Installation and commissioning manual
Wireless Data System
DATAEAGLE 2XXX Compact®
Schildknecht AG
D -71711 Murr – Haugweg 26
Phone ++49 (0)7144 89718-0 - Fax ++49 (0) 7144 8971829
Email: [email protected] - Internet: www.schildknecht.ag
DATAEAGLE 2XXX Compact V2
Version: 07.04.2014

Installation and commissioning DATAEAGLE 2XXX Compact
© Copyright
Schildknecht AG
All rights reserved.
No part of this publica-
tion may be reproduced
or translated in full or in
part without prior written
permission.
Right to make changes
Changes may be made
at any time to the form,
equipment and technol-
ogy of items covered in
this documentation. For
this reason, no claims
relating to the aforemen-
tioned may be derived
from the information,
illustration and descrip-
tions provided in these
operating instructions for
appliances or systems
manufactured after the
date of issue of these
operating instructions.
Warranty
Schildknecht AG can
accept no liability for in-
direct damage or direct
damage, incidental
damage, consequential
damage or compensa-
tion for expenses in-
curred by performance
of contract which arise
from delivery, provision
and use of this material.
Introduction
The technical description of the wireless data systems from
Schildknecht AG consists of an operating instruction for all
product families and an installation and commissioning man-
ual for each product family. Please read both documents
carefully before you start working with the wires data sys-
tems. Both documents should be considered as a single enti-
ty.
You are here
The operating instruction is intended to help you familiarize
yourself with the structure and function of wireless data sys-
tems.
Here you get general information about the complete prod-
uct family. Please read the operating instructions first if you
are not familiar with the structure and function of wireless da-
ta systems.

Installation and commissioning DATAEAGLE 2XXX Compact
Next, read the installation and commissioning manual of the
wireless data system.
To start with, we have a few important things to say about
safety. Please observe these instructions without fail, in order
to avoid property damage and personal injury.
We show you step by step how to install the system, put it in-
to operation and how to operate it.
Any questions? First, have a look in the table of contents.
You will quickly find what you are looking for.
If you do need us in person: just call us or send a fax:
Schildknecht AG
Haugweg 26
D -71711 Murr
Phone
+49 / (0) 7144 89718-0
Fax
+49 / (0) 7144 8971829
Internet
www.schildknecht.ag
e-mail
[email protected]
FAX
WWW
e-mail

Installation and commissioning DATAEAGLE 2XXX Compact
List of contents
Subject Page no.
Introduction
1.General information 1-1
1.1.Guide to symbols 1-1
1.2.Copyright and brand names 1-1
1.3.Declaration of conformity and EC directives 1-1
2.Safety instructions 2-1
2.1.Intended use 2-1
2.2.General information 2-1
2.3.Installations instructions 2-2
2.4.Safety instructions for operation 2-2
2.5.Personnel qualification 2-3
3.Structure 3-1
3.1.System description 3-1
3.2.Radio module 3-3
3.3.I/O module 3-5
4.Installation of new devices 4-1
4.1.Overview Installation 4-1
4.2.Configure DIL switches 4-2
4.2.1.DIL switches for I/O modules with 6 digital I/Os 4-3
4.2.2.DIL switches for I/O modules with 8 digital I/Os 4-4
4.2.3.Example for DIL switch configuration for I/O modules
with 6 digital inputs 4-5
4.3.Install unit on top-hat rail 4-6
4.4.Install antenna cable 4-7
4.5.Install I/O plug 4-8
4.6.Connect power supply 4-8

