Scholl 26060/4 User manual

GBA C 0100 2 E
BA Page 1 of 26 Januar 16, 2018
Last revised 01-2018 Rev. 2
Scholl Apparatebau GmbH & Co. KG
Instructions for Use
Hot plate table top 30-100°C
continuously heated separately heated (2 zones)
Model-No. Art. No. Model-No. Art. No.
26060/4 C 0100 26080/4/G C 1102
: : : :
26150/8 C 0149 26150/8/G C 1149
Scholl Apparatebau GmbH & Co. KG
Zinhainer Weg 4
D–56470 Bad Marienberg/Germany
Phone [phone]
Fax [phone] (Service)
Internet www.scholl-gastro.de
E-mail [email protected]e

GBA C 0100 2 E
BA Page 2 of 26 Januar 16, 2018
Last revised 01-2018 Rev. 2
Scholl Apparatebau GmbH & Co. KG
Hot plate table top 30-100°C
continuously heated
Model-No. Art. No. Art. No. Art. No. Art. No. Art. No.
D (mm) 400 500 600 700 800
26060/- C 0100 C 0110 C 0120 C 0130 C 0140
26070/- C 0101 C 0111 C 0121 C 0131 C 0141
26080/- C 0102 C 0112 C 0122 C 0132 C 0142
26090/- C 0103 C 0113 C 0123 C 0133 C 0143
26100/- C 0104 C 0114 C 0124 C 0134 C 0144
26110/- C 0105 C 0115 C 0125 C 0135 C 0145
26120/- C 0106 C 0116 C 0126 C 0136 C 0146
26130/- C 0107 C 0117 C 0127 C 0137 C 0147
26140/- C 0108 C 0118 C 0128 C 0138 C 0148
26150/- C 0109 C 0119 C 0129 C 0139 C 0149
Hot plate table top 30-100°C
separately heated (2 zones)
Model-No. Art. No. Art. No. Art. No. Art. No. Art. No.
D (mm) 400 500 600 700 800
26060/-/G C 1110 C 1120 C 1130 C 1140
26070/-/G C 1111 C 1121 C 1131 C 1141
26080/-/G C 1102 C 1112 C 1122 C 1132 C 1142
26090/-/G C 1103 C 1113 C 1123 C 1133 C 1143
26100/-/G C 1104 C 1114 C 1124 C 1134 C 1144
26110/-/G C 1105 C 1115 C 1125 C 1135 C 1145
26120/-/G C 1106 C 1116 C 1126 C 1136 C 1146
26130/-/G C 1107 C 1117 C 1127 C 1137 C 1147
26140/-/G C 1108 C 1118 C 1128 C 1138 C 1148
26150/-/G C 1109 C 1119 C 1129 C 1139 C 1149

GBA C 0100 2 E
BA Page 3 of 26 Januar 16, 2018
Last revised 01-2018 Rev. 2
Scholl Apparatebau GmbH & Co. KG
TABLE OF CONTENTS
Table of contents............................................................................................................................................... 3
Preface............................................................................................................................................................... 5
1Conventions............................................................................................................................................... 6
1.1 Pictograms –General safety notes .................................................................................................. 6
1.2 Pictograms –Warning notes............................................................................................................ 8
1.3 Pictograms –Important notes ......................................................................................................... 9
2Product information ................................................................................................................................ 10
2.1 Execution ....................................................................................................................................... 10
2.2 Information regarding compliance with standards, laws and directives ....................................... 10
2.3 Safety ............................................................................................................................................. 11
3Packing, transport, intermediate storage, scope of delivery .................................................................. 12
3.1 Packing ........................................................................................................................................... 12
3.2 Transport........................................................................................................................................ 12
3.3 Intermediate storage ..................................................................................................................... 12
3.4 Scope of delivery............................................................................................................................ 12
4Installation and electrical installation ..................................................................................................... 13
4.1 Installation ..................................................................................................................................... 13
4.2 Electrical installation ...................................................................................................................... 13
5Operation ................................................................................................................................................ 14
5.1 Intended use .................................................................................................................................. 14
5.2 Unintended use.............................................................................................................................. 14
6Maintenance ........................................................................................................................................... 15
6.1 Maintenance and repair ................................................................................................................ 15
6.2 Cleaning and care........................................................................................................................... 15
7Troubleshooting ...................................................................................................................................... 17

