INTRODUCTION
All information necessary for a correct assembly to ensure trouble free operation of the cable reel are described in the present operating
instructions. The warranty given by the manufacturer is only valid if these operating instructions are observed and adhered to. Terms and
conditions are available upon request or at https://www.schill.de/en/footer/general-terms.
Additional user manuals for other product variants can be found at https://www.schill.de/en/downloads or received on request (see
"CONTACT").
GENERAL
Automatic cable rewinder provide for a modern power supply of workstations or the perfect supply of electrical energy, data, and signals
for mobile devices. The cable is only pulled out when needed and in the required length. The remainder stays neatly stored on the cable
reel and is protected from contamination and damage. The power connection is always accessible, but never in the way. The cable length
can be easily adapted to a changing work situation. There is no cable chaos, no tripping hazard anymore. If the cable connection is no
longer needed, a short pull on the cable stopper will suffice and the cable will roll up neatly. The automatic cable rewinder provides safety
and order.
In the MFK version, commercially available pre-assembled cables can be used without having to guide them via a rotary
transformer. The physical properties of the cable are retained.
HANDLING
The coiled cable should be pulled out to the required length against the spring tension, but please refrain from the use of undue force. The
cable is coiled and fixed in position as described under "LOCKING DEVICE". The cable should never be pushed in manually. If the cable
becomes entangled when winding it onto the reel, simply pull the cable out again and then rewind.
Attention
When rolling up and unrolling, the connection cable must be stored inside the coil and secured with the Velcro fastener (see
cable assembly). Otherwise, the line may be damaged and there is a risk of injury due to the swirling end of the connection
cable.
MAINTENANCE
The cable reel does not require any maintenance, due to the excellent antifriction properties of the plastic bearing. However, the cable
must be checked in regular intervals for damages and replaced if necessary.
SPIRAL SPRING
The spiral spring is subject to natural wear and tear and can result in a fatigue fracture of the spring steel. Based on experience, we
recommend changing the spring after approx. 30.000 operations. The term “operations” defines not only a complete winding and
unwinding of the spring but also includes a partial movement of the spring. For a safe replacement of the coil spring, please refer to
paragraph (“REPLACING THE SPIRAL SPRING”).
CABLE STOPPER
The length of the available cable can be individually adjusted with the provided cable stopper.
The reliable clamping adapts to various cable diameters between 6 and 12 mm. For a thicker
cable, a larger version is available. The stopper also serves as a safeguard against retraction
of the cable in case of a not intended release. It should therefore never be removed.

automatic cable rewinder FT 260/350 - EFT 265 MFK
installation and operating instruction
installation and operating instruction FT 260_350-EFT 265 MFK - A5 page 3 01.04.2021
Schill GmbH & Co. KG; Bruckstraße 44; 70734 Fellbach www.schill.de
LOCKING DEVICE
As a standard feature the cable reel has a disengageable cable locking device. The latching mechanism ensures that the pulled-out cable
stays without traction fixed in place. When the cable is being pulled out, the spring detent passes over a series of grooves. An audible
click indicates that the locking device is engaged. If you gently rewind the cable after the clicking sound, you will notice that the spring
detent will engage into the notches, locking the cable in position. The cable can be disengaged by gently continuing to pull the cable until
the click can no longer be heard. The tensioned spring will pull the cable back onto the reel.
Attention
Do not release the cable when rewinding, the tension of the spring can accelerate the winding speed to such a degree that the
swinging cable end could cause injury. Also damage to the cable and spring could be the result of such an action.
The locking device FT / FTE 260 can be disengaged by pulling the knurled grip out by approx. 1cm and turning it between 90° and
180°. This will disengage the locking device the cable is then constantly under tension.
CABLE ASSEMBLY
The standard MFK cable reels are supplied as standard without cable
assembly (see "Installation Cables".
The cable is installed in the cable reel in such a way that a cable with the
connection length X protrudes on the connection side. Cable assembly is
described below. To change the extension length, the connection cable must
be rolled up in the coil and fastened.
Attention
When rolling up and unrolling, the connecting cable must be stored
inside the coil and secured with the Velcro fastener. Otherwise, the line
may be damaged and there is a risk of injury due to the swirling end of
the connection cable.
The maximum pull-out length depends on cable outer diameter (OD), cable
weight incl. plug-in device, weight of the cable stopper and the built-in coil
spring.
FT 260 - EFT 265
Starting from a standard spring, with a maximum of 24 revolutions, the following pull-out and connection lengths are possible.
cable OD [mm]
pull-out length [m]
connection length [m]
≤ 8
10
1,5
≤ 10
8
1,2
≤ 12
6
0,9
The maximum spring force is 30N (3kg).

