Schwank infraSchwank D Series User manual

infraSchwank D / calorSchwank D
Radiant Tube Heater
15 U / 20 U / 30 U / 40 U / 50 U / 60 U
1-stage / modulating lambdaPlus
single heater and flue gas collection system [herringbone] type F
Technical Manual Technical Instructions
Operating Instructions
Legal Requirements
Assembly Instructions
Installation Instructions
Commissioning
Service Guide
0085BO0037
Version 021 infra D U-Form 16/19
Technische Änderungen vorbehalten

SCHWANK GmbH
Bremerhavener Str. 43 • 50735 Cologne • Germany
Postfach 62 02 49 • 50695 Cologne • Germany
Tel.: + 49 [0] 221 / 7176 0
Fax: + 49 [0] 221 / 7176 288
Internet: www.schwank.de
Schwank companies in: Austria ▪Belgium ▪Canada ▪China ▪Czech Republic ▪France ▪Germany ▪Great
Britain ▪Hungary ▪Netherlands ▪Poland ▪Romania ▪Russia ▪Slovakia ▪Ukraine ▪USA ▪Distribution in more
than 40 countries worldwide

Content
3
Version 021 infra D Form_U 16/19 Technische Änderungen vorbehalten
1 Introduction..........................................................................................................................................................4
2 Your Safety ...........................................................................................................................................................4
Notes for your safety.................................................................................................................................4
3 Scope of Delivery ...............................................................................................................................................5
4 Planning ................................................................................................................................................................7
Position of suspension...............................................................................................................................7
Positioning ..................................................................................................................................................8
Air supply / Exhaust Requirements .........................................................................................................9
5 Legal Requirements ..........................................................................................................................................17
6 Operation ...........................................................................................................................................................18
Switching on the heater ........................................................................................................................18
Switching off the heater ........................................................................................................................18
Fault...........................................................................................................................................................18
Maintenance...........................................................................................................................................18
7 Technical specification ....................................................................................................................................19
Technical data ........................................................................................................................................21
8 Operating description .....................................................................................................................................23
9 Assembly instructions ........................................................................................................................................24
Assembly radiant and burner kit ..........................................................................................................24
Assembly burner kit exhaust gas collection system...........................................................................30
10 Installation instructions.....................................................................................................................................32
Gas-pipe-system and mounting of heaters........................................................................................32
Exhaust flue installation single heater ..................................................................................................34
Installation exhaust collecting system [herringbone].......................................................................34
Electrical installation [wiring diagram] ...............................................................................................35
Electrical connection Operation without MODBUS control............................................................35
Electrical connection Operation with MODBUS control..................................................................36
Electrical connection exhaust gas collecting system [herringbone system] ................................36
11 Commissioning instructions ...........................................................................................................................42
Before commissioning ............................................................................................................................42
Parameter IC 4000/1 and setting .........................................................................................................43
Assignment MODBUS address...............................................................................................................44
External identification MODBUS address.............................................................................................44
Adjusting nominal thermal load at single-stage operation .............................................................45
Adjusting thermal loads for modulating operation lambdaPlus .....................................................45
Commissioning exhaust gas collecting system [herringbone] ........................................................48
Determination of nozzle pressure .........................................................................................................49
12 Service guide / Trouble shooting ...................................................................................................................50
Maintenance and annual check ........................................................................................................50
Error codes ...............................................................................................................................................51
Troubleshooting / Error causes..............................................................................................................52
13 Change of gas family.......................................................................................................................................53
14 Accessories.........................................................................................................................................................54
Ball guards................................................................................................................................................54
Reflector elongation ..............................................................................................................................57
Set angled mounting tubes...................................................................................................................58
Gas filter groups ......................................................................................................................................58
Water protection box burner kit ...........................................................................................................59
tetraSchwank ..........................................................................................................................................60
15 Spare parts .........................................................................................................................................................61
Spare parts infraSchwank D / calorSchwank D 15-60U ....................................................................62
Spare parts burner kit infra D / calor D 15-60U ...................................................................................62
16 EC type examination certificate.....................................................................................................................63
17 EC declaration of conformity..........................................................................................................................65
18 Product information related to Ecodesign Regulation No 2015/1188......................................................66

