Schwank InfraSave 2100 User manual

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
INSTALLATION / OWNER’S MANUAL
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation and operating and maintenance instruc-
tions thoroughly before installing or servicing this equipment.
SAFETY ALERT:
This heater must be installed and serviced only by a trained gas service technician.
Failure to comply could result in personal injury, death, fire and/or property damage.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other gas fired appliance.
This heater model is approved to two different heater standards:
 A “Patio Heater” for Outdoor Use in Residential and Commercial/Industrial Applications
 And as a “Gas-Fired High Intensity Infrared Heater” for Indoor Spaces of Commercial/
Industrial Applications. The heater cannot be used indoors in a residence.
IF YOU SMELL GAS:
 Extinguish any open flame
 Do not attempt to light this or any other appliance
 Don’t touch any electrical switch, or telephone
 Immediately leave the area and call your gas supplier from a neighbor’s phone
 Follow any and all instruction from your gas supplier
 If your gas supplier is not available, call the fire department
WARNING
bistroSchwank Series
Models: 2100; 2100-SS*
2152; 2152-SS*
FIELD CONVERTIBILITY:
This appliance is field convertible to
LP gas (except 2152/IO-152: NG only).
Only use kit available from manufacturer.
Follow kit instructions and all local and
national codes.
INSTALLER: PRESENT THIS MANUAL
TO THE END USER.
Keep this manual in a secure place.
Record for future reference:
Model #:
Serial #:
(located on heater rating label)
Series Models:
IO-100; IO-100-SS*
IO-152; IO-152-SS*
PatioHeaterforOutdoorApplicationandGas-FiredHighIntensityInfraredHeat-
erforCommercial/IndustrialNon-ResidentialIndoorSpaces
* Marine Grade Stainless Steel Cabinet
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
2
NOTICE:
The manufacturer reserves the right to make changes to equipment and
specifications without obligation or notification.
This publication, or parts thereof, may not be reproduced in any form, without
prior written consent from the manufacturer
Unauthorized use or distribution of this publication is strictly prohibited.
Schwank Group
2 Schwank Way
Waynesboro, Georgia,
USA 30830
5285 Bradco Boulevard
Mississauga, Ontario
L4W 2A6
Technical Support & Customer Service:
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
Complete product information:
www.schwankgroup.com
Www.patioschwank.com
www.infrasave.com
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
3
TABLE OF CONTENTS
TOPIC PAGE NUMBER
IMPORTANT INFORMATION - READ FIRST
IMPORTANT WARNINGS ........................... 4
HEATER EXPANSION ................................. 5
GAS CONNECTION ..................................... 5
VENTING ................................................ 5, 13
‘SMOKE’ & DISCOLORATION .................... 5
MOUNTING CLEARANCES:
OUTDOORS ........................................... 6
INDOORS ............................................... 9
DIMENSIONS & CONFIGURATION .......... 11
MOUNTING KIT OPTIONS ................. 12 - 15
1. APPLICATION...................................................16
OUTDOOR / PATIO......................................16
INDOOR INSTALLATION.............................16
2. AIRCRAFT HANGARS......................................17
3. GARAGES & PARKING STRUCTURES...........17
4. OTHER THAN SPACE HEATING.....................17
5. PRE-INSTALLATION SURVEY.........................17
6. INSTALLATION REQUIREMENTS...................18
6.1 MOUNTING CLEARANCES.......................18
6.2 HEATER MOUNTING................................18
7. GAS SUPPLY PIPING.......................................19
7.1 GAS PRESSURE.......................................19
Models: 2100; 2100-SS; 2152; 2152-SS
IO-100; IO-100-SS; IO-152; IO-152-SS
PatioHeaterforOutdoorApplication
andGas-FiredLuminous(HighIntensity)InfraredHeater
forCommercial/IndustrialNon-ResidentialIndoorSpaces
This heater model is approved to two different heater standards:
 A “Patio Heater” for Outdoor Use in Residential and Commercial/Industrial Applications
 And as a “Gas-Fired High Intensity Infrared Heater” for Indoor Spaces of Commercial/Industrial Applications.
The heater cannot be used indoors in a residence.
