Grizzly G0513 SERIES User manual

G0513/G0514 Heavy-Duty Bandsaw -41-












 





































 
 


 


 












































 
  




G0513/G0514

-42- G0513/G0514 Heavy-Duty Bandsaw







 



 









 








 










G0513/G0514

G0513/G0514 Heavy-Duty Bandsaw -43-
 








































G0513/G0514

-44- G0513/G0514 Heavy-Duty Bandsaw
REF PART # DESCRIPTION
04 P0513004 RING 10MM
05 P0513005 MACHINE BODY
06 PSS07M SET SCREW M5-0.8 X 5
08 PW03M FLAT WASHER 6MM
09 PWRCRD220L POWER CORD
10 PN01M HEX NUT M6-1.0
11 P0513011 POINTER
12 P0513012 STEP SCREW
13 P0513013 UPPER SHAFT
14 PRP10M ROLL PIN 5 X 36
15 P0513015 UPPER WHEEL SHAFT HINGE
16 P0513016 UPPER WHEEL SHAFT
17 P0513017 BUSHING
18 P6204 BEARING 6204
19 P0513019 UPPER WHEEL 17"
20 PR25M INT RETAINING RING 47MM
21 PW01M FLAT WASHER M8
22 PSB13M CAP SCREW M8-1.25 X 30
23 P0513023 SAW BLADE 131.7" X 0.5" X 5MM
24 PLW04M LOCK WASHER 8MM
25 PSB07M CAP SCREW M6-1.0 X 30
26 P0513026 TIRE
27 P0513027 LOWER WHEEL 17"
28 P0513028 IDLE PULLEY
29 PN32 HEX NUT 1"-14
30 PLW09 LOCK WASHER 1"
31 P0513031 MOTOR CORD
32 P0513032 SPRING
33 PRP02M ROLL PIN 3 X 16
34 P0513034 LOCATE BLOCK
35 P51201 BEARING 51201
36 P0513036 SWITCH
37 P0513037 HANDWHEEL
38 P0513038 ADJUSTING ROD
39 PFS07M FLANGE SCREW M5-.8 X 10
40 PTLW02M EXT TOOTH WASHER 5MM
41 PN06M HEX NUT M5-0.8
42 PFS08M FLANGE SCREW M5-0.8 X 16
43 P0513043 SWITCH PLATE
44 PSB11M CAP SCREW M8-1.25 X 16
45 PW01M FLAT WASHER 8MM
46 P0513046 UPPER WHEEL SLIDING BRACKET
47 PSB06M CAP SCREW M6-1.0 X 25
48 P013048 RIVET 3.2 X 10MM
49 PSB04M CAP SCREW M6-1.0 X 10
50 P0513050 CLEAR WINDOW
55 P0513055 UPPER WHEEL COVER
56 PSB06M CAP SCREW M6-1.0 X 25
57 PW03M FLAT WASHER 6MM
58 P0513058 BRUSH
59 PSB06M CAP SCREW M6-1.0 X 25
60 P0513060 STAR HANDLE
61 P0513061 NYLON NUT M6-1.0
REF PART # DESCRIPTION
62 P0513062 STRAIN RELIEF
63 P0513063 POINTER
64 PN03M HEX NUT M8-1.25
65 PB45M HEX BOLT M8-1.25 X 100
66 P0513066 KNOB BOLT M10-1.5 X 20
67 P0513067 KNOB BOLT M10-1.5 X 53
68 P0513068 THREADED HANDLE M10-1.5
69 P0513069 CAM
70 P0513070 PILLOW BLOCK
71 P0513071 KNOB
72 P0513072 LEVER ROD
73 PN09M HEX NUT M12-1.75
74 P0513074 SHAFT
75 PSB14M CAP SCREW M8-1.25 X 20
76 PLW04M LOCK WASHER 8MM
77 PLW03M LOCK WASHER 6MM
78 P0513078 COVER
79 PSS09M SET SCREW M8-1.25 X 20
80 PN03M HEX NUT M8-1.25
81 P0513081 LOWER WHEEL SHAFT
82 P0513082 MOTOR 2HP
82-1 P0513082-1 MOTOR FAN COVER
83 PB79M HEX BOLT M10-1.5 X 25
84 PLW06M LOCK WASHER 10MM
85 P0513085 MOTOR BRACKET
86 PSB14M CAP SCREW M8-1.25 X 20
87 P0513087 PLATE
88 PFS07M FLANGE SCREW M5-0.8 X 10
89 P0513089 PILLOW BLOCK
90 PK15M KEY 5 X 5 X 35
91 PB81M HEX BOLT M8-1.0 X 20 LH
92 P0513092 MOTOR PULLEY
93 P0513093 V-BELT A42
94 PSB04M CAP SCREW M6-1.0 X 10
95 P0513095 LOWER WHEEL COVER
96 PW03M FLAT WASHER 6MM
97 PW01M FLAT WASHER 8MM
98 PSB84M CAP SCREW M10-1.5 X 35
99 PN02M HEX NUT M10-1.5
100 P0513100 SMALL GEAR
101 P0513101 STAR HANDLE
102 P0513102 TRUNNION SUPPORT BRACKET
103 PLW06M LOCK WASHER 10MM
104 PW04M FLAT WASHER 10MM
105 PSB28M CAP SCREW M6-1.0 X 15
106 PSB37M CAP SCREW M6-1.0 X 50
107 P0513107 PILLOW BLOCK
108 PN01M HEX NUT M6-1.0
109 P0513109 ADJUSTMENT BOLT M6-1.0
110 P6000 BEARING 6000
111 PSB61M CAP SCREW M10-1.5 X 20
112 PW01M FLAT WASHER 8MM
113 PW01M FLAT WASHER 8MM
G0513