infraSchwank D / calorSchwank D shape U
4
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
1 Introduction
Thank you for choosing a high efficiency
SCHWANK radiant tube.
Your infraSchwank D / calorSchwank D is a modern
and low-pollution tube heater for economic and
comfortable heating of industrial and commercial
buildings.
The design and operation of the heater are
according to the requirements of the existing
standards.
Please read this manual carefully before using the
heater. Please follow carefully all instructions and
warnings. The manufacturer will not be held
responsible for damages resulting from installation
errors or failure to comply with the manufacturer’s
instructions.
Grey marked text shows information to
modulating operation for tube heaters
infraSchwank D / calorSchwank D.
Follow carefully all warnings in chapter 2 “Your
Safety”.
These tube heaters are constructed exclusively for
the application of large industrial and commercial
space heating. Any other use is not permitted and
therefore Schwank is not liable for any improper
use.
2 Your Safety
You will find the following symbols in this manual:
Danger!
Note that you and others can be hurt.
Attention!
Note that the appliance can be
damaged.
Danger!
Note that electrical shocks can be very
dangerous. Pay attention while working
on the electrical equipment.
Advice!
You find additional instructions about the
application/handling of the heater.
Notes for your safety
This appliance is designed according to the
requirements of the existing standards.
Nevertheless it is possible that dangers for you and
others result from the installation and/or operating
errors.
To avoid this, please read and follow the
instructions carefully.
General Notes
Only use the radiant tube if it is in a technically
faultless condition.
This manual is an integral and essential part of the
product and must be given to the user. Keep the
manual near the heater.
Any person pursuing any of the following tasks must
read this manual:
operating
assembling
installation
commissioning
maintenance / trouble shooting
You need an explicit permission from the
manufacturer for any kind of changes and
reconstruction.
Use original spare parts only.
Safety for the electrical equipment
Danger of electrical shocks!
Electrical shocks can be very dangerous!
The electrical installation must be carried out by a
qualified service engineer following the existing
national and international standards.
Check the electrical equipment regularly.
Defect wires etc. must be replaced immediately.
The appliance must be cut off from the power
supply while working with the electrical equipment.
Make sure that nobody can connect the
appliance to the power supply while you are
installing or maintaining the unit.
After-sales Service
For all installation operations, start-up, gas
changes, etc. always consult a qualified service
engineer.
In case of doubt, contact SCHWANK GmbH,
phone + 49 [0] 221 / 7176 0.


infraSchwank D / calorSchwank D shape U
5
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
turnaround box turbulator
reflector long tube bar
suspension bracket radiant tube flange packing
burner kit
reflector short
3 Scope of Delivery
Fig. 1: Tube heater infraSchwank D / calorSchwank D 20U
Scope of delivery
The radiant tube infraSchwank D / calorSchwank D
consists of following kits:
Burner kit:
Burner-unit with gas-burner, pre-mixing
chamber, burner control unit IC 4000/1,
gas combination valve [single-stage or
modulating]
air differential pressure switch, electrical plug
connection and fan, burner kit complete
preassembled
Radiation kit:
Radiant tubes with turnaround box, flange
packing,
Corrosion resistant and radiant-optimized
reflector, end cap and brackets for hanging
[calorSchwank D: isolated reflectors]
Accessories
Central control unit SchwankControl Touch with
temperatures and operating schedules,
MODBUS control
Central control SRT-1 with temperatures and
operating schedules
Gas cock [gas connection] with thermal shut-off
device
Gas hose connection
Gas filter
Supply air- / exhaust flue-system
flue gas heat exchanger for the utilisation of
condensing technology – tetraSchwank
Adjustable steel wire suspension system [Gripple]
Brackets for wall mounting of angled position [15-
30°] for infraSchwank D / calorSchwank D 15-40U
Flue gas diverter [type A]
Ball protection grids [e.g. for sport halls]
Reflector elongations
Set for angled mounting
Water protection cover box for burner kit
[stainless steel]
Flue gas adapter

