Schindler Cube Plus User manual

Cube Plus
USER’S MANUAL

INDEX
Fare clic o toccare qui per immettere una data.
1 - Foreword.................................................................................................................................... 3
1.1 - PACKAGE CONTENT ............................................................................................................. 3
3 - Warning and precautions............................................................................................................ 6
3.1 - SAFETY RULES ...................................................................................................................... 8
3.2 - PRECAUTIONS .................................................................................................................... 10
4 - Description .............................................................................................................................. 11
4.1 –Connectors DESCRIPTION .................................................................................................. 12
4.2 - LAN.................................................................................................................................... 12
4.3 - USB .................................................................................................................................... 12
5.1 - SIM CARD INSERTION ......................................................................................................... 13
5.2 - External antenna ................................................................................................................ 13
5.2.1 - Instructions for using the antenna ............................................................................... 13
6 - Power supply............................................................................................................................ 13
7 –Mounting Options.................................................................................................................... 15
7.1 - Wall Mounting.................................................................................................................... 15
7.2 - DIN Mounting..................................................................................................................... 15
8 –LABEL ...................................................................................................................................... 17

1 - Foreword
CB3 Basic EU - User Guide
3
1 - FOREWORD
We kindly require you to read this manual carefully in order to be able to use the CUBE PLUS (code AC GTW01)
device as well as possible.
This User Guide is related to all variants of the CUBE PLUS:
•CUBE PLUS AP
•CUBE PLUS NA
•CUBE PLUS XA
•CUBE PLUS XC
•CUBE PLUS XE
•CUBE PLUS WAN
1.1 - PACKAGE CONTENT
The product package contains the following material:
•CUBE PLUS
•Antenna
•User manual

1 - Foreword
CB3 Basic EU - User Guide
4
2- Technical features
2.1 PHYSICAL DESCRIPTION
SIZES
150mm x 134 mm x 48 mm (whole)
WEIGHT
311g
OPERATING TEMPERATURE
From –10°C to +65°C
HUMIDITY
From 0 to 95% not condensed
2.2 EXTERNAL CONNECTIONS
TELEPHONY
2-pole external terminal
LAN (4)
RJ45 connectors
RS232 (2)
RJ11 female connectors
USB
Type A USB
ANTENNA (2)
SMA female connector
POWER SUPPLY INPUT
12 ÷ 24 Vdc, 0.8 A max
RS485
3-pole external screw terminal
AUX-IN/OUT
4-pole external screw terminal
RST
Push Button
2.3 CONSUMPTION
AVERAGE CONSUMPTION
Standby/Typical application: 3,12W
Maximum application: 6,52W
2.4 FEATURES OF THE TELEPHONE (TA) CONNECTION POINT
INTERFACE
2-pole external terminal
CALL MODE
Originated call (MOC); Terminated call (MTC)
INPUT DIALLING
DTMF
COMPLIANT WITH
ETSI ES 201 970 V1.1.1
CALL CURRENT LEVEL (RING)
35Vrms ± 10% + 38Voffset
CALL CURRENT FREQUENCY
25Hz ± 5%
CALL CURRENT MODULATION
1,0s emission; 4,0s silence
LOCAL TONE MODULATION ACCURACY (EMISSION / SILENCE)
± 1%
SHORT CIRCUIT CURRENT
>35mA
TELEPHONE CONNECTION POINT CHARACTERISTIC IMPEDANCE
750Ω // 150nF + 270Ω
MAXIMUM TELEPHONE LINE LENGTH
500 meters (depending on the number of connected devices)
2.5 FEATURES OF THE LAN CONNECTION POINT
INTERFACE
4 x RJ45 (LAN 10/100)
COMPATIBILITY
IEEE 802.3
2.6 FEATURES OF THE RS232 CONNECTION POINT
INTERFACE
RJ11 CONNECTOR
COMPATIBILITY
RS232
2.7 FEATURES OF THE RS485 CONNECTION POINT
INTERFACE
3-pole external screw terminal
COMPATIBILITY
RS485
2.8 FEATURES OF THE USB CONNECTION POINT
INTERFACE
Type A connector
COMPATIBILITY
USB 2.0
CUBE PLUS XE
2.9.1 MODEM PERFORMANCES
BAND
FDD B1/B3/B7/B8/B20/B28A;
WCDMA B1/B3/B8; GSM/EDGE B3/B8
RF power
2G (GSM): - LB: Class 4(2W, 33dBm ± 2dB)
Class E2(0.5W, 27dBm ± 3dB
@EDGE)
HB: Class 1(1W, 30Bm ± 2dB)
Class E2(0.4W, 26dBm +3/-4 dB
@EDGE)
3G (WCDMA): Class 3(0.25W, 24dBm +1,7/-
3,7 dB)
4G (FDD & TDD): Class 3(0.2W, 23dBm ± 2,7
dB @1RB))
DATA TRANSFER
LTE category 4
LTE FDD: Max 150Mbps (DL)/Max 50Mbps
(UL)
DC-HSPA+ 42 Mbps)
Modulation
E-GSM/DCS: GMSK, 8PSK
UMTS: QPSK
LTE: QPSK, 16 QAM and 64 QAM
2.10.1 BLUETOOTH
Frequency range
2402 ÷ 2480 MHz
RF power
BLE: 8.2 dBm
Modulation
GFSK

