Crestron DigitalMedia DM-CONN-ULTRA-PLUG-20 User manual

This guideexplains howtousetheDM-CONN-ULTRA-PLUG-20
Connectors withtheDM-CRIMP-ULTRA-PLUGTerminationTool,both
soldseparately.
TheCrestron®DM-CONN-ULTRA-PLUG-20is ashieldedCAT6aRJ-45
plugdesignedfor usewiththeDM-CONN-ULTRA-RECP-20/50andthe
DM-CONN-ULTRA-RECP-XA-20(45-DegreeAngled)Connectors (sold
separately)for DigitalMedia™ UltraCables (DM-CBL-8G and
DM-CBL-ULTRA,soldseparately).
Theterminationtool(DM-CRIMP-ULTRA-PLUG)is requiredto terminate
theDM-CONN-ULTRA-PLUG-20.
TheDM-CONN-ULTRA-PLUG-20ships in packs of20.Eachpackincludes
aplugbody,theoptionalbootandlatchprotector,andthetermination
moduletobeusedwiththetermination tool.
For simplicityinthis guide,theplugis referredto as the
DM-CONN-ULTRA-PLUG.
PreparetheCableforTermination
Flushcutters,aflatscrewdriver,ajacketstripper,andthetermination
tool(DM-CRIMP-ULTRA-PLUG)arenotincludedandarerequiredfor
cabletermination.
Prepare DM-CBL-8G Cable
CAUTION:Donot nickthefoilshieldor theinsulation ofthewires.
1. Striptheouter jacketof thecableabout2in.from theendof thecable.
2. Foldbackthefoilsothatitlies over thecablejacket.
3. Foldbackthedrainwireandwrapitaroundthefoilshield.
1
DM-CONN-ULTRA-PLUG-20 & Termination Tool
Connectors and Termination Tool for DigitalMedia™Ultra Cables

4. Usingflush cutters,removethemylar wrap.
5. Gentlyspreadthefour twistedpairs toexposethecenter spline.
6. Removethecenter spline.
Prepare the DM-CBL-ULTRA Cable
CAUTION:Donot nickthebraidshieldor theinsulation ofthewires.
1. Striptheouter jacketof thecableabout2in.from theendof thecable.
2. Foldbackthebraidshieldsothatitlies over thecablejacket.
3. Removethefoilshieldfrom eachof thefour twistedpairs.
4. Gentlypullthebraidshieldawayfrom thecable.Twistthebraidshield
together creatingathread-likewire,andthen wrapthebraidshield
wirearoundthecablejustabovethecablejacket,leavingabout1/2in.
offoilshieldvisible.
2
DM-CONN-ULTRA-PLUG-20 & Termination Tool QuickStart
Connectors and Termination Tool for DigitalMedia™Ultra Cables

Attach theWires to theTermination
Module
1. If usingtheoptionalbootandlatch protector,pullthecablethrough
thebootandlatchprotector beforecontinuing.
2. Gentlyspreadthetwistedpairs andarrangethepairs inlineprior to
insertingthem intothetermination module.
NOTE:For aT568Ascheme,leadwith thebrownandwhitepair and
then theorangeandwhite.For aT568Bscheme,leadwith thebrown
andwhitepair andthenthegreenandwhite.
3. Insert thewires of theDM-CBL-8G or theDM-CBL-ULTRAintothe
termination module,andthenpullthewires untilthebraidor foilshield
is seatedimmediatelybelowthewirechannels.
NOTE:Ensurethatanybraidedor foilshieldis foldedover thecable
jacket,wrappedinthedirectionof theclamp.
4. Press thewires to seat them beforeclosingtheclamp.With theclamp
positionedbelowtheshield,snaptheclampclosedusingeither your
fingers or theDM-CRIMP-ULTRA-PLUG terminationtoolto secure
thecable.Ifusingtheterminationtool,insertthewirewiththeclamp
sideupbeforepressingthetool.
3
DM-CONN-ULTRA-PLUG-20 & Termination Tool QuickStart
Connectors and Termination Tool for DigitalMedia™Ultra Cables

5. Laceallfour pairs intotheappropriatechannels on thetermination
module.Ensureeach wirelies belowthetopsurfaceof thetermination
module.
6. Usingflush cutters,cut thewires flushwiththeedgeof thechannels.
7. Trim theexcess DM-CBL-ULTRAbraidshieldor theexcess
DM-CBL-8G drainandfoilshield.
8. Attachtheplugbodyontotheterminationmodule,matchingtheplug
bodylatchtothetermination modulelatch.
4
DM-CONN-ULTRA-PLUG-20 & Termination Tool QuickStart
Connectors and Termination Tool for DigitalMedia™Ultra Cables

TerminatetheCable
1. InserttheDM-CONN-ULTRA-PLUGintothe
DM-CRIMP-ULTRA-PLUGterminationtool.
2. Press theDM-CONN-ULTRA-PLUGdowntofullyseatittothebaseof
theDM-CRIMP-ULTRA-PLUG terminationtool,then press thehandle
toterminatetheDM-CONN-ULTRA-PLUG.
3. If usingtheoptionalboot,engageboththetopandbottomlatches.
Dismantle the
DM-CONN-ULTRA-PLUG
DismantlingtheDM-CONN-ULTRA-PLUG connector requires removing
thebootandtheplugbody.
Remove the Boot
Usingascrewdriver,disengagethelatches onthebody oftheplugand
slidethebootoff thecable.
5
DM-CONN-ULTRA-PLUG-20 & Termination Tool QuickStart
Connectors and Termination Tool for DigitalMedia™Ultra Cables

Remove the Plug Body
1. InserttheDM-CONN-ULTRA-PLUGintothe
DM-CRIMP-ULTRA-PLUG as shown.Oncethe
DM-CONN-ULTRA-PLUGis inplace,pulltoremovetheplugbody.
2. Usingascrewdriver,opentheclampandremovelacedconductors.
NOTE:Aprobepic canbeusedtoremovethelacedconductors.
Visit theProduct Page
ScantheQRcodetovisittheproductpage.
DM-CONN-ULTRA-PLUG-20
www.crestron.com/model/6511276
DM-CRIMP-ULTRA-PLUG (TerminationTool)
www.crestron.com/model/6511278
