OPERATING INSTRUCTIONS
Parquet Saw FBS P
Order no. 619006 2021-07

3
2021-07 OPERATING IN TRUCTION
Parquet saw FB P
# 619006
TABLE OF CONTENTS
CHAP 1 afety instructions 4-7
CHAP 2 Product Information
2.1 Technical description 8
2.2 Technical data 8
2.3 Identification 9
2.3 Standard accessories 9
2.4 Accessories and tools 9
CHAP 3 Operation
3.1 Operating elements 10
3.2 Startup 11/12
3.3 Working method 13
3.4 Tool selection 13
CHAP 4 Maintenance
4.1 Tool selection 14
4.2 Maintenance and care 15
4.3 Troubleshooting 15
4.4 Disposal 15
CHAP 5 pare Parts
5.1 Attachment parts
5.2 Motor parts
Declaration of Conformity att

4 OPERATING IN TRUCTION 2021-07
Parquet saw FB P
# 619006
1 AFETY IN TRUCTION
DEVICE AFETY
Before using the electrical device, read and act upon the operating instructions and the safety
instructions, commands and local accident prevention rules and regulations.
Failure to comply with or disregard the symbols attached to the appliance or this manual may
result in electric shock, fire and / or serious injury to the operator or bystanders.
The electrical appliances are manufactured according to the state of the art and recognized
safety rules. Nevertheless, if used improperly, hazards to persons as well as the impairment of
the electrical appliance and other property may arise.
When working with the electrical appliance, pay attention to third parties, especially children. If
the appliance fails, it must be switched off immediately and disconnected from the mains to
prevent further damage or damage. Safety-impairing disturbances are to be eliminated
immediately.
Explanation
of symbols
INTENDED U E
The parquet saw (hereinafter also referred to as electrical appliance, appliance or machine) is
intended exclusively for cutting parquet and wood-based surfaces prior to detachment, as well
as for cutting and cleaning joints and cracks in mineral surfaces, only by using the tools
recommended in this manual.
The operator is expressly advised that the appliance may only be used as intended.
The appliance is NOT suitable for the following applications:
- Machining with cutting discs or wire brushes
- Machining of doors, frames or freestanding objects.
In the case that the electrical appliance is not used as intended, this is the sole responsibility of
the user. Any liability of the manufacturer is therefore eliminated.
Read and follow all safety instructions. Make sure that the nameplate, safety symbols such as
bids warnings precautions and instructions are attached to the electrical appliance or included
in the user manual. Failure to comply with or disobey the instructions on this product or in this
manual may result in danger, electric shock, fire, and / or serious injury or damage.
ACCE ORIE / APPLICATION TOOL
Only use the recommended accessories and make sure that they are working properly.
Only use original spare parts and accessories.
If you can attach other types of accessories or attachments, safe use of the appliance is not
guaranteed.
Commandment Warning Hint Prohibition

5
2021-07 OPERATING IN TRUCTION
Parquet saw FB P
# 619006
1 AFETY IN TRUCTION
The insert tool must have at least as high a permissible speed as the maximum speed indicated
on the electrical appliance. Failure to comply with the risk of breakage and flying around the
tool.
The dimensions of the insert tool must correspond to the dimensions of the electrical appliance
and must fit exactly on the spindle of the electrical appliance. When using unsuitable tools
danger by strong Virbration, imbalance and thus loss of control of the electrical device.
Check the tools for damage or heavy wear before each use. Do not use damaged tools.
If the appliance or tool has been dropped, check the tool or use undamaged. To exclude any
visible damage, insert the insert tool and start a test run. Run the electrical device for one
minute at maximum speed, usually breaking damaged tools within this test time.
OCCUPATIONAL AFETY / OCCUPATIONAL AFETY
Always wear the following protective equipment while using the appliance: protective goggles,
dust mask, ear protection, protective gloves and sturdy shoes. During detachment, noises of
such high intensity may occur which, if prolonged, may result in damage to the ear canal.
Without protective suits or devices during use, eyes or body may be injured. Dust can spread
in the air and be inhaled while using the appliance.
eep hands, feet, and non-adherent parts of clothes away from rotating insert tool.
Never disconnect the appliance before the tool has come to a complete standstill. The rotating
insert tool may come into contact with the shelf, which may cause you to lose control of the
electrical appliance and cause serious injury. The rotating insert tool can cause serious injury
and / or damage.
eep others at a safe distance from your work area. Anyone entering the work area must wear
personal protective equipment. Fragments of the workpiece or broken insert tools may fly away
and cause injury even outside the direct working area.
Always keep the power cord above the electrical appliance and away from the rotating tool so
that it does not come into contact with it. Overmilling or damage to the cable by the electrical
device may result in electric shock.
Always hold the appliance by its insulated gripping surfaces to avoid the risk of electric shock
when accidentally overcutting hidden power lines or the power cord.
Do not run the appliance while carrying it. Your clothing may be caught by accidental contact
with the rotating insert tool, which can cause serious injury.
WORKING ENVIRONMENT
The electrical appliance is only suitable for indoor use.
Do not expose the appliance to water or rain. Risk of electric shock.
Do not use the appliance near flammable materials.
Risk of ignition and explosion due to sparking.
No Smoking!
Ventilate rooms regularly!