infraSchwank D / calorSchwank D shape U
6
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
Structure of burner kit
Fig. 2: Burner kit with burner control unit IC 4000/1
1. Burner control unit IC4000/1
2. Air pressure switch
3. Fan air restrictor plate
[incoming side, not shown]
4. Fan
5. Air baffle plate [only 15 / 20 / 30 / 40U]
6. Gas combination valve
[1-stage, modulating]
7. Test nipple connection pressure
8. Test nipple nozzle pressure
9. Adjustment screw nozzle pressure
10. Adjustment screw start step valve
11. Inspection glass
12. Burner cup
13. Burner nozzle
14. Ignition and ionisation electrode
15. Ignition cable
16. Ionisation cable
17. 3-pin power supply socket
18. Locking screw
19. Venturi
20. Burner baffle [only 15 / 20 / 30 / 40U]
21. Gasket

infraSchwank D / calorSchwank D shape U
7
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
4 Planning
Room temperature control
Radiant tube heating-systems must be equipped
with a temperature control.
Section heating is allowed without temperature
control.
Position of suspension
Suspension height
Radiant tubes must be positioned so that no one in
the radiation area is exposed to an extreme high
heat level. This is ensured when the minimum
suspension heights shown in the following table are
adhered to:
Tab 1: Minimum suspension heights
Key:
A = Minimum height when hanging horizontally
B = Minimum height when hanging angled
Type a
[cm]
c
[cm]
infracalor infracalor
15 U 110 20 10 50 15 15
20 U 110 20 10 50 15 15
30 U 130 20 10 50 15 15
40 U 170 25 10 50 25 15
50 U 230 35 10 70 35 15
60 U 300 45 10 100 35 15
b
[cm]
d
[cm]
Tab 2: Safe distances
Key:
a = Minimum radial safety distance [inside radiation area]
b = Minimum upper safety distance when hanging horizontally
c = Minimum upper safety distance when hanging angled
d = Minimum lateral distance to supply pipes outside radiation
area
Distances to flammable materials in the
radiant area
Radiant tubes must be positioned so that the
surface temperature of:
components with flammable materials,
flammable equipment, stored flammable
materials
never rises above 85° C.
Fig. 3: Suspension heights and distances for horizontal
application
Fig. 4: Suspension heights and distances for angled application
Direction of radiation
Radiant tubes infraSchwank D / calorSchwank D
can be positioned horizontal or at an angle [max.
30° from vertical]. For this purpose suspension steel
chains and cables are installed at the suspension
brackets.
Nominal
thermal load in
kW
Suspension height in m
[max. radiation intensity 200 W/m2]
A = horizontal B = angled [30°]
15 3.5 m 3.1 m
20 4.0 m 3.6 m
30 4.8 m 4.3 m
40 5.5 m 4.9 m
50 6.8 m 6.2 m
60 8.0 m 7.3 m