Installation and commissioning DATAEAGLE 2XXX Compact
5.Extension and exchange 5-1
5.1.Preparation 5-1
5.1.1.System requirements 5-1
5.1.2.Create a new folder 5-1
5.1.3.Microsoft Internet Explorer 5-2
5.1.4.Install USB drivers 5-3
5.1.5.Install Dataeagle Wizard 5-6
5.2.Extension 5-7
5.2.1.Configure DIL switches 5-8
5.2.2.Set address switch 5-8
5.2.3.Install module on top-hat rail 5-9
5.2.4.Install I/O plug 5-10
5.2.5.Connect power supply 5-10
5.2.6.Start Dataeagle Wizard and configure I/O module 5-11
5.3.Exchange 5-16
5.3.1.Remove the wiring 5-17
5.3.2.Remove the old module 5-17
5.3.3.Configure DIL switches – only I/O modules 5-18
5.3.4.Set address switch - only I/O modules 5-18
5.3.5.Install module on top-hat rail 5-18
5.3.6.Install I/O plug or antenna cable 5-19
5.3.7.Connect power supply 5-19
5.3.8.Start Dataeagle Wizard 5-20
5.3.9.Which one is the Master, and which one the Slave? 5-21
5.3.10.Configure radio module 5-24
6.Dismantling and disposal 6-1
7.Tips and Tricks 7-1
7.1.Improving the EMC safety 7-1
7.1.1.Introduction 7-1
7.1.2.Basic guidelines 7-1
7.2.Guidelines for optimized installation of antennas 7-5
7.3.Advices for troubleshooting 7-7
8.Technical specifications 8-1

Installation and commissioning DATAEAGLE COMPACT 2XXX 1-1


Chapter 1 – General information
1. General information
1.1. Guide to symbols
This section contains an explanation of the symbols used in
this manual.
Indicates an imminently hazardous situation which, if not
avoided, may result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in property damage.
Indicates sections which contain important information.
Indicates work operations which need to be carried out.
This symbol is followed by a description about how the status
of the system changes after an operation has been carried
out.
1.2. Copyright and brand names
Brand names and product names mentioned in this manual
are trademarks or registered trademarks of their respective
owners.
Microsoft Windows 7, Windows Vista, Windows 2000, Win-
dows XP and Microsoft Internet Explorer are registered
trademarks of Microsoft Corp.
Adobe Reader is a registered trademark of Adobe Systems
Corp.
DATAEAGLE® is a registered trademark of Schildknecht AG.
1.3. Declaration of conformity and EC direc-
tives
Information about the declaration of conformity and about EC
directives can be found under:
http://www.schildknecht.info/dokumente/doc.pdf
CAUTION

Installation and commissioning DATAEAGLE COMPACT 2XXX 2-1
Chapter 2 - Safety instructions
2. Safety instructions
2.1. Intended use
Information about the intended use can be found in the oper-
ating instructions wireless data systems DATAEAGLE.
2.2. General information
In order to guarantee safe use and fault-free operation, the
according safety instructions have to be observed under all
circumstances.
Safety instructions which apply to all product families are de-
scribed in the operating instructions for wireless data sys-
tems DATAEAGLE. This manual is part of the system docu-
mentation. Read these instructions before installation and
commissioning of the wireless data system.
Safety instructions which apply only to an individual wireless
data system are described below and in the according sec-
tion of this installation and commissioning manual.

Installation and commissioning DATAEAGLE COMPACT 2XXX 2-2
Chapter 2 - Safety instructions
2.3. Installations instructions
Country licenses can be found in the attached declara-
tion of conformity.
Risk of electrical shock.
Always disconnect the modules from the power source
when working on the modules (installation, etc.)!
Risk of injury.
Comply with the local regulations and safety instruc-
tions during installation!
Static charges can damage electronic devices.
Remove electrostatic discharge from your body before
touching the device!
The modules must not be opened or modified (except
the steps described in this manual). Do not repair the
module yourself, replace it with an equivalent module.
Repairs may only be carried out by the Schildknecht AG.
The Schildknecht AG is not liable for damage resulting
from a failure to comply.
2.4. Safety instructions for operation
Electromagnetic radiation.
Keep at least a distance of 20 cm to the antennas when
the devices are in operation.
CAUTION
CAUTION

Installation and commissioning DATAEAGLE COMPACT 2XXX 2-3
Chapter 2 - Safety instructions
2.5. Personnel qualification
Only qualified personnel may carry out the following tasks:
Installation
Commissioning
Operation
Maintenance
Within the context of safety regulations, qualified personnel
are individuals authorized to commission, to ground, and to
identify equipment and systems in accordance with the safe-
ty-engineering standards.
All operating personnel must be trained accordingly.
Personnel involved with operating the unit in conjunction with
controllers must possess sound programming skills for the
individual controller and programming language in question.