6 OPERATING IN TRUCTION 2021-07
Parquet saw FB P
# 619006
MAINTENANCE / REPAIR
When working on the electrical device always unplug the mains plug! Maintenance,
replacement, or adjustment of the tool or engine components may result in personal injury to
the operator and / or bystanders when the electrical appliance is plugged into the electrical
outlet.
Clean the ventilation slots of the electrical appliance regularly.
The engine fan pulls dust into the case - a heavy build-up of metal dust can cause electrical
hazards.
Do not disassemble the appliance and do not attempt your own repair. If you have problems or
questions, please contact the manufacturer. The repair may only be carried out by trained,
expert persons.
When replacing spare parts or electrical connections, the technical data specified by the
manufacturer must be observed or original spare parts must be used.
The electrical appliance must not be used if the condition of all connecting cables or
components is not perfect.
ELECTRICAL CONNECTION / ELECTRICAL COMPONENT
Only connect the electrical appliance to the electrical values stated on the rating plate.
Check before startup.
Only connect the appliance to an approved power cord and plug.
For Europe must have power cables of the approved type HAR designation H07BQ-F3G1,50
and plugs of approved type 2P + T16A-250V are used. Using the appliance with cables of
insufficient average and / or excessive length may result in personal injury or property damage.
Have electrical equipment such as a relay, protective circuit or power line checked by an
authorized electrician. If the voltage loop is repeatedly snapped or undershot, it can cause
electrocution.
Never work with a damaged cable or plug. Worn or damaged cables or plugs should be
replaced by an electrician or authorized service personnel.
Never switch off the earthing cable or render it unusable. Using the appliance in an
ungrounded circuit can result in electrocution.
Consult an electrician if the grounding wire is missing or if you believe that the circuit does not
have adequate grounding.
Do not use the appliance if the cable is damaged. Do not pull on the cable to move the
electrical appliance. Using the appliance with a damaged cord can cause electric shock.
Work on electrical components of the electrical appliance may only be carried out by a
qualified electrician.
1 AFETY IN TRUCTION

7
2021-07 OPERATING IN TRUCTION
Parquet saw FB P
# 619006
KICKBACK AND RELATED WARNING
ickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad, brush or
any other accessory.
Pinching or snagging causes rapid stalling of the rotating accessory which in turn causes the
uncontrolled power tool to be forced in the direction opposite of the accessory’s rotation at the
point of the binding.
For example, if an abrasive wheel is snagged or pinched by the workpiece, the edge of the
wheel that is entering into the pinch point can dig into the surface of the material causing the
wheel to climb out or kick out. The wheel may either jump toward or away from the operator,
depending on direction of the wheel’s movement at the point of pinching. Abrasive wheels
may also break under these conditions.
ickback is the result of power tool misuse and/or incorrect operating procedures or conditions
and can be avoided by taking proper precautions as given below.
Maintain a firm grip on the power tool and position your body and arm to allow you to resist
kickback forces. Always use auxiliary handle, if provided, for maximum control over kickback or
torque reaction during start-up. The operator can control torque reactions or kickback forces, if
proper precautions are taken.
Never place your hand near the rotating accessory. Accessory may kickback over your hand.
Do not position your body in the area where power tool will move if kickback occurs. ickback
will propel the tool in direction opposite to the wheel’s movement at the point of snagging.
Use special care when working corners, sharp edges, etc. Avoid bouncing and snagging the
accessory. Corners, sharp edges or bouncing have a tendency to snag the rotating accessory
and cause loss of control or kickback.
Do not attach a saw chain woodcarving blade or toothed saw blade.
Such blades create frequent kickback and loss of control.
1 AFETY IN TRUCTION