automatic cable rewinder FT 260/350 - EFT 265 MFK
installation and operating instruction
installation and operating instruction FT 260_350-EFT 265 MFK - A5 page 4 01.04.2021
Schill GmbH & Co. KG; Bruckstraße 44; 70734 Fellbach www.schill.de
FT 350
Starting from a standard spring, with a maximum of 29 revolutions, the following pull-out and connection lengths are possible.
cable OD [mm]
pull-out length [m]
connection length [m]
≤ 8
17
1,5
≤ 10
18
1,2
≤ 12
20
0,9
The maximum spring force is 55N (5.5kg).
The values specified in the tables are approximate values. If you have any questions, please contact the manufacturer directly (see
"CONTACT").
CABLE INSTALLATION
•Loosen all the screws and remove the cover ccarefully.
Attention
The spiral spring in the coil is under tension. Please ensure that the locking mechanism is activated.
•Take the tension off the coil. To do this, proceed as follows:
➢Carefully turn the coil against the clockwise direction until the rattling of the ratchet is no longer heard. A pull will be
noticeable. Do not let go of the coil.
➢Slowly run back the coil. The coil should be easily movable at the end and not locked in the locking.
•Dismantle strain relief and screws in the coil.
•Guide the cable through the opening in the coil until connection length X.
•Fix the cable with the strain relief.
•Store the overstanding connecting cable inside the coil and securely with the Velcro fastener.
•Install the cable stopper at the end of the pull-out cable.
•Wind the pull-out cable counterclockwise on the coil.
•Adjust the pre-load:
Hold the stopper outside the housing and hold it with one hand. Now turn the coil as often as you want to pre-load. At the end let it
snap into the notches (see "LOCKING DEVICE").
•Undertake the re-assembly in reverse order (see “TIGHTENING TORQUE”).
•After the complete re-assembly undo the locking. Pull on the cable stopper, wind out the cable complete and slowly rewind it.
•Before re-mounting at the operation area, please check for a correct performance.
TECHNICAL DATA
Our cable reels with their robust design are made for operating in factories and workshops. The sturdy plastic design, made from high-
quality materials, is completely electrically insulated, corrosion resistant and has very good winding characteristics. The cable reels come
as a standard without cable.
•Spiral spring for approx. 30. 000 operations
•Locking by reliable spring rest (only switch-off with FT version)
•Without slip ring / rotary join
•Without thermal safety guards
•Cable assembly
cable outer diameter[mm]
FT260/EFT265 pull-out length
FT 350 pull-out length
connection length
≤ 8
10m
17m
1,5m
≤ 10
8m
18m
1,2m
≤ 12
6m
20m
0,9m
•Cable stopper with segmented gentle clamp 6 –12mm / 6 –16mm
•Bracket / Fixing:
➢FT 260 Universal holder for wall or ceiling mounting
➢FT 350 serial holder for wall mounting (optional ceiling holder)
➢EFT 265 mounting holes 4 x Ø=6mm
•Ambient temperature range -25°C to 40°C
The specified range of ambient temperature applies only to the reels and not to the cable assembly or connectors. These are only part of
the delivery in exceptional cases. Specifications for plug-in connections can be found under the standard DIN EN 60390.
The dimensions, weights, lengths, coloures and traction are subject to modifications. We cannot rule out discrepancies and we reserve the
right to make technical changes to the product without giving advance notice.