Installation and commissioning DATAEAGLE COMPACT 2XXX 3-1
Chapter 3 – Structure
3. Structure
3.1. System description
The system is used for the wireless bidirectional transmission
of digital and analog signals. It consists of a radio module
and up to five I/O modules on each side.
The modules are connected together by T-bus plugs.

Installation and commissioning DATAEAGLE COMPACT 2XXX 3-2
Functional
principle
I/O module 1
ChannelConfiguration
IO1 Input
IO2 Input
IO3 Output
IO4 Output
I/O module 2
ChannelConfiguration
IO1 Output
IO2 Output
IO3 Input
IO4 Input
Chapter 3 – Structure
A door control is used as an example to explain the function-
al principle:
A rolling shutter should be opened and closed via radio sig-
nal. Two limit switches (top/bottom) report when the rolling
shutter has reached the end position (open/closed).
The signal „Open door“ is connected to the first channel
(IO1) of I/O module, sent through the T-bus plug to the radio
module 1 and from there transmitted to radio module 2. Ra-
dio module 2 sends the signal through the T-bus plug to the
first channel of I/O module 2 and can now control the rolling
shutter drive. The signal „Close door“ is connected the same
way to the second channel (IO2).
The limit switches are connected to IO3 and IO4 of I/O mod-
ule 2 and transmit the signals from I/O module 2 to I/O mod-
ule 1.

Installation and commissioning DATAEAGLE COMPACT 2XXX 3-3
Chapter 3 – Structure
3.2. Radio module
The radio module transmits the signals via radio and is avail-
able in two radio technologies.
Device type Part no. Radio technology Transmission power
DEC 2320 10974 869 MHz 500 mW
DEC 2700 10975 2,4 GHz Bluetooth 100 mW
Radio modules are configured with the software Dataeagle
Wizard (see chapter 5.3.8)
New devices are pre-configured in the factory.
Further settings are not necessary.

Installation and commissioning DATAEAGLE COMPACT 2XXX 3-4
Chapter 3 – Structure
The illustration shows all connections of the radio module.
The table shows the meaning of the LEDs at the radio
module:
Name Colour Function
ON Green Power ok
BF Red Without function
RX Yellow Receiving radio data
LINK Blue DE2700:
Bluetooth connection established
DE2320:
Flashes every second when connected
Antenna
connection
Power supply
USB
connection
Status LEDs

Installation and commissioning DATAEAGLE COMPACT 2XXX 3-5
Chapter 3 – Structure
3.3. I/O module
Input and output cables are connected to the I/O module. I/O
modules are available in three versions:
Version 1 6 Digital inputs/outputs (configurable)
2 Analog inputs 0-10 V
2 Analog outputs 0-10 V
Version 2 6 Digital inputs/outputs (configurable)
2 Analog inputs 4-20 mA
2 Analog outputs 4-20 mA
Version 3 8 Digital inputs / 8 Relay outputs (configurable)
I/O modules are configured with the software Dataeagle
Wizard (see chapter 5.3.8)
New devices are pre-configured in the factory.
Further settings are not necessary.