8 OPERATING IN TRUCTION 2021-07
Parquet saw FB P
# 619006
2 PRODUCT INFORMATION
2.1 Technical description
With our new parquet saw, its 2400 watt strong motor and the especially
manufactured saw blades, continuous ergonomic work when cutting parquet
flooring is guaranteed.
Professional device for the renovation of cracks and joints up to 50 mm depth and
for cutting parquet before removing. With integrated connection for dust extraction.
(Vacuum connection suitable for 50 mm and 76 mm connectors)
2.3 Identification
Do not press spindle lock
during operation!
2.2 Technical data
Saw Blade -Ø : 180 / 205 mm
Motor Power : 2400 W
Speed : 8.500 U/min
Cutting depth infinitely adjustablw : up to max. 50mm
Sound emission values determined according to EN 60745
Typically the A-weighted noise levels of the product are:
- Sound pressure level : 84 dB(A)
- Sound power level : 95 dB(A)
- Uncertainty : = 3 dB
Vibration total values when surface grinding:
- Emissivity : ah = 6,0 m/s²
- Uncertainty : = 1,5 m/s²
The vibration level given in this information sheet has been measured in accordance with a
standardised test given in EN 62841 and may be used to compare one tool with another. It may
be used for a preliminary assessment of exposure.The declared vibration emission level
represents the main applications of the tool. However if the tool is used for different applications,
with different accessories or insertion tools or is poorly maintained, the vibration emission may
differ.
IDENTIFICATION LABEL
HINT
Dispose of the machine according to
Directive 2012/19/EU
EC conformity
Protective insulation Protection class II
Read the operating instructions
before operation
Wear ear protection at noise
above 85 db (A)!

9
2021-07 OPERATING IN TRUCTION
Parquet saw FB P
# 619006
2 PRODUCT INFORMATION
2.4 tandard accessories
(A) Angle grinder with suction
housing
and guide rod (disassembled)
(B) 5 x Standard saw blade
for wood
1 x already installed
4 x replacement part
(C) Tool for saw blade change
(D) Tools and accessories for
guide rod assembly
(E) Cable rewind
(A)
(B)
(E)
(C)
(D)

10 OPERATING IN TRUCTION 2021-07
Parquet saw FB P
# 619006
3 OPERATION
3.1 Operating elements
Safety switch
Height
adjustment
Wheel guide
Guide handle
Height adjustable
Depth adjustment
sawblade
Drive motor
Mobile suction
housing with
extraction nozzle

11
2021-07 OPERATING IN TRUCTION
Parquet saw FB P
# 619006
Assembly of the guide rod
For easy transport, the device is delivered disassembled.
Assembly according to the following steps:
1. Attach bracket:
Place the guide rod on the machine recess with the bracket, screw and nut.
Then screw on with the ring spanner. Fix from the bottom with the nut.
2. Attach saw blade adjustment:
Fix the adjusting rod to the housing with the fastening bolt and the angled screwdriver.
3. Hang the tension spring inon the bracket. 4. Attach clamping screw for grip angle
The standard saw blade for wood is already installed, the device is now ready for use.
Disassembly in reverse order.
3 OPERATION
3.2 tartup

12 OPERATING IN TRUCTION 2021-07
Parquet saw FB P
# 619006
3 OPERATION
CONTROL
Please check before every start whether all device
parts are assembled safely and correctly.
The electrical device is equipped with a switch-on /
lock. This prevents unwanted start-up and locks the
switch in continuous operation.
WITCHING ON AND OFF
Connecting the power supply.
Schnitttiefeneinstellung in Ruheposition
Hook the safety line on the safety switch
on the right hand and insert the switch.
Turn on the device on the angle motor with
your left hand as follows
Continuous operation with switch locking:
Slide the lock (1) in the direction of the arrow and then
press and hold the switch lever (2). The device is now
switched on.
For continuous operation, push the lock (1) once more
in the direction of the arrow to lock the switch push-
button (2).
To switch off, press and release the switch lever (2) or
pull out the safety switch key.
Restart protection - after a power failure, the switched-
on power tool does not restart!
Always operate the device with both hands on the
guide handle and with hinged safety switch.
3.2 tartup
(1) (2)

