schmersal TZG User manual

EN Operating instructions. . . . . . . . . . . . .pages 1 to 4
Translation of the original operating instructions
1
TZG
Operating instructions
Safety switch
EN
1. About this document
1.1 Function
This operating instructions manual provides all the information you
need for the mounting, set-up and commissioning to ensure the safe
operation and disassembly of the safety switchgear. he operating inst-
ructions must be available in a legible condition and a complete version
in the vicinity of the device.
1.2 Target group: authorised qualified personnel
All operations described in this operating instructions manual must
be carried out by trained specialist personnel, authorised by the plant
operator only.
Please make sure that you have read and understood these operating
instructions and that you know all applicable legislations regarding
occupational safety and accident prevention prior to installation and
putting the component into operation.
The machine builder must carefully select the harmonised standards to
be complied with as well as other technical specifications for the selec-
tion, mounting and integration of the components.
1.3 Explanation of the symbols used
Information, hint, note:
This symbol is used for identifying useful additional information.
Caution: Failure to comply with this warning notice could
lead to failures or malfunctions.
Warning: Failure to comply with this warning notice could
lead to physical injury and/or damage to the machine.
1.4 Appropriate use
The products described in these operating instructions are developed to
execute safety-related functions as part of an entire plant or machine. It
is the responsibility of the manufacturer of a machine or plant to ensure
the correct functionality of the entire machinery or plant.
The safety switchgear must be exclusively used in accordance with the
versions listed below or for the applications authorised by the manufac-
turer. Detailed information regarding the range of applications can be
found in the chapter "Product description".
1.5 General safety instructions
The user must observe the safety instructions in this operating instruc-
tions manual, the country-specific installation standards as well as all
prevailing safety regulations and accident prevention rules.
Further technical information can be found in the Schmersal
catalogues or in the online catalogue on the Internet: www.
schmersal.net.
The information contained in this operating instructions manual is provi-
ded without liability and is subject to technical modifications.
If multiple safety components are wired in series, the Perfor-
mance Level to EN ISO 13849-1 will be reduced due to the
restricted error detection under certain circumstances. The
entire concept of the control system, in which the safety com-
ponent is integrated, must be validated to EN ISO 13849-2.
There are no residual risks, provided that the safety instructions as well
as the instructions regarding mounting, commissioning, operation and
maintenance are observed.
Content
1 About this document
1.1 Function ..............................................1
1.2 Target group: authorised qualied personnel..................1
1.3 Explanation of the symbols used ...........................1
1.4 Appropriate use ........................................1
1.5 General safety instructions ...............................1
1.6 Warning about misuse ...................................2
1.7 Exclusion of liability .....................................2
2 Product description
2.1 Ordering code .........................................2
2.2 Special versions........................................2
2.3 Destination and use .....................................2
2.4 Technical data .........................................2
2.5 Safety classication .....................................2
3 Mounting
3.1 General mounting instructions .............................2
3.2 Dimensions ...........................................3
4 Electrical connection
4.1 General information for electrical connection..................3
4.2 Contact variants........................................3
5 Set-up and maintenance
5.1 Functional testing.......................................3
5.2 Maintenance ..........................................3
6 Disassembly and disposal
6.1 Disassembly...........................................3
6.2 Disposal ..............................................3
7 Appendix
7.1 EC Declaration of conformity ..............................4
x.000 / 02.2015 / v.A. - 1011211192-EN / D / 2015-02-10 / AE-Nr. 4294