automatic cable rewinder FT 260/350 - EFT 265 MFK
installation and operating instruction
installation and operating instruction FT 260_350-EFT 265 MFK - A5 page 5 01.04.2021
Schill GmbH & Co. KG; Bruckstraße 44; 70734 Fellbach www.schill.de
Additional information with respect to cable types, spring tensions, power loads and weights can be found on the product rating plate, in
our current product catalogue and on our website https://www.schill.de/en/
EXCHANGING THE PULL-OUT CABLE
•Disconnect the cable reel from the power supply and remove from the operation site.
•Loosen all the screws and remove the housing cover.
•Carefully remove the cover.
Attention
The spiral spring in the coil is under tension. Please ensure that the locking mechanism is activated.
•To replace the pull-out cable, you should make sure the spring is unwound for your own safety! Please adhere to the following
instruction:
1. Carefully pull on the cable stopper until the click of the notches have faded, you immediately notice a pull on the cable
stopper in the opposite direction.
2. Let the coil run back slowly and count the number of turns. This is important to adjust later the exact preload on the
spring again, without damage to coil or spiral spring. In the end the coil should be able to move freely.
3. Remove the damaged cable from the coil.
4. Remove strain relief.
5. Remove defective pull-out cable.
6. Remove the cable stopper and attach to the new cable.
•Undertake the re-assembly in reverse order (see “TIGHTENING TORQUE”).
•Adjust the pre-load:
Hold the stopper outside the housing and hold it with one hand. Now turn the coil as often as you counted. At the end let it snap
into the notches (see "LOCKING DEVICE").
•After the complete re-assembly undo the locking. Pull on the cable stopper, wind out the cable complete and slowly rewind it.
•Before re-mounting at the operation area, please check for a correct performance.
EXCHANGING THE SPIRAL SPRING
•Disconnect the cable reel from the power supply and remove from the operation site.
•Loosen all the screws and remove the housing cover.
•Carefully remove the cover.
Attention
The spiral spring in the coil is under tension. Please ensure that the locking mechanism is activated.
•To replace the pull-out cable, you should make sure the spring is unwound for your own safety! Please adhere to the following
instruction:
1. Carefully pull on the cable stopper until the click of the notches have faded, you immediately notice a pull on the
cable stopper in the opposite direction.
2. Let the coil run back slowly and count the number of turns. This is important to adjust later the exact preload on the
spring again, without damage to coil or spiral spring. In the end the coil should be able to move freely.
•Turn the drum and release the coil from the housing by undoing the centre screw.
•Put the coil on the side with the spring cover disc top. Remove the spring cover disk.
•Remove the plastic axle.
•Remove the defective spring.
•Carefully Re-assemble the coil. Undertake the Re-assembly in reverse order (see “TIGHTENING TORQUE”).
•If necessary, wind down the pull-out cable completely by turning the coil and insert the new spring. Pay attention to the
installation position!
•Insert the new spring. Pay attention to the installation position!
ATTENTION
Due to the manufacturing design the spring is under tension and could unwind very fast and cause injuries if handled
improper.
•Reinsert the plastic axle and assemble the spring cover disc. Ensure the retainer pin is engaging the spring eye.
•Adjust the pre-load:
Hold the stopper outside the housing and hold it with one hand. Now turn the coil as often as you counted. At the end let it snap
into the notches (see "LOCKING DEVICE").
•After the complete re-assembly undo the locking. Pull on the cable stopper, wind out the cable complete and slowly rewind it.
•Before re-mounting at the operation area, please check for a correct performance.

automatic cable rewinder FT 260/350 - EFT 265 MFK
installation and operating instruction
installation and operating instruction FT 260_350-EFT 265 MFK - A5 page 6 01.04.2021
Schill GmbH & Co. KG; Bruckstraße 44; 70734 Fellbach www.schill.de
INSTALLATION HEIGHT
The installation height of the cable rewinder is not limited. The maximum extension length is the specified cable length. The standard
cables are designed to withstand the weight of the extended cable included cable stopper. Additional tensile forces (cause by additional
weights for example) are not permitted.
When the cable is pull-out horizontally due to the weight of cable a slack occurs. This is about 10% of the cable pull-out length.
INSTALLATION INSTRUCTIONS FT 260
Wall mounting with universal holder DWB260
The cable reel can be rotated 150°
PLEASE NOTE
The cable reel housing must be pushed onto the universal holder pin, then insert
the slider into the intended position of the cable reel housing.
The universal holder DWB 260 is included in the scope of delivery, but no
fastening screws.
Ceiling mounting with universal holder DWB260
The cable reel can be rotated 360°.
PLEASE NOTE
The cable reel housing must be pushed onto the universal holder pin, then insert
the slider into the intended position of the cable reel housing.
Do not forget to fix the slider with the securing screw!
ATTENTION
If repeated over-tightening, the connection cable can be mechanically
stressed and torn off.
The universal holder DWB 260 is included in the scope of delivery, but no
fastening screws.

