Operating Instructions
Dust Filter STF for Explosion Protection Zones
30.30.01.01548/00 | 02.2018

www.schmalz.com
Note
These operating instructions were originally written in German and have been translated into English.
Store in a safe place for future reference.
Subject to technical changes without notice. No responsibility is taken for printing or other types of
errors.
Published by
© J. Schmalz GmbH, 02.2018
This document is protected by copyright. J. Schmalz GmbH retains the rights established thereby.
Reproduction of the contents, in full or in part, is only permitted within the limits of the legal provisions
of copyright law. Any modifications to or abridgments of the document are prohibited without explicit
written agreement from J. Schmalz GmbH.
Contact
J. Schmalz GmbH
Johannes-Schmalz-Str. 1
72293 Glatten, Germany
Tel. [phone]
Fax [phone]
[e-mail]
www.schmalz.com
Contact information for Schmalz companies and trade partners worldwide can be found at
www.schmalz.com/salesnetwork

Contents
Dust Filter STF for Explosion Protection Zones
www.schmalz.com
1Safety Instructions...............................................................................................4
1.1Classification of safety instructions ...................................................................................4
1.2 Warnings ...........................................................................................................................5
1.3 Mandatory symbols ...........................................................................................................5
1.4 General safety instructions................................................................................................6
1.4.1 Explosion protection..........................................................................................................6
1.4.2 Fundamental safety instructions........................................................................................6
1.4.3 Regulations in these instructions.......................................................................................7
1.5 Intended use......................................................................................................................7
1.6 Non-intended use..............................................................................................................7
1.7 Requirements and instructions for installation, maintenance and operating staff.............8
2Product Description.............................................................................................9
2.1 Versions.............................................................................................................................9
3Installation and Operation .................................................................................10
3.1 General operating information.........................................................................................10
3.1.1 Installation position for the dust filter...............................................................................10
3.1.2 Mounting the dust filter....................................................................................................11
3.2 Establishing equipotential bonding..................................................................................11
3.2.1 Grounding the dust filter..................................................................................................12
3.2.2 Grounding the vacuum hoses .........................................................................................12
3.3 Attaching the hoses.........................................................................................................12
3.4 Resistance measurement................................................................................................12
4Maintenance......................................................................................................13
4.1 Removing and cleaning filter cartridges..........................................................................13
4.2 Spare and wearing parts .................................................................................................14
5Disposal ............................................................................................................14

SAFETY INSTRUCTIONS
4 | EN www.schmalz.com 30.30.01.01548/00
1 Safety Instructions
1.1 Classification of safety instructions
Danger
This warning informs the user of a risk that will result in death or serious injury if it is not avoided.
DANGER
Type and source of danger
Consequence
►
Remedial action
Warning
This warning informs the user of a risk that could result in death or serious injury if it is not avoided.
WARNING
Type and source of danger
Consequence
►
Remedial action
Caution
This warning informs the user of a risk that could result in injury if it is not avoided.
CAUTION
Type and source of danger
Consequence
►
Remedial action
Attention
This warning informs the user of a risk that could result in damage to property if it is not avoided.
ATTENTION
Type and source of danger
Consequence
►
Remedial action
General notes
This symbol is used when important notes and information regarding the use of the machine/the
system/the device are provided.
Note/information

SAFETY INSTRUCTIONS
30.30.01.01548/00 www.schmalz.com EN | 5
1.2 Warnings
Explanation of the warning symbols used in the operating instructions.
Warning
symbol
Description
Warning
symbol
Description
General warning symbol
Flying debris
Electrical voltage
Warning of overpressure
Floating dust particles
Explosive atmosphere
1.3 Mandatory symbols
Explanation of the mandatory symbols used in the operating instructions.
Mandatory
symbols
Description
Mandatory
symbols
Description
Wear a mask
Wear eye protection
Activate prior to maintenance or repair

SAFETY INSTRUCTIONS
6 | EN www.schmalz.com 30.30.01.01548/00
1.4 General safety instructions
1.4.1 Explosion protection
DANGER
Ignition sources
Risk of explosion
►
When used in potentially explosive atmospheres:
Preclude possible ignition sources (e.g. hot surfaces, open flames, hot
gases or liquids, mechanically produced sparks, adiabatic compression,
shock waves, exothermic chemical reactions, thermal reactions, the
spontaneous combustion of dust, electric arcs or the discharge of static
electricity or propagating brush discharges).
Never strike the dust filter with objects or tools (spark discharge).
1.4.2 Fundamental safety instructions
WARNING
Ignoring the general safety guidelines
Personal injury/damage to plants or systems
►
The operating instructions contain important information on using the dust filter.
Read the operating instructions thoroughly and keep them for later reference.
►
Do not connect the filter or start operations until after you have read and
understood the operating instructions fully.
►
Use only the connections, mounting holes and attachment materials that have
been provided.
►
Carry out mounting or removal only when the device is in an idle,
depressurized state.
►
Only qualified specialist personnel, mechanics and electricians are permitted to
perform the installation. Qualified specialist personnel are persons who have
received technical training and have the knowledge and experience –including
knowledge of applicable regulations –necessary to enable them to recognize
possible dangers and implement the appropriate safety measures while
performing tasks. The same applies to maintenance!
►
General safety regulations, European standards and VDE guidelines must be
observed and complied with.
►
It is not permitted to make changes to system components.
►
Protect the components from damage of any kind.