TOPIC PAGE NUMBER
8. ELECTRICAL - BASIC REQUIREMENTS ……..19
9. LAYOUT, COMFORT & CONTROL.................20
10. INSTALLATION PROCEDURES .....................21
11. LIGHTING INSTRUCTIONS............................22
11.1 SHUT DOWN INSTRUCTIONS..............22
12. HEATER FINISH & APPEARANCE.................22
13. SERVICING GUIDE.........................................23
14. VENTILATION FOR INDOOR APP’S...............24
15. REMOTE CONTROL OPTIONS......................25
Remote Control Quick Setup ............... 26 - 30
16. SEQUENCE OF OPERATION-FENWAL 35-60
DSI...................................................................31
17. SPARK IGNITION CIRCUIT ............................32
18-A WIRING DIAGRAM - SINGLE-STAGE..........33
18-B WIRING DIAGRAM - TWO-STAGE..............34
18-C WIRING - 2-STAGE SWITCH CONTROL.....35
19. TROUBLESHOOTING GUIDE.........................36
20. COMMISSIONING REPORT...........................38
21. HIGH ALTITUDE DERATION.........................40
22. ACCESSORIES: Control & Mounting...............41
23. REPLACEMENT PARTS LIST.........................43
Stainless Steel Enclosure Components............44
LIMITED WARRANTY........................Back Page
IMPORTANT Installer: Present this manual to the end user. Acquaint
the end user with Important Information: Cover & pages 4 to
7.
END USER: In particular you must be aware of ‘Clearances to Combustible’ re-
quirements and the limitations of stacking or placing material near the heaters.
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
4
Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury or death. Read and understand this installation and op-
eration manual thoroughly prior to assembly, installation, operation or service to
this appliance.
This heater must be installed and serviced only by a trained gas service techni-
cian.
Do not store or use gasoline or other flammable vapours and liquids in the vicinity
of this or any other gas fired appliance.
Failure to comply to these warnings could result in personal injury, death, fire and/
or property damage.
This appliance may have sharp edges and corners. Wear protective clothing such
as gloves and protective eye wear when servicing this or any other appliance.
WARNING
This heater is not for installation in a Class 1 or Class 2 explo-
sive environment, nor for any residential application. If installa-
tion of this equipment is in question, consult with local authorities having jurisdiction (Fire Mar-
shal, labor department, insurance underwriter, or others).
Revisions to codes and/or standards, may require revision to equipment and installation proce-
dures. In case of discrepancy, the latest codes, standards, and installation manual will take pri-
ority over prior releases.
IMPORTANT: DO NOT INSTALL THIS HEATER INDOORS IN A STRUCTURE WITH NO IN-
SULATION IN THE ROOF—CONDENSATION WILL OCCUR.
Due to the effects of radiant heat upon certain materials it is not
recommended to store or place items that could be damaged or
distorted, directly under this heater....i.e. combustible patio furni-
ture etc.
 Clothing or other flammable materials should not be hung from, or placed near to the heater
 Children and Adults should be alerted to the hazards of high surface temperatures and
should be careful to avoid burns or clothing ignition
WARNING
WARNING
DO NOT INSTALL THIS APPLIANCE IN A RECESS, ALCOVE, OR
ENCLOSURE.
While minimum clearances to combustibles are stipulated to ensure safe installation, adequate
free space must be provided to allow the products of combustion to escape from the heater to
atmosphere when installed outdoors, or to mechanical exhaust withdrawal when installed in-
doors. Also refer to “Outdoor” and “Indoor” definitions and requirements on page 9.
Do not allow the products of combustion to accumulate in any space or enclosure.
WARNING
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
5
Heater Expansion
It is a normal condition that during heat-up and cool-down a radiant
heater will expand and contract. Allowances for heater expansion
must be made in the gas connection and heater suspension. Improp-
er installation, alteration, or adjustment can result in property dam-
age, injury or death.
