Autonics SCM-WF48 User manual

S-31
(A)
electric
sensor
(B)
Fiber
optic
sensor
(C)
Door/Area
sensor
(D)
Proximity
sensor
(E)
Pressure
sensor
(F)
Rotary
encoder
(G)
Connector/
Socket
(H)
Temp.
controller
(I)
SSR/
Power
controller
(J)
Counter
(K)
Timer
(L)
Panel
meter
(M)
Tacho/
Speed/ Pulse
meter
(N)
Display
unit
(O)
Sensor
controller
(P)
Switching
mode power
supply
(Q)
Stepper
motor&
Driver&Controller
(R)
Graphic/
Logic
panel
(S)
Field
network
device
(T)
Software
(U)
Other
Communication Converter
SCM-38I
SCM-US48I
SCM-US
※Specifically designed to connect to
particular Autonics and Konics products
which support the PC loader port.
SCM-WF48
Wi-Fi/RS485, USB wireless communication converter
(converting Wi-Fi to RS485, USB)
Features
Converting USB or RS485 signal to Wi-Fi signal and wireless
communication up to max. 100m
Compact size(W48×H25.3×L76mm, excepting antenna)
Built-in surge protection circuit,
reverse polarity protection circuit
Supports AP mode and infrastructure mode
DIN rail and panel mounting
(available soon)
SCM Series
(pending)
Features
● Available to transmit signals to max. 1.2km by
converting USB signal to RS485 signal
● Realizing electrical insulation(2500V RMS) between
USB port and RS485 port through RS485 transceiver.
● Improved stability and durability with built-in protection circuit
● Easy connections between devices with bus power supplied
from USB host controller without external power supply
● Offering USB 2.0 A/B type cable with built-in ferrite core
for noise reduction
● Various operating systems supported
(Windows 98, 98SE, ME, 2000, Server 2003, XP, Vista, 7)
● User friendly features through compatibility with USB 1.1 and USB 2.0
USB to Serial converter(converting signal USB to Serial)
Features
● Built-in surge protection circuit
● The insulation type of signal line
(Insulating RS232C and RS485)
● Create Tx-Enable signal automatically
RS232C to RS485 converter(converting signal RS232C to RS485)
Features
● Applicable OS : Windows 98, 98SE, ME, 2000,
Server 2003, XP, Vista, 7
● Both USB 1.1 and USB 2.0 compatible
● Data transmission / power supply indicating LED
● Easy to connect with PC
● Built-in protection circuit
● Ferrite core cable for noise reduction
● Non-isolation type
USB to Serial converter(converting signal USB to Serial)
Please read “Caution for your safety” in operation
manual before using.

S-32
SCM Series
RS485 communication specifications
Connection RS485
Standard EIA RS485
Protocol Modbus RTU
Com. method 2-wire half duplex
Synchronous method Asynchronous
Effective com.
distance Max. 800m
Com. speed※1
4800, 9600, 19200, 38400, 57600,
115200bps
(factory default: 115200bps)
Data bit※15bit,6bit,7bit,8bit(factory default:8bit)
Stop bit※11bit, 2bit(factory default: 1bit)
Parity bit※1None, Even, Odd(factory default: None)
Multi-drop Max. 31 Multi-drop
Connection type 4-wire screw terminal
(2-wire communication method)
※1: You can set this by DAQMaster.
Wi-Fi communication specifications
Protocol TCP/IP(IPv4)
Standard 802.11 b/g/n(IEEE 802.11b) compatible
Com. speed Max. 11 Mbps
Frequency range 2.4 to 2.497 GHz
Security WEP, WPA, WPA2-PSK, Enterprise
Antenna 2dBi external antenna
Com. distance Max. 100 m
USB communication specifications
Power 5 V, 500 mA
Standard USB 2.0(compatible sub-transmission)
Com. method 2-wire half duplex
Connections USB 2.0 Mini 5P type(Male)
SCM-WF48
Model SCM-WF48
Power supply 24VDC
Allowable voltage range 12-28VDC
Communication type RS485, USB, Wi-Fi
Isolation resistance Min. 200 MΩ(at 500 VDC megger between external terminal and case)
Protection circuit Reverse polarity protection circuit, surge protection circuit
Dielectric strength 1,000VAC 50/60Hz for 1 min.(between external terminal and case)
Noise resistance ±500 V the square wave noise(pulse width: 1㎲) by the noise simulator
Vibration 1.5 mm amplitude at frequency or 300m/s2 of 10 to 55 Hz(for 1min.) in each of X, Y, Z directions for 2 hours
Shock 500m/s2(approx. 50G) in each of X, Y, Z directions for 3 times
Environ
-ment
Ambient
temperature -10 to 55℃, storage: -20 to 60℃
Ambient humidity 35 to 80%RH, storage: 35 to 80%RH
Protection IP20(IEC standards)
Mounting DIN rail or panel mounting
Accessories USB 2.0 Mini 5P type cable (length: 1 m),
Connector for RS-485 (4-pin, male type) 1EA
Weight※1Approx. 160g(approx. 57g)
※1: The weight is with packaging and the weight in parentheses is only unit weight.
※Environment resistance is rated at no freezing or condensation.
SCM-US48I / SCM-38I / SCM-US
Specifications
Model SCM-US48I SCM-38I SCM-US
Power supply 5VDC USB bus Power 12-24VDC ± 10% 5VDC USB bus Power※1
Power consumption Max. 1W Max. 1.7W Max. 1W
Max. com speed※21,200 to 115,200bps(Recommended : 9,600bps)
Communication type Half duplex type
Available com. distance USB: Max. 1m ± 30%
RS485: Max.1.2km Max. 1.2km 1.5m(not extension)
Multi-drop Max. 31 multi-drop
-
Protocol※2
Data bit 5 to 8 data bits -
Stop bit 1 or 2 stop bits -
Parity bit None/Odd/Even -
Connection type
USB: B type connector RS232: D-sub 9Pin USB: A type connector
RS485: 4-wire screw terminal(2wire communication type) Earphone jack(4 pole stereo phone
plug)
Isolation type Isolation Non-isolation
Dielectric strength
●Between terminals and case:
200VAC 50/60Hz for 1 min.
●Between USB and RS485:
2500VAC 50/60Hz for 1 min.
●Between terminals and case:
200VAC 50/60Hz for 1 min.
●Between RS232C and RS485:
2500VAC 50/60Hz for 1 min.
-
※1: USB bus power is supplied from PC or USB host controller.
※2: Protocol and communication speed are set by Hyper terminal. DAQMaster, ParaSet, Modbus Poll.
When communicating with Autonics products, set communication speed to 9,600bps.

S-33
(A)
electric
sensor
(B)
Fiber
optic
sensor
(C)
Door/Area
sensor
(D)
Proximity
sensor
(E)
Pressure
sensor
(F)
Rotary
encoder
(G)
Connector/
Socket
(H)
Temp.
controller
(I)
SSR/
Power
controller
(J)
Counter
(K)
Timer
(L)
Panel
meter
(M)
Tacho/
Speed/ Pulse
meter
(N)
Display
unit
(O)
Sensor
controller
(P)
Switching
mode power
supply
(Q)
Stepper
motor&
Driver&Controller
(R)
Graphic/
Logic
panel
(S)
Field
network
device
(T)
Software
(U)
Other
Communication Converter
SCM-WF48 1.Wi-Fi antenna
: Antenna for transmitting and receiving Wi-Fi communication
data. It may be broken when excessive pressure is applied.
2. Fixing screw hole
: Used for mounting the unit on a panel.
3. Rail Lock
: Used for fixing this unit at DIN rail mounting.
4. Communication method switch
: Switch for select communication method.
6. Indicator
: Indicator for statue of AP mode and Infrastructure mode.
7. RS485 connector: Used for connecting RS485 communication cable.
8. USB connector: Used for connecting a PC, etc. with an USB cable.
Mode
Status AP mode Infrastructure mode
Red ON Initial error※1Try to AP connection
Green ON AP ready
AP connection is complete
Orange ON Protocol socket error※2
OFF Power is not supplied.
5. Terminating resistance switch
: Switch for whether using terminating resistance.
※It is applied only when selecting RS485 communicaiton method.
※Specifications of terminating resistance: 120 Ω, 1%(F) grade chip
resistance, 1/4 W
[RT]: It uses terminating resistances.
[OFF]: It does not use terminating resis-
tance.
RT OFF
(default)
4
1
2
3
5
6
7
8
USB RS485
(default)
For setting SCM-WF48I by DAQMater, select USB communication
method.
Integrated device management program (DAQMaster)
DAQMaster is the integrated device management program. Set the communication method switch of SCM-WF48 as
USB, and connect this unit and a PC with USB cable.
You can set the communication setting for SCM-WF48 by DAQMaster.
Visit our website (www.autonics.com) and download DAQMaster.
※There might be some differences in the specication above depending on PC environment.
※Environment resistance is rated at no freezing or condensation.
SCM-US48I / SCM-38I / SCM-US
Specifications
Part descriptions
Item Minimum requirements
System IBM PC compatible computer with Intel Pentium Ⅲ or above
Operating system Microsoft Windows 98/NT/XP/Vista/7
Memory 256MB or more
Hard disk More than 1GB of free hard disk space
VGA 1024×768 or higher resolution display
Others RS-232 serial port(9-pin), USB port
※1: Re-set AP mode with DAQMaster.
※2: Re-supply the power to server and client.
※When power is supplied, this green/red indicator flashes 3 to 4
times in turn.
Model SCM-US48I SCM-38I SCM-US
Insulation resistance Min. 100MΩ(at 500VDC megger)
-
Noise strength ±500V the square wave noise(pulse width: 1㎲) by the noise simulator -
Vibration Mechanical 0.75mm amplitude at frequency of 10 to 55Hz in each of X, Y, Z directions for 1 hour
Malfunction 0.5mm amplitude at frequency of 10 to 55Hz in each of X, Y, Z directions for 10 minutes
Shock Mechanical 300m/s2 (approx. 30G) in each of X, Y, Z directions for 3 times
Malfunction 100m/s2 (approx. 10G) in each of X, Y, Z directions for 3 times
Environ
-ment
Ambient temperature -10 to 55℃, storage: -20 to 60℃
Ambient humidity 35 to 85%RH, storage: 35 to 85%RH
Approval
Accessory USB 2.0 AB type connector
(length: 1m)
-
Unit weight Approx. 34.5g Approx. 46g Approx. 41g

S-34
SCM Series
20±5 20±5
1,000±30
USB B Type USB A Type
USB 2.0 AB type cable
(unit: mm)
98
25.3
76
41.3
2-Ø3.5
28
39
45
SCM-WF48
SCM-US48I
3-Ø4
38
75.5
39
25.6
23.5
Dimensions
※USB 2.0 AB type cable is including the product and is also sold separately.
(model: USB AB CABLE)
(unit: mm)
(unit: mm)

S-35
(A)
electric
sensor
(B)
Fiber
optic
sensor
(C)
Door/Area
sensor
(D)
Proximity
sensor
(E)
Pressure
sensor
(F)
Rotary
encoder
(G)
Connector/
Socket
(H)
Temp.
controller
(I)
SSR/
Power
controller
(J)
Counter
(K)
Timer
(L)
Panel
meter
(M)
Tacho/
Speed/ Pulse
meter
(N)
Display
unit
(O)
Sensor
controller
(P)
Switching
mode power
supply
(Q)
Stepper
motor&
Driver&Controller
(R)
Graphic/
Logic
panel
(S)
Field
network
device
(T)
Software
(U)
Other
Communication Converter
※LED indicator
1. O.P.R: Power
2. A.C.C: Rx/Tx data transmission
52
40.3
18
12
8
8
4.5
1 2
Ø2.5×4P-1.5m
VCC
R×D GND
T×D
12
18
O.P.R
A C.C
SCM-US
SCM-US48I & SCM-38I
'B'(Length of screw) "A" size
(23N+0.5)
"B" size
(23N-3)
1 23.5mm 20mm
2 46.5mm 43mm
3 69.5mm 66mm
4 92.5mm 89mm
There is no Serial Port in SCM-US48I..
'B'(Length of screw)
M3 screw bolt
Panel
'A'(Height of layer)
Installations
SCM-WF48
Mounting
1) Hang up the backside holder on a DIN rail.
2) Press the unit toward ① direction until it snaps.
Removing
1) Pull rail locks of the backside of this unit to ②
direction.
2) Pull the unit to ③ direction
1) This unit is able to mount on a panel with two fixing screws at center of both sides.
2) For mounting the unit, use M3 screws. Tighten screws with 0.4 N.m torque.
①
②
Rail Lock DIN rail
Fixing screw
hole
③ Mounting to and removing from DIN rail
Mounting to panel
SCM-38I3-Ø4
38
75.5
81.7
39
89
23.5
25.6
Dimensions
(unit: mm)
(unit: mm)