GBA C 0100 2 E
BA Page 4 of 26 Januar 16, 2018
Last revised 01-2018 Rev. 2
Scholl Apparatebau GmbH & Co. KG
7.1 Possible malfunctions .................................................................................................................... 18
8Technical data.......................................................................................................................................... 19
8.1 Dimensioned drawing .................................................................................................................... 20
8.1.1 Dimensioned drawing hot plate table top 30-100°C continuously heated ............................... 20
8.2 Circuit diagram............................................................................................................................... 21
8.2.1 Circuit diagram hot plate table top 30-100°C continuously heated .......................................... 21
8.2.2 Circuit diagram hot plate table top 30-100°C separately heated .............................................. 22
8.3 Spare parts list ............................................................................................................................... 23
9Disposal and Environmental Notes ......................................................................................................... 24
9.1 Disposal of packing material .......................................................................................................... 24
9.2 Disposal of the appliance ............................................................................................................... 24
10 Warranty and service ......................................................................................................................... 25
10.1 Warranty conditions ...................................................................................................................... 25
10.2 Service............................................................................................................................................ 25
10.3 Service address .............................................................................................................................. 26

GBA C 0100 2 E
BA Page 5 of 26 Januar 16, 2018
Last revised 01-2018 Rev. 2
Scholl Apparatebau GmbH & Co. KG
PREFACE
Congratulations!
In purchasing this new SCHOLL appliance you have chosen a product which meets highest technical stand-
ards while providing outstanding convenience in practical use.
This appliance has been designed with minimal energy consumption in mind. Used responsibly, it will serve
you well in an ecologically sound manner.
Please read the information in this manual carefully before starting up this appliance. On the following
pages you will find important notes regarding its operation, care and maintenance so that you will be able
to enjoy its use for a long time.
If a malfunction should nevertheless occur, please consult the "Troubleshooting" section first. In many cases
you should be able to remedy minor problems yourself, thus saving unnecessary service costs.
Please retain this manual carefully and pass it on to any subsequent user for his or her information and
safety.
A quality product, properly treated, will give you many years of satisfactory service.
We trust you will enjoy using this product!
Yours sincerely
Gustav Scholl Apparatebau GmbH & Co. KG

GBA C 0100 2 E
BA Page 6 of 26 Januar 16, 2018
Last revised 01-2018 Rev. 2
Scholl Apparatebau GmbH & Co. KG
1 CONVENTIONS
1.1 PICTOGRAMS –GENERAL SAFETY NOTES
Be sure to observe these Instructions for Use as well as the safety notes to prevent
injuries or damage to health or property. Do not alter or modify this appliance.
Never use a defective appliance. If you suspect the unit of being faulty or discover
an unusual noise or smell, turn off the power switch and pull the plug out of the
socket-outlet, or otherwise disconnect the appliance from the mains and de-
energize it (i.e., ensure that it no longer carries any voltage). Do not use this appli-
ance when its power cord is damaged.
Failure to observe this warning may result in a fire hazard or electrical shock!
Maintenance and repair work must be carried out only by qualified professionals
using original spare parts and accessories. Do not attempt to carry out repairs on
this appliance yourself!
Connect this appliance to suitably earthed mains outlets only. Ensure that your
mains power supply conforms to the data stated on the nameplate of the appliance.
Failure to observe this warning may result in a fire hazard or electrical shock!
Place this appliance on a sturdy, level and heat-resistant surface to prevent fire
hazards and accidents.
This appliance is not intended to be used by persons (including children) of limited
physical, sensory or intellectual abilities, or lacking in experience and/or knowledge,
unless they are supervised by a person responsible for safety who instructs them in
the use of the device. Children should be supervised to ensure they will not play
with this appliance.
Do not run the power cord near heat sources, over sharp edges, etc. Always pull on
the plug, not the cord, to remove it from a socket-outlet since the cord might be
damaged as a result. Do not allow cords to hang unsupported. Route the cord so
that it will not form a tripping hazard!
Do not allow this appliance to operate unattended. Ensure that its thermostat
switch is set to „0“ before inserting the plug into an electrical socket-outlet or con-
necting the appliance to the power supply. Avoid starting the unit unintentionally.
Connecting the unit to the mains with its thermostat switch not set to „0“ may
cause accidents.