1 - Foreword
CB3 Basic EU - User Guide
5
CUBE PLUS XA
2.9.2 MODEM PERFORMANCES
BAND
FDD B1/B2/B3/B4/B5/B7/B28A;
WCDMA B1/B2/B4/B5;
GSM/EDGE B2/B3/B5/B8
RF power
2G (GSM): - LB: Class 4(2W, 33dBm ± 2dB)
Class E2(0.5W, 27dBm ± 3dB
@EDGE)
HB: Class 1(1W, 30Bm ± 2dB)
Class E2(0.4W, 26dBm +3/-4 dB
@EDGE)
3G (WCDMA): Class 3(0.25W, 24dBm +1,7/-
3,7 dB)
4G (FDD & TDD): Class 3(0.2W, 23dBm ± 2,7
dB @1RB))
DATA TRANSFER
LTE category 4
LTE FDD: Max 150Mbps (DL)/Max 50Mbps
(UL)
DC-HSPA+ 42 Mbps)
Modulation
E-GSM/DCS: GMSK, 8PSK
UMTS: QPSK
LTE: QPSK, 16 QAM and 64 QAM
2.10.2 BLUETOOTH
Frequency range
2402 ÷ 2480 MHz
RF power
BLE: 8.2 dBm
Modulation
GFSK
CUBE PLUS AP
2.9.3 MODEM PERFORMANCES
BAND
WCDMA B1,B5,B6,B19,B8
FDD B1,B3,B5,B8,B9,B18(B26), B19,B28
RF power
3G (WCDMA): Class 3(0.25W, 24dBm +1,7/-
3,7 dB)
4G (FDD & TDD): Class 3(0.2W, 23dBm ± 2,7
dB @1RB))
DATA TRANSFER
LTE category 4
LTE FDD: Max 150Mbps (DL)/Max 50Mbps
(UL)
DC-HSPA+ 42 Mbps)
Modulation
UMTS: QPSK
LTE: QPSK, 16 QAM and 64 QAM
2.10.3 BLUETOOTH
Frequency range
2402 ÷ 2480 MHz
RF power
BLE: 8.2 dBm
Modulation
GFSK

3 - Warning and precautions
CB3 Basic EU - User Guide
6
3 - WARNING AND PRECAUTIONS
This product may be installed by qualified personnel only.
INFORMATION TO THE CUSTOMERS OF PROFESSIONAL EQUIPMENT
To the senses of the art. 13 of the Decree Legislative 25 July 2005, n. 151 “Realization of the Directives
2002/95/CE, 2002/96/CE and 2003/108/CE, related to the reduction of the use of dangerous substances in
the electric equipments and electronics, as well as to the disposal of the refusals”
The symbol of the crossed bin, printed on the equipment or on its package, points out that the product at
the end of its life cycle must be separately picked up from the other refusals.
Particularly, the diversified collection of the present equipment, reached to the end of life, is organized and
managed:
a) directly from the customer, in the case in which he decides to unravel of equipment without replacing it
with a new equipment, equivalent and having the same functions;
b) from the producer, understood as the subject that has first introduced and commercialized in Italy or
resells in Italy with his own mark the new equipment that has replaced the preceding one, in the case in
which, contextually to the decision to unravel of the equipment, reached to the end of life, the consumer
purchase a product type equivalent and having the same functions. In such last case the consumer can ask
to the producer for the withdrawal of the present equipment within and not over 15 consecutive calendar
days from the delivery of mentioned new equipment.
The suitable diversified collection of the disused equipment for recycling, to the treatment and the
compatible environmental disposal, contributes to avoid possible negative effects on the environment and
on the people health and it favors the reemploy e/o recycle of some materials of which the equipment is
composed.
The unauthorized disposal of equipments from the consumer behaves the application of the sanctions
according to the normative of the current law.
CUBE PLUS XE
On what concerns CE, the equipment must be compliant with essential safety requirements and this has
to be guaranteed by manufacturer or directly by the Company that takes under its responsibility the
direct launch of the equipment itself on the market with its brand name or as an importer.
The product has to meet to certain and specific safety requirements for people, goods, animals and often
for environmental needs as well. These last requirements are the main and essential ones and are
established by European harmonization directives applicable in all the 27 member countries of EU and in
other 3 countries member of the so-called European Economic Area (Norway, Iceland and Liechtenstein).