SAFETY INSTRUCTIONS
30.30.01.01548/00 www.schmalz.com EN | 7
1.4.3 Regulations in these instructions
WARNING
Failure to observe the instructions
Risk of fatal injuries
►
The dust filter must not be started or used until the operating instructions have
been read and understood.
These operating instructions are an integral part of the dust filter. They must accompany it wherever it
is transported.
1.5 Intended use
This dust filter is intended solely for filtering mechanical components in air. This device must not be
used to filter other media or liquids.
The vacuum must not exceed -500 mbar. Overpressure is not permissible. The dust filter is classified
as follows according to ATEX directive 2014/34 EU:
II 3G IIB T4
II 3D T135° C
The classification for the overall system is determined based on the component with the lowest
classification.
WARNING
Transporting or sucking through liquids or bulk material
Personal injury and/or damage to property
►
Do not transport or suck through liquids or bulk material
CAUTION
Pressure can cause closed devices to explode
Personal injury and/or damage to property
►
Wear eye protection
1.6 Non-intended use
The manufacturer accepts no liability for damages caused by the use of the dust filter for other
purposes.

SAFETY INSTRUCTIONS
8 | EN www.schmalz.com 30.30.01.01548/00
1.7 Requirements and instructions for installation, maintenance and
operating staff
DANGER
Errors during operation, maintenance or repair work
Risk of explosion
►
The operator must ensure that the personnel employed receive special
training for performing work in potentially explosive atmospheres.
Comply with the applicable national regulations.
All personnel working with the product must be familiar with basic mechanical and pneumatic
principles as well as the appropriate technical terminology.
To ensure safe operation, this work may only be performed by qualified personnel or trained persons
working under the supervision of qualified personnel.
Qualified specialist = an employee who has received technical training and has the knowledge and
experience –including knowledge of corresponding regulations –necessary to enable him or her to
recognize possible dangers and implement the appropriate safety measures while performing tasks.
WARNING
Risk of injury due to misuse or non-observance of warning and safety
notices
Persons could be harmed
►
The equipment must be used by trained personnel only.

PRODUCT DESCRIPTION
30.30.01.01548/00 www.schmalz.com EN | 9
2 Product Description
2.1 Versions
The dust filter is available in two different versions. The basic model STF 50 is included in delivery with
the hoist for explosion protection zones. The model STF 60 is available as a retrofitting kit for older
hoist models for explosion protection zones from year of manufacture 5/2017 or later.
Components
Item
Designation
1
Air outlet connection (vacuum generator)
2
Hose clamps
3
Air inlet connection (suction cup)
4
Upper housing section
5
Lower housing section (dust collecting pan)
6
Filter cartridge
7
Housing cover
8
Mounting bracket
3
2
5
7
1
8
6
4

INSTALLATION AND OPERATION
10 | EN www.schmalz.com 30.30.01.01548/00
3 Installation and Operation
Installation may only be carried out by qualified specialist personnel.
(See chapter 1.8, Requirements and instructions for installation, maintenance and operating staff).
DANGER
Sources of ignition during installation
Risk of explosion
►
Ensure that a potentially explosive atmosphere is not produced during
installation.
3.1 General operating information
Operating temperature between -40°C and +80°C
The filter must be watertight
Do not draw in warm air.
The unit must be easily accessible. (Checks, cleaning and replacing the filter cartridge)
For the tube lifter Jumbo, holes for mounting the filter are located on the
components used for blower attachment.
The tube lifter must not be operated without the dust filter.
3.1.1 Installation position for the dust filter
The dust filter can be installed vertically or horizontally. When mounting the unit vertically, ensure that
the dust collecting system (5) is at the bottom.
Incorrect installation voids the warranty for the dust filter and vacuum generator

INSTALLATION AND OPERATION
30.30.01.01548/00 www.schmalz.com EN | 11
3.1.2 Mounting the dust filter
1. Prepare the holes in the crane column or wall bracket for attaching the dust filter.
If the product came with a blower console (1.1), there are
already mounting points for the dust filter.
2. Ground the dust filter (see chapter 3.2.1).
3. Screw the dust filter onto the mounting bracket (8) using two
M8 screws.
4. Prepare the vacuum hoses for grounding (see chapter 3.2.2).
5. Attach and ground the vacuum hoses with the hose clamps
(see 3.3).
3.2 Establishing equipotential bonding
DANGER
Replacing the filter cartridge while vacuum is applied
Risk of injuries
►
Before replacing the filter cartridge, ensure that the vacuum generator is
switched off and that there is no residual vacuum.
WARNING
Dispersed dust particles
Damage to eyes and respiratory tract
►
Before blowing out the filter cartridge, put on eye protection and a respiratory
mask.
WARNING
Dirt particles in the vacuum supply hose
Risk of explosion
►
►
Ensure that no dirt enters the blower supply hose.
Ensure that no dust gets inside the filter cartridge during blowing.
WARNING
Insufficient grounding
Risk of explosion
►
Grounding connections must be checked regularly to ensure explosion
protection.
2
1.1