infraSchwank D / calorSchwank D shape U
8
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
Positioning
The radiant tube can be mounted with
chains [links min. 4 mm]
adjustable steel wire suspension system
[Schwank accessories]
If you chose chains please use bolts with lock nuts
for fixing the chain to the suspension bracket.
The radiant tube has to be fixed by
vertical chains etc. to the roof or to
supporting devices.
Chains and steel cables have to be fixed
in vertical direction or slightly diagonally
outwards above the fixing points of the
suspension brackets to the roof or to
supporting devices. Fixing of the
suspension cables or chains diagonally
inwards to the centre of the heater is not
permitted [see Fig 5].
Please note that the radiant tube being
in operation expands several
centimetres because of thermal
expansion. Avoid therefore inflexible
suspension.
Do not use fixing elements like open
hooks etc.
Hang the heater in balance. We recommend the
use of turnbuckles or adjustable steel cable grips
for ease of adjustment and balance.
Fixing points for chains or steel cables on the heater
are shown in Fig. 15 and 16 on pages 20 and 21.
Attention!
If you do not align the burner kit
correctly material damage and
destruction of the heater may occur.
Fig. 5: Chains and steel wire mounting
Fig. 6: Slope of radiant tube heater
SCHWANK GmbH will not accept liability
for damages caused by incorrect
mounting of the burner unit. Correct
mounting is the responsibility of the
installer.
Attention!
Make sure that the heater has in
longitudinal direction a slight slope
[3 mm per meter] to the turnaround box
[Fig. 6].
wrong
wrong
correct
Correct = vertical or slightly
diagonally outwards
x x
15/20/30U: x= 15 mm
40U: x= 20 mm
50
/
60U: x= 30 mm
Wrong = diagonally inwards

infraSchwank D / calorSchwank D shape U
9
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
Air supply / Exhaust Requirements
The calculation of air supply / exhaust
requirements of a building heated by radiant tube
heaters is subject of European Directive EN 13410.
Please follow local by-laws as well.
Please see the max. lengths of combustion air
supply- and exhaust flue pipe on page 9 [Tab 3,
point 3].
Place of Installation
The room to be heated must have an air volume of
minimum 10 m³ for each kW of the nominal
thermal load of the installed heater.
Air supply [combustion air from inside the
room, types A3 and B23]
Heating installations with combustion air from
inside the room are only allowed in rooms without
string air pollution. Otherwise use system with
combustion air from outside [type C].
In halls and buildings with a normal air change by
means of joints and gaps it is not necessary to
install additional equipment to ensure combustion
air supply.
Air supply / exhaust systems
For the radiant tube infraSchwank D / calor
SchwankD the following air supply / exhaust
systems are possible:
1. Indirect flue into the room
[Type A3 without exhaust system,
combustion air from inside the room]
2. Flued with individual exhaust system,
combustion air from inside the room
[Type B23]
3. Flued with individual exhaust system,
combustion air from outside the room
[Type C]
4. Flued with flue collecting system and
central flue fan – combustion air either from
inside or from outside [according to EN 777,
Type F]
1. Indirect flue into the room
[Type A3 without exhaust system combustion
air from inside the room]
The exhaust air of the tube heater has to be
conducted from the inside of the room to the
outside.
Conduction of the exhaust air may be carried out
with one of the following 3 methods:
a) Thermal ventilation: Combustion air and
exhaust air are to be conducted through
fixed outlets positioned on the roof or on
the walls of the building.
b) Mechanical ventilation: Combustion air and
exhaust air are to be conducted through
one or more fans positioned on the roof or
on the walls of the building.
c) Natural ventilation: Combustion air and
exhaust air are to be conducted through
outlets as a result of differences in pressure
and in temperature between the internal
and external side of a building.
For exact dimensioning and positioning
of supply air and exhaust air outlet of the
building according to EN 13410 or
G 638-2 please contact Schwank GmbH,
phone +49 [0] 221 / 7176 0.


infraSchwank D / calorSchwank D shape U
10
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
2. Exhaust flue with individual exhaust system -
combustion air from inside the room
[Type B23]
Only use this system in rooms with no air pollution
and without relevant pressure differences to
outside. Otherwise use type C.
3. Exhaust flue with individual exhaust system -
combustion air from outside the room
[Type C]
Combustion air and exhaust air are to be
conducted by a temperature stable, concentric
pipe from a wall or roof entrance.
Max. length of the concentric pipe can be 6 m
plus two 90° elbows.
The concentric pipe ends at a bifurcated pipe.
Please ensure that theconnection for exhaust air
between heater and bifurcated pipe is a flexible
pipe. Do not use back-pressure valves or dampers
in the exhaust flue.
Tab. 3: air/exhaust routing
Fig. 7: Air/exhaust-system,
version aluminium or stainless steel
4. Exhaust flue with flue collecting system and
central flue fan
[according to EN 777, Type F]
The heating installation must not exceed 10 radiant
tubes. The exhaust air of each tube is collected
via a central collecting tube system by a central
flue fan and led to the chimney. Planning,
construction and layout of such installations must
be carried out by Schwank employees, as well as
commissioning. The strict observance of the
Schwank layout-drawings and calculation figures
are the precondition of the manufacturer’s
warranty.
With system F the radiant heaters will be installed
with their individual flue fans. Please note that it
necessary to install in the collecting pipe behind
each radiant heater and in the following collection
pipes damper or a pressure-balancing device. This
ensures a precise regulation and an even exhaust
flue of each radiant tube.
For detailed information regarding
setting up and commissioning of a flue
collection system please see
corresponding sections in chapters
4, 10 and 11.
Max.length
betweenheater
androof/wall
entrance
max.number
ofelbows
(90°)
Øofair/exhaust
flue
6m 2 100mm
infraSchwankD/calorSchwankD,shapeU
Flexible exhaust system with
roof terminal
Flexible exhaust system with
wall terminal
Flexible exhaust system with
roof terminal
Flexible exhaust system with
wall terminal


infraSchwank D / calorSchwank D shape U
11
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change




Control points
Exhaust gas:
Stainless steel flexible pipe with
connecting flange
Combustion air:
15-20U: aluminium flexible pipe
30-40U: stainless steel flexible pipe
Transition stainless steel
flexible pipe on aluminum
pipe
Flexible exhaust system infraSchwank D / calorSchwank D 15-40U [wall terminal]
- version aluminium -
The stainless flexible pipe [exhaust
line] must be installed uncut for the
heater 40/50/60U. Make sure that
there is no sink in the pipe.
Connection stainless steel flexible
pipe to aluminium tube must be
glued with heat-resistant sealing
material and locked by means of
self-tapping screws.
All socket connections on the
exhaust and air line must be locked
by means of self-tapping screws.
The wall terminal is mounted with a
small gradient to outside to prevent
intrusion of driving rain.
The 90° elbow at the sucking fan side is
to mount with the opening on the top.
infraSchwank D / calorSchwank D
type 50– 60 U cannot be operated
using a wall terminal.
Please note the safety distance to
flammable materials:
- single-wall exhaust pipe: 40 mm
- double-wall exhaust pipe + wall
terminal: 0 mm
System certification tube heater
infraSchwank D/ calorSchwank D with
exhaust line system
CE 0432-CPD-217915, System 0.2 / 0.5
[Muelink&Grol]
The wall duct is fastened with screws
by means of the integrated flange
plate on the building wall. The flange
plate supports and secures the wall
duct.
Following components are required for mounting
the wall terminal aluminum design
[Distance heater- terminal approx. 1.5 m]:
Wall terminal M&G: Article no. 12221797
Testing set C 15-20kW: Article no. 12676660
Testing set C 30-40kW: Article no. 12676750
Fig 8: Position of control points 15 – 40U [wall terminal], version aluminium

infraSchwank D / calorSchwank D shape U
12
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change




Dimension flat roof sockets
Flat version – Article no. 12201087
Hi
g
h version
–
Article no. 12201788
Control points
Transition stainless steel
flexible pipe on
aluminum pipe
Exhaust gas:
Stainless steel flexible pipe
Combustion air:
15-20U: aluminium
flexible pipe
30-60U: stainless steel
flexible pipe
Flexible exhaust system infraSchwank D / calorSchwank D 15-60U [roof terminal]
- verison aluminium -
The stainless flexible pipe [exhaust line]
must be installed uncut. Make sure that
there is no sink in the pipe.
Connection stainless steel flexible pipe
to aluminium tube must be glued with
heat-resistant sealing material and
locked by means of self-tapping screws.
All socket connections on the exhaust
and air line must be locked by means of
self tapping screws.
The 90° elbow at the sucking fan side is
to mount with the opening on the top.
System certification tube heater
infraSchwank D/ calorSchwank D with
exhaust line system
CE 0432-CPD-217915, System 0.2 / 0.5
[Muelink&Grol]
Please note the safety distance to
flammable materials:
- single-wall exhaust pipe: 40 mm
- double-wall exhaust pipe + roof
terminal: 0 mm
The roof terminal is slide in from above
into the roof socket. in from above into
the roof socket. The fixing inside the
building takes place via a clamp to the
building ceiling.
Following components are required for mounting
the roof terminal aluminum version
[Distance heater- terminal approx. 1.5 m]:
Roof terminal M&G: Article no. 12221770
Testing set C 15-20kW: Article no. 12676660
Testing set 30-60kW: Article no. 12676750
Fig. 9: Position of control points [roof terminal], version aluminium

infraSchwank D / calorSchwank D shape U
13
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change




Flexible exhaust system deltaSchwank [wall terminal]
infraSchwank D / calorSchwank D 15-60U
- version stainless steel -
Install stainless steel flexible pipe
without sink.
Join parts of the roof terminal strongly
together by compression and using
of jointing and sealing paste
[e.g. Ceramax]!
All joints inside the building tighten
securely with clamp fittings!
The 90° elbow at the sucking fan side is to
mount with the opening on the top.
The wall terminal is mounted with a
small gradient to outside to prevent
intrusion of driving rain.
The wall terminal is fastened to the
building wall with screws by means of
the integrated flange plate. The flange
plate supports and secures the wall
terminal.
Please note the safety distance to
flammable materials:
-single-wall exhaust pipe: 80 mm
-double-wall exhaust pipe
+ wall terminal: 0 mm
System certification tube heater
infraSchwank D/ calorSchwank D with
exhaust line system
Future ew CE 0432-CPR-00055-209 /
Future ew-flex CE 0036-CPR-00055-207 /
Future dw CE 0432- CPR-00055-301
[Schräder]
Following components are required for mounting
the wall terminal stainless steel version
[Distance heater- terminal approx. 1.5 m]:
Stainless steel exhaust system wall terminal
DN 100/160: Article no. 12202220
Fig. 10: Position of control points 15 – 60U [wall terminal], version stainless steel

infraSchwank D / calorSchwank D shape U
14
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change




Flexible exhaust system [roof terminal]
infraSchwank D / calorSchwank D 15- 60U
- version stainless steel -
Install stainless steel flexible pipe
without sink.
Join parts of the roof terminal strongly
together by compression and using
of jointing and sealing paste
[e.g. Ceramax]!
All joints inside the building tighten
securely with clamp fittings!
The 90° elbow at the sucking fan side is
to mount with the opening on the top.
Please note the safety distance to
flammable materials:
-single-wall exhaust pipe: 80 mm
-double-wall exhaust pipe
+ roof terminal: 0 mm
System certification tube heater
infraSchwank D/ calorSchwank D with
exhaust line system
Future ew CE 0432-CPR-00055-209 /
Future ew-flex CE 0036-CPR-00055-207 /
Future dw CE 0432- CPR-00055-301
[Schräder]
The roof terminal is fastened with screws
by means of the integrated flange plate
on the building ceiling. The flange plate
supports and secures the roof terminal.
Following components are required for mounting
the roof terminal stainless steel version
[Distance heater- terminal approx. 1.5 m]:
Stainless steel exhaust system roof terminal
DN 100/160 Article no. 12202080
Fig. 11: Position of control points 15 – 60U [roof terminal], version stainless steel

infraSchwank D / calorSchwank D shape U
15
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change






Installation tetr aS ch w an k _T A _F ri sch lu ft_4817
Exhaust system deltaSchwank [roof terminal]
with downstream heat exchanger tetraSchwank in room air operation and with outside
air intake in fresh air operation
- version stainless steel -
Install stainless steel flexible pipe
without sink.
Join parts of the roof terminal strongly
together by compression and using
of jointing and sealing paste
[e.g. Ceramax]!
All joints inside the building tighten
securely with clamp fittings!
tetraSchwank heat exchanger should be
mounted with slight slope [3 mm /1 m] to
the T-piece.
Please note the safety distance to
flammable materials:
-single-wall exhaust pipe: 80 mm
-double-wall exhaust pipe
+ roof terminal: 0 mm
System certification tube heater
infraSchwank D/ calorSchwank Dwith
exhaust line system
Future ew CE 0432-CPR-00055-209
The roof terminal is fastened with
screws by means of the integrated
flange plate on the building ceiling.
The flange plate supports and secures
the roof terminal.
Fig 12: Installation tetraSchwank in room air operation, with roof
terminal stainless steel
Installations exhaust system with heat recovery:
1. flue gas heat exchanger tetraSchwank
- pre-assembled
L= 4700 mm Article no. 62000020
2. ventilator tetraSchwank with protection grating
3. T-piece stainless steel with condensation outlet
connection R ½“
4. fastening clamp for suspension, premounted
5. single-wall roof terminal with in room air
operation Article no. 12201941
double wall roof terminal with outside air intake
in fresh air operation Article no. 62000090
Fig 13: Installation tetraSchwank with outside air intake in fresh air operation, with roof terminal stainless steel
>
1,0m

infraSchwank D / calorSchwank D shape U
16
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
Control point chimney
sweeper
Tube heater
Damper behind heater
Connecting pipe
Collecting exhaust pipe
Central fan
Damper in front of central
fan
Exhaust gas
i
Exhaust pipe collecting system [herringbone] with central fan
System F approved according to EN 777 and DIN EN 416
Exhaust pipe collecting system consist of
following main components:
Tube heater infraSchwank D/ calorSchwank D
Spiral duct and connection elements for
exhaust collecting system [different
dimensions]
Central low-pressure fan
Fan monitoring kit
Article no. 700 0012 0
Planning and calculation of the
complete system including collecting
pipes, fans and chimneys
must only be done by Schwank.
Planning details have to be strictly
adhered to during mounting and
assembly. Commissioning of the system
should be carried out by Schwank.
Fig. 14: Installation exhaust collecting system with central fan , system F [principle scheme]

infraSchwank D / calorSchwank D shape U
17
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
5 Legal Requirements
We recommend that these installation guidelines
should be observed with the relevant Building
Standards Regulations of your country. Comply
with any local by-laws and the current IEE Wiring
Regulations.
Notwithstanding their limited scope, the
appliance should be installed by a competent
person in accordance with the relevant
provisions of the Gas Safety [Installation and Use]
Regulations. Caution must also be taken of any
obligations arising from the Health and Safety of
Work Act. Full compliance with all relevant
regulations, including amendments in force at
the time of installation is a requirement of our
warranty.
In Germany the following rules, standards and
regulations must be observed.
EnEV Verordnung über
energiesparenden Wärmeschutz
und energiesparende
Anlagentechnik bei Gebäuden
DIN EN 12831 Heizungsanlagen in Gebäuden
Verfahren zur Berechnung der
Norm-Heizlast
DIN EN 13384 Abgasanlagen
DIN V 18599 Energetische Bewertung von
Gebäuden – Berechnung des
Nutz-
End- und Primärenergiebedarfs
für Heizung, Kühlung, Trinkwasser
und Beleuchtung
DVGW G 660 Technische Regeln für die
mechanische Abführung der
Abgase von Feuerstätten
VDE 0722 Elektrische Vorschriften
VDE 0100 Bestimmungen für das Errichten
von Starkstromanlagen
Beachten Sie außerdem die Bestimmungen der
jeweiligen
LBO Landesbauordnung
FeuVO Feuerungsverordnung der
Länder
TAB Technische Anschluss-
bedingungen der örtlichen
Energieversorgungs-
unternehmen

