenlage setzen (optional) ��������������������������������������������
Zwischenlage löschen ����������������������������������������������������������
Zwischenlage anfahren ���������������������������������������������������������
Endlage anfahren ������������������������������������������������������������������
Weitere Funk-Handsender anlernen ������������������������������������
Einstellungen des Funk-Handsenders löschen ��������������������
Werksreset ����������������������������������������������������������������������������
7
11
12
189
192
194
195
197
198
199
201
203
203
205
207
207
208
211
213
Urheberrechtlich geschützt, 2013, Alfred Schellenberg GmbH� Alle Rechte vorbehalten�
Jede vom Urheberrechtsgesetz nicht zugelassene Verwertung, insbesondere Verviel-
fältigung, Übersetzung, Verarbeitung bzw� Weitergabe von Inhalten in Datenbanken
oder anderen elektronischen Medien und Systemen, ist verboten�

76
DE
SICHERHEIT UND HINWEISE
Sehr geehrte Kundin, sehr geehrter Kunde,
bitte lesen Sie vor der Montage und Inbetriebnahme
diese Anleitung vollständig durch� Beachten Sie alle
Sicherheitshinweise, bevor Sie mit den Arbeiten
beginnen� Bewahren Sie die Anleitung auf und
weisen Sie jeden Benutzer auf eventuelle Gefahren hin, die im
Zusammenhang mit diesem Produkt stehen� Übergeben Sie die
Anleitung bei einem Besitzerwechsel auch dem Nachbesitzer�
Bei Schäden, die durch unsachgemäßen Gebrauch oder durch
fehlerhafte Montage entstehen, erlischt die Garantie und jeder
Gewährleistungsanspruch�
SICHERHEITSHINWEISE
Es besteht Verletzungsgefahr durch Stromschlag�
Vor Arbeiten an elektrischen Anlagen muss diese
spannungsfrei geschaltet werden�
Den Funk-Handsender nur in trockenen Räumen verwenden�
Die funkbetriebene Rollladenanlage muss während des Betriebs
einsehbar sein, insbesondere wenn die Rollladenanlage durch
mehr als einen Funk-Handsender angesteuert wird�
Halten Sie Personen aus dem Fahrbereich der Rollladenanlage
fern� Es besteht Verletzungsgefahr�
Der Funk-Handsender ist kein Spielzeug, halten Sie Kinder
davon fern�
Es besteht Verletzungs- und Erstickungsgefahr durch
Kleinteile des Funk-Handsenders und der Verpackung�

8
Für den Betrieb einer Rollladenanlage über einen
Funk-Handsender müssen die landesspezischen Bestimmun-
gen beachtet werden�
Batterien nur durch den gleichen Typ ersetzen, LR03 / AAA�
Den Rohrmotor nicht über Endlagen fahren�
Beschädigungsgefahr!
CE-ERKLÄRUNG UND KONFORMITÄT
Den Funk-Handsender (20015/20019/20021/20022)
und die Batterien nicht im Hausmüll entsorgen� Den
Funk-Handsender an einer geeigneten Stelle für elek-
trische Altgeräte abgeben� Verbrauchte Batterien an
einer entsprechenden Sammelstelle abgeben�
BESTIMMUNGSGEMÄSSE VERWENDUNG
Den Funk-Handsender nur mit Geräten verbinden, die vom
Hersteller dafür zugelassen sind�
Eine andere oder darüber hinausgehende Verwendung des
Funk-Handsenders gilt als nicht bestimmungsgemäß�
Der Funk-Handsender darf nicht in Bereichen mit hohem
Risiko der Störung Dritter (z�B� Krankenhäuser, Flughäfen oder
ähnlichen Einrichtungen) betrieben werden�
Es besteht kein Schutz vor Störungen durch andere ordnungs-
gemäß aufgebaute und betriebene Funkanlagen, insbesondere
durch solche, die im gleichen Frequenzbereich arbeiten�
Die über den Funk-Handsender betriebenen Rollladenanlagen
müssen in einem einwandfreien Zustand sein�

98
DE

10
Für Folgeschäden, Sachschäden und Personenschäden
bei nicht bestimmungsgemäßer Verwendung haftet die
Alfred Schellenberg GmbH nicht�
Der Betrieb des Funk-Handsenders in der Nähe von Geräten mit
magnetischer Strahlung oder metallischen Flächen beeinträch-
tigt die störungsfreie Funktion�
Die Reichweite des Funk-Handsenders ist durch europäische
Verordnungen und Richtlinien des Gesetzgebers begrenzt�
Die Reichweite des Funk-Handsenders beträgt ca� 150 Meter
auf freiem Feld und ca� 20 Meter im Gebäude�
NUTZUNGSHINWEISE
Pro Kanal können bis zu 5 Rohrmotoren angelernt werden� Alle
5 Rohrmotoren werden über den Funk-Handsender gleichzeitig
angesteuert� Hierbei werden auch unterschiedlich programmier-
te Endlagen bei Fenstern und Türen berücksichtigt� An einen
Rohrmotor können bis zu 5 Funk-Handsender angelernt werden�

1110
DE
TECHNISCHE DATEN
Sendefrequenz 868,4 MHz
Reichweite auf freiem Feld bis zu 150 Meter
Reichweite im Gebäude bis zu 20 Meter
Spannungsversorgung 3 V DC
Batterietyp 2 x LR03 / AAA
Schutzart IP 20
Umgebungstemperatur 0° bis 50° Celsius
Die baulichen Gegebenheiten beeinträchtigen die
Reichweite und Funktion des Funk-Handsenders�

1212
ANZEIGEN- UND TASTENERKLÄRUNG
Beschriftungsfelder
Taste Programmierung
Ein- und Ausschalten des
Programmiermodus� Taste
bendet sich im Batteriefach
auf der Rückseite�
Batteriefach 2x (AAA)
Rückseite
5
LED-Anzeige / Kanal 1
Blinkt während der
Programmierung�
Taste Auffahrt
Rollladen/Markise fährt
nach oben / aus�
Taste Stopp
Stoppt die Auf-/Abfahrt
des Rohrmotors�
Taste Abfahrt
Rollladen/Markise fährt
nach unten /ein�
Vorderseite
1
3
4
2

1312
GB
TABLE OF CONTENTS
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Safety and notices ����������������������������������������������������������������
Technical data �����������������������������������������������������������������������
Display and key explanation �������������������������������������������������
Installation �����������������������������������������������������������������������������
Hand-held wireless remote control programming
Tubular motor: address assignment �������������������������������������
Programming mode start ������������������������������������������������������
Pairing the hand-held wireless remote control with the
tubular motor �������������������������������������������������������������������������
Tubular motor rotation check ������������������������������������������������
Tubular motor direction change ��������������������������������������������
Setting the upper end position ����������������������������������������������
Setting the lower end position ����������������������������������������������
Concluding the program mode ���������������������������������������������
Intermediate position deletion �����������������������������������������������
Intermediate position approach ��������������������������������������������
Intermediate position approach ��������������������������������������������
End position approach ����������������������������������������������������������
Pairing of other hand-held wireless remote controllers �������
Deleting the settings of the hand-held wireless remote
controller �������������������������������������������������������������������������������
Factory default reset �������������������������������������������������������������
14
18
19
189
192
194
195
197
198
199
201
203
203
205
207
207
208
211
213
Copyright protected, 2013 Alfred Schellenberg GmbH All rights reserved� Any use,
in particular reproduction, translation, processing or transmission of content into
databases or other electronic media and systems beyond the authorization provided
by the copyright legislation is strictly prohibited�

14
SAFETY AND NOTICES
Dear customers,
please completely read this instruction manual before
the installation and commissioning� Observe all
safety instructions before you begin executing any
work� Keep the instruction manual stored at hand and
advise each user about possible dangers that are related to this
product� In case of a change in ownership pass on the instruction
manual to the new owner� In case of damages which are caused
by misuse or improper installation the warranty and any warran-
ty claim will be void�
SAFETY INSTRUCTIONS
There is a risk of injury from electric shock� Before
working on electrical equipment, it must be complete-
ly de-energized�
Only operate the hand-held wireless remote control in dry rooms
(IP20)�
The radio-controlled shutter system must be accessible during
operation, especially when the shutter system is controlled by
more than one hand-held wireless remote controller�
Keep people away from the movement range of the roller shutter
system� There is a risk of injury�
The hand-held wireless remote control is not a toy, keep children
away from it�
There is a danger of injury and suffocation from small parts of
the hand-held wireless remote controller and the packaging�

1514
GB
When operating a shutter system via a hand-held wireless remo-
te controller the country-specic regulations must be observed.
Only replace the batteries with the same type, LR03 / AAA�
Do not move the tubular motor beyond the end positions�
Risk of damage!
CE DECLARATION AND CONFORMITY
Do not dispose of the hand-held wireless remote
control (20015/20019/20021/20022) and the batteries
together with household waste! Deposit the hand-held
wireless remote control at a facility authorized for the
disposal of electrical equipment� Deposit used batte-
ries at an appropriate collection point�
INTENDED USE
Only connect the hand-held wireless remote control with
devices that are approved by the manufacturer for the
respective use�
Using the hand-held wireless remote control for other purposes
is considered contrary to its designated use�
The hand-held wireless remote control may not be operated in
areas with high risk or if third parties are disturbed (for example
hospitals, airports and similar facilities)�
There is no protection from interference from other properly
constructed or operated radio equipment, particularly by those
who work in the same frequency range�
The roller shutter systems which are operated with the
hand-held wireless remote control must be in a awless
condition�

16

1716
GB
The Alfred Schellenberg GmbH shall not be liable for any
consequential damage, property damage and personal injury
due to improper use�
The operation of the hand-held wireless remote control in the
vicinity of equipment that emits electromagnetic radiation or has
metal surfaces can affect the correct operation�
The range of the hand-held wireless remote control is limited by
European regulations and legislative directives�
The range of the hand-held wireless remote control is approx�
150 meters in the open eld, and 20 meters within buildings.
NOTES REGARDING THE USE
Per channel, up to 5 tubular motors can be paired� All 5 tubular
motors can be controlled simultaneously via the hand-held
wireless remote control� Differently programmed end positions
in windows and doors will be considered, too� A single tubular
motor can be paired with up to 5 hand-held wireless remote
controllers�

18
TECHNICAL DATA
Transmission frequency 868,4 MHz
up to 150 meters
Range within buildings up to 20 meters
Power supply 3 V DC
Battery type 2 x LR03 / AAA
Protection class IP 20
Ambient temperature 0° to 50° Celsius
The structural conditions affect the range and function
of the hand-held wireless remote control�

1918
GB
DISPLAY AND KEY EXPLANATION
programming button
On/off switching of the
programming mode� The
button is located in the
battery compartment on the
rear side�
Battery compartment
2x (AAA)
Rear side
5
LED display / channel 1
Flashes during the
programming�
open button
Shutter/awning moves
upwards/extends�
stop button
Stops the up/down
movement of the
tubular motor�
close button
Shutter/awning moves
downwards/retracts�
Front side
1
3
4
2

20
TABLE DES MATIÈRES
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Sécurité et consignes �����������������������������������������������������������
Caractéristiques techniques �������������������������������������������������
Explication des afchages et des touches ���������������������������
Montage ��������������������������������������������������������������������������������
Programmation du radioémetteur portatif
Moteur tubulaire : Assigner une adresse ������������������������������
Démarrer le mode de programmation ����������������������������������
Connecter le radioémetteur portatif au moteur tubulaire �����
Contrôler le sens de rotation du moteur tubulaire ����������������
Modier le sens de rotation ��������������������������������������������������
Régler le point limite haut �����������������������������������������������������
Régler le point limite bas �������������������������������������������������������
Quitter le mode de programmation ���������������������������������������
Régler le point intermédiaire (en option) �������������������������������
Effacer le point intermédiaire ������������������������������������������������
S‘approcher du point intermédiaire ��������������������������������������
S‘approcher du point limite ���������������������������������������������������
Soumettre d‘autres émetteurs portatifs à l‘apprentissage ���
Effacer les réglages du radioémetteur portatif ���������������������
Réajustage des réglages départ usine ���������������������������������
21
24
25
189
192
194
195
197
198
199
201
203
203
205
207
207
208
211
213
Soumis au droit d‘auteur, 2013 Alfred Schellenberg GmbH� Tous droits réservés�
Défense de toute utilisation non autorisée par le droit d‘auteur, et notamment de la
reproduction, de la traduction, de la transformation ou de la transmission des contenus
des bases de données ou des autres médias et systèmes électroniques�
This manual suits for next models
3
Table of contents
Languages:
