AMG210M
AMG210M PoE Series
Mini Media Converter
Installation Manual - Hardware
PACKING LIST
The following items should be included in the box:
• Mini PoE Media Converter
• 52VDC Power Supply (with region specic plug)
• Installation & DIP Switch Manual
• SFP Module* (*only included with some models)
If any of the above items are missing or damaged
please contact your supplier or distributor.
POWER
The mini PoE media converter is powered
by a 48-56VDC power supply. A DC type
power supply is included with each unit.
The centre pin is positive while the outer sleeve is
negative. The connector type is a 2.1MM input jack.
The power consumption of the AMG210M
mini PoE media converters are detailed below:
• 1Gb Models(No PoE Load) <3W*
• 1Gb Models(Max PoE Load) <33W*
*Excludes SFP Module
The unit supports IEEE 802.3af/at PoE up to 30W
D39247-00
LED INDICATORS
The mini media converters feature LED indicators
to aid in system operation and fault diagnosis. The
meaning of each LED is described in the table below:
POE
On: PoE power is being supplied
O: No PoE power is being
supplied
TP
L/A
Solid: RJ45 is connected but no
data is being received
Flashing: RJ45 is connected and
data is being received
PWR
On: Unit is powered up
O: Unit is not powered up
SPD
On: RJ45 is connected at the
highest possible speed
O: RJ45 is not connected or is
connected at a speed slower than
the highest possible
FX
L/A
Solid: SFP is connected but no data
is being received
Flashing: SFP is connected and
data is being received
DUP
On: RJ45 is in full duplex mode
O: RJ45 is in half duplex mode
amgsystems.com

AMG210M-1GAT-1S-P30
100MB/1Gb SFP POE MEDIA CONVERTER
No. Function Status Description
1 LFP
OFF Disable
ON Enable
2 ALS
OFF Disable
ON Enable
3 FX Reset
OFF Enable
ON Disable
4 FX Speed
OFF 1000Mb
ON 100Mb
LFP - Link Fault Pass-Through. When enabled a failure on either
the RJ45 or SFP will cause the corresponding port to link down
so that the fault can be detected by other connected devices.
ALS - Automatic Laser Shutdown. When enabled if the bre
link is broken or disconnected then the laser will be turned o
except for sending periodic signals to check if the bre link
has been re-established. The ALS function helps to extend
the life of the optical device and reduce power consumption.
FX Reset - When enabled (DIP Switch OFF) if the bre link goes
down then the media converter will perform an automatic
power cycle to try and re-establish the bre link operation.
FX Speed - When enabled the SFP port supports 100Mb
speed. When disabled the SFP port is locked to 1Gb speed.
-
Note: After changing any DIP switch settings please cycle
power to the unit to ensure the new settings are applied.
AMG210M
AMG210M PoE Series
Mini Media Converter
Installation Manual - DIP Switch Settings
amgsystems.com
D39247-00
WALL MOUNTING
The mini PoE media converter can be mounted
to a wall using the integrated screw holes
in the base of the module as shown below:
RACK MOUNTING
The AMG210M series mini PoE media
converters do not support rack mounting and
cannot be installed in the AMG210C rack.