INSTALLATION AND OPERATION
12 | EN www.schmalz.com 30.30.01.01548/00
All grounding wires for equipotential bonding must be provided with a green and yellow
cable. Minimum cross section 4 mm².
The equipotential bonding consists of an electrically conductive connection from the suction cup via
the operator handle, lift tube, rotary union, supply hose, dust filter, blower, and crane system to the
customer-supplied connection point for equipotential bonding. Additional grounding wires should be
installed on all moving parts.
3.2.1 Grounding the dust filter
The dust filter is grounded by three spring clips between the filter
cartridge and the filter housing.
1. Open the filter housing.
2. Insert the filter cartridge (6).
3. Ensure that the filter cartridge (6) is grounded with the housing
using three spring clips (6.1).
4. Close the housing cover.
3.2.2 Grounding the vacuum hoses
The vacuum hoses are grounded by the hose clamps and wire spirals.
During preparation, observe the relevant parts of the operating instructions for the hoist.
3.3 Attaching the hoses
The filter connections are optimized for the internal diameter of the vacuum hoses.
Attach the hoses using the hose clamps SSD (2) included in the delivery.
3.4 Resistance measurement
Measure the total resistance once the installation is complete.
In this process, observe the relevant parts of the operating instructions for the hoist.
6
6.1
6

MAINTENANCE
30.30.01.01548/00 www.schmalz.com EN | 13
4 Maintenance
DANGER
Damage from vacuum generator that has not been switched off
Personal injury
►
Switch off vacuum generators (such as blowers or pumps) during cleaning,
maintenance and repair work.
Component
Task
Maintenance period
Filter cartridge
Clean and check for damage
According to the operating
instructions of the connected devices
Replace
At least once after 5 cleanings or at
least once every 2 years
Connection hoses
Check for damage and leaks
Monthly or after repairs have been
conducted
Plastic housing and bracket
Check for damage and tears
Check when performing filter
maintenance
4.1 Removing and cleaning filter cartridges
WARNING
Whirling dust particles
Damage to eyes and respiratory tract
►
Wear eye protection
►
Wear respiratory protection
1. Open the filter housing.
2. Remove the filter cartridge (6) from the housing.
3. Replace heavily contaminated or damaged filter cartridge.
4. Blow the filter cartridges from the inside out (never wash or brush it).
Filter cartridges must be blown from the inside out using dry
compressed air (max. 5 bar) until there are no more dust formations.
5. Before installation, check the clean filter cartridge for damage to the
paper bellows and the rubber gaskets.
Damaged filter cartridges must not be reused.
If you are not sure, install a new filter cartridge.
6. Insert the filter cartridge (6).
7. Make sure that the filter cartridge is grounded (see chapter 3.2.1).
8. Close the housing cover.
To blow out the unit, set a pipe on a compressed-air gun that is bent at the end by
approx. 90°. The pipe must be long enough to reach the bottom of the cartridge.
6

DISPOSAL
14 | EN www.schmalz.com 30.30.01.01548/00
4.2 Spare and wearing parts
We guarantee this device pursuant to our General Terms and Conditions of Sale and Delivery.
The same applies to spare parts, provided that these are original parts supplied by us.
We are not liable for any damage resulting from the use of non-original spare parts or accessories.
Designation
Use
Part no.
Legend
Filter cartridge Jumbo
Dust filter STF-EX
10.07.01.00395
W
Hose clamp SSB 59-63
STF 50
10.07.10.00096
S
Hose clamp SSB 40-60
STF 50
10.07.10.00005
S
Hose clamp SSB 60-80
STF 60
10.07.10.00063
S
S= Spare part, W= Wearing part
5 Disposal
After replacement or after final decommissioning, the system, as well as the components and
assemblies that were replaced, are to be disposed of in accordance with country-specific guidelines.
ATTENTION
Incorrect disposal of the dust filter
Environmental damage
►
Disposal according to country-specific regulations

www.schmalz.com
World of Vacuum Technology
Schmalz Services
Global contact
Our sales network of local field representatives, international subsidiaries and trade
partners ensures quick and competent information and consultation in more than 50
countries worldwide.
www.schmalz.com/salesnetwork
Online documentation
Conveniently download catalogs, operating instructions and CAD data and get
comprehensive information about our products and services.
www.schmalz.com/dokumentationen
“How to” videos
In short, easy-to-understand videos we explain the extensive features of our
products. Take a look, it’s worth it!
www.schmalz.com/gewusst-wie
Further services ranging from consultation to training can be found at
www.schmalz.com/services
J. Schmalz GmbH
Johannes-Schmalz-Str. 1
72293 Glatten, Germany
Phone [phone]
Fax [phone]
[e-mail]
www.schmalz.com
30.30.01.01548/00 | 02.2018
