Schrack Technik HSMPES06 User manual
WINSTRUCTION SHEET: HSMPE
PAGE 1/5
INSTRUCTION SHEET: HSMPE_E / 02-2015
Errors and omissions excepted.
SCHRACK TECHNIK GMBH
Seybelgasse 13, A - 1230 Vienna, PHONE +43 1/866 85-0
1 Power strip (variations not shown)
2 Fixing brackets
3 Screws 2.9 x 10 mm
WTECHNICAL DATA
WSCHRACK-INFO
• Power supply voltage: ~ 230 V
• Measurement range: 0,1A - 16 A
• Temperature range: + 5...+ 45°C
• Storage temperature: -15...+40°C
• Relative humidity: < 80% non-condensing
Measurement and
display values
Power
(I)
Voltage (U) Effective
power (P)
Energy
consumption
(kWh)
Phase shift angle (φ)Frequency
(f)
Measuring accuracy 0.01 A 0.1 V 1 W 1 Wh 0.1 ° 0.1 Hz
Display accuracy 0.1 A 1 V 1 W 1 Wh 1 ° 1 Hz
PAGE 2/5
INSTRUCTION SHEET: HSMPE_E / 02-2015
Errors and omissions excepted.
SCHRACK TECHNIK GMBH
Seybelgasse 13, A - 1230 Vienna, PHONE +43 1/866 85-0
WSAFETY INFORMATION
Use only in indoor, well ventilated and dry areas.
Never use the power strip immediately after bringing it into a warm room from a cold one.
The condensation this creates can, in some cases, cause a shortcircuit and destroy the product.
It also presents a fatal electrocution hazard!
The power cable of the power strip must be neither repaired nor replaced. If the power cable is damaged, the
power strip must be replaced.
Ensure when selecting the installation site that no high humidity, high temperatures (see Technical Data),
PRLVWXUHVROYHQWVÀDPPDEOHJDVHVGXVWRUYDSRUVDUHSUHVHQW 7KHKHDWJHQHUDWHGGXULQJRSHUDWLRQPXVW
be dissipated.
The power strip may be operated only when connected to power socket protected by a 16A fuse. Do not ex-
ceed the maximum power transmission (see Technical Data). If the power strip shows outward signs of wear
from transport or improper handling, it must not be put into operation or must be put out of operation immedi-
ately and must be replaced or sent back to the manufacturer for repair.
Danger of fatal electric shock:
Never carry out work on the power strip with wet hands.
5LVNRI¿QJHUFUXVKLQJGXULQJLQVWDOODWLRQRUPRXQWLQJZRUN
is a maintenance-free system.
There is no need to open the housing during installation.
Do not use aggressive substances such as spirits or acids to clean the unit, as these can damage it.
To clean the housing use a slightly moistened cloth.
Observing these notices is part of our terms of warranty.
7KHSURGXFWIXO¿OOVWKHUHTXLUHPHQWVRIWKHYDOLG(XURSHDQDQGQDWLRQDOGLUHFWLYHVDQGVWDQGDUGV
7KH&(FRQIRUPLW\KDVEHHQGRFXPHQWHGDQGWKHFRUUHVSRQGLQJFHUWL¿FDWHVDUHRQ¿OHDWWKH
manufacturer's location.
This
WINTENDED USE
The power strip is intended solely for the common connection of different electrical devices in power consumption of
the connected equipment for consumption monitoring purposes.
Uses other than that specified above are not permitted and may lead to damage to the power strip. No modification
may be made to any part of the power strip. Any such modification forfeits all warranty liability.
PAGE 3/5
INSTRUCTION SHEET: HSMPE_E / 02-2015
Errors and omissions excepted.
SCHRACK TECHNIK GMBH
Seybelgasse 13, A - 1230 Vienna, PHONE +43 1/866 85-0
WINSTALLATION
)RU¿WWLQJLQDFDELQHWPRXQWWKH¿[LQJEUDFNHWVRQWR
the power strip.
Place the brackets in the desired position on the
power strip, insert and tighten screws.
7KH¿[LQJEUDFNHWVPXVWEH¿WWHGLQWKHVDPHSRVLWL-
on on both sides.
3RVLWLRQWKHSRZHUVWULSRQWKHPRXQWLQJSUR¿OHRI
the cabinet.
Fixing materials are not included.
Installation Options
7KHYHUVDWLOHPRXQWLQJEUDFNHWVFDQEH¿WWHGWRWKH
power strip in four different positions (each rotated
by 90°).
This facilitates installation of the power strip accor-
ding to individual needs.
PAGE 4/5
INSTRUCTION SHEET: HSMPE_E / 02-2015
Errors and omissions excepted.
SCHRACK TECHNIK GMBH
Seybelgasse 13, A - 1230 Vienna, PHONE +43 1/866 85-0
WINITIAL OPERATION
WDISPLAY
The following values can be read from
the display.
Display Overview
1
2
3
4
5
6
1. kW - Power measurement
Electrical output of all connected devices taking
into account the phase shift.
2. Hz - Frequency
Current power frequency.
3. kWh - Kilowatt-hour
Records the power consumed by all connected
devices. The counter reading is stored and can
be reset to zero using the Reset button.
4. V - Power supply voltage
Current voltage of the power supply.
5. Phase angle
Displays the phase shift in the power supply.
6. A - Amps
Current drawn at the present time by all con-
nected devices.
The display (arrow) is situated on the front of the
power strip.
7KHYDOXHVVKRZQLQWKHGLVSOD\IXO¿OO$FFXUDF\
class 1.
Insert the power strip's plug into the power socket.
Press button (1) to activate the display (arrow).
The display will turn of again after 30 seconds.
Now you may plug your equipment into the power
strip.
For voltage and current consumption... see Technical
Data.
Before interrupting the power supply to your equip-
ment, make certain that the equipment has been
correctly switched off.
PAGE 5/5
INSTRUCTION SHEET: HSMPE_E / 02-2015
Errors and omissions excepted.
SCHRACK TECHNIK GMBH
Seybelgasse 13, A - 1230 Vienna, PHONE +43 1/866 85-0
WOPERATION
Press the button (1) to reactivate the display.
Button (1) must be pressed for at least one second.
The display will now light up.
By pressing button (1) for at least 10 seconds, the
energy counter will be reset to zero.
This process can be carried out at any time during
operation (the connected devices do not have to be
shut off).
The displayed kWh counter reading is stored and
retained even if the power strip is unplugged.
If necessary, write down the current counter reading
¿UVW
Press the button (1) until the kWh counter reading
(arrow) is at zero.
The kWh counter resumes counting immediately
after you release the button (1).
WWHAT TO DO IF...
WSTORAGE AND DISPOSAL
We recommend that the power strip be disconnected
from the power supply and
stored if it is not to be used for an extended
period.
Protect power strips in storage from mois-
ture and dust; for further informationsee
Technical Data.
Do not throw electrical devices into
household waste. These must be disposed
of in an environmentally responsible man-
ner via your local collection point!
Display no longer
shows all readings.
Unplug power strip from power
supply and plug back in. Strip
re-starts.
Connected equipment
must be switched
off before strip is
unplugged.
No voltage at a
socket on the strip.
Contact our service department.