WARNING
Venting
Inadequate venting of a heater may result in asphyxiation, carbon
monoxide poisoning, injury or death. When used indoors, this heater
is indirectly vented from the space. Venting must be in accordance
with all local, state, provincial, and national codes (ANSI Z223.1/
NFPA 54 in USA; B149.1 in Canada) and as indicated in this manual. Refer to Sec-
tion 13
Gas Connection
Improper installation, connection, or adjustment can result in property
damage, toxic gases, asphyxiation, injury or death. Use an approved
stainless steel flexible gas connector (field supplied) to connect to the
gas supply to the heater in accordance with all local, state, provincial,
and national codes (ANSI Z223.1/NFPA 54 in USA; B149.1 in Canada) and as indicated in this
WARNING
WARNING
WARNING Start-up ‘Smoke’ & Discoloration Condition
During start-up, the heating of material coatings used in the production process of the heater
may create a small amount of smoke during the initial period of operation. This condition is
normal and temporary .
Ensure that there is sufficient ventilation to adequately clear any ‘smoke’ from the space.
Notify site management and safety personnel to ensure that alarm systems are not unduly activated.
WARNING Heater Discoloration / Staining
Stainless Steel & Painted Finishes: Surface discoloration or staining will occur on any heater
body due to heat. Discoloration due to heat is a normal occurrence especially with all stainless steel.
Surface discoloration does not affect the operation or performance of the heater nor the manufactur-
er’s component warranties. (Refer to Section 12: Heater Finish & Appearance, page 20)
Some discoloration may be the result of the deposit of ambient air-borne particulate or gases within
the space that have passed through combustion to create ‘smoke’. The combustion of fuel gas in a
clean environment will not cause smoke discoloration deposits.
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
6
WHEN INSTALLED AS AN OUTDOOR PATIO HEATER
 see pages 9 - 10 for Indoor installation
 Also refer to “Outdoor” and “Indoor” definitions and requirements on page 11
Certain materials or items, when stored under the heater, will
be subjected to radiant heat and could be seriously dam-
aged.
Location of flammable or explosive objects, liquids or vapors close to the heater may cause
fire or explosion and result in property damage, injury or death. Do not use, store or locate
flammable or explosive objects, liquids or vapors in proximity of the heater.
The clearance to combustible material represents the minimum
distance that must be maintained between the outer heater surface
and a nearby surface. The stated clearance to combustibles repre-
sents a surface temperature of 117F° (65C°) above ambient tem-
perature when installed outdoors.
It is the installer’s responsibility to ensure that building materials
with a low heat tolerance which may degrade at lower tempera-
tures are protected to prevent degradation. Examples of low heat
tolerance materials include vinyl siding, fabrics, some plastics,
filmy materials, etc.
It is beyond the scope of these instructions to consider all conditions that may be encoun-
tered. Consult local authorities such as the Fire Marshall, insurance carrier, or safety authori-
ties if you are uncertain as to the safety or applicability of the proposed installation.
Refer to Table 1 & Figure 1 Next Page for the minimum mounting and clearances to
combustibles for Outdoor Patio application.
WARNING
DO NOT INSTALL THIS APPLIANCE IN A RECESS, ALCOVE,
OR ENCLOSURE.
Adequate free space must be provided to allow the products of combustion to escape from
the heater to atmosphere when installed outdoors, or to mechanical exhaust withdrawal
when installed indoors. Do not allow the products of combustion to accumulate in any space
or enclosure.
WARNING
Note: Do not store or place anything directly under heater
Ensure mounting height in any location is sufficient to prevent patrons from
coming in contact with heater, and clearance to combustibles is maintained.
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
7
MODEL NO
Ends HORIZONTAL UP TO MAXIMUM 30° ANGLE
E A S T B F
2135 / IO-135 -N\L 14” 13” 14” 17” 9” 60”
2150/ IO-150 -N\L 14” 16” 19” 20” 8” 62”
MH
108”
120”
MA
102”
114”
CH
133”
148”
CA
127”
142”
2152/ IO-152 -N 14” 16” 19” 120” 148” 20” 8” 62” 114” 142”
Table 1: OUTDOOR - MINIMUM MOUNTING & CLEARANCES TO COMBUSTIBLES
The clearance to combustible material represents the minimum distance that must be main-
tained between the outer heater surface and a nearby surface. In an OUTDOOR application
the stated clearance to combustibles represents a surface temperature of 117F° (65C°)
above ambient temperature.
It is the installer’s responsibility to ensure that building materials with a low heat tolerance
which may degrade at lower temperatures are protected to prevent degradation. Examples of
low heat tolerance materials include awnings, vinyl siding, fabrics, some plastics, filmy materi-
als, etc.
Figure 1: OUTDOOR - MOUNTING CLEARANCES
See Table 2 Next Page for “Suggested Mounting Height for Comfort”
NOTE: MOUNT HEATER AT MAXIMUM 30° ANGLE TO AVOID DAMAGE
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
8
Table 2: SUGGESTED MOUNTING DISTANCES FOR COMFORT
MOUNTING PARAMETERS ***
MODEL
2135 (-SS) / IO-135 (-SS)
35,000 Btuh
MODEL
2150 / 2152 (-SS)
IO-150 / IO-152 (-SS)
50,000 Btuh
A - Mounting angle Horizontal 300 Horizontal 300
H - Suggested height above deck 9’ 6” 9’ 0” 10’ 6” 10’ 0”
S - Side distance to patio edge 4’ 0” 4’ 0” 5’ 0” 5’ 0”
Y - Side distance between heaters 8’ 0” 8’ 0” 10’ 0” 10’ 0”
W - Distance effective coverage 7’ 0” 8’ 0” 8’ 0” 10’ 0”
Z - Front distance between heaters 14’ 0” 16’ 0” 15’ 0” 18’ 0”
*** Note: Mounting
angles and distances
are suggested to en-
sure comfort, and are
subject to site and
design conditions.
If in doubt, please
contact your
Schwank / InfraSave
distributor.
Ensure mounting
height in any location
is sufficient to prevent
patio patrons from
coming in contact
with the heater
Figure 2: MOUNTING PARAMETER DISTANCES
S Y
Z
H
A
W
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
9
WHEN INSTALLED INDOORS FOR COMFORT OR SPACE HEAT
 see pages 6- 8 for Outdoor installation
 Also refer to “Outdoor” and “Indoor” definitions and requirements on page 11
 And refer to Indoor Ventilation Requirements page 19
Clearance to Combustibles
Location of flammable or explosive objects, liquids or vapors
close to the heater may cause fire or explosion and result in property damage, injury or death.
Do not use, store or locate flammable or explosive objects, liquids or vapors in proximity of the
heater.
The clearance to combustible material represents the minimum dis-
tance that must be maintained between the outer heater surface and
a nearby surface. The stated clearance to combustibles represents a
surface temperature of 90F° (50C°) above room temperature.
It is the installer’s responsibility to ensure that building materials
with a low heat tolerance which may degrade at lower temperatures
are protected to prevent degradation. Examples of low heat toler-
ance materials include vinyl siding, fabrics, some plastics, filmy ma-
terials, etc.
In locations used for the storage of combustible materials, signs must be posted to specify the
maximum permissible stacking height to maintain the required clearances from the heater to
the combustibles. Such signs must either be posted adjacent to the heater thermostats or in
the absence of such thermostats in a conspicuous location.
In addition to stored or stationary material, consideration must also be given to moveable ob-
jects such as cranes, vehicles, and overhead doors, and structural objects such as electrical
and gas lines, electrical fixtures, and sprinkler heads.
Heaters must be located an appropriate distance from sprinkler heads. This distance may be
greater than the certified clearance to combustibles. Check the temperature rating of the sprin-
kler heads and locate heaters at a safe distance - in some instances the sprinkler heads may
need to be replaced by higher temperature heads.
It is beyond the scope of these instructions to consider all conditions that may be encountered.
Consult local authorities such as the Fire Marshall, insurance carrier, or safety authorities if you
are uncertain as to the safety or applicability of the proposed installation.
Refer to Figure 3 and Table 3 NEXT PAGE for the mounting requirements and certified
clearances to combustibles for indoor installation. Also refer to ventilation requirements
for indoor installations on page 19.
WARNING
DO NOT INSTALL THIS APPLIANCE IN A RECESS, ALCOVE,
OR ENCLOSURE.
Adequate free space must be provided to allow the products
of combustion to escape from the heater to atmosphere when installed outdoors, or to me-
chanical exhaust withdrawal when installed indoors. Also refer to “Outdoor” and “Indoor” defi-
nitions and requirements on page 11.
Do not allow the products of combustion to accumulate in any space or enclosure.
WARNING
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
10
Table 3: INDOOR - MINIMUM MOUNTING & CLEARANCES TO COMBUSTIBLES
The clearance to combustible material represents the minimum distance that must be main-
tained between the outer heater surface and a nearby surface. The stated clearance to com-
bustibles represents a surface temperature of 90F° (50C°) above indoor room temperature.
It is the installer’s responsibility to ensure that building materials with a low heat tolerance
which may degrade at lower temperatures are protected to prevent degradation. Examples of
low heat tolerance materials include awnings, vinyl siding, fabrics, some plastics, filmy materi-
als, etc.
Note: Do not store or place anything directly under heater
Ensure mounting height in any location is sufficient to prevent patrons from
coming in contact with heater, and clearance to combustibles is maintained.
Figure 3: INDOOR - MOUNTING CLEARANCES
MODEL NO
Ends HORIZONTAL UP TO MAXIMUM 30° ANGLE
E A S T B F
2135 / IO-135 -N\L 14” 18” 18” 20” 11” 60”
2150 / IO150 -N\L 14” 21” 23” 25” 10” 62”
MH
108”
120”
MA
102”
114”
CH
138”
153”
CA
132”
147”
Under
U
45”
60”
Table 4: INDOOR - SUGGESTED MOUNTING HEIGHT FOR COMFORT
MOUNTING
PARAMETERS ***
MODEL
2135 / IO-135
35,000 Btuh
MODEL
2150/2152 / IO-150/152
50,000 Btuh
Mounting angle Horizontal 300 Horizontal 300
Suggested height above deck/floor 9’ 6” 9’ 0” 10’ 6” 10’ 0”
NOTE: MOUNT HEATER AT MAXIMUM 30° ANGLE TO AVOID DAMAGE
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
11
MODEL* Voltage
VAC
Current
amps Btu/hr input Total Weight lbs. [kg]
Length
Inches [mm]
2135 (-SS) / IO-135 (-SS) 24 40 VA** 35,000 39 [18] 44” [ 1118]
2150 (-SS) / IO 150 (-SS) 24 40 VA** 50,000 44 [20] 44” [ 1118]
2152 (-SS) / IO 152 (-SS) 24 40 VA** 50,000 / 36,500 44 [20] 44” [ 1118]
HEATER DIMENSIONS & CONFIGURATIONS
Figure 3: DIMENSIONS
Side View
Table 3: CAPACITIES & CONFIGURATIONS
 Add fuel gas designation to model number: -N for natural gas; -L for
 Standard model constructed of weather resistant aluminized steel with a high temperature
flat black coating. The “-SS” model is constructed with a stainless steel weather enclosure
 Model 2152 / IO-152 is a two-stage heater
** Transformer Capacity: For multiple heater installation, the first heater requires 40VA and
each consecutive heater requires 20VA. The sum total will be the required Transformer capac-
ity. If total VA exceeds one transformer capacity select the next higher VA rated transformer.
End View
MOUNTING KIT OPTIONS see illustrations next page
ITEM NO PART NUMBER DESCRIPTION
1 JP-2100-MB WALL MOUNTING BRACKET
2 JP-2300-MK ARM MOUNTING BRACKET
3 JP-2300-PK POST BRACKET
Chain mounting bracket JP-2100-HS is supplied as an integral part of the heater.
Other optional mounting kits are available:
WARNING: Wall Mounting Bracket JP-2100-MB, or Arm Mounting Bracket JP-2300-MK:
Ensure that anchoring to the structure is of sufficient strength, integrity and
workmanship, to adequately support the weight of the heater and any other
potential loads such as snow build up. Mount heater up to maximum 30° angle.
11”
44”
10.5”
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
12
ITEM 1: WALL MOUNTING BRACKET
JP-2100-MB
ITEM 2: ARM MOUNTING KIT
JP-2300-MK CHAIN HANGING SUPPORT
(SUPPLIED WITH HEATER)
ITEM 3: POST MOUNTING BRACKET
JP-2300-PK
CHAIN SUSPENSION
(BRACKET COMES
ASSEMBLED TO HEATER)
POST MOUNT
ARM MOUNT
WALL MOUNT
Figure 5: MOUNTING OPTIONS
Figure 4: MOUNTING KIT OPTIONS
NOTE: MOUNT HEATER AT MAXIMUM 30° ANGLE TO AVOID DAMAGE
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
13
Figure 6: MOUNTING ARM WALL PLATE (for JP-2300-MK)
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
14
Figure 7: WALL MOUNT BRACKET JP-2100-MB
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
15
1. Install the Wall Mount Bracket to the structure using field supplied hardware. Ensure
strength and integrity of mechanical fastening to structure for the weight of the heater and
any potential snow load.
2. Install the heater bracket on the heater using four nuts.
3. Install the heater bracket to the wall mount bracket, and remove the chains from the top of
the heater.
Figure 8: HEATER INSTALLATION: WALL MOUNT BRACKET
NOTE: MOUNT AT MAXIMUM 30° ANGLE TO AVOID DAMAGING HEATER
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
16
1. APPLICATION: This gas-fired infrared heater is suitable for installation for heating of out-
door commercial / industrial / residential areas and indoor commercial / industrial / non-
residential spaces.
It is beyond the scope of these instructions to consider all conditions that may be encountered.
Installation in the USA must conform to all local and national code requirements including the
current National Fuel Gas code ANSI Z223.1, and the National Electrical Code ANSI/NFPA No
70 (latest edition). All installations in Canada must conform to local and national code require-
ments including, CAN/CGA-B149.1 installation code for gas burning appliances and equipment
and the Canadian Electrical Code PART 1 CSA C22.1 (latest edition). In case of discrepancy
due to revisions to standards and codes, the latest standards, codes, and installation manual
are in effect and take priority.
DO NOT INSTALL THIS APPLIANCE IN A RECESS, ALCOVE, OR ENCLOSURE.
Adequate free space must be provided to allow the products of combustion to escape from the
heater to atmosphere when installed outdoors, or to mechanical exhaust withdrawal when in-
stalled indoors. Also refer to “Outdoor” and “Indoor” definitions and requirements below.
Do not allow the products of combustion to accumulate in any space or enclosure
OUTDOOR / PATIO Installation:
This heater is certified for use on outdoor patio’s in accordance with ANSI Z83.26 / CSA
2.37 . Schwank warrants that the heater will operate as designed in mild wind conditions
up to 10 MPH. Note this unit is not designed to operate in adverse weather conditions
including higher wind speeds exceeding the certification requirement of 10 MPH.
What is “Outdoor”?:
An appliance approved for “outdoor use” may be installed with shelter no more inclusive than:
 With walls on all sides, but with no overhead cover, (overhead permanently open) or
 Within a partial enclosure which includes an overhead cover and no more than two side
walls. These side walls may be parallel, as in a breezeway, or at right angle to each other.
The open sides must be permanently open or
 Within a partial enclosure which includes an overhead cover and three side walls, as long
as 30 percent or more of the horizontal periphery of the enclosure is permanently open.
If these “outdoor” conditions are not met, the appliance is approved for “indoor use”
and ventilation requirements of local codes apply. See “Indoor Application” below.
INDOOR Installation:
This heater is certified for space or spot heating of commercial / industrial non-
residential indoor spaces in accordance with ANSI Z83.19b / CSA 2.35b.
Inadequate venting of a heater may result in asphyxiation, carbon monoxide poisoning, injury or death.
Heating system venting must be in accordance with all local, state, provincial, and national codes (ANSI
Z223.1/NFPA 54 in USA; B149.1 in Canada).
INDOOR INSTALLATION IN A STRUCTURE THAT HAS NO INSULATION IN THE
ROOF CAN RESULT IN THE FORMATION OF CONDENSATION ON COLD SURFACES.
WARNING
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
17
2. INSTALLATION IN COMMERCIAL AIRCRAFT HANGARS
Luminous (high intensity) radiant tube heaters are suitable for use in aircraft hangars when in-
stalled in accordance with the latest edition of the Standard for Aircraft Hangars, ANSI/NFPA
No 409 in the USA, or the Canadian Natural Gas and Propane Installation Code, B149.1.
A. A minimum clearance of 8 ft (2.4 m) must be maintained from the bottom of the heater to
the floor in other sections of the aircraft hangar, such as offices and shops, which communi-
cate with areas for servicing or storage. Refer to Table 1 for clearances to combustibles.
B. Heaters must be located so as to be protected from damage by aircraft and other objects,
such as cranes and movable scaffolding.
C. Heaters must be located so as to be accessible for servicing and adjustment.
3. INSTALLATION IN COMMERCIAL GARAGES AND PARKING STRUCTURES
Luminous (high intensity) radiant heaters are suitable for use in commercial garages when in-
stalled in accordance with the latest edition of the Standard for Parking Structures, ANSI/NFPA
88A, or the Standard for Repair Garages, ANSI/NFPA No. 88B, or the Canadian Natural Gas
and Propane Installation Code, B149.1.
An overhead heater shall be located to maintain the minimum
distance to combustibles, as shown on the heater rating plate,
from the heater to any vehicles parked below the heater.
Overhead heaters shall be installed at least 8 ft (2.4 m) above the floor.
4. INSTALLATIONS OTHER THAN SPACE HEATING
Use for process or other applications that are not space heating will void the C.S.A. certification
and product warranty. Process application requires field inspection and/or certification by local
authorities having jurisdiction. Process application design should be provided by local experi-
enced process design experts.
5. PRE INSTALLATION SURVEY
It is recommended that a full heating design including heat loss calculation be conducted on
the structure or area to be heated. Heater sizing and placement must consider available
mounting height, sources of greatest heat loss, and obstructions on the site. The certified clear-
ances to combustibles with respect to stored material, moveable objects (cranes, vehicles, lifts,
overhead doors, etc), structural components, and sprinkler system heads. Consideration must
also be given to ventilation fan placement (outdoor heaters do not require ventilation). Carefully
survey the area to be heated, and for best results place heaters in the coldest area(s) and at
sufficient spacing to provide uniform radiant heat coverage.
WARNING
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
18
6. INSTALLATION REQUIREMENTS
6.1 MOUNTING CLEARANCES
Series 2100 / IO-100 Heaters must be mounted with minimum clearances to combustible ma-
terials. Refer to the introductory section “Clearance to Combustibles” page 6 and to Table 1
and Figure 1 page 7.
THIS HEATER HAS HOT SURFACES: Minimum mounting height is to be no less than
96” [244 cm] above the floor / deck to the bottom of the heater. Do not locate heater where
patrons can come into contact with heater. Do not store or place items directly underneath
heater. Maintain clearance to combustibles.
The heater must be located with respect to building construction and equipment so as to pro-
vide sufficient clearance and accessibility for servicing of burner and ignition control and
cleaning . Provide adequate clearance around air openings into the combustion chamber.
6.2 HEATER MOUNTING
Refer to Table 2 and Figure 2. Series 2100 / IO-100 Heaters are approved for both horizon-
tal and angle mounting on the short axis. A maximum 30° mounting angle is allowed to
prevent damage to the heater. Improper angle mounting can result in damage to the
heater or unsafe operation, and will void warranty.
IMPORTANT: For either horizontal or angle mounting, the long axis of the heater must be
level. Use only non-combustible mounting hardware. Diagram 2 on Page 5 illustrates typical
suspension hardware that may be used., and provided by Schwank as an optional compo-
nent.
Installation must conform with all local, state, provincial and national code requirements in-
cluding the current latest edition ANSI Z223.1 (NFPA 54) in the U.S.A. and B149.1 installa-
tion code in Canada, for gas burning appliances and equipment. The latest edition Electrical
Code ANSI/NFPA N0 70 in the U.S.A. and PART 1 CSA C22.1 in Canada must also be ob-
served.
The heating system must have gas piping of the correct diameter, length, and arrangement to
provide for and satisfy the total system input. A layout drawing is necessary to calculate
properly sized gas supply piping.
Handle heater with care during installation and service to avoid scratching or damag-
ing the surface finish.