G0513/G0514 Heavy-Duty Bandsaw -45-
REF PART # DESCRIPTION
114 PS17M PHLP HD SCR M4-0.7 X 6
115 P0513115 GEAR PLATE
116 P0513116 NYLON NUT M8-1.25
117 PS17M PHLP HD SCR M4-0.7 X 6
118 P0513118 LOCK HANDLE
119 PW05M FLAT WASHER 4MM
120 P0513120 POINTER
121 P0513121 TRUNNION PLATE
122 PLW04M LOCK WASHER 8MM
123 PB03M HEX BOLT M8-1.25 X 16
124 PCB23M CARRIAGE BOLT M8-1.25 X 80
125 P0513125 FENCE ASSEMBLY W/RAILS
126 P0513126 TABLE 17" X 17"
127 P0513127 TABLE INSERT
128 P0513128 TABLE PIN
129 PSB85M CAP SCREW M6-1.0 X 6
130 P0513130 LEFT COVER
131 PTS001M THUMB SCREW M6-1 X 16
132 P0513132 LOWER BLADE GUIDE SUPPORT
133 P0513133 GUIDE RING
134 P0513134 LOWER ADJUST SHAFT
135 P0513135 RIGHT COVER
136 PSB50M CAP SCREW M5-0.8 X 10
137 PW02M FLAT WASHER 5MM
138 P0513138 PROTECTIVE COVER
139 PSB72M CAP SCREW M10-1.5 X 30
140 P0513140 STEP SCREW
141 P0513141 FLAT WASHER
142 P0513142 SLIDING PLATE
143 PR05M EXT RETAINING RING 15MM
144 P6202 BEARING 6202
145 P0513145 UPPER BLADE GUIDE SUPPORT
146 P0513133 GUIDE RING
147 PTS001M THUMB SCREW M6-1.0 X 16
148 PCB10M CARRIAGE BOLT M8-1.25 X 85
149 PSB28M CAP SCREW M6-1.0 X 15
150 P0513150 ADJUST BAR
151 P0513151 UPPER SPACING SLEEVE
152 PSB02M CAP SCREW M6-1.0 X 20
153 P0513153 UPPER GUIDE SUPPORT BLOCK
REF PART # DESCRIPTION
154 PS38M PHLP HD SCR M4-0.7 X 10
155 PN04M HEX NUT M4-0.7
156 P0513156 RACK
157 P0513157 UPPER GUIDE HOSE
158 P0513158 HANDWHEEL
159 PSB02M CAP SCREW M6-1.0 X 20
160 P0513160 LOCATE BUSHING
161 P0513161 BUSHING
162 PSB14M CAP SCREW M8-1.25 X 20
163 PLW04M LOCK WASHER 8MM
164 P0513164 GUIDE BRACKET
165 P0513165 WORM CYLINDER
166 P0513166 FIXED PLATE
167 P0513167 GEAR
168 P0513168 FIXED BOLT
169 P0513169 COVER
170 PSB11M CAP SCREW M8-1.25 X 16
171 PS07M PHLP HD SCR M4-0.7 X 8
172 PSS11M SET SCREW M6-1.0 X 16
173 P0513173 MITER GAUGE ASSY
173-1 P0513173-1 GUIDE BAR
173-2 P0513173-2 GUIDE
173-3 P0513173-3 POINTER
173-4 P0513173-4 NYLON WASHER 1⁄4"
173-5 P0513173-5 HANDLE 1⁄4"
173-6 P0513173-6 MITER GAUGE BODY
173-7 P0513173-7 SHAFT
173-8 PS37M PHLP HD SCR M6-1.0 X 6
173-9 PFS01M FLANGE SCREW M5-0.8 X 8
174 P0513174 BRUSH
175 PSB02M CAP SCREW M6-1.0 X 20
176 P0513176 BUSHING
177 P0513177 MACHINE WARNING/ID
178 PLABEL-14 ELECTRICITY WARNING
179 PLABEL-11 SAFETY GLASSES WARNING
180 PLABEL-12 READ MANUAL WARNING
181 PLABEL-19 BLADE TOUCH WARNING
182 PLABEL-20 DOOR CLOSE WARNING
183 PLABEL-18 UNPLUG WARNING
184 G8588 CAST LOGO
G0513