13
2021-07 OPERATING IN TRUCTION
Parquet saw FB P
# 619006
3 OPERATION
3.4 Choice of tools
Standard or P D saw blade
For cutting parquet and wood-based surfaces
Diamond cutting disc
For cutting and cleaning joints and cracks in mineral surfaces
3.3 Working method
ET CUTTING DEPTH
The desired depth of cut can be infinitely adjusted with the adjusting lever (1)
and the wing nut setting (2).
Rest position - no cutting depth maximum cutting depth
Before switching on, lift the appliance off the floor.
Switch on the electrical appliance and start it up.
Place the device with both hands on the handle - position the cutting disc on the joint
or the surface of the parquet - push it forward evenly.
Hold the unit firmly with both hands
Make sure that neither hands nor feet get into the area of the cutting disc, otherwise
you may seriously injure yourself!
Always wear ear protection and safety glasses when working.
U E OF A UCTION DEVICE
If the dust level is too high, wear respiratory protection and attach the vacuum cleaner
to the nozzle of the hood. First turn on the scrubber vacuum, then switch on the
appliance.
END OF WORK
Release the lock and pull out the mains plug. After switching off, the sanding pad will
continue to run for a short time. Make sure that all rotating parts of the device have
(1)
(2)

14 OPERATING IN TRUCTION 2021-07
Parquet saw FB P
# 619006
Unplug the power cord!
Set depth setting to rest position.
Put the device on its side.
open damper
Remove saw blade guide.
Set saw blade depth to maximum.
To unscrew, press the spindle lock with
one hand and release the saw blade nut
with fork wrenches
Insert the new saw blade in reverse order CAUTION
To avoid imbalance, the cutting disc must
be aligned in the middle of the guide
Remove saw blade, spacers
and mounting nut
4 MAINTENANCE
4.1 Insert / replace tools

15
2021-07 OPERATING IN TRUCTION
Parquet saw FB P
# 619006
4 MAINTENANCE
4.2 Cleaning and care
4.3 Troubleshooting
4.4 Disposal
Before any maintenance / care or repair work unplug the power cord.
CLEANING
Wipe the electrical appliance regularly with a dry cloth.
Check the ventilation slots on the engine block regularly and keep them clean.
Clean the inside of the hood after each use of fixed dirt and blow out with dry
compressed air.
MAINTENANCE
The Flex motor is equipped with carbon brushes. If the wear limit is reached, the
electronic device switches off automatically.
Through the vents the coal fire can be observed during use.
In case of strong coal fire, switch off the appliance immediately and send it to the
manufacturer or an authorized service center.
REPAIR
Repairs or replacement of electrical components should only be carried out
by a specialist.
The product you have purchased is subject to Directive 2012/19/EU of the
European Parliament and the Council of the European Union on waste electrical
and electronic equipment (WEEE) and should not be disposed of as unsorted
municipal waste. Please utilize your local WEEE collection facilities in the
disposition of this product and otherwiseobserve all applicable national
requirements.
Does the safe use or maintenance of the appliance raise any questions, do not hesitate to contact
ither your dealer.
Cause
Machine will
not start
Loud engine
noise
Insufficient
performance
High
vibration
Elimination
No electricity
Power cord defective
Coals worn out
Bearing or gear parts
defective
Worn abrasive
Unsuitable abrasive
Imbalance of the
grinding plate
Fault
Check mains voltage
Replace power cord
Exchange coals
Replace parts
Replace abrasive
Check correct fit
Replace sanding pad

DECLARATION OF CONFORMITY
We Schwam orn Gerate au Gm H
Ro ert-Bosch-Strasse 8
73117 Wangen/Göppingen
GERMANY
declare under our responsi ility that the product
Machine type Parquet Saw FBS P
Order-No. 619006
Serial-No. ______________________
Year of manufacture ______________________
comply with the EU-Directrives
Machinery directive 2006/42/EC
EMC directive 2004/108/EC
in accordance with with following standards
EN 62841
Wangen, July 2021
Signatory:
Eckart Schwam orn, managing director

17
2021-07 OPERATING IN TRUCTION

18 2021-07
OPERATING IN TRUCTION

19
2021-07 OPERATING IN TRUCTION

Schwamborn eratebau mbH
Robert-Bosch-Strasse 8
73117 Wangen/ öppingen
Tel.: [phone]
[email protected]