automatic cable rewinder FT 260/350 - EFT 265 MFK
installation and operating instruction
installation and operating instruction FT 260_350-EFT 265 MFK - A5 page 7 01.04.2021
Schill GmbH & Co. KG; Bruckstraße 44; 70734 Fellbach www.schill.de
INSTALLATION INSTRUCTIONS EST 265
EST 265 is screwed to the mounting surface via 4 holes on the housing.
INSTALLATION INSTRUCTIONS FT 350
Wall mounting with universal holder WB 038/350
The cable reel can be rotated 150°
PLEASE NOTE
Tighten screws (with spring ring and underlay) at the top and bottom with torque 40
Nm
Ceiling mounting with universal holder WB 038 / 350 and DB 038
The cable reel can be rotated 360°
Attention
in case of multiple overturns, the connecting cable can be mechanically loaded and, if
necessary, torn off.
The ceiling holder DB 038 is not included and is available as an accessory.

automatic cable rewinder FT 260/350 - EFT 265 MFK
installation and operating instruction
installation and operating instruction FT 260_350-EFT 265 MFK - A5 page 8 01.04.2021
Schill GmbH & Co. KG; Bruckstraße 44; 70734 Fellbach www.schill.de
Wall holder WB 038/350 Ceiling holder DB 350
The ceiling holder DB 038 is not included and is available as an
accessory.
Wall holder WB 038 is included in the scope of delivery,
but no fastening screws.
DIMENSIONS
FT 260

automatic cable rewinder FT 260/350 - EFT 265 MFK
installation and operating instruction
installation and operating instruction FT 260_350-EFT 265 MFK - A5 page 9 01.04.2021
Schill GmbH & Co. KG; Bruckstraße 44; 70734 Fellbach www.schill.de
EFT 265
FT 350
The dimensions, weights, lengths, coloures and traction are subject to modifications. We cannot rule out discrepancies and we reserve the
right to make technical changes to the product without giving advance notice.

automatic cable rewinder FT 260/350 - EFT 265 MFK
installation and operating instruction
installation and operating instruction FT 260_350-EFT 265 MFK - A5 page 10 01.04.2021
Schill GmbH & Co. KG; Bruckstraße 44; 70734 Fellbach www.schill.de
TIGHTENING TORQUE
Gehäuseschrauben
cover screws
0,8 Nm
electrical connections
electrical connections
0,5 Nm
Achsschraube
axle screw
1 Nm
MS grinding ring nut M3.5
MS slip ring nut M3,5
0,3 - 0,35 Nm
Strain
strain relief
0,8 Nm
MS Grinding Ring Screw M3
MS slip ring screw M3
0,6 - 0,7 Nm
Hosestopper
Cable stopper
0,8 Nm
DECLARATION OF CONFORMITY
Declarations of conformity are available upon request or at https://www.schill.de/en/downloads/
SPARE PART ORDER
If you require spare parts, please contact our local distribution partner or give us a ring on 0049 711/ 578807-0 or send a mail at
[email protected].
Please have the product number or the part number ready.
CONTACT
Administration Fellbach
Schill GmbH & Co. KG
Bruck Straße 44
70734 Fellbach
Telefon: [phone]
Telefax: [phone]
E-Mail: [email protected]
Manufacture Laichingen
Schill GmbH & Co. KG
Hirschstr. 81
89150 Laichingen
Telefon: [phone]
Telefax: [phone]
E-Mail: [email protected]