-46- G0513/G0514 Heavy-Duty Bandsaw
REF PART # DESCRIPTION
04 P0513004 RING 10MM
05 P0514005 MACHINE BODY
06 PSS07M SET SCREW M5-0.8 X 5
08 PW03M FLAT WASHER 6MM
09 PWRCRD220L POWER CORD
10 PN01M HEX NUT M6-1.0
11 P0513011 POINTER
12 P0513012 STEP SCREW
13 P0513013 UPPER SHAFT
14 PRP10M ROLL PIN 5 X 36
15 P0513015 UPPER WHEEL SHAFT HINGE
16 P0513016 UPPER WHEEL SHAFT
17 P0513017 BUSHING
18 P6204 BEARING 6204
19 P0514019 UPPER WHEEL 19"
20 PR25M INT RETAINING RING 47MM
21 PW01M FLAT WASHER 8MM
22 PSB13M CAP SCREW M8-1.25 X 30
23 P0514023 SAW BLADE 143" X .75" X 5MM
24 PLW04M LOCK WASHER 8MM
25 PSB07M CAP SCREW M6-1.0 X 30
26 P0514026 TIRE
27 P0514027 LOWER WHEEL 19"
28 P0514028 IDLE PULLEY
29 PN32 HEX NUT 1"-14
30 PLW09 LOCK WASHER 1"
31 P0513031 MOTOR CORD
32 P0513032 SPRING
33 PRP02M ROLL PIN 3 X 16
34 P0513034 LOCATE BLOCK
35 P51201 BEARING 51201
36 P0513036 SWITCH
37 P0513037 HANDWHEEL
38 P0513038 ADJUSTING ROD
39 PFS07M FLANGE SCREW M5-0.8 X 10
40 PTLW02M TOOTH LOCK WASHER 5MM
41 PN06M HEX NUT M5-0.8
42 PFS08M FLANGE SCREW M5-0.8 X 16
43 P0513043 SWITCH PLATE
44 PSB11M CAP SCREW M8-1.25 X 16
45 PW01M FLAT WASHER 8MM
46 P0513046 UPPER WHEEL SLIDING BRACKET
47 PSB05M CAP SCREW M6-1.0 X 50
48 P0513048 RIVET 3.2 X 10MM
49 PSB04M CAP SCREW M6-1.0 X 10
50 P0513050 CLEAR WINDOW
55 P0514055 UPPER WHEEL COVER
56 PSB06M CAP SCREW M6-1.0 X 25
57 PW03M FLAT WASHER 6MM
58 P0513058 BRUSH
59 PSB06M CAP SCREW M6-1.0 X 25
60 P0513060 STAR HANDLE
REF PART # DESCRIPTION
61 P0513061 NYLON NUT M6-1.0
62 P0513062 STRAIN RELIEF 16MM
63 P0513063 POINTER
64 PN03M HEX NUT M8-1.25
65 PB45M HEX BOLT M8-1.25 X 100
66 P0513066 KNOB BOLT M10-1.5 X 20
67 P0513067 KNOB BOLT M10-1.5 X 53
68 P0513068 THREADED HANDLE M10-1.5
69 P0513069 CAM
70 P0513070 PILLOW BLOCK
71 P0513071 KNOB
72 P0513072 LEVER ROD
73 PN09M HEX NUT M12-1.75
74 P0513074 SHAFT
75 PSB14M CAP SCREW M8-1.25 X 20
76 PLW04M LOCK WASHER 8MM
77 PLW03M LOCK WASHER 6MM
78 P0513078 COVER
79 PSS09M SET SCREW M8-1.25 X 20
80 PN03M HEX NUT M8-1.25
81 P0513081 LOWER WHEEL SHAFT
82 P0513082 MOTOR 2HP
83 PB79M HEX BOLT M10-1.5 X 25
84 PLW06M LOCK WASHER 10MM
85 P0513085 MOTOR BRACKET
86 PSB14M CAP SCREW M8-1.25 X 20
87 P0513087 PLATE
88 PFS07M FLANGE SCREW M5-0.8 X 10
89 P0513089 PILLOW BLOCK
90 PK15M KEY 5 X 5 X 35
91 PB81M HEX BOLT M8-1.0 X 20 LH
92 P0514092 MOTOR PULLEY
93 P0514093 V-BELT A42
94 PSB04M CAP SCREW M6-1.0 X 10
95 P0514095 LOWER WHEEL COVER
96 PW03M FLAT WASHER 6MM
97 PW01M FLAT WASHER 8MM
98 PSB84M CAP SCREW M10-1.5 X 35
99 PN02M HEX NUT M10-1.5
100 P0513100 SMALL GEAR
101 P0513101 STAR HANDLE
102 P0513102 TRUNNION SUPPORT BRACKET
103 PLW06M LOCK WASHER 10MM
104 PW04M FLAT WASHER 10MM
105 PSB28M CAP SCREW M6-1.0 X 15
106 PSB37M CAP SCREW M6-1.0 X 50
107 P0513107 PILLOW BLOCK
108 PN01M HEX NUT M6-1.0
109 P0513109 ADJUSTMENT BOLT M6-1.0
110 P6000 BEARING 6000
111 PSB61M CAP SCREW M10-1.5 X 20
112 PW01M FLAT WASHER 8MM
113 PW01M FLAT WASHER 8MM
G0514

G0513/G0514 Heavy-Duty Bandsaw -47-
REF PART # DESCRIPTION
114 PS17M PHLP HD SCR M4-0.7 X 6
115 P0513115 GEAR PLATE
116 P0513116 NYLON NUT M8-1.25
117 PS17M PHLP HD SCR M4-0.7 X 6
118 P0513118 LOCK HANDLE
119 PW05M FLAT WASHER 4MM
120 P0513120 POINTER
121 P0513121 TRUNNION PLATE
122 PLW04M LOCK WASHER 8MM
123 PB03M HEX BOLT M8-1.25 X 16
124 PCB05M CARRIAGE BOLT M8-1.25 X 80
125 P0514125 FENCE ASSEMBLY W/RAILS
126 P0513126 TABLE 19" X 19"
127 P0513127 TABLE INSERT
128 P0513128 TABLE PIN
129 PSB85M CAP SCREW M6-1.0 X 6
130 P0513130 LEFT COVER
131 PTS001M THUMB SCREW M6-1 X 16
132 P0513132 LOWER BLADE GUIDE SUPPORT
133 P0514133 GUIDE RING
134 P0513134 LOWER ADJUST SHAFT
135 P0513135 RIGHT COVER
136 PSB50M CAP SCREW M5-0.8 X 10
137 PW02M FLAT WASHER 5MM
138 P0513138 PROTECTIVE COVER
139 PSB72M CAP SCREW M10-1.5 X 30
140 P0513140 STEP SCREW
141 P0513141 FLAT WASHER
142 P0513142 SLIDING PLATE
143 PR05M EXT RETAINING RING 15MM
144 P6202 BEARING 6202
145 P0513145 UPPER BLADE GUIDE SUPPORT
146 P0513146 GUIDE RING
147 PTS001M THUMB SCREW M6-1.0 X 16
148 PCB10M CARRIAGE BOLT M8-1.25 X 85
149 PSB28M CAP SCREW M6-1.0 X 15
150 P0513150 ADJUST BAR
151 P0513151 UPPER SPACING SLEEVE
152 PSB02M CAP SCREW M6-1 X 20
153 P0513153 UPPER GUIDE SUPPORT BLOCK
REF PART # DESCRIPTION
154 PS38M PHLP HD SCR M4-0.7 X 10
155 PN04M HEX NUT M4-0.7
156 P0513156 RACK
157 P0513157 UPPER GUIDE HOSE
158 P0513158 HANDWHEEL
159 PSB02M CAP SCREW M6-1.0 X 20
160 P0513160 BUSHING
161 P0513161 BUSHING
162 PSB14M CAP SCREW M8-1.25 X 20
163 PLW04M LOCK WASHER 8MM
164 P0513164 GUIDE BRACKET
165 P0513165 WORM CYLINDER
166 P0513166 FIXED PLATE
167 P0513167 GEAR
168 P0513168 FIXED BOLT
169 P0513169 COVER
170 PSB11M CAP SCREW M8-1.25 X 16
171 PS07M PHLP HD SCR M4-0.7 X 8
172 PSS11M SET SCREW M6-1.0 X 16
173 P0513173 MITER GAUGE ASSY
173-1 P0513173-1 GUIDE BAR
173-2 P0513173-2 GUIDE
173-3 P0513173-3 POINTER
173-4 P0513173-4 NYLON WASHER 1⁄4"
173-5 P0513173-5 HANDLE
173-6 P0513173-6 MITER GAUGE BODY
173-7 P0513173-7 SHAFT
173-8 PS37M PHLP HD SCR M6-1.0 X 6
173-9 PFS01M FLANGE SCREW M5-0.8 X 8
174 P0513174 BRUSH
175 PSB02M CAP SCREW M6-1.0 X 20
176 P0513176 BUSHING
177 P0513177 MACHINE WARNING/ID
178 PLABEL-14 ELECTRICITY WARNING
179 PLABEL-11 SAFETY GLASSES WARNING
180 PLABEL-12 READ MANUAL WARNING
181 PLABEL-19 BLADE TOUCH WARNING
182 PLABEL-20 DOOR CLOSE WARNING
183 PLABEL-18 UNPLUG WARNING
184 G8588 CAST LOGO
G0514