3 - Warning and precautions
CB3 Basic EU - User Guide
7
Product compliance with main requirements has been evaluated and checked by the manufacturer by
following specific procedures (Conformity Clearance Procedure), whose content is specified by each
single harmonization directive.
•(Vdc) –Direct current
CUBE PLUS XA
Contains FCC ID: 2AZ9H-CUBEPXA
Contains FCC ID: RI7LE910CXLA
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
This product complies with FCC and ISED radiation exposure limits set forth for an uncontrolled
environment. The antenna should be installed and operated with minimum distance of 20 cm between
the radiator and your body.
XXXX-XX-XXXXX
Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar
interferência em sistemas devidante autorizados
CUBE PLUS AP

3 - Warning and precautions
CB3 Basic EU - User Guide
8
Sp
3.1 - SAFETY RULES
The passage from a cold room to a warm one may cause condensate to build up inside the device.
In these cases, it is recommended to wait at least 1 hour before using the product in order to avoid
any malfunction.
Attention: connect the equipment with an outlet installed in the immediate proximity and easily
accessible for the operator. Under no circumstance, it is allowed to cut the mains plug to connect
the equipment securely.
Attention: electrical shock risk. The power supply used for this device requires lethal voltage levels.
The case includes a connection compartment and arrangements. You may have access to it after
having removed a closure cover by means of a tool. The underlying protection against direct
contacts with live parts shall never be removed, except for authorised technicians.
Avoid having access to the internal parts of the device.
If any object or liquid should penetrate the device, detach the power supply cable immediately.
Before reusing the device, have it checked by qualified personnel.
For assistance, please apply to qualified personnel.
In case of intervention, always make sure that the device is completely and efficaciously
disconnected.
In case of fire, avoid using water as an extinguisher.
Since the GSM system is a radiofrequency technology (RF), it may interfere with the operation of any
other phone set or electronic device which is not properly protected against radiofrequency energy.
CUBE PLUS shall be arranged at least 2 m far from any electronic equipment (telephone set, etc) to
avoid any interference problems.
Never put your hands on the antenna when the device is in use.
Never use the device if the antenna is visually damaged. In this case, ask for a replacement through
the customer-care service.
During the CUBE PLUS functioning, you should keep at least at 20cm far from the antenna.

3 - Warning and precautions
CB3 Basic EU - User Guide
9
People with auxiliary systems such as pacemakers and electro acoustic devices (hearing aids) should
keep at a safe distance.
Plug RS485, DIDO, FXS, PWR UART ports, even if not used, with the correct connector.

3 - Warning and precautions
CB3 Basic EU - User Guide
10
3.2 - PRECAUTIONS
Attention: many of the components used in this device are sensitive to electrostatic discharges.
If you should handle connection cables, please disconnect the device and avoid any direct contact
with the terminals of conductors.
For cleaning operations use a soft and dry piece of cloth or a piece of cloth soaked in a light
detergent solution. Never use any type of solvent, such as alcohol or gasoline, in order to avoid
damaging any finish.
The non-observance of the precautions might permanently damage the device.
The CUBE PLUS-EU device will be installed within restricted access area and it is accessible only by
highly qualified staff.

4 - Description
CB3 Basic EU - User Guide
11
4 - DESCRIPTION
CUBE PLUS is the easiest way to get telecommunication services to premises that cannot be reached by
telephone landlines, but where there is adequate cellular telephone coverage.
Through the mobile network, CUBE PLUS allows you to make/receive calls from standard telephones, PBX,
fax, modem, without difference with respect to a standard PSTN line.
Voice, data and fax services require different phone numbers: during the installation the end-user will be
assigned three different phone numbers, for voice, data and fax reception respectively.
When making a call (both voice, data or fax), CUBE PLUS uses the main number (the voice number), while in
order to receive a data or fax call, it is necessary that CUBE PLUS is called on its corresponding data or fax
number.

4 - Description
CB3 Basic EU - User Guide
12
4.1 –CONNECTORS DESCRIPTION
CUBE PLUS is arranged in a plastic case that shall be fastened to the wall by qualified installers.
Connectors and lighted signals are arranged on two sides: at the bottom and in the front.
The following is arranged at the bottom:
(1) Diversity antenna
(2) RS232 connection
(3) Digital input and digital output
(4) RESET Push Button
(5) MAIN antenna
(6) RS485 connection point
(7) Sim holder
(8) RJ45 (4x) 10/100 connectors
(9) USB 2.0
(10) RS232 connection
(11) FXS Telephony connection
(12) Power supply 8-28 Vdc and RS232 (TX & RX)
4.2- LAN
Four LAN 10/100 (type RJ45) socket is arranged on the CUBE PLUS.
Use a LAN 10/100 cat.5 network cable and connect it to the device’s LAN socket.
4.3- USB
Two USB host v2.0 sockets (A type) are arranged on the CUBE PLUS.
The USB ports allow you to connect an USB equipments like USB memory key, also running at different speed
(high speed and full speed).
1
2
3
4
5
6
7
9
8
11
12
10

6 - Power supply
CB3 Basic EU - User Guide
13
5- Connection and commissioning
5.1 - SIM CARD INSERTION
To have access to the SIM card compartment, it is necessary to remove the rubber cover
of the device and then to insert the SIM card with the circuit facing down and the beveled
corner must be to the upper left, as shown in the figure.
5.2 - EXTERNAL ANTENNA
The antenna supplied might fail to provide for an optimal reception of the RF signal in well-defined operating
conditions. For this reason, CUBE PLUS is also arranged to operate with an external omnidirectional antenna.
The antenna includes a dipole, a wall fixing metal bracket and an extension cable.
IMPORTANT: the external antenna installation should be performed by qualified personnel only.
The external antenna should have the following properties:
-Frequency Range ( MHz) : 698～960/1710～2690
-VSWR. ≤2.0
-Gain peak ( dBi): ¼
-Input Impedance(Ω): 50
-Polarization: Vertical
-Connector Type: SMA-J
5.2.1 - Instructions for using the antenna
The antenna shall be arranged at least 2 m far from any electronic equipment that may be available in the
environment and at least 15 cm far from any obstacle. It shall be put into such a position that it can provide
for a good reception of the radio field.
If the local equipment should start showing any malfunction or disturbance when the equipment is in use,
move the antenna to another place.
Avoid using the monopole when the equipment is installed in a closed or particularly shielding environment.
Use the external antennas with a nominal impedance of 50.
Never put your hands on the antenna when the device is in use. This may compromise the quality of the
connection and force CUBE PLUS to require a higher transmission power.
Never use CUBE PLUS if the antenna is visually damaged. In this case, it shall be replaced without any delay.
6 - POWER SUPPLY
The interface can be supplied by direct current with a 12-24 Vdc nominal voltage.
Equipment is intended to be supplied by d.c. power supply having a transient voltage of 1500 Vpeak

6 - Power supply
CB3 Basic EU - User Guide
14
The equipment shall be powered by ES1 d.c. power supply at 12-24 Vdc and protected by means of external
fuse rated 2 A placed on positive terminal.

7 –Mounting Options
CB3 Basic EU - User Guide
15
7 –MOUNTING OPTIONS
7.1 - WALL MOUNTING
Use the appropriate holes in the fixing tabs to screw n.2 screw #12 or M5
7.2 - DIN MOUNTING
1. Lift the DIN hook by pressing on the tab and pulling up
2. Hook the box to the DIN rail as follow:
a. Place the Cube on the DIN rail
1
2

7 –Mounting Options
CB3 Basic EU - User Guide
16
b. Push down the hook
c. The Cube is hooked

8 –LABEL
CB3 Basic EU - User Guide
17
8 –LABEL
-CUBE PLUS XE

8 –LABEL
CB3 Basic EU - User Guide
18
-CUBE PLUS XA

8 –LABEL
CB3 Basic EU - User Guide
19
CUBE PLUS
-CUBE PLUS AP