S-36
SCM Series
Cable connection
Connection of SCM-WF48 and Multi-drop
SCM-WF48
USB Mini 5P
(Male) type
USB A(Male)
type
A B V G
+RS485
-RS485
Ground
24VDC
SCM-WF48
SCM-WF48
B(-)
A(+)
ON OFF
GND
V(12-24VDC)
Terminating
resistance (120Ω)
A(+) B(-) A(+) B(-) A(+) B(-)
RS485
DEVICE
#1
A(+)
B(-)
...
RS485
DEVICE
#2
RS485
DEVICE
#30
RS485
DEVICE
#31
AP mode
Infrastructure mode
SCM-WF48
SCM-WF48
Wireless router
※One wireless router can connect
max. up to 254 units of SCM-WF48.
Wi-Fi or LAN
connection Wi-Fi RS485
RS485
※Before using this unit, set the communication method switch of SCM-WF48 as USB, and connect this unit and a PC with USB cable.
You can set the communication setting for SCM-WF48 by DAQMaster.
SCM-WF48
Wi-Fi or USB
connection RS485 Connectable max. 31 units of
Autonics products which support
communication
Wi-Fi
Example of connections
Computer
Computer
Computer
Connectable max. 31 units of
Autonics products which support
communication
Connectable max. 31 units of
Autonics products which support
communication

S-37
(A)
electric
sensor
(B)
Fiber
optic
sensor
(C)
Door/Area
sensor
(D)
Proximity
sensor
(E)
Pressure
sensor
(F)
Rotary
encoder
(G)
Connector/
Socket
(H)
Temp.
controller
(I)
SSR/
Power
controller
(J)
Counter
(K)
Timer
(L)
Panel
meter
(M)
Tacho/
Speed/ Pulse
meter
(N)
Display
unit
(O)
Sensor
controller
(P)
Switching
mode power
supply
(Q)
Stepper
motor&
Driver&Controller
(R)
Graphic/
Logic
panel
(S)
Field
network
device
(T)
Software
(U)
Other
Communication Converter
SCM-US
Computer
USB
Serial
Autonics and Konics products
which support the PC loader port
USB A Type
SCM-38I
G: GROUND
V: 12-24VDC input
RS485 signal line
B(-)
A(+)
A B V G
ON OFF
● Terminating resistance selection
ON: Using terminating resistance
OFF: Not using terminating resistance
● Multi-drop connection method with PC
Computer
RS232C RS485
R×D-R×D
T×D-T×D
GND-GND
RS485
DEVICE
#1
RS485
DEVICE
#2
RS485
DEVICE
#30
RS485
DEVICE
#31
RS232C Cable
...
B(-)
GND
VCC
(12-24VDC)
A(+) B(-) A(+) B(-) A(+) B(-)
B(-)
A(+)
Terminating
resistance
(100 to 120Ω)
A(+)
ON OFF
● RS232C cable connection
①① ①①
②② ②②
⑥⑥
⑥⑥
⑦⑦ ⑦⑦
⑧⑧ ⑧⑧
⑨⑨ ⑨⑨
③③ ③③
④④
④④
⑤⑤
⑤⑤
Computer Computer
<Standard connection> <Using Auto-loop Back>
DCD
DSR
RXD
RTS
TXD
CTS
DTR
RI
GND
DCD
DSR
RXD
RTS
TXD
CTS
DTR
RI
GND
SCM-38I SCM-38I
※When the software of the communication driver uses Auto-loop Back, please connect as the above.
SCM-48I
Computer
USB RS485
B(-)
A(+)
ON OFF
USB B Type
A(+) B(-) A(+) B(-) A(+) B(-)
B(-)
A(+)
RS485
DEVICE
#1
RS485
DEVICE
#2
RS485
DEVICE
#30
RS485
DEVICE
#31
Terminating
resistance
(100 to 120Ω)

S-38
SCM Series
Driver installation (SCM-WF48, SCM-US48I, SCM-US)
USB Driver Installation
1) Visit our website(www.autonics.com) to download USB
Driver.
2) Unzip the downloaded 'SCM-WF48.zip', 'SCM-US48I.
zip', or 'SCM-US.zip' at any directory.
3) When connecting product with USB port, 'Found
New Hardware Wizard" will appear automatically. 'Do
you want to search software by connecting 'Window
Update'?. Click 'No' button and the following window will
be displayed to proceed Driver installation.
Select 'Install from a list or specific location' (Advanced)'
(S) and click 'Next'.
4)Select 'Search for best driver in these locations' and
'include this location in the search' continuously.
Click the 'Browse' button.
5)When 'Browse Folder' window is displayed, select 'SCM-
WF48\Driver' for SCM-WF48, or 'SCM-US\Driver' for
SCM-US48I, SCM-US, and click 'Finish'. Click 'Next' to
proceed with the USB Driver installation.
6) Hardware installation message will appear while Found
New Hardware Wizard is running. Click 'Continue
Anyway' to proceed with installation.
7) The following window will be displayed if the USB Driver
is installed properly. Click the 'Finish' button.