NOTE: MOUNT HEATER AT MAXIMUM 30° ANGLE TO AVOID DAMAGE
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
19
7. GAS SUPPLY PIPING
 All piping must be installed according to applicable local and national codes
 A listed flexible connector (field supplied) must be installed between the heater and gas
supply piping. For outdoor installation the connector must be in compliance with AN-
SI Z21.75 / CSA 6.27. A 1/2” x 24” stainless steel flexible gas connector (JL-0771-XX -
approved Indoor/Outdoor) is available as an option from Schwank / InfraSave.
 A drip-pocket must be provided at the inlet connection
 Provide a 1/8” NPT plugged tapping, accessible for test gage connection, immediately
upstream of the gas supply connection to the heater.
 On propane-fired units, a main line filter is recommended (field supplied)
 Piping joint compounds must be resistant to the action of liquefied petroleum gases
 All piping joints must be tested for leaks with a soap and water solution.
CAUTION: DO NOT INSTALL ANY GAS PIPING IN HEAT ZONES
The maximum supply pressure must be limited to 14”w.c. (0.5 psi). If the line pressure is
above 14”w.c., then a separate pressure reducing regulator must be installed in the gas
supply. The minimum pressure at the inlet to the heater regulator (gas valve) must be equal to
or greater than 6.0”w.c. for natural gas and 11.0”w.c. for propane gas.
Proper manifold pressure must be adjusted during commissioning, and will be maintained
when the main burner is operating under the following supply pressure:
7.1 GAS PRESSURE
LINE PRESSURE ”w.c. MANIFOLD PRESSURE ”w.c.
GAS TYPE MINIMUM MAXIMUM AT GAS VALVE TEST PORT
NATURAL GAS 6.0 14.0 5.0
PROPANE GAS 11.0 14.0 10.0
NATURAL GAS (ONLY) 6.0 14.0 5.0 High; 3.0 Low
Table 4
MODELS
2135/50; IO-135/150
2152 / IO-152 (2-Stage)
2135/50; IO-135/150
8. ELECTRICAL REQUIREMENTS - see also Wiring Diagrams pages 31 - 32
All electrical installations must meet local codes and the latest edition ANSI/NFPA N0 70 in
the U.S.A. and Electrical Code PART 1 CSA C22.1 in Canada .
TRANSFORMER SPECIFICATIONS (field supplied)
Single heater requires 24 Volt, 60 Hz electrical transformer sized at 40 VA.
Multiple heaters in a zone are powered by a single transformer (field supplied). The
proper transformer is 24 Volt AC, 60 Hz, sized at 40VA for the first heater plus 20VA for each
additional heater in the zone - round up the calculated value to the next higher available sized
transformer. For example, four heaters in a zone require a transformer of : 1 x 40VA + 3 x 20
VA = 100 VA .
Natural Gas: Orifice sized for 1000 BTU/CU.FT.
Propane Gas: Orifice sized for 2500 BTU/CU.FT.
alfresco-heating.com
888-Warm-Glo

2100 / IO 100 Manual
IM110107
RD: SEPT 2016
R.L. 7
20
PROPER WIRING POLARITY MUST BE MAINTAINED, particularly when grouping the heat-
ers in a zone. Total wiring distances of up to 200' must use minimum 16 gauge electrical wire,
and wiring distances of over 200' must use minimum 14 gauge electrical wire. The heater
must be electrically grounded in accordance with local and national electrical codes. Malfunc-
tion of the heating system will result if the voltage varies by more than ±10% .
The heater can be controlled by a line voltage thermostat, a 24 volt thermostat or “off-on”
switch. Total load of all heaters must be considered in determining the required contact rating
of the controlling thermostat or switch.
While better than
nothing, heat from
one side limits comfort
Heat from two
or more sides
maximizes
comfort
One Side Heating -
Limited Comfort
Coverage
Better:
Two Sides Heating
- Improved Comfort
Best:
Multi-Side Heating -
Most Uniform
Comfort
ZONE 1 ZONE 1
ZONE 2
ZONE 3
ZONE 2
ZONE 3
9. LAYOUT, COMFORT & CONTROL
Every patio heater layout is unique. Where possible it is recommended that heaters on op-
posing sides (two or more sides) of a patron or heating zone be activated simultaneously to
accomplish highest comfort level.
NOTE: MOUNT HEATER AT MAXIMUM 30° ANGLE TO AVOID DAMAGE
alfresco-heating.com
888-Warm-Glo