-48- G0513/G0514 Heavy-Duty Bandsaw
204
213
215
209 226
205 203
202
216
211
212
208
207
218
220
222
222
210
206
214
219
201
221
227
225
223
220
217
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 P0513201 LARGE FENCE RAIL
201 P0514201 LARGE FENCE RAIL
202 P0513202 ADJUSTABLE BASE
203 P0513203 FIXED SHAFT
204 P0513204 SHAFT
205 P0513205 SPRING PIECE
206 P0513206 BRACKET
207 P0513207 SUPPORT TUBE
207 P0514207 SUPPORT TUBE
208 P0513208 INTERVAL SHEATH
209 P0513209 HANDLE
210 P0513210 ADJUSTABLE RUNNER
211 P0513211 CONVEX WINDOW
212 PSB83M CAP SCREW M6-1.0 X 55
213 P0513213 LOCK MECHANISM
214 P0513214 SMALL FENCE RAIL
214 P0514214 SMALL FENCE RAIL
215 PN01M HEX NUT M6-1.0
216 PFS04M FLANGE SCREW M4-.7 X 6
217 P0513217 LARGE RAIL CAP
218 P0513218 FENCE CAP
219 P0513219 SMALL RAIL CAP
220 PHTEK3M TAP SCREW M3.5 X 8
221 P0513221 SCALE
221 P0514221 SCALE
222 PN01M HEX NUT M6-1.0
223 PLW03M LOCK WASHER 6MM
224 PSB01M CAP SCREW M6-1.0 X 16
225 PB08M HEX BOLT M6-1.0 X 20
226 PFS05M FLANGE SCREW M4-.7 X 10
227 PW03M FLAT WASHER 6MM
G0513/G0514