S-39
(A)
electric
sensor
(B)
Fiber
optic
sensor
(C)
Door/Area
sensor
(D)
Proximity
sensor
(E)
Pressure
sensor
(F)
Rotary
encoder
(G)
Connector/
Socket
(H)
Temp.
controller
(I)
SSR/
Power
controller
(J)
Counter
(K)
Timer
(L)
Panel
meter
(M)
Tacho/
Speed/ Pulse
meter
(N)
Display
unit
(O)
Sensor
controller
(P)
Switching
mode power
supply
(Q)
Stepper
motor&
Driver&Controller
(R)
Graphic/
Logic
panel
(S)
Field
network
device
(T)
Software
(U)
Other
Communication Converter
※This Driver Installation is described based on the
procedure for Windows XP.
There might be some differences in the specification
above depending on OS.
Serial Port Driver Installation
1) After installing USB Driver, Serial Port (COM port),
'Found New Hardware Wizard' will appear (Serial
Port Driver installation follows the same procedures
described in installing USB Driver).
2) After selecting 'Install from a list or specific location
(advance)', click 'Next' button. The following window will
be displayed for 'Search and installation options'
3) Because a driver location was selected when installing
USB driver, click 'Next' button.
4)Hardware installation message will appear while Found
New Hardware Wizard is running. Click 'Continue
Anyway' to proceed with installation.
5)'Completing the Found New Hardware wizard' will be
displayed if the Serial Port Driver is installed properly.
Click the 'Finish' button.
※Verify that drivers were installed properly with the
windows Device Manager after finishing USB Driver and
Serial Port Driver installation.
Open the folder [My computer], open the system folder
(click right), click the hardware tab, and click the Device
Manager Button. Then, make sure that 'SCM-WF48
Driver(Autonics Corp)', 'SCM-US48I Driver(Autonics
Corp)' or 'SCM-US Driver(Autonics Corp)' is found in
'Common Serial Bus Controller' category and 'Port (COM
and LPT) is found in 'SCM-WF48 Serial Port (COM □)',
'SCM-US48I Serial Port(COM ) or 'SCM-US Serial
Port(COM )'.

S-40
SCM Series
Proper usage
● In case of connecting PC with SCM-WF48, SCM-US48I or SCM-US, when changing PC USB port and connecting this
unit to another (changed) USB port, USB driver will be reinstalled. This is not a malfunction.
● When connecting SCM-US or SCM-US48I communication module, please connect PC first. Then, connect RS485
communication product afterward. When disconnecting the units, remove the unit in reverse order.
● Using the Twisted pair cable (AWG24), which is suitable to RS485 communication is recommended. If the Twisted pair
cable is not used, be sure preserving identically the length of A(+) and B(-) cables.
● After connecting SCM-WF48 with RS485 communication DEVICE, be sure to attach the terminating resistor (120Ω).
After connecting SCM-38I, SCM-US48I with RS485 communication DEVICE, be sure to attach the terminating resistor
(100 to 120Ω).
● In case of connect PC with SCM-WF48, SCM-US48I, or SCM-US , No. of COM Port will be numbered in order.
This is not a malfunction. (e.g. COM 14, COM 15, ..., COM 256)
● When connecting SCM-WF48, SCM-US48I or SCM-US with USB cable, check COM port number before communication.
It may take some time for computer to detect the cable after the cable is connected. (This is not a malfunction.)
● When connecting PC with SCM-WF48, SCM-48I or SCM-US, do not use the extension cable to extend USB cable length.
It may cause a malfunctions.
● Be cautious when using SCM-WF48 or SCM-US as non-isolated type.
Check the connection, disconnection and short of communication cable before supplying the power to SCM-WF48.
● Only use Autonics products that are available for SCM-US.
● Observe the rated voltage.
● To avoid malfunctions due to noise, do not place the unit close to a high-voltage power line.
● Proper application environment
(Avoid following environments for unit to be used.)
• Where severe vibration or shock exists
• Where close to a strong alkali or strong acid
• Where direct rays of light exist
• Where near facilities generating strong magnetic forces or electric noise.
● Storage
Keep the unit -20 to 60℃, 35 to 85%RH with avoiding direct rays of light. It is recommended to keep the unit package
as it is.
● Installation environment
• It shall be used indoor
• Altitude max. 2000m
• Pollution degree 2
• Installation category II