Installation and commissioning DATAEAGLE COMPACT 2XXX 3-6
Chapter 3 – Structure
The illustration shows all connections and possible adjust-
ments of the I/O module:
The function of the channel (input or output) is set with the
DIL switches. The inputs of version 1 and 2 can be config-
ured with or without pull-up resistors. (see chapter 4.2.1)
The table shows the meaning of the LEDs at the I/O module:
Name Colour Function
ON Green Power ok
ERR Red Error
IO1… Green Condition „on“ at the respective input or
output
Status
LEDs
Analog
I/Os
Digital
I/Os Power
supply
Address
switch
DIL
switches

Installation and commissioning DATAEAGLE COMPACT 2XXX 4-1
Chapter 4 – Installation of new devices
4. Installation of new devices
Please be certain to read the guidelines in chapter 7
„Tips and Tricks – improvement of the electromagnetic
compatibility (EMC)“. Observe these guidelines during
the complete installation procedure. Thereby you avoid
electromagnetic interferences and you improve the data
transmission quality.
New devices are pre-configured in the factory.
Further settings are not necessary.
4.1. Overview Installation
The installation is very easy and is carried out according to
the procedure shown below:
Configure DIL switches at I/O module

Install unit on top-hat rail

Connect antenna cable

Connect I/O plugs

Connect power supply
In case of limited space in the control cabinet:
Connect the power supply before you install the unit on
the top-hat rail.

Installation and commissioning DATAEAGLE COMPACT 2XXX 4-2
Chapter 4 – Installation of new devices
4.2. Configure DIL switches
The DIL switches are used to define whether a channel
works as an input or output.
When a signal should be transmitted from Ato Bthe I/O
channel on side A must be configured as input and the
same channel on side B must be configured as output.
Two switch blocks with 6 DIL switches each are available for
configuration.

Installation and commissioning DATAEAGLE COMPACT 2XXX 4-3
2 DIL switches
for each I/O
Second switch =
output = ON 
First switch
without function
Chapter 4 – Installation of new devices
4.2.1. DIL switches for I/O modules with 6 digital I/Os
I/O modules with 6 digital I/Os (version 1 and 2) have 2DIL
switches for each channel. The first DIL switch defines
whether the input is designed with or without pull-up resistor.
The second DIL switch defines whether the channel works
as an input or as an output.
The table shows the allocation of the DIL switches to the
channels (IOx):
Channel Block Switch Function
IO1
1
1 ON =
with pull-up OFF = without pull-up
2 ON = output OFF = input
IO2 3 ON =
with pull-up OFF = without pull-up
4 ON = output OFF = input
IO3 5 ON =
with pull-up OFF = without pull-up
6 ON = output OFF = input
IO4
2
1 ON =
with pull-up OFF = without pull-up
2 ON = output OFF = input
IO5 3 ON =
with pull-up OFF = without pull-up
4 ON = output OFF = input
IO6 5 ON =
with pull-up OFF = without pull-up
6 ON = output OFF = input
No settings are necessary for the analog inputs and out-
puts.
Block 1 Block 2

Installation and commissioning DATAEAGLE COMPACT 2XXX 4-4
1 DIL switch for
each I/O
Chapter 4 – Installation of new devices
4.2.2. DIL switches for I/O modules with 8 digital I/Os
I/O modules with 8 digital I/Os (version 3) have 1DIL switch
for the channel configuration (ON = Relay output, OFF = Dig-
ital input).
The table shows the allocation of the DIL switches to the
channels (IOx):
Channel Block Switch Function
IO1
1
1 ON = output OFF = input
IO2 2 ON = output OFF = input
IO3 3 ON = output OFF = input
IO4 4 ON = output OFF = input
IO5 5 ON = output OFF = input
IO6 6 ON = output OFF = input
IO7
2
1 ON = output OFF = input
2
OFF
IO8 3 ON = output OFF = input
4
OFF
5 OFF
6 OFF
DIL switches 2 and 4 of block 2 must be set to OFF.
Block 1 Block 2
CAUTION

Installation and commissioning DATAEAGLE COMPACT 2XXX 4-5
Chapter 4 – Installation of new devices
4.2.3. Example for DIL switch configuration
for I/O modules with 6 digital inputs
The system should be configured as shown below:
Channel Side A Side B
IO1 Input with pull-up Output
IO2 Input with pull-up Output
IO3 Output Input
IO4 Output Input
Configuration of the DIL switches:
Block 1 Block 2
Side B
Side A