infraSchwank D / calorSchwank D shape U
18
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
6 Operation
The installation must be carried out by
a qualified engineer following the
manufacturer’s instructions.
SCHWANK will not accept liability damages
caused by improper assembly and/ or operating
of the heater. Proper assembly and operation is
the responsibility of the user.
Switching on the heater
First switch on the central control unit
SchwankControl Touch and activate a
heating command.
After a pre-purge period of about 25 sec.
the ignition starts.
Switching off the heater
Disable the heating command on central
control unit SchwankControl Touch.
If the radiant tube is controlled by a thermostat
the heater will be switched on and off
automatically.
Fault
If no flame is reported during the pre-purge
period and the safety time [approx. 30 sec.] the
heater repeats the ignition process. If there is no
flame after the second ignition process the
heater switches off automatically and is locked.
Investigation and repair must be carried
out by authorized personnel. After
clearance of the fault the heater can be
reset.
The cause of the fault / error code is
displayed on the central control unit
SchwankControl Touch or can read out via
corresponding service software IC 4000.
See chapter 12 for error codes.
Lock release [Reset]
Activate the reset command via the
central control unit or interrupt the electric
power supply for 3 seconds.
Maintenance
Servicing of the heater is essential for continued
efficient operation. Servicing should be carried
out not less than once a year by a qualified
service engineer. After any servicing, the heater
must be recommissioned as detailed in
Chapter 12.


infraSchwank D / calorSchwank D shape U
19
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
7Technical
specification
Appliance Automatic heating device, heat
transfer by means of infrared dark
radiation.
Fuel Types Natural gas
Propane
Minimum connection pressure in front of valve
Attention!
Max. connection pressure: 60 hPa
Gas connection 15-30U R=1/2’’ male
40-60U R=3/4’’ male
Exhaust gas Flange at radiant tube end
connection for exhaust connection Ø
100 [flexible stainless steel
pipe / exhaust gas adapter]
Electrical connection power supply
Single-phase AC 230 V, N, PE - 50Hz
The connecting cable for the power supply is
connected to the IC 4000/1 burner control with
the provided 4-pin plug.
The power supply for the heater must be flexible
with maximal wire cross-section
- 3x 1.5 mm2Ölflex- or silicone cable
To set the bluTek-burner kit free of voltage it is
only necessary to remove the plug of the power
supply.
Regulation
The heating system is controlled via the central
control unit SchwankControl Touch.
The corresponding heating commands for the
heater are sent via MODBUS communication.
Connection MODBUS control from
SchwankControl Touch to IC 4000/1
Use for MODBUS transmission max. 3x 0.5 mm2
cable.
Route the cable through the lower cable gland
into the housing of burner control unit IC 4000/1
and connected to the corresponding spring
terminals on the circuit board.
Fig. 15: Measurements infraSchwank D / calorSchwank D 15U, 20U [view from below]
Gas type 15-50U 60U
Natural Gas H 15 hPa 20 hPa
Natural Gas L 20 hPa 30 hPa
Propane 40 hPa 40 hPa
infraSchwank D / calorSchwank D 20U
Detail A
Cross dimensions at burner kit
15-40U A=80 mm
50-60U A=100 mm
Detail B
Cross dimensions reflector
valid for all types
Detail A / B
infraSchwank D / calorSchwank D 15U

infraSchwank D / calorSchwank D shape U
20
Version 021 infra D Form_U 16/19 _INT Technical specification subject to change
Fig. 16: Measurements infraSchwank D / calorSchwank D 30U, 40U, 50U and 60U [view from below]
infraSchwank D / calorSchwank D 50U
infraSchwank D / calorSchwank D 30U
infraSchwank D/ calorSchwank D 40U
infraSchwank D / calorSchwank D 60U