GBA C 0100 2 E
BA Page 7 of 26 Januar 16, 2018
Last revised 01-2018 Rev. 2
Scholl Apparatebau GmbH & Co. KG
Protect this appliance from moisture (water spray, rain). Do not immerse the appli-
ance in water or other fluids and do not place it in a dishwasher. Any penetration of
water into the unit will increase the risk of an electrical shock.
Do not touch the surfaces of the appliance. The surfaces of this appliance may get
hot. Please allow the unit to cool down fully before cleaning or stowing it. Never
cover this appliance.
Burn injury or fire hazard!

GBA C 0100 2 E
BA Page 8 of 26 Januar 16, 2018
Last revised 01-2018 Rev. 2
Scholl Apparatebau GmbH & Co. KG
1.2 PICTOGRAMS –WARNING NOTES
Cleaning must only be performed by qualified persons who have read and under-
stood these Instructions for Use and are familiar with applicable hygiene rules. En-
sure that care is exercised during cleaning of the unit.
For light cleaning, wipe down the surface with a cloth or soft brush/sponge soaked
in warm water which contains a small amount of dishwashing detergent. Follow this
up by wiping with clear water until no cleaning agent residue remains on the sur-
face, as the latter might cause discoloration or stains. Finish by rubbing the surface
dry.
To remove more stubborn or extensive residue, a stainless steel cleaning product
may be used.
Never use any of the following for cleaning:
aggressive or bleaching products, i.e., containing active oxygen, chlorine, or
caustic/corrosive constituents.
abrasive cleaning products such as scouring creams/pastes, steel wool, sa-
ponified steel wool, metal or plastic sponges, or sponges with a scratchy
surface (scouring side).
Never use steam and/or pressure jet cleaning equipment to clean this appliance!
This might damage the appliance to the point where it may
pose a hazard to your life!
Before any cleaning, maintenance or repair work is carried out, the appliance must
be disconnected from the mains and de-energized. To do so, it is not enough to set
the power switch to OFF. Instead, the mains plug must be pulled or the electrical
circuit must be de-energized, respectively. Check that no voltage is present before
opening the appliance, and lock out the circuit to make it safe against re-energizing.
The total permitted regeneration and hot-holding time according to HACCP will be
exceeded after 3 hours.
Risk of potential health impairment!
Allow the unit to cool down before starting any cleaning work.
Burn hazard!

GBA C 0100 2 E
BA Page 9 of 26 Januar 16, 2018
Last revised 01-2018 Rev. 2
Scholl Apparatebau GmbH & Co. KG
1.3 PICTOGRAMS –IMPORTANT NOTES
DANGER
indicates an immediately threatening hazard.
Failure to observe this warning notice will result in severe physical injury or death.
WARNING
indicates a potentially dangerous situation.
Failure to observe this warning notice may result in severe physical injury or
death.
CAUTION
indicates a potentially harmful situation.
Failure to observe this notice may result in damage to property.
DANGER –electrical voltage
indicates an immediately threatening hazard.
Failure to observe this warning notice will result in severe physical injury or death.
CAUTION! IMPORTANT
Improper use may result in minor injuries or damage to property.
In addition to these Instructions for Use, a number of accident prevention and other
regulations apply with regard to the operation of this appliance. As regards food
handling, please observe HACCP rules concerning compliance with hygiene require-
ments.
If you have any questions, please contact your supervisor(s) or safety representa-
tive.
This product must not be disposed of in domestic waste.
Please arrange for proper recycling of this product via your local provider of waste
disposal services.

GBA C 0100 2 E
BA Page 10 of 26 Januar 16, 2018
Last revised 01-2018 Rev. 2
Scholl Apparatebau GmbH & Co. KG
2 PRODUCT INFORMATION
Hot plates are electrically heated and are used for keeping the preheated food and baked goods on output
temperature. Hot plates are feeded from above using appropriate dishes.
2.1 EXECUTION
Chrome nickel steel 18/10
Continuously adjustable temperature from 30°C - 100°C by thermostat
With control lamp
Voltage 230 V~, power 500-2000 W
connecting cable approx. 1,7m long, with right angle plug
115 mm total height
2.2 INFORMATION REGARDING COMPLIANCE WITH STANDARDS,LAWS AND DIRECTIVES
This appliance conforms to the following:
Standards, laws, directives
2006/95/EG
Low Voltage Directive
DIN EN 60335-1
Household and similar electrical appliances - Safety
- Part 1: General requirements
DIN EN 60335-2-12
Household and similar electrical appliances –Safety
- Part 2-12: Particular requirements for warming plates and similar
appliances