2
Operating instructions
Safety switch TZG
EN
1.6 Warning about misuse
In case of improper use or manipulation of the safety switch-
gear, personal hazards or damages to machinery or plant
components cannot be excluded when safety switchgear is
used. The relevant requirements of the standard ISO 14119
must be observed.
1.7 Exclusion of liability
We shall accept no liability for damages and malfunctions resulting from
defective mounting or failure to comply with this operating instructions
manual. The manufacturer shall accept no liability for damages resul-
ting from the use of unauthorised spare parts or accessories.
For safety reasons, invasive work on the device as well as arbitrary re-
pairs, conversions and modifications to the device are strictly forbidden;
the manufacturer shall accept no liability for damages resulting from
such invasive work, arbitrary repairs, conversions and/or modifications
to the device.
2. Product description
2.1 Ordering code
This operating instructions manual applies to the following types:
TZG
➀➁
/
➂
No. Option Beschreibung
➀
Slow action
P Snap action only 1 NC /1 NO contact
➁
01 Head positioned to the front
02 Head positioned to the left
03 Head positioned to the right
04 Head positioned to the rear
➂
103 1 NC contact / 1 NO contact
110 2 NC contacts
1103 2 NC contact / 1 NO contact
3330 3 NC
Not all component variants, which are possible according to this order
code, are available.
Only if the information described in this operating instructions
manual are realised correctly, the safety function and therefo-
re the compliance with the Machinery Directive is maintained.
2.2 Special versions
For special versions, which are not listed in the order code below 2.1,
these specifications apply accordingly, provided that they correspond to
the standard version.
2.3 Destination and use
The safety switch has been designed to prevent, in conjunction with the
control part of a machine, movable safety guards from being opened
before hazardous conditions have been eliminated. They are also suita-
ble for fitting on profile sections and existing equipment.
Safety switches can only be used for applications, in which
the hazardous situation is terminated without delay (e.g. run-
on movements) when the safety guard is opened.
When the safety guard is opened, the NC contacts are positively ope-
ned and the NO contacts are closed.
The user must evaluate and design the safety chain in accordance with
the relevant standards and on the required safety level.
2.4 Technical data
Standards: IEC 60947-5-1; EN ISO 13849-1;
ISO 14119; BG-GS-ET-15
Enclosure: glass-fibre reinforced thermoplastic, self-extinguishing
Actuator: steel
Contact material: Silver
Protection class: IP67
Contact type: change-over with double break Zb, or 3 NC contacts,
galvanically separated contact bridges
Switching system: A IEC 60947-5-1; slow action, NC contact with
positive break
Connection: screw terminals
Cable type: solid wire
Cable section: 0,5 … 2,5 mm²
Cable type: stranded wire
Cable section 0,5 … 1,5 mm²,
with conductor ferrules,
Cable entry: M20 × 1,5
Actuating speed: 0.2 m/s
Actuating frequency: max. 1200 operations/h
Mechanical life: > 1 million operations
Ambient temperature: −25 °C … +70 °C
Utilisation category: AC-15, DC-13
Ie/Ue:8 A / 230 VAC; 5 A / 24 VDC
only TZGP: 6 A / 230 VAC; 4 A / 24 VDC
Ui:400 V
only TZGP 250V
Uimp:2.5 kV
Ithe:10 A
Us:24 VAC/DC 110/230 VAC
Max. fuse rating: 10 A gG D-fuse
2.5 Safety classification
Standards: EN ISO 13849-1
B10d (NC contact): 2.000.000
B10d (NO contact) at 10% ohmic contact load: 1.000.000
Service life: 20 years
MT
TF
Bdxx
hs/h3600
d
10d op op
op
n
0,1 x nop tcycle
3. Mounting
3.1 General mounting instructions
3/2 mounting holes are provided for fixing the switch. The safety switch
must not be used as end stop. Any mounting position. The mounting
position however must be chosen so that the components are protected
against soiling and damage. In case of painting activities, the compo-
nents must be covered. The supplied fixing material must be used. If
another actuating direction is desired, the four screws of the actuating
head must be loosened. Turn the actuating head in the desired direc-
tion and retighten the screws (tightening torque 0.5 Nm). The default
screws installed in the actuating head can be replaced with the supplied
tamperproof screws.
Mounting of the actuators: See mounting instructions actuators.
Please observe the remarks of the standards EN ISO 12100,
EN 953 and ISO 14119.
The 3-pole variants can only be connected to 2 screw points.
For stability reasons, at least the hatched area shown on the
image must be provided as full contact surface.

3
TZG
Operating instructions
Safety switch
EN
60 30
3.2 Dimensions
All measurements in mm.
TZG 2-pole / TZGP
35
5
39,5
30
50
39,5
R5
96.5
10
5.3
106.5
55
M20x1,5
TZG 3-pole
5
39,5
30
50
39,5
122
75,5
35
5.3
M20x1,5
4. Electrical connection
4.1 General information for electrical connection
The electrical connection may only be carried out by autho-
rised personnel in a de-energised condition.
The contact labelling can be found in the wiring compartment of the
switch. For the cable entry, only suitable plastic cable glands with an
appropriate degree of protection must be used. After wiring, dust and
soiling must be removed from the wiring compartment. The safety
switch is double insulated. The use of a protective ground connector
therefore is not authorised.
4.2 Contact variants
Contacts are shown with safety guard closed.
TZG../103 / TZGP TZG../110
11
23
12
24
11
21
12
22
TZG../1103 TZG../3330
11
21
33
12
22
34
11
21
31
12
22
32
5. Set-up and maintenance
5.1 Functional testing
The safety function of the safety components must be tested. The
following conditions must be previously checked and met:
1. Check the free movement of the actuating element.
2. Check the integrity of the cable entry and connections.
3. Check the switch enclosure for damage.
5.2 Maintenance
A regular visual inspection and functional test, including the following
steps, is recommended:
1. Check the free movement of the actuating element.
2. Remove particles of dust and soiling.
3. Check cable entry and connections.
Damaged or defective components must be replaced.
6. Disassembly and disposal
6.1 Disassembly
The safety switchgear must be disassembled in a de-energised condi-
tion only.
6.2 Disposal
The safety switchgear must be disposed of in an appropriate manner in
accordance with the national prescriptions and legislations.

EC Declaration of conformity
Translation of the original
Declaration of Conformity
4
Operating instructions
Safety switch TZG
EN
TZG-C-EN
7. Appendix
The currently valid declaration of conformity can be down-
loaded from the internet at www.schmersal.net.
7.1 EC Declaration of conformity
Name of the safety component: TZG
Type: Refer to 2.1 Ordering code
Description of the safety component: Positive break position switch with separate
actuator for safety functions
Relevant EC-Directives: 2006/42/EC EC-Machinery Directive
Person authorized for the compilation
of the technical documentation:
Oliver Wacker
Möddinghofe 30
42279 Wuppertal
K. A. Schmersal GmbH & Co. KG
Möddinghofe 30, D - 42279 Wuppertal
Postfach 24 02 63, D - 42232 Wuppertal
Phone: +49 - (0)2 02 - 64 74 - 0
Telefax: +49 - (0)2 02 - 64 74 - 1 00
E-Mail: [email protected]
Internet: http://www.schmersal.com
Place and date of issue: Wettenberg, February 10, 2015
Authorised signature
Philip Schmersal
Managing Director
EC Declaration of conformity
K.A. Schmersal GmbH & Co. KG
Möddinghofe 30
42279 Wuppertal
Germany
Internet: www.schmersal.com
We hereby certify that the hereafter described safety components both in its basic design and const-
ruction conform to the applicable European Directives.
